HOW TO USE THIS INSTALL GUIDE
1
Open the Bookmarks menu and find your vehicle OR scroll
down until you find the install guide for your vehicle.
2
Print only the pages for your vehicle using the advanced
options in the Print menu.
3
Install your Maestro AR according to the guide for your vehicle.
Pressing the printer icon or "quick printing" this document will print
NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here in
are the properties of their respective owners.
WARNING
all of the guides in this compilation.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for iDataLink Maestro AR-CH4
Summary of Contents for iDataLink Maestro AR-CH4
- Page 1 SELECT VEHICLE PRINT PAGES NEEDED HOW TO USE THIS INSTALL GUIDE Open the Bookmarks menu and find your vehicle OR scroll down until you find the install guide for your vehicle. Print only the pages for your vehicle using the advanced options in the Print menu.
- Page 2 PROGRAMMED FIRMWARE Extension harness provided with ADS-AR-CHR04 iDatalink Maestro AR Amplifier Replacement Interface Kenwood amplifier iDatalink Maestro AR-CH4 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here...
-
Page 3: Table Of Contents
CHRYSLER 300 WITH HARMAN KARDON 2017 WELCOME TAbLE OF CONTENTS Settings and Features Congratulations on the purchase of your iDatalink Maestro AR Amplifi er replacement solution. You are Installation Instructions now a few simple steps away from enjoying your new car amplifi er. -
Page 4: Chrysler 300 With Harman Kardon
• Bass Tone Control Subwoofer Volume • Mid Tone Control Not applicable • Treble Tone Control Tweeter Output Gain • Surround Control Not applicable • Speed Compensated Volume None Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com... - Page 5 CHRYSLER 300 WITH HARMAN KARDON 2017 INSTALLATION INSTRUCTIONS STEP 1 • For technical assistance call 1-866-427-2999 or e-mail “support@idatalink.com”. Visit us at “maestro.idatalink. • Remove the factory amplifi er (refer to wire chart for com/support” and “www.12voltdata.com/forum/” amplifi er location).
- Page 6 - CONNECT THE BLACK WIRE FROM ADAPTER TO BLACK WIRE (PIN 11) OF 18-PIN CONNECTOR. CONNECTION NOT REQUIRED - CONNECT THE OTHER SIDE OF ADAPTER TO MAESTRO AR MODULE (POSITION A). 18 PIN CONNECTOR KENWOOD KENWOOD EXTENSION HARNESS AMPLIFLIER MAESTRO AR MODULE Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com...
- Page 7 Left Rear Deck Speaker (-) Orange Right Rear Speaker (+) OUTPUT 11 Orange/Black Right Rear Speaker (-) White Left Rear Speaker (+) OUTPUT 12 White/Black Left Rear Speaker (-) Amplifi er location: Left end of dash Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com...
- Page 8 PROGRAMMED FIRMWARE Extension harness provided with ADS-AR-CHR04 iDatalink Maestro AR Amplifier Replacement Interface Kenwood amplifier iDatalink Maestro AR-CH4 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here...
- Page 9 CHRYSLER PACIFICA WITH HARMAN KARDON 2017 WELCOME TAbLE OF CONTENTS Settings and Features Congratulations on the purchase of your iDatalink Maestro AR Amplifi er replacement solution. You are Installation Instructions now a few simple steps away from enjoying your new car amplifi er.
- Page 10 • Bass Tone Control Subwoofer Volume • Mid Tone Control Not applicable • Treble Tone Control Tweeter Output Gain • Surround Control Not applicable • Speed Compensated Volume None Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com...
- Page 11 CHRYSLER PACIFICA WITH HARMAN KARDON 2017 INSTALLATION INSTRUCTIONS STEP 1 • For technical assistance call 1-866-427-2999 or e-mail “support@idatalink.com”. Visit us at “maestro.idatalink. • Remove the factory amplifi er (refer to wire chart for com/support” and “www.12voltdata.com/forum/” amplifi er location).
- Page 12 - CONNECT THE BLACK WIRE FROM ADAPTER TO BLACK WIRE (PIN 11) OF 18-PIN CONNECTOR. CONNECTION NOT REQUIRED - CONNECT THE OTHER SIDE OF ADAPTER TO MAESTRO AR MODULE (POSITION A). 18 PIN CONNECTOR KENWOOD KENWOOD EXTENSION HARNESS AMPLIFLIER MAESTRO AR MODULE Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com...
- Page 13 Right Rear Door Tweeter (+) OUTPUT 11 Orange/Black Right Rear Door Tweeter (-) White Left Rear Door Tweeter (+) OUTPUT 12 White/Black Left Rear Door Tweeter (-) Amplifi er location: Left quarter panel Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com...
- Page 14 PROGRAMMED FIRMWARE Extension harness provided with ADS-AR-CHR04 iDatalink Maestro AR Amplifier Replacement Interface Kenwood amplifier iDatalink Maestro AR-CH4 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here...
