EPIC Series - Assembly Instructions

Advertisement

Table of Contents
loading

Related Manuals for NobleChairs EPIC Series

Summary of Contents for NobleChairs EPIC Series

  • Page 1 EPIC Series - Assembly Instructions...

  • Page 2: Content Checklist

    Read over the manual before you begin. Two people are suggested for assembly. CONTENT CHECKLIST Screw Kit: 2x Philips Head Screw 4x M8 Screw (20mm) 4x Split Washer 4x Washer 1x Neck Pillow 1x Lumbar Pillow 1x Allen Key 1x Wheel Base 1x Chair Base 1x Backrest 4x M8 Screw (30mm) with...
  • Page 3 TILT MECHANISM INSTALLATION Place the CHAIR BASE upside-down on a soft Install the TILT MECHANISM by diagonally tightening surface and position the TILT MECHANISM in the the screws into the CHAIR BASE with the ALLEN KEY. correct direction. Place a SPLIT WASHER and then a WASHER onto Place plastic LEVER COVERS onto metal handles, each of the 4 M8 SCREWS.

  • Page 4: Tilt Mechanism

    CHAIRBASE INSTALLATION Align the top of the HYDRAULICS into the bottom of the Push and sit down to lock it into place. TILT MECHANISM. BACKREST INSTALLATION Using the ALLEN KEY, unscrew the 4 M8 (30mm) pre-mounted screws and washers on the side of the backrest. Pull the lever up from the bottom so the mounting bracket snaps forward.
  • Page 5 BACKREST INSTALLATION Starting with the right side, attach the backrest to the metal While firmly pushing SIDE COVERS into place, use the brackets with the 4 M8 (30mm) screws using the ALLEN KEY. ALLEN KEY to secure the SIDE COVERS with the 2 PHILIPS HEAD SCREWS.

  • Page 6: Armrest Adjustments

    4D ARMREST ADJUSTMENTS Ensure that the armrests are balanced to your liking. Use the appropiate function to adjust the armrests. If not, adjust by loosening and tightening the screws with the ALLEN KEY. Use the right lever to adjust the chair’s height. TILT ADJUSTMENT Turn the cylinder knob under the chair clockwise to tighten the Use the left lever to lock/unlock the tilt mechanism.

  • Page 7: Seating Adjustment

    Push firmly to lock them back into place. Safety Information The maximum recommended user weight of the EPIC Series is up to 120kg or 264.5 pounds. Don’t use noblechairs in an abusive manner. noblechairs is not liable for any damages resulting from improper assembly and usage.
