- Page 1 桂 林 鑫 鹰 飞 翔 模 型 有 限 公 司 Guilin XinYing FeiXiang Aircraft Model Co.,Ltd 30cc Sbach 3 4 2 ARF ASSEMBLY MANUAL Contact Address：5th Floor,LiDong Technology Building,High-tech Zone, Guilin,China http://www.xyfx-model.com.cn Email：info@xyfx-model.com...
- Page 2 Use epoxy to hinges, then stick to rudder Install control horn to rudder 方向舵装上三角摇臂 先在合叶上涂上 epoxy 然后粘好在方向舵上 Use epoxy to another side of rudder, then stick to fuselage Install the tail landing gear as above 把方向舵上另一边的合叶涂上 epoxy 在粘好在机身上 尾起落架的组装 Apply epoxy and attach the steering accessory Install tail landing gear as above to rudder 把尾起落架的转向配件用...
- Page 3 Install the rudder rod Install the rudder rod tightly 装好方向舵的拉杆 装好方向舵舵机的拉杆，注意一定要拉紧 Stick the hinges to elevator Install control horn to elevator 升降舵粘好合叶 升降舵装三角摇臂 Install servos to elevator on the fuselage Install push rod to elevator 在机身上装升降舵的舵机 装好升降舵的推拉杆...
- Page 4 Stick hinges to aileron Apply epoxy to aileron, then fasten to wing 副翼粘好合叶 在副翼的合叶上涂好 epoxy 后把它固定好在 机翼上 Install the wing push rod as above Connect push rod to aileron and wing 机翼的推拉杆的装法 把推拉杆链接机翼和副翼 Install wing to fuselage as above Fastern wing to fuselage with screws 把机翼插在机身上...
- Page 5 Drill holes on wheel pant Install wheel to pant 先在轮罩上钻好孔 在把轮子装好在轮子罩上 Fasten wheel and pant to landing gear Fasten landing gear to fuselage with screws 接着把轮子和轮子罩固定在起落架上 然后在把起落架用螺丝固定在机身上 Al ign mounting template with firewall and Install DLE30cc engine as above tape in place. DLE30cc 发动机的安装...
- Page 6 Gather the fuel tank as above Install the fuel tubing 油箱的配件 油箱里面的安装 Secure the rubber stopper with set screw. Fix the fuel tank in the fuselage 全部安装好了,在把油塞用螺丝锁紧 把油箱放在机身里面固定好 Install the cowl to fuselage with screws Install the canopy to fuselage with screws 头罩安装在机身上锁上螺丝...
