TABLE OF CONTENTS
1
Before driving
2
When driving
Interior
3
features
Maintenance
4
and care
When trouble
5
arises
Vehicle
6
specifications
For U.S.
7
owners
Index
L/C200_U (OM60G31U)
Adjusting and operating features such as door locks,
mirrors, and steering column
Driving, stopping and safe-driving information
Air conditioning and audio systems, as well as other in-
terior features for a comfortable driving experience
Cleaning and protecting your vehicle, performing do-it-
yourself maintenance, and maintenance information
What to do if the vehicle needs to be towed, gets a flat
tire, or is involved in an accident
Detailed vehicle information
Reporting safety defects for U.S. owners
Alphabetical listing of information contained in this
manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Land Cruiser 200 2010 and is the answer not in the manual?

Questions and answers

Summary of Contents for Toyota Land Cruiser 200 2010

  • Page 1 TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column When driving Driving, stopping and safe-driving information Interior Air conditioning and audio systems, as well as other in- features terior features for a comfortable driving experience Maintenance Cleaning and protecting your vehicle, performing do-it- and care...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Index 1-6. Theft deterrent system Before driving Engine immobilizer system ........ 96 Alarm ........98 1-1. Key information Keys ........24 1-7. Safety information Correct driving posture ..102 1-2. Opening, closing and locking SRS airbags ....... 104 the doors Front passenger occupant Smart key system....
  • Page 3 Windshield wipers and 3-2. Using the audio system washer ......179 Audio system type ....264 Rear window wiper and Using the radio ....267 washer ......184 Using the CD player ... 276 Headlight cleaner switch ..185 Playing back MP3 and WMA discs .......
  • Page 4 TABLE OF CONTENTS Index 3-5. Using the interior lights Maintenance and care Interior lights list ....371 • Interior lights ....372 • Personal lights ....373 4-1. Maintenance and care Cleaning and protecting 3-6. Using the storage features the vehicle exterior ... 414 List of storage features..
  • Page 5 When trouble arises Vehicle specifications 5-1. Essential information 6-1. Specifications Emergency flashers .... 492 Maintenance data (fuel, oil level, etc.) ... 548 If your vehicle needs to be towed ....... 493 Fuel information....558 If you think something Tire information ....561 is wrong ......
  • Page 6 Pictorial index Exterior Windshield wipers P. 179 Headlights (low beam) P. 175 Moon roof P. 89 Hood P. 429 Outside rear view mirrors P. 83 Headlights (high beam) and daytime running lights P. 175, 176 Parking lights P. 175 Front side marker lights P.
  • Page 7 Tail lights P. 175 Rear window defogger P. 262  Roof luggage carrier P. 220 Rear window wiper P. 184 Fuel filler door P. 92 Side door P. 42 License plate lights P. 175 Tires ●Rotation P. 445 Back door P.
  • Page 8 Pictorial index Interior Head restraint P. 67 Seat belt P. 71 SRS driver airbag P. 104 Power window switch P. 86 SRS front passenger airbag P. 104 Ashtray P. 388 Floor mat P. 396 ITYPC033 Armrest P. 395 Glove box P.
  • Page 9 Personal lights P. 373 SRS curtain shield airbag P. 104 Interior light P. 372 Rear seat entertainment Personal lights P. 373 system Interior light P. 372 Interior light P. 372 Garage door opener switches P. 399 Moon roof switches P. 89 ...
  • Page 10 Pictorial index Interior Driving position memory switches P. 63 Door lock switch P. 42 ITYPC005 Power window switches P. 86 Window lock switch P. 86 L/C200_U (OM60G31U)
  • Page 11 Power outlet P. 391 Cigarette lighter P. 390 Ashtray P. 388 Shift lever P. 158 Seat heater switches P. 393 Crawl Control switch P. 204 ECT switch P. 159 Shift lock override button P. 532 ITYPC035 Parking brake lever P. 164 AUX port P.
  • Page 12 Pictorial index Instrument panel Headlight switch P. 175 Turn signal lever P. 163 Fog light switch P. 178 Audio remote controls (steering switches) P. 309 Gauges and meters P. 166 Multi-information display P. 172 Windshield wipers and washer switch P. 179 Rear window wiper and washer switch P.
  • Page 13 Without navigation system Clock P. 386 Front passenger AIR BAG Front passenger’s seat belt ON and AIR BAG OFF reminder light P. 505 indicator P. 119 Security indicator light P. 96 Audio system P. 264 Emergency flasher Outside temperature switch P.
  • Page 14: Instrument Panel

