AGP G5 125 Original Instructions Manual

Concrete grinder
Hide thumbs
Table of Contents

Advertisement

Quick Links

CONCRETE GRINDER
ORIGINAL INSTRUCTIONS
For your personal safety, READ and
UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
180mm Model
CAUTION:
For tools equipped with overload protection, when the motor shuts off due to overload,
always run the machine with no load for at least 3 minutes to reduce temperature before
returning to operation to avoid burn-out of the motor.
125mm Model

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G5 125 and is the answer not in the manual?

Questions and answers

Related Manuals for AGP G5 125

Summary of Contents for AGP G5 125

  • Page 1 CONCRETE GRINDER ORIGINAL INSTRUCTIONS For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. 125mm Model 180mm Model CAUTION: For tools equipped with overload protection, when the motor shuts off due to overload, always run the machine with no load for at least 3 minutes to reduce temperature before returning to operation to avoid burn-out of the motor.
  • Page 2 Model 125mm Model 180mm Model Power Input 110-120V:1700W, 220-240V:2200W Voltage 110-120V~ 50-60Hz , 220-240V~ 50-60Hz (See machine nameplate) No Load/min 4500 ~ 9500 3200 - 6500 Wheel Diameter 125mm (5") 180mm (7") Spindle Thread Arbor 22.23mm (7/8") & 25.4 (1") 22.23mm (7/8") Dimensions 246mm x 280mm x 325mm...

  • Page 3: Work Area Safety

    General Safety Rules WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fi re and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
  • Page 4 moment of inattention while operating power tools may result in serious personal injury. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
  • Page 5 5. SERVICE Have your power tool serviced by a qualifi ed repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. Only use original Festool parts for repair and maintenance. The use of incompatible accessories or spare parts can result in electric shocks or other injuries.

  • Page 6: Kickback And Related Warnings

    and may cause loss of control. • Do not use a damaged accessory. Before each use inspect the accessory such as abrasive wheels for chips and cracks, backing pad for cracks, tear or excess wear, wire brush for loose or cracked wires. If power tool or accessory is dropped, inspect for damage or install an undamaged accessory.

  • Page 7: Electrical Connection

    • Never place your hand near the rotating accessory. Accessory may kickback over your hand. • Do not position your body in the area where power tool will move if kickback occurs. Kickback will propel the tool in direction opposite to the wheel’s movement at the point of snagging. •...

  • Page 8: To Reduce The Risk Of Injury From Jams, Slips Or Thrown Pieces

    injury. BEFORE USING THIS TOOL WARNING: Some dust created by the power sanding, sawing, grinding, drilling and other construction activities contains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead-bases paints •...
  • Page 9 • Keep Work Area Clean. Cluttered areas and benches invite accidents. Floor must not be slippery. Know Your Machine. Read and thoroughly understand the Operator’s Manual and labels affixed to the tool. Learn its applications and limitations as well as the specific potential for hazards peculiar to this tool. To reduce the risk of injury from accidental contact with moving parts, don’t do layout, assembly, or setup work on the machine while any parts are moving.

  • Page 10: Motor Safety Protection

    from the outlet to avoid injury or possible death from electrical shock. MOTOR SAFETY PROTECTION IMPORTANT: To avoid motor damage, this motor should be blown out or vacuumed frequently to keep dust from interfering with normal motor ventilation. Connect this tool to a power source with the appropriate voltage for your model. If the motor won’t start, turn the switch “OFF”...

  • Page 11: Basic Operation

    BASIC OPERATION NOTE: Make sure that the power circuit voltage is the same as that shown on the specification plate of the machine and that switch is “OFF” before connecting the tool to the power circuit. THE SWITCH The machine has a lockable trigger switch. Squeeze the trigger to Trigger Switch start the machine.

  • Page 12: Safety Guard

    This machine is designed specifically for dry grinding of concrete and similar materials. It uses dry diamond cup wheels and must be used with a suitable vacuum cleaner. Never exhaust the dust directly into the atmosphere. To attach vacuum hose to Dust Port,hold machine firmly with one hand. Then with a twisting motion push the vacuum hose onto the Dust Port.

  • Page 13: Replacing Carbon Brushes

    INSTALLING DIAMOND CUP INSTALLING DIAMOND CUP WHEELS W/ M14 FEMALE THREAD. WHEELS WITH ARBOR HOLE. Face Spanner Wrench Lock Nut Wrench L-Hex Wrench L-Hex Wrench Arbor Nut Inner Flange STORAGE CAUTION: Do not store machine resting on its bristles – Store on its side. CAUTION: Do not store machine with its power supply cable pinched.

  • Page 14: Maintenance

    MAINTENANCE WARNING: To reduce the risk of injury from unexpected starting or electrical shock, unplug the power cord before working on the machine. Keep the tool clean. Remove accumulated dust from working parts. Make sure that the tool operates properly. Periodically check screws and bolts for tightness.
  • Page 15 WIRING...
  • Page 16 EXPLODED VIEW (125mm Model)
  • Page 17 PARTS LIST (125mm Model) Parts Name Q'TY Parts Name Q'TY POWER SUPPLY CABLE1.5 (16A)x2Cx3M-H07RNF ARMATURE 220V CORD ARMOR BALL BEARING 6202-2NSE PANHEAD TAPPING SCREW M4x14 ARMATURE GEAR M1.5 x 12T CABLE CLIP GEAR PLATE TRIGGER SWITCHLOCK-ON PANHEAD MACHINE SCREW M4x25 HANDLE BRACKET HANDLE HALF-RIGHT BALL BEARING 608 zz...
  • Page 18 EXPLODED VIEW (180mm Model)
  • Page 19 PARTS LIST (180mm Model) Parts Name Q'TY Parts Name Q'TY POWER SUPPLY CABLE1.5 (16A)x2Cx3M-H07RNF PANHEAD TAPPING SCREW M5x60 CORD ARMOR FAN BAFFLE PANHEAD TAPPING SCREW M4x14 BALL BEARING 6200-LLU CABLE CLIP ARMATURE 220V TRIGGER SWITCH LOCK-ON BALL BEARING6202-2NSE HANDLE HALF-RIGHT ARMATURE GEAR M1.5 x 9T HANDLE HALF-RIGHT GEAR PLATE...
  • Page 20 FLOOR GRINDING TROLLEY EXPLODED VIEW...

  • Page 21: Power Supply Cable

    FLOOR GRINDING TROLLEY PARTS LIST Parts Name Q'ty HANDLE GRIP-LEFT REAR HANDLE GRIP-LEFT FRONT HANDLE GRIP-RIGHT REAR HANDLE GRIP-RIGHT FRONT SCREW M4 x 45 SCREW M4 x 30 SCREW M4 x 12 HANDLE COLUMN DEPTH ADJUST NUT FRAME WIRE LEAD 14AWG x 12cm MOTOR SWITCH POWER SUPPLY CABLE...
