IAI SCON First Step Manual

SCON
First Step Guide
Sixth Edition
Thank you for purchasing our product.
Make sure to read the Safety Guide and detailed Instruction Manual (DVD) included with the product in addition to
this First Step Guide to ensure correct use.
This Instruction Manual is original.
Warning : Operation of this equipment requires detailed installation and operation instructions which are
provided on the DVD Manual included in the box this device was packaged in. It should be retained
with this device at all times.
A hardcopy of the Manual can be requested by contacting your nearest IAI Sales Office listed at
the back cover of the Instruction Manual or on the First Step Guide.
• Using or copying all or part of this Instruction Manual without permission is prohibited.
• The company names, names of products and trademarks of each company shown in the sentences are registered
trademarks.

Product Check

This product is comprised of the following parts if it is of standard configuration.
If you find any fault in the contained model or any missing parts, contact us or our distributor.
1. Parts
No. Part Name Model
1 Controller Main Body Refer to "How to read the model plate", "How to read the model"
Accessories
2 I/O Flat Cable CB-PAC-PIO***
Service Connector for Pulse
3 Plug : 10114-3000PE, Shell : 10314-52F0 (Supplier : 3M)
Train Control
4 System I/O Plug FMC1.5/4-ST-3.5 (Supplier : Phoenix Contact)
5 Power Supply Plug for Brake MC1.5/2-ST-3.5 (Supplier : Phoenix Contact)
6 AC Power Supply plug MSTB2.5/6-STF-5.08 (Supplier : Phoenix Contact)
7 Absolute Battery AB-5
8 First Step Guide
9 Instruction Manual (CD/DVD)
10 Safety Guide

2. Teaching Tool (to be purchased separately)

A teaching tool such as PC software is necessary when performing the setup for position setting, parameter
setting, etc. that can only be done on the teaching tool.
Please prepare either of the following teaching tools such as PC software.
No. Part Name
PC Software
1
(RCS232C converter adapter and external equipment communication cable are included)
PC Software
2
(USB converter adapter, USB cable and external equipment communication cable are included)
3 Touch Panel Teaching
4 Touch Panel Teaching (Dead-man Switch is included)
5 Touch Panel Teaching (Dead-man Switch and TP Adapter (RCB-LB-TG) are included)
6 Teaching Pendant
7 Teaching Pendant (Dead-man Switch and TP Adapter (RCB-LB-TG) are included)
8 Simplified Teaching Pendant
9 Data Setter
10 Touch Panel Indicator (Specified only for SCON-C)
3. Instruction manuals related to this product, which are contained in the Instruction manual (CD/DVD).
No. Name
1 SCON Controller Instruction Manual
2 SCON-CA Controller Instruction Manual
3 PC Software RCM-101-MW/ RCM-101-USB Instruction Manual
4 Touch Panel Teaching CON-PT/PD/PG Instruction Manual
5 Teaching Pendant CON-T/TG Instruction Manual
6 Simplified Teaching Pendant RCM-E Instruction Manual
7 Data Setter RCM-P Instruction Manual
8 Touch Panel Indicator RCM-PM-01 (Specified only for SCON-C)

4. How to read the model plate

Model
MODEL SCON-CA-60A-NP-2-1
Serial number
SERIAL No. 800056144 L11

5. How to read controller model

S C O N - C A - 2 0 I H A - N P - 2 - 0 - C T 4 - * *
<Series>
<Type>
C : Standard Type
CA : High Performance Type
<Actuator Characteristics>
[Motor Type]
20 : 20W 200 : 200W
30D : 30W (Excluding RS) 200S : 200W (LSA)
30R : 30W (for RS) 300S : 300W (LSA)
60 : 60W 400 : 400W
100 : 100W 600 : 600W
100S : 100W (LSA) 750 : 750W
<Option>
150 : 150W 750S : Equipped with
No Indication : Standard Type
Loadcell
HA : High Acceleration/Deceleration Type
RCS2-RA13R
<Encoder Type>
I : Incremental
A : Absolute

