- Page 1 桂 林 鑫 鹰 飞 翔 模 型 有 限 公 司 Guilin XinYing FeiXiang Aircraft Model Co.,Ltd 30cc G eebee- R3 ARF ASSEMBLY MANUAL Contact Address：5th Floor,LiDong Technology Building,High-tech Zone, Guilin,China www.xyfx-model.com.cn Email：info@xyfx-model.com...
-
Page 2: Kit Contents
KIT CONTENTS... - Page 3 Stick the hinges to the rudder firmly with AB glue Fix the control horn to rudder Drill a 6mm diameter hole on the bottom of rudder, fix the steel wire to the bottom of rudder with AB glue...
- Page 4 Put some AB glue on the hinges which link with rudder, then stick to the fuselage Fix the tail landing to fuselage Assemble control horn, rudder cable, ball link and connecting rod to rudder...
- Page 5 Fix rudder servo, rudder cable, ball link and connecting rod as picture Stick the hinges to the elevator firmly with AB glue Fix the horn to elevator with self-tapping screws...
- Page 6 Put some AB glue on the hinges which link with elevator, then stick to the horizontal tail Cut the hole on fuselage for elevator servo Fix the elevator servo as picture...
- Page 7 Assembly horizontal tail to fuselage, then measure the same angle for both sides Fix horizontal screws, rubber loop and washer Check the horizontal tail and fuselage at correct angle, then fix them with screws...
- Page 8 Stick hinges to aileron firmly with AB glue Put some AB glue to hinges which link with aileron , then stick to the wing Fix control horn, push rod and servo to the aileron...
- Page 9 Cut the film on the wing for landing gear Check the right or left side landing gear, then assembly it Put some AB glue into landing gear trail on the wing, then fix the landing steel wire firmly...
- Page 10 Fix the landing gear plates as picture Fix the wheel and wheel adapter as picture Put the wheel active cover on the wheel pant, then drill hole to fix it on the wheel pant...
- Page 11 Drill hole on the wheel pant, then fix it to the wing Cut the film on the fuselage for wing Push the wing into fuselage as picture...
- Page 12 Fix the two wings to fuselage with two screws one each side Align mounting template with fire wall and tape in place Drill engine mounting holes according to the signals on fire wall...
- Page 13 Fix the engine to fire wall as picture Gather the fuel tank parts as picture Fix the fuel tank as picture...
- Page 14 How to drill a hole on the cowling: tape one piece paper on the fuselage and mark the hole position, then put the cowling on fuselage and align it with the hole, then drill the hole on cowling Fix the cowling on fuselage with screws Fix the spinner and propeller onto the engine...
- Page 15 Fix the canopy on fuselage with screws as picture CG as above picture The installation is completed! ENJOY YOUR FLY!!!