    Pictorial index Instrument panel With navigation system Clock Outside temperature display P. 387 Front passenger AIR BAG ON and Front passenger’s seat belt AIR BAG OFF indicator P. 119 reminder light P. 505 Navigation system Security indicator light P. 96 Air conditioning system Emergency flasher...
  • Page 15 Telephone switch P. 338 Talk switch P. 338 DISP switch P. 172 Cruise control switch P. 186 : Refer to “Navigation System Owner’s Manual”. L/C200_U (OM60G31U)
  • Page 16 Pictorial index Instrument panel Engine (ignition) switch P. 154 Center differential lock/unlock switch P. 199 VSC OFF switch P. 208 Four-wheel drive control switch P. 199 L/C200_U (OM60G31U)
  • Page 17 Outside rear view mirror control switches P. 83 Instrument panel light control knob P. 167 Odometer/trip meter and trip meter reset button P. 166 Tilt and telescopic steering control switch P. 80 Roll sensing of curtain shield airbags off switch P.
  • Page 18: For Your Information

    Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
  • Page 19 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
  • Page 20 CAUTION ■ General precautions while driving Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
  • Page 21 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
  • Page 22 L/C200_U (OM60G31U)
  • Page 23: Before Driving

    Before driving 1-1. Key information 1-4. Opening and closing the windows and moon roof Keys ........24 Power windows ....86 1-2. Opening, closing and locking Moon roof......89 the doors 1-5. Refueling Smart key system ....26 Wireless remote control ..39 Opening the fuel tank cap ....
  • Page 24: 1-1. Key Information

    1-1. Key information Keys The following keys are provided with the vehicle. Electronic keys • Operating the smart key system (P. 26) • Operating wireless remote control function (P. 39) Mechanical keys Key number plate Using the mechanical key Take out the mechanical key. After using the mechanical key, store it in the electronic key.
  • Page 25 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made at your Toyota dealer using the key number plate. (P. 533) ■...
  • Page 26: 1-2. Opening, Closing And Locking The Doors

    1-2. Opening, closing and locking the doors Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) ITY12C002 Locks and unlocks the doors (P. 27) Locks and unlocks the doors (P.
  • Page 27 Press the lock button to lock the doors. Pressing and holding the button closes the windows and moon roof. (This setting must be cus- tomized at your Toyota dealer.) ITY12C008 Back door Press the unlock button to unlock the doors.
  • Page 28 1-2. Opening, closing and locking the doors Press the lock button to lock the doors. Antenna location and effective range ■ Antenna location Antennas outside cabin Antennas inside cabin Antenna outside luggage com- partment ITY12C019 L/C200_U (OM60G31U)
  • Page 29 1-2. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) When locking or unlock- ing the doors The system can be oper- ated when the electronic key is within about 2.3 ft. (0.7 m) of an outside door handle.
  • Page 30 1-2. Opening, closing and locking the doors ■ Operation signals A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) ■ Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system and wireless remote control from operating properly.
  • Page 31 1-2. Opening, closing and locking the doors ■ Switching the door unlock function If it is possible to set which doors the entry function unlocks. STEP Turn the “ENGINE START STOP” switch OFF. STEP When the indicator on the key surface is turned off, press and hold for approximately 5 seconds while pressing the key.
  • Page 32 1-2. Opening, closing and locking the doors ■ Battery-saving function In the following circumstances, the entry function is disabled in order to pre- vent the vehicle and electronic key batteries from discharging. ● When the entry function has not been used for 2 weeks or more ●...
  • Page 33 1-2. Opening, closing and locking the doors ■ Note for the smart key system ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases. • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
  • Page 34 1-2. Opening, closing and locking the doors ■ Alarms and warning indicators A combination of exterior and interior alarms as well as warnings displayed on the multi-information display are used to prevent theft of the vehicle and unforeseeable accidents resulting from erroneous operation. Perform the appropriate correction procedure described in the following table.
  • Page 35 1-2. Opening, closing and locking the doors Alarm Situation Correction procedure When the “ENGINE START STOP” switch is in IGNITION ON or ACCES- Shift the shift lever to Interior alarm SORY mode, an attempt “P” and turn the sounds continu- was made to open the “ENGINE START ously...
  • Page 36 1-2. Opening, closing and locking the doors Alarm Situation Correction procedure The driver’s door was closed after the key was Turn the “ENGINE carried outside the vehicle, START STOP” switch and the “ENGINE START OFF and close the STOP” switch was not driver’s door again Interior alarm turned OFF...
  • Page 37 1-2. Opening, closing and locking the doors ■ Certification for the smart key system FCC ID:NI4TMLF-5 NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 38 (P. 28) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves. Then, consult your doctor to see if you should disable the entry function.
  • Page 39: Wireless Remote Control