List of Specifications

Item
Corresponding Motor Capacity
Power-supply Voltage
Rush Power-supply Voltage 100V AC
*1
Current
Power-supply Voltage 200V AC
Load Capacity
Leak Current *2
Heat Generation
Power Supply Frequency
PIO Power Supply *3
Power Supply for Electromagnetic Brake
(for actuator equipped with brake)
Transient Power
Cutoff Durability
Motor Control System
Corresponding Encoder
Actuator Cable Length
Serial Communication Interface
External Interface
Cable Length
Data Setting and Input
Data Retention
Memory
Reference
Operation Mode
*** shows the cable
length Number of Positions in Positioner
Mode
Pulse Train Input
Control Pulse
Applicable Cable Size
Mode Frequency
2
0.5mm (AWG20)
(Dedicated
Command Pulse
Applicable Cable Size for PIO
2 Multiplying Factor
2.0mm (AWG14) Specifications)
(Electrical Gear : A/B)
Enclosed in Absolute Type
Feedback Pulse
(Dedicated for PIO
Specifications)
LED Display
(mounted on Front Panel)
Electromagnetic Brake Compulsory Release
Switch (mounted on Front Panel)
Insulation Resistance
Insulation Strength
Model
Environment Surrounding air temperature
RCM-101-MW
Surrounding humidity
Surrounding environment
RCM-101-USB
Surrounding storage temperature -10 to 65°C
CON-PT Surrounding storage humidity
CON-PD Vibration Durability
CON-PG
Protection Class
CON-T
CON-TG Weight
RCM-E Cooling Method
RCM-P

External Dimensions

RCM-PM-01
*1 In-rush current will flow for approximately 20msec after the power is turned on (at 40°C).
Note that the value of in-rush current differs depending on the impedance of the power supply line.
*2 Leak current varies depending on the capacity of connected motor, cable length and the surrounding environment. Measure the
Manual No.
leak current at the point where a ground fault circuit interrupter is to be installed when leakage protection is conducted.
ME0161
A ground fault circuit interrupter needs to be selected carefully considering the purposes of prevention of fire and
ME0243
protection of human.
ME0155
Use the harmonic type (for inverter) for the ground fault circuit interrupter.
ME0227
*3 It is not necessary to supply power to PIO when operating with using ROBONET, Gateway Unit or SIO Converter
ME0178
without using PIO. In this case, set the parameter No. 74 (PIO Power Supply Monitor) to "1" (Invalid). It will generate
ME0174
the error code No. 0CF (I/O 24V Power Supply Error) if the setting is not done.
ME0175
Power Capacity and Heat Generation
ME0182
Rated Power Capacity = Motor Power Capacity + Control Power Capacity
Peek Max. Power Capacity = Peek Max. Motor Power Capacity + Control Power Capacity
Actuator Motor Type
MADE IN JAPAN
20
30D (Excluding RS)
30R (for RS)
60
<Identification for IAI use only>
60 (RCS3-CTZ5)
* There is no identification in some cases.
100
<ROBO Cylinder High-Speed Type Connection> 100S (LSA)
<Power-supply Voltage> 150
1 : Single-Phase 100V AC
200
2 : Single-Phase 200V AC
200S
<I/O Cable Length>
(LSA excluding LSA-N15H)
0 : Equipped with no cable
200S (LSA-N15H)
2 : 2m
300S (LSA)
3 : 3m (Standard)
5 : 5m 400
<I/O Type> 400 (RCS3-CT8)
NP : NPN Specification (Sink Type) (Standard)
600
PN : PNP Specification (Source Type)
750
DV : DeviceNet Connection Type
750S
CC : CC-Link Connection Type
PR : PROFIBUS Connection Type
RS : Rotary Shaft
(Note)
CN : CompoNet Connection Type
ML : MECHATROLINK Connection Type (Note)
(Note)
EC : EtherCAT Connection Type
EP : EtherNet/IP Connection Type (Note)
(Note) Specified only for SCON-CA

