- Page 1 V487 IRELESS ODEM User’s Guide An Arcadian Networks Inc. Technical Document Version: 113 P/N: 3BR0035...
- Page 2 Copyright and Trademark Information: © 2008 Arcadian Networks Inc. All rights reserved. Arcadian Networks Inc. reserves the right to alter the equipment specifications and descriptions in this publication without prior notice. No part of this publication shall be deemed part of any contract or warranty unless specifically incorporated by reference into such contract or warranty.
- Page 3 Warning! Changes or modifications to this equipment not expressly approved by Arcadian Networks, Inc. could void the user’s authority to operate the equipment. Warning! This product was tested and shipped with shielded coaxial cable and Category 5 Ethernet cable equipped with a shielded RJ-45 connector.
- Page 4 Installation and Safety Information The following information is provided to ensure safe operation of this equipment. Arcadian Networks assumes no liability in the event that the customer fails to comply with the following safety precautions and warnings. DC System Power-on 1- When connecting the DC power lines, make sure to connect the Ground line first.
- Page 5 V487i WMU User’s Guide Safety Summary Warnings: Carefully connect units to the supply circuit so that wiring is not overloaded. Connect the Ground first (and remove Ground last when disconnecting). Read the installation instructions before connecting the system to its power source.
- Page 6 Overview and Purpose ..........7 1.1 Purpose of This User’s Guide .......... 7 1.2 Target Audience............... 7 1.3 Document Conventions............ 8 1.4 Arcadian Networks ............8 Modem Features and Components ......9 2.1 Right Panel Indicators ............9 2.2 Left Panel Connectors............10 Using the Modem ............
-
Page 7: Target Audience
V487i WMU User’s Guide VERVIEW AND URPOSE Welcome to the User’s Guide for the Arcadian Networks Inc. V487 Modem. Figure 1-1: The Arcadian Networks V487 Wireless Modem Unit Purpose of This User’s Guide This guide is designed to be used as a tool in the initial installation and periodic maintenance of the V487. -
Page 8: Document Conventions
V487i WMU User’s Guide Document Conventions This guide is intended for service personnel required to install, configure or maintain the V487 modem. The following icons appear throughout this guide: Note: This is a note. It provides additional information on the current topic. - Page 9 V487i WMU User’s Guide ODEM EATURES AND OMPONENTS The V487 modem offers the following features: • Point-to-multipoint broadband wireless Internet access • Superior operations over a wide range of modulation formats and IF bandwidths, including noisy channels • Easy installation •...
- Page 10 V487i WMU User’s Guide Left Panel Connectors There are two connectors located on the left panel of the V487 modem. RF Link Power Figure 2-2: V487 WMU Left side Panel Connectors Connector Function POWER Connect 9.5V to 29 V external power source here.
- Page 11 ODEM Follow the steps below to use the modem properly. To use the modem: Check that the computer with which you are using the V487 modem contains a working Ethernet network card, and has the following software installed and operational: •...
- Page 12 V487i WMU User’s Guide ECHNICAL PECIFICATIONS General Dimensions 12.6 x 7.9 x 4.4 in. (32 x 20 x 11 cm) Operating -33 to 60° C Temperature Power 9.5V-29V (Max 3A) Interface Data Interface RS232 (SCADA service)RJ45 – 10/100 baseT Ethernet full/half duplex RF Interface 50 ohm N Type Female Connector...
- Page 13 V487i WMU User’s Guide Service Network Management Protocol: SNMP MIB: RFC1213, RFC1493, RFC2233, RFC2669, RFC2670, DOCSIS Privacy MIB Provisioning: As per DOCSIS Security Link Layer DES CBC, 40 and 56 Bits per user (Sara) Encryption: Two-layer key distribution protocol, which Distribution: includes DES-ECB and RSA public key encryption and HMAC-SHA1 authorization...
- Page 14 V487i WMU User’s Guide ROBLEM ROUBLESHOOTING If you encounter problems with your modem, try the following steps. Check for damage to the external modem casing during shipping or installation. If you see visible damage, the modem may need replacement. Verify that the 9.5Volt to 29V modem power supply jack is connected to the modem POWER connector on the Left side of the modem, and that the modem power supply is connected to a known-good AC power outlet.
- Page 15 V487i WMU User’s Guide Problem Description Possible Cause Potential Resolutions • The connection The LAN LED does not 1. Check the light up. 10/100BaseT between the cable connection. modem and the PC may be 2. Check the faulty. network configuration: IP address, Gateway, DHCP, and DNS.
- Page 16 V487i WMU User’s Guide ARRANTY NFORMATION The Arcadian Networks Inc. Limited Warranty and related information can be found in the terms and conditions and/or other contracts under which this product was purchased. - 16 -...
- Page 17 V487i WMU User’s Guide ONTACTING RCADIAN ETWORKS For further information about the V487 WMU or other Arcadian Networks products, visit the Arcadian Networks Website at: www.arcadiannetworks.com - 17 -...