    Opens the windows and moon roof (press and hold) Sounds alarm (press and hold) (P. 98) : This setting must be custom- ized at your Toyota dealer. ■ Operation signals ● Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked.
  • Page 40 1-2. Opening, closing and locking the doors ■ Alarm Using the wireless remote control to lock the door will set the alarm system. (P. 98) ■ Electronic key battery depletion P. 535 ■ If the wireless remote control does not operate properly ●...
  • Page 41 1-2. Opening, closing and locking the doors ■ Certification for wireless remote control FCC ID: HYQ14AAB FCC ID: HYQ13BZS FCC ID: HYQ14ABK FCC ID: HYQ13CZA : For U.S. mainland only NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 42: Side Doors

    1-2. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the smart key system, wireless remote control or door lock switch. ■ Entry function P. 26 ■ Wireless remote control P. 39 ■ Door lock switch Locks all doors Unlocks all doors...
  • Page 43 1-2. Opening, closing and locking the doors Locking the driver’s door from the outside without a key STEP Move the inside lock button to the lock position. STEP Close the door. The door cannot be locked if the “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode, or the electronic key is left inside the vehicle.
  • Page 44 1-2. Opening, closing and locking the doors Automatic door locking and unlocking systems The following functions can be set or canceled: Function Operation Shift position linked Shifting the shift lever out of “P” locks all door locking function doors. Shift position linked Shifting the shift lever to “P”...
  • Page 45 1-2. Opening, closing and locking the doors Shift lever Driver’s door lock Function position switch position Shift position linked door lock- ing function “P” Shift position linked door unlocking function Speed linked door locking func- tion “N” Driver’s door linked door unlock- ing function When the setting or canceling operation is complete, all doors are locked and then unlocked.
  • Page 46 1-2. Opening, closing and locking the doors CAUTION ■ To prevent an accident Observe the following precautions while driving the vehicle. Failing to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. ●...
  • Page 47: Back Door

    1-2. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened by the following procedures. ■ Locking and unlocking the back door Door lock switch P. 42 Entry function P. 26 Wireless remote control P.
  • Page 48 1-2. Opening, closing and locking the doors Rear step bumper The rear step bumper is for rear end protection and easier step- up loading. ■ When closing the back door ● Make sure that the lower side of the back door is closed before closing the upper side of the back door.
  • Page 49 1-2. Opening, closing and locking the doors CAUTION ■ While driving ● Keep the back door closed while driving. If the back door is left open, it may hit near-by objects while driving or lug- gage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
  • Page 50 1-2. Opening, closing and locking the doors CAUTION ■ Operating the back door Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in seri- ous injury. ● Remove any heavy loads, such as snow and ice, from the back door before opening it.
  • Page 51 Doing so may cause hands to be caught or the back door damper stay to break, causing an accident. ● Do not attach any accessories other than genuine Toyota parts to the back door. Such additional weight on the back door may cause the back door to fall closed again after it is opened.
  • Page 52: Adjustable Components (Seats, Mirrors, Steering Wheel)