Basic Specifications

Less than 400W 400W or more
20W to 399W 400W to 750W
Single-Phase 100 to 115V AC
(Power fluctuation within ±10%)
Single-Phase 200 to 230V AC
(Power fluctuation within ±10%)
Single-Phase 200 to 230V AC
(Power fluctuation within ±10%)
20A (Controller side), 70A (Drive side)
20A (Controller side), 80A (Drive side)
Refer to Power Capacity and Heat Generation
3.0mA Primary side when noise filter is connected to power supply line
Refer to Power Capacity and Heat Generation
50/60Hz
24V DC±10%
24V DC±10% 1A (MAX.)
(supplied from external equipment)
SCON-C 10ms (50Hz), 8ms (60Hz)
SCON-CA 20ms (50Hz), 16ms (60Hz)
Sine Wave PWM Vector Current Control
Incremental Serial Encoder, Absolute Serial Encoder, ABZ (UVW) Parallel Encoder
MAX. 20m
RS485 : 1CH ... based on Modbus Protocol RTU/ASCII
Speed : 9.6 to 230.4Kbps
Control available with serial communication in the modes other than the pulse train
PIO Signal I/O dedicated for 24V DC (selected from NPN/PNP) ... Input 16 ports max.,
Specifications output 16 ports max.
Fieldbus DeviceNet/CC-Link/PROFIBUS/CompoNet/MECHATROLINK ...Each dedicated controller
Specification [Refer to each Fieldbus Instruction Manual]
PIO MAX. 10m
RS485 Total cable length 100m or less.
Fieldbus Refer to each Fieldbus specification
PC Software, Touch Panel Teaching, Teaching Pendant
SCON-C Saves position data and parameters to non-volatile memory
(Limitation in number of writing 100,000 times)
SCON-CA Saves position data and parameters to non-volatile memory
(There is no limitation in number of writing)
Positioner Mode/Pulse Train Control Mode
(selected by Pulse Train Mode Changeover Switch on Front Panel)
Standard 64 points, maximum 512 points (PIO Type), 768 points (only for SCON-CA Fieldbus Type)
(Note) Number of positions differs depending on the selection in PIO pattern and fieldbus operation mode.
SCON-C Differential System (Line Driver System) : MAX. 500Kpps
SCON-CA Differential System (Line Driver System) : MAX. 2.5Mpps
Common to C/CA Open Collector Type : 200Kpps max. (under condition AK-04 is used)
1/50 < A/B < 50/1
Setting Range of A and B (set to parameter) : 1 to 4096
SCON-C Differential System (Line Driver System) : MAX. 500Kpps (Linear output available up to 109Kpps)
SCON-CA Differential System (Line Driver System) : MAX. 2.5Mpps
Common to C/CA Open Collector Type : MAX. 500Kpps (under condition JM-08 is used)
PWR (green) : Controller in normal condition, SV (green) : Servo on,
ALM (orange) : Alarm generated, EMG (red) : Emergency Stop
Switching NOM (standard)/BK RLS (compulsory release)
500V DC 100MΩ or more
1,500V AC for 1 min. (Note) Withstand voltage of force control loadcell is 50V DC
0 to 40°C
85%RH or less (non-condensing)
[Refer to Installation Environment]
90%RH or less (non-condensing)
XYZ Each direction 10 to 57Hz Pulsating amplitude 0.035mm (continuous) 0.075mm (intermittent)
57 to 150Hz 4.9m/s 2 (continuous) 9.8m/s 2 (intermittent)
IP20
Approx. 800g Approx. 1100g
Natural air-cooling Forced Air Cooling
58W × 194H × 121D [mm] 72W × 194H × 121D [mm]
Motor Power Peek Max. Motor Control Power Rated Power Peek Max. Power
Capacity Power Capacity Capacity Capacity Capacity [VA]
[VA] [VA] [VA] [VA]
26 78 74 126
46 138 94 186
138 414 186 462
138 414 186 462
197 591 245 639
234 702 282 750
283 851 331 899
328 984 376 1032
421 1263 469 1311
48
486 1458 534 1506
773 2319 821 2367
662 1986 710 2034
920 2760 968 2808
1230 3690 1278 3738
1164 2328 1212 2376
3042 3090
1521 1569
4563 4611
LSA : Linear Actuator