- Page 15 DODGE CHALLENGER WITH HARMAN KARDON 2016-2017 WELCOME TAbLE OF CONTENTS Settings and Features Congratulations on the purchase of your iDatalink Maestro AR Amplifi er replacement solution. You are Installation Instructions now a few simple steps away from enjoying your new car amplifi er.
-
Page 16: Settings And Features
• Bass Tone Control Subwoofer Volume • Mid Tone Control Not applicable • Treble Tone Control Tweeter Output Gain • Surround Control Not applicable • Speed Compensated Volume None Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com... -
Page 17: Installation Instructions
DODGE CHALLENGER WITH HARMAN KARDON 2016-2017 INSTALLATION INSTRUCTIONS STEP 1 • For technical assistance call 1-866-427-2999 or e-mail “support@idatalink.com”. Visit us at “maestro.idatalink. • Remove the factory amplifi er (refer to wire chart for com/support” and “www.12voltdata.com/forum/” amplifi er location). -
Page 18: Wiring Diagram
- CONNECT THE BLACK WIRE FROM ADAPTER TO BLACK WIRE (PIN 11) OF 18-PIN CONNECTOR. CONNECTION NOT REQUIRED - CONNECT THE OTHER SIDE OF ADAPTER TO MAESTRO AR MODULE (POSITION A). 18 PIN CONNECTOR KENWOOD KENWOOD EXTENSION HARNESS AMPLIFLIER MAESTRO AR MODULE Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com... -
Page 19: Vehicle Wire Reference Chart
Left Rear Speaker (-) Orange Right Rear Tweeter (+) OUTPUT 11 Orange/Black Right Rear Tweeter (-) White Left Rear Tweeter (+) OUTPUT 12 White/Black Left Rear Tweeter (-) Amplifi er location: Driver kick panel Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com... -
Page 20: Automotive Data Solutions Inc
PROGRAMMED FIRMWARE Extension harness provided with ADS-AR-CHR04 iDatalink Maestro AR Amplifier Replacement Interface Kenwood amplifier iDatalink Maestro AR-CH4 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here... - Page 21 DODGE CHARGER WITH HARMAN KARDON 2016-2017 WELCOME TAbLE OF CONTENTS Settings and Features Congratulations on the purchase of your iDatalink Maestro AR Amplifi er replacement solution. You are Installation Instructions now a few simple steps away from enjoying your new car amplifi er.
- Page 22 • Bass Tone Control Subwoofer Volume • Mid Tone Control Not applicable • Treble Tone Control Tweeter Output Gain • Surround Control Not applicable • Speed Compensated Volume None Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com...
- Page 23 DODGE CHARGER WITH HARMAN KARDON 2016-2017 INSTALLATION INSTRUCTIONS STEP 1 • For technical assistance call 1-866-427-2999 or e-mail “support@idatalink.com”. Visit us at “maestro.idatalink. • Remove the factory amplifi er (refer to wire chart for com/support” and “www.12voltdata.com/forum/” amplifi er location).
- Page 24 - CONNECT THE BLACK WIRE FROM ADAPTER TO BLACK WIRE (PIN 11) OF 18-PIN CONNECTOR. CONNECTION NOT REQUIRED - CONNECT THE OTHER SIDE OF ADAPTER TO MAESTRO AR MODULE (POSITION A). 18 PIN CONNECTOR KENWOOD KENWOOD EXTENSION HARNESS AMPLIFLIER MAESTRO AR MODULE Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com...
- Page 25 Left Rear Speaker (-) Orange Right Rear Tweeter (+) OUTPUT 11 Orange/Black Right Rear Tweeter (-) White Left Rear Tweeter (+) OUTPUT 12 White/Black Left Rear Tweeter (-) Amplifi er location: Left end of dash Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com...
- Page 26 PROGRAMMED FIRMWARE Extension harness provided with ADS-AR-CHR04 iDatalink Maestro AR Amplifier Replacement Interface Kenwood amplifier iDatalink Maestro AR-CH4 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here...
- Page 27 DODGE VIPER WITH HARMAN KARDON 2016-2017 WELCOME TAbLE OF CONTENTS Settings and Features Congratulations on the purchase of your iDatalink Maestro AR Amplifi er replacement solution. You are Installation Instructions now a few simple steps away from enjoying your new car amplifi er.
- Page 28 • Bass Tone Control Subwoofer Volume • Mid Tone Control Not applicable • Treble Tone Control Tweeter Output Gain • Surround Control Not applicable • Speed Compensated Volume None Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com...
- Page 29 DODGE VIPER WITH HARMAN KARDON 2016-2017 INSTALLATION INSTRUCTIONS STEP 1 • For technical assistance call 1-866-427-2999 or e-mail “support@idatalink.com”. Visit us at “maestro.idatalink. • Remove the factory amplifi er (refer to wire chart for com/support” and “www.12voltdata.com/forum/” amplifi er location).