    1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Seat position fore/aft control switch Seatback angle control switch Seat cushion (front) angle control switch Vertical height control switch Lumbar support control switch (driver’s side only) Active head restraint When the occupant’s lower back presses against the seatback during a rear-end collision, the head restraint moves slightly for-...
  • Page 53 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Active head restraint Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may make the inner struc- ture of the head restraint appear. This does not indicate a problem. During rear-end collision...
  • Page 54: Rear Seats

    1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats Second seat Seatback angle adjustment lever Seat position adjustment lever Third seat L/C200_U (OM60G31U)
  • Page 55 1-3. Adjustable components (seats, mirrors, steering wheel) Tumbling the second seats and third seat entry STEP For easy access to the third seat, perform in “Tumbling the second seats”. (P. 56) ■ Before tumbling the second seats Stow the seat belt buckles and STEP lower the head restraints to the lowest position.
  • Page 56 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Tumbling the second seats Fold down the seatback while STEP pulling seatback angle adjustment lever, and swing the whole seat up and forward. Hook the holding strap to the STEP assist grip and secure the seat by pulling its free end.
  • Page 57 1-3. Adjustable components (seats, mirrors, steering wheel) Remove the seat hook covers STEP from the back of the seat cush- ion, and install them on the seat hooks. When returning the second seat to its original position, remove the seat hook covers from the floor and install them in the back of the ITY13C025 seat cushion.
  • Page 58 1-3. Adjustable components (seats, mirrors, steering wheel) Folding up the third seats ■ Before folding up the third seats Stow the seat belts buckles. STEP ITY13C018 STEP Stow the center head restraint in the seatback. (P. 70) Pass the outer seat belts through STEP the seat belt hangers and secure the seat belt plates.
  • Page 59 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Folding up the third seats Fold down the head restraints STEP while pulling the head restraint angle lever. ITY13C022 Push the seatback angle levers STEP and fold the third seats. Pull the seat leg lock release STEP levers.
  • Page 60 1-3. Adjustable components (seats, mirrors, steering wheel) Secure the seats by the strikers. STEP Remove the seat hook covers STEP from the back of the seat cush- ion, and install them on the seat hooks. ITY13C030 ■ Returning the third seats Remove the seat hook covers STEP from the floor and install them...
  • Page 61 1-3. Adjustable components (seats, mirrors, steering wheel) Secure the seats by the strikers. STEP Pull the handle and raise the STEP seatbacks. Fix the handle securely in its orig- inal position after use. Raise the head restraints. STEP L/C200_U (OM60G31U)
  • Page 62 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Seat adjustment Do not recline the seat more than necessary when the vehicle is in motion, to reduce the risk of sliding under the lap belt. If the seat is too reclined, during an accident the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoulder belt, increasing the risk of death or serious injury.
  • Page 63: Driving Position Memory System

    1-3. Adjustable components (seats, mirrors, steering wheel) Driving position memory system Your preferred driving position (the position of the driver’s seat, steering wheel and outside rear view mirrors) can be entered into the computer’s memory and recalled with the touch of a button. It is also possible to set this function to activate automatically when the doors are unlocked.
  • Page 64 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Recalling the memorized position Check that the shift lever is set in “P”. STEP Turn the “ENGINE START STOP” switch to IGNITION ON mode. Press button “1”, “2” or “3” to STEP recall the desired position.
  • Page 65 1-3. Adjustable components (seats, mirrors, steering wheel) STEP Open one of the doors. If a door is not opened within 60 seconds after is pressed, the doors will be locked again and the alarm will automatically be set. In case that the alarm is triggered, immediately stop the alarm. (P.
  • Page 66 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Canceling the linked door unlock operation STEP Turn the “ENGINE START STOP” switch to OFF after closing the driver’s door. STEP Using the wireless remote control: While pressing “SET” button, press button on the wireless remote control until the signal beeps.
  • Page 67: Head Restraints