Selection of Circuit Interrupter

• 3 times of the rated current flows to the controller during the acceleration/deceleration. Select an interrupter that does not trip
with this value of current. If a trip occurs, select an interrupter that possesses the rated current of one grade higher. (Refer to
the operation characteristics curves in the product catalog.)
• Select an interrupter that does not trip with the in-rush current. (Refer to the operation characteristics curves in the product
catalog.)
• Consider the current that enables to cutoff the current even when a short circuit current is flown for the rated cutoff current.
Rated Interrupting Current > Short Circuit Current = Primary Power Capacity / Power Voltage
Consider margin for the rated current on the circuit breaker.
Rated Current for Circuit Interrupter > (Rated Motor Power Capacity [VA] + Control Power Capacity [VA]) /
AC Input Voltage × Safety Margin (reference 1.2 to 1.4 times)
External Dimensions
Less than 400W
58
29
4.2
Absolute Battery
(for Absolute Encoder Type)
Regenerative Resistor Unit (Option) : REU-1, REU-2
This is a unit that converts the regenerative current to heat when the motor decelerates.
[Specification]
Item
W34mm × H195mm × D126mm
Body Size
Body Weight
Internal Regenerative Resistor
REU-1 Controller Connection Cable
(2nd unit or later) (Model Code CB-ST-REU010) 1m
Accessories
REU-2 Controller Connection Cable
(First Unit) (Model Code CB-SC-REU010) 1m
[Reference Connectable Quantity]
Motor Wattage Connectable Number of
Regenerative Resistor Units
Horizontal Mount/Vertical Mount
(Note 3)
To 100W
101 to 400W
401 to 750W
(Note 1) This is a reference for the case when the actuator is ran forward and backward on 1,000mm stroke with the
operation duty 50% under the rated acceleration/deceleration speed and rated load.
(Note 2) It is necessary to have the regenerative resistor listed above when the operation duty is above 50%.
The maximum quantity of the external regenerative resistor units that can be connected is as stated below:
• 2 units for less than 400W
(Note 3) It is necessary to have one unit for LSA/LSAS-N10S Type.
Brake Box (Option) : RCB-110-RA13-0
This is applied on NS Actuator and RCS-RA13R with brake.
1 unit of Brake Box possesses brakes for 2 shafts.
[Specification]
Item
Body Size W162 × H94 × D65.5mm
Power Voltage and Current 24V DC±10% 1A
Encoder Cable
Connection Cable
(Model Code CB-RCS2-PLA010) 1m
[24V Power Supply Connector]
Connector on
Cable Side
MC1.5/2-STF-3.5 (Phoenix Contact)
(Enclosed in
standard package)
Applicable Cable AWG28 to 16
Pin No. Signal
Heat Generation
[W] 1 0V Power Supply Grounding for
Terminal
Assignment
30
2 24VIN For Brake Excitation and
31 24V Power Supply
33
[Connectors 1 and 2 for external brake release switch connection]
33
32 Connected
Brake Release Switch
Equipment
35
Connector on
36
Cable Side XAP-02V-1
37
(Please prepare (Contact BXA-001T-P0.6) (JST)
38
separately)
38
Switch Rating 30V DC Minimum Current 1.5mA
Pin No. Signal
56
Terminal 1 BKMRL Brake Release Switch Input
40
Assignment
Power Supply Output for Brake
45
2 COM
Release Switch Input
47
56 (Note) Short circuit of pin No. 1 and 2 of this connector releases the brake compulsorily.
Same as the brake release switch on SCON main unit, it is possible to release the brake.
58
Do not keep the compulsory release condition while in automatic operation.
400W or more
72
43 min80 121
4.2
Side View (in common)
Absolute Battery
(for Absolute Encoder Type)
[Appearance]
Specification
min
φ5
34
100 126
0.9kg
235Ω 80W
Not Required
5
1
16.6
2
• 4 units for 400W or more
[Appearance]
Specification
Primary Secondary
Shaft Shaft
Encoder Output Connector
LS Input Connector
Encoder Input Connector
Explanation
Brake Excitation
4-φ5 5 152 5
162
142
Connector 2 for
External Brake Release
Switch Connection
(for the secondary shaft)
Explanation Connector 2 for Power Supply POWER ON LED
External Brake Release Input Connector (turns in green while on)
Switch Connection
(for the primary shaft)
