- Page 1 HDMI 1.4 HDMI Clock Resynthesizer User Manual rev: 140505 Made in Taiwan...
- Page 2 fety Noti The CV-55 has been t tested for c conformanc ce to safety HDMI 1 .4 HDMI C Clock Resy ynthesizer regulations s and requ uirements, a and has b been certifie ed for inte ernational u use. Howev ver, like al electronic e equipments...
- Page 3 HDMI 1.4 HDMI Clock Resynthesizer boosts up your HDMI extension transmission over long cable and makes multiple layer cascading of HDMI products possible. The CV-55A receives the HDMI signals input and resynchronizes and equalizes the signals with state-of-art jitter cleaning technology.
- Page 4 SPECIFICATIONS Model Name CV-55A Technical Role of usage HDMII to HDMI Repeater with Clock Cleaning HDMI standards 1.4a Input Video bandwidth 3Gbps per data channel Video support 480i/480p/576i/576p/720p/1080i/1080p deep color Audio support Bypass [1] Human body model — ±19kV [air-gap discharge] & ±12kV [contact discharge] ESD protection [2] Core chipset —...
- Page 5 PANEL DESCRIPTIONS Front Panel HDMI OUT: Connect to a HDMI display with a HDMI male-male cable here. LED signal Mini USB for FW updae Rear Panel 5V DC power jack HDMI IN: Connect to a HDMI source with a HDMI male-male cable here.
- Page 6 SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the CV-55A features and specifications is subject to change without further notice.
