V384 IRELESS ODEM User’s Guide An Arcadian Networks Inc. Technical Document Version: 1.02 P/N: 3BR0038...
Page 2
The information contained herein is merely descriptive in nature, and does not constitute a binding offer for the sale of the product described herein. Any use of the Arcadian Networks Inc. logo or trademarks is forbidden without prior written approval from Arcadian Networks Inc.
Page 3
FCC Compliance Statement NOTE: This equipment is authorized under FCC ID:V72V384 to operate in the A Block of the Upper 700 MHz Band pursuant to Part 27 of the FCC’s rules. In addition, this equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules.
CONTENTS Overview and Purpose ............. 1 Purpose of This User’s Guide .......... 1 Target Audience............... 1 Arcadian ................2 Modem Features and Components ......... 3 Front Panel Indicators ............3 Rear Panel Connectors............ 5 Using the Modem .............. 6 Technical Specifications ..........7 Problem Troubleshooting ..........
VERVIEW AND URPOSE Welcome to the User’s Guide for the Arcadian Networks Inc. V384 Modem. Figure 1-1: The Arcadian V384 Wireless Modem Unit 1.1 Purpose of This User’s Guide This guide is designed to be used as a tool in the initial installation and periodic maintenance of the V384.
Tip: This is a tip. It provides time saving information to the reader. 1.4 Arcadian Arcadian Networks Inc. provides fixed wireless broadband end-to-end telephony and high-speed data connections to business and residential subscribers. Arcadian Networks Inc. technology uses point-to-multipoint architecture to deliver circuit-switched telephony and data over IP to commercial and private customers throughout the world.
Four Light Emitting Diode (L.E.D.) indicators are located at the front of the modem. The L.E.D.s provides information about the type and status of modem operations, as described in Table 1. Figure 2-1: V384 WMU Front Panel L.E.D. Indicators www.arcadiannetworks.com...
Page 8
Table 2-1: L.E.D. Status and Functions L.E.D. Indicator Function • On = Power On POWER • Off = Power Off • Flashing = Fatal Error • On = Modem is connected to the Internet STATUS • Off = Modem is not connected to the Internet RF LINK When Status L.E.D.
2.2 Rear Panel Connectors There are three connectors located on the rear panel of the V384 modem. Power Figure 2-2: V384WMU Rear Panel Connectors Connector or Button Function POWER Connect the 9 volt external power source here. Connect an RJ-45 Ethernet cable to this port.
ODEM Follow the steps below to use the modem properly. To use the modem: Check that the computer with which you are using the V384 modem contains a working Ethernet network card, and has the following software installed and operational: •...
ECHNICAL PECIFICATIONS General Dimensions 5.25 x 4.25 x 1.00 in. (13 x 11 x 2.5 cm) Operating 32 to 112° F (0 to 45° C) Temperature Power 800 mA at 9V Power Supply 110 - 220 VAC LED Indicators (4) Power, Status, RF/Link, LAN/USB Interface Data Interface...
Page 12
Service Network Management Protocol: SNMP MIB: RFC1213, RFC1493, RFC2233, RFC2669, RFC2670, DOCSIS Privacy MIB Provisioning: As per DOCSIS Security Link Layer DES CBC, 40 and 56 Bits per user Encryption: Two-layer key distribution protocol, which Distribution: includes DES-ECB and RSA public key encryption and HMAC-SHA1 authorization Upstream QoS Committed...
ROBLEM ROUBLESHOOTING If you encounter problems with your modem, try the following steps. Check for damage to the external modem casing during shipping or installation. If you see visible damage, the modem may need replacement. Verify that the 9-Volt modem power supply jack is connected to the modem POWER connector on the rear of the modem, and that the modem power supply is connected to a known-good AC power outlet.
Page 14
Problem Description Possible Cause Potential Resolutions • The connection The LAN&USB LED 1. Check the does not light up. 10/100BaseT between the cable connection. modem and the PC may be faulty. 2. Check the network configuration: IP address, Gateway, DHCP, and DNS.
ARRANTY NFORMATION The Arcadian Networks Inc. Limited Warranty and related information can be found in the terms and conditions and/or other contracts under which this product was purchased. www.arcadiannetworks.com...
The Responsible Party for this equipment is: Company: Arcadian Networks Inc. Address: 400 Columbus Avenue - Suite 210E Valhalla NY 10595 Country: USA Telephone number: 1-914-579-6300 Arcadian Networks Inc. hereby certifies and declares that the following equipment: Brand Type Product description ARCADIAN...
ONTACTING RCADIAN For further information about the V384WMU or other Arcadian Networks Inc products, visit the Arcadian Website at: www.Arcadiannetworks.com www.arcadiannetworks.com...