- Page 30 - CONNECT THE BLACK WIRE FROM ADAPTER TO BLACK WIRE (PIN 11) OF 18-PIN CONNECTOR. CONNECTION NOT REQUIRED - CONNECT THE OTHER SIDE OF ADAPTER TO MAESTRO AR MODULE (POSITION A). 18 PIN CONNECTOR KENWOOD KENWOOD EXTENSION HARNESS AMPLIFLIER MAESTRO AR MODULE Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com...
- Page 31 Right Rear Speaker (+) OUTPUT 11 Orange/Black Right Rear Speaker (-) White Left Rear Speaker (+) OUTPUT 12 White/Black Left Rear Speaker (-) Amplifi er location: Right rear of trunk fl oor Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com...
- Page 32 PROGRAMMED FIRMWARE Extension harness provided with ADS-AR-CHR04 iDatalink Maestro AR Amplifier Replacement Interface Kenwood amplifier iDatalink Maestro AR-CH4 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here...
- Page 33 JEEP GRAND CHEROKEE WITH HARMAN KARDON 2015-2017 WELCOME TAbLE OF CONTENTS Settings and Features Congratulations on the purchase of your iDatalink Maestro AR Amplifi er replacement solution. You are Installation Instructions now a few simple steps away from enjoying your new car amplifi er.
- Page 34 • Bass Tone Control Subwoofer Volume • Mid Tone Control Not applicable • Treble Tone Control Tweeter Output Gain • Surround Control Not applicable • Speed Compensated Volume None Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com...
- Page 35 JEEP GRAND CHEROKEE WITH HARMAN KARDON 2015-2017 INSTALLATION INSTRUCTIONS STEP 1 • For technical assistance call 1-866-427-2999 or e-mail “support@idatalink.com”. Visit us at “maestro.idatalink. • Remove the factory amplifi er (refer to wire chart for com/support” and “www.12voltdata.com/forum/” amplifi er location).
- Page 36 - CONNECT THE BLACK WIRE FROM ADAPTER TO BLACK WIRE (PIN 11) OF 18-PIN CONNECTOR. CONNECTION NOT REQUIRED - CONNECT THE OTHER SIDE OF ADAPTER TO MAESTRO AR MODULE (POSITION A). 18 PIN CONNECTOR KENWOOD KENWOOD EXTENSION HARNESS AMPLIFLIER MAESTRO AR MODULE Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com...
- Page 37 Orange Right Rear Speaker (+) OUTPUT 11 Orange/Black Right Rear Speaker (-) White Left Rear Speaker (+) OUTPUT 12 White/Black Left Rear Speaker (-) Amplifi er location: Rear cargo area fl oor Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com...
- Page 38 PROGRAMMED FIRMWARE Extension harness provided with ADS-AR-CHR04 iDatalink Maestro AR Amplifier Replacement Interface Kenwood amplifier iDatalink Maestro AR-CH4 Installation Harness NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here...
- Page 39 MASERATI GHIBLI WITH HARMAN KARDON 2014-2017 WELCOME TAbLE OF CONTENTS Settings and Features Congratulations on the purchase of your iDatalink Maestro AR Amplifi er replacement solution. You are Installation Instructions now a few simple steps away from enjoying your new car amplifi er.
- Page 40 • Bass Tone Control Subwoofer Volume • Mid Tone Control Not applicable • Treble Tone Control Tweeter Output Gain • Surround Control Not applicable • Speed Compensated Volume None Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com...
- Page 41 MASERATI GHIBLI WITH HARMAN KARDON 2014-2017 INSTALLATION INSTRUCTIONS STEP 1 • For technical assistance call 1-866-427-2999 or e-mail “support@idatalink.com”. Visit us at “maestro.idatalink. • Remove the factory amplifi er (refer to wire chart for com/support” and “www.12voltdata.com/forum/” amplifi er location).
- Page 42 - CONNECT THE BLACK WIRE FROM ADAPTER TO BLACK WIRE (PIN 11) OF 18-PIN CONNECTOR. CONNECTION NOT REQUIRED - CONNECT THE OTHER SIDE OF ADAPTER TO MAESTRO AR MODULE (POSITION A). 18 PIN CONNECTOR KENWOOD KENWOOD EXTENSION HARNESS AMPLIFLIER MAESTRO AR MODULE Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com...
- Page 43 Purple Right Front Tweeter (+) OUTPUT 10 Purple/Black Right Front Tweeter (-) Orange OUTPUT 11 Orange/Black White Subwoofer 2 (-) OUTPUT 12 White/Black Subwoofer 2 (-) Amplifi er location: Left quarter panel Automotive Data Solutions Inc. © 2017 ADS-AR-CHR04 maestro.idatalink.com...
