- Page 1 HUAWEI DP300 Desktop Presence V500R002C00 Quick Installation Guide Issue: 06 Part Number: 31507084 Date: 2016-12-15 HUAWEI TECHNOLOGIES CO., LTD.
-
Page 2: Unpacking The Carton
Unpacking the Carton What's in the Box Power adapter (1) power cable (1) DP300 (1) Network cable (1) DVI-VGA cable (2) Audio cable (1) Copyright © Huawei Technologies Co., Ltd.2016. All rights reserved. -
Page 3: Installing The Base
1. Place the screen of DP300 down on the desktop. 2. Buckle the support plate on the base into the support frame on the back of DP300, as shown in figure . Tighten the captive screws, as shown in figure... - Page 4 Indicator Camera status indicator Shows the camera running status. Core part Built-in microphone DP300 embeds two microphones: one on the left, and the other on the right. Camera lens DP300 embeds a camera and a lens cover. Text reflector Pull out the text reflector to push texts on the conference desktop to the display.
- Page 5 Used to upgrade the mini system and restore button on, hold down the RESET button for 10s to start factory defaults. the mini system. When DP300 is working, hold down the RESET button for 10s to restore factory defaults. Others COM port Used to communicate with the IP network.
-
Page 6: Connecting Cables
Power switch Used to power on or off DP300. Connecting Cables The following figure shows the recommended cable connections for DP300. You can also connect cables for DP300 based on your actual needs. Powering on the Endpoint After all cables are connected, connect the endpoint to a power source and turn the power switch to ON. The following table describes the indicator status of the power button on DP300. -
Page 7: Loading The Configuration File
To load the configuration file on the USB device: 1. Use the USB configuration tool to import the configuration file to a USB device. For details, see the HUAWEI DP300 Desktop Presence V500R002C00 Deployment Guide. - Page 8 HUAWEI TECHNOLOGIES CO., LTD. Huawei Industrial Base Bantian Longgang Shenzhen 518129 People’s Republic of China www.huawei.com...
