AdMore Lighting LED360-S-TS Instructions

Light kit for givi e360 cases

Advertisement

Congratulations on your purchase of the LED360-S-TS LIGHT KIT!
The LED360-S-TS LIGHT KIT will work on any motorcycle fitted with side-mounted GIVI
E360 cases. The kit is easy to install and significantly enhances your visibility on the
road and the good looks of your E360 cases. Each kit contains two high intensity LED
light strips that fit perfectly behind the original wrap-around red lens of each E360 case.
The custom wire harness with the embedded mini controller fits neatly under your
motorcycle seat or behind the tail light assembly. The mini controller allows you to
connect the light kit to your bike's tail and brake lights and turn signals! Your case
lights will always be on when riding, the lights will brighten when you apply your brakes
and each case light will flash with your right or left turn signal.
This instruction set is available at
www.admorelighting.com
on this product's page under
the "Documentation" tab.
Please note: We make no guarantee that the LED360-S-TS LIGHT KIT is legal for
street use in your area. You should never rely on your LED360-S-TS LIGHT KIT
alone – always ensure that your stock brake light and turn signals are functioning
properly. The LED360-S-TS LIGHT KIT is intended to complement your bike's
original safety lights for added safety.
