- Page 1 Instruction Manual Digital Wireless Stereo Headphones SWHP12...
-
Page 3: Table Of Contents
Thank you for purchasing your new Sandstrøm digital wireless stereo headphones. Please check that you have all the items and familiarise yourself with this instruction manual. Contents Unpacking ..............................4 Product Overview ............................5 Connections ..............................6 Installing and Charging the Batteries ......................8 Operations ..............................9 Pairing ................................. -
Page 4: Unpacking
Unpacking Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to any local regulations. The following items are included: Headphones Transmitter 3.5mm to 6.3mm AA Rechargeable Batteries x 2 Adapter x 1 (NiMH 800mAh 1.2V) P.N.: DH104ET-01S-1 P.N.: 41-03-35TO63PG-07... -
Page 5: Product Overview
Product Overview Transmitter Front View Transmitter Rear View Headphones 1. Signal / Charge Indicator 2. Pair Button 3. Audio Input Sockets 4. DC In Socket 5. Battery Cover 6. Volume +/– Control • Switch this button to increase / decrease the volume Pairing Button • Press this button for pairing... -
Page 6: Connections
Connections Transmitter Stereo System white RCA Cable (not included) RCA to 3.5mm Adapter Cable (included) RCA to 3.5mm Cable (included) Mains Adapter (included) - Page 7 Connect the transmitter to your stereo system by using one of the following methods: Use a RCA cable (not included) to connect the transmitter’s audio input sockets to the RCA sockets of your stereo system. Use the RCA to 3.5mm adapter cable (included) to connect the transmitter’s audio input sockets to the 3.5mm plug extended from your stereo system.
-
Page 8: Installing And Charging The Batteries
Installing and Charging the Batteries Remove the battery cover and insert 2 x rechargeable AA batteries (included) into the battery compartment. Replace the battery cover. Switch off the headphone and place it into the transmitter contacts touching the charge pins. Red LED flashes when charging is activated. Charge the batteries for 16 hours before initial use. -
Page 9: Operations
Operations To start up this system and enjoy your music, please follow the steps below: Connect the transmitter with your audio source. Connect the mains adapter to the transmitter and then a mains socket. The LED on the transmitter will illuminates Red. Turn on your audio source. Turn on the headphones receiver by pressing the ON/OFF button. -
Page 10: Pairing
Pairing If the LED on the headphones remains Red and the headphones do not work, start the Pairing process by pressing the Pair button for 3 seconds on the transmitter and the headphones simultaneously until the LED flashes green. The LED will stop flashing and illuminate solid green when the pairing process is finished. -
Page 11: Hints And Tips
Hints and Tips No Sound • Ensure that the mains adapter is fully connected into the mains socket and that its cable is properly connected to the DC IN socket on the transmitter. • Ensure that the headphones are switched ON. • The headphone’s battery charge level may be too low. -
Page 12: Safety Warnings
Safety Warnings • For traffic safety, do not use earphones while driving or cycling. • Avoid listening to sound at high levels for prolonged periods of time. This may be harmful to you and may cause hearing loss. • The mains adapter is used as the disconnect device which shall remain readily operable. • This unit shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus. - Page 14 NOTE: If you require a replacement for any of the items listed below, please quote their corresponding part numbers: Replacement Part Part Number Transmitter DH104ET-01S-1 3.5mm to 6.3mm Adapter 41-03-35TO63PG-07 AA Rechargeable Batteries 79-01-12801A-13 Mains Adapter 25-030603E-09 RCA to 3.5mm Cable 42-06-DS082T-06 RCA to 3.5mm Adapter Cable 43-03-YCABLE-06...