    1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. Front seats Vertical adjustment Pull the head restraint up. Down Press hold lock release button when lowering Lock release button the head restraint. Angle adjustment Second seats Vertical adjustment Down...
  • Page 68 1-3. Adjustable components (seats, mirrors, steering wheel) Third outboard seats To fold Pull the head restraint angle lever to fold the head restraint. ITY13C040 ■ Adjusting the height of the head restraints Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears.
  • Page 69 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Removing the head restraints Front seats and third center seat Pull the head restraint up while pressing the lock release button. Lock release button ITO13C143 Second seats Pull the head restraint up while pressing the lock release button.
  • Page 70 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Installing the head restraints STEP Align the head restraint with the installation holes. STEP Push down the head restraint to the lock position. ■ When not using the third center seat head restraint Open the zipper on the back of the third seat and stow the head restraint inside.
  • Page 71: Seat Belts

    1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
  • Page 72 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Adjusting the height of the belt (front and second outboard seats) Down Move the height adjuster up and down as needed until you hear a click. ITY13C055 Third center seat belt The third center seat belt is a 3-point type restraint with 2 buckles. Both seat belt buckles must be correctly located and securely latched for proper operation.
  • Page 73 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Release method The belt can be completely released when not required, such as when removing the third seat. To release the hooked tab, insert STEP the mechanical key into the hole on the buckle with the light gray buckle release button.
  • Page 74 1-3. Adjustable components (seats, mirrors, steering wheel) Seat belt pretensioners (front and second outboard seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal collision.
  • Page 75 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Pregnant women Obtain medical advice and wear the seat belt in the proper way. (P. 71) Women who are pregnant should position the lap belt as low as possible over the hips in the same manner as other occu- pants.
  • Page 76 ■ Seat belt extender If your seat belts cannot be fastened securely because they are not long enough, personalized seat belt extender is available from your Toyota dealer free of charge. ITY13C060 L/C200_U (OM60G31U)
  • Page 77 ● If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. L/C200_U (OM60G31U)
  • Page 78 ● Do not attempt to install, remove, modify, disassemble or dispose of a seat belt. Have any necessary repairs carried out by your Toyota dealer. Inap- propriate handling of the pretensioner may cause it to activate or operate improperly and may cause death or serious injury.
  • Page 79 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Using a seat belt extender ● Do not wear the seat belt extender, if you can fasten the seat belt without the extender. ● Do not use the seat belt extender when installing a child restraint system, because the belt will not securely hold the child restraint system, increas- ing the risk of death or serious injury in the event of a sudden stop, sudden swerve or accident.
  • Page 80: Steering Wheel

    1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position while the “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. Down Toward the driver Away from the driver Auto tilt away and auto return When “ENGINE...
  • Page 81: Inside Rear View Mirror

    1-3. Adjustable components (seats, mirrors, steering wheel) Inside rear view mirror In auto mode, sensors are used to detect the headlights of vehicles behind and automatically reduce the reflected light. Turns auto mode on/off The indicator comes on when auto mode is turned on. The mirror will revert to the auto mode each time the “ENGINE...
  • Page 82 1-3. Adjustable components (seats, mirrors, steering wheel) ■ To prevent sensor error To ensure correct functioning of the sen- sors, do not touch or cover the sensors. ITY13C080 CAUTION ■ While driving Do not adjust the position of the mirror. Doing so may lead to mishandling of the vehicle and an accident, or result- ing in death or serious injury.
  • Page 83: Outside Rear View Mirrors

    1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch when the “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. Select a mirror to adjust STEP Left Right Adjust the mirror STEP Right...
  • Page 84 1-3. Adjustable components (seats, mirrors, steering wheel) ■ When the mirrors are fogged up Turn on the outside rear view mirror defoggers to defog the mirrors. (P. 262) ■ Auto anti-glare function When the anti-glare inside rear view mirror is set to auto mode, the outside rear view mirrors will activate in conjunction with the anti-glare inside rear view mirror to reduce reflected light.
  • Page 85 1-3. Adjustable components (seats, mirrors, steering wheel) NOTICE ■ If ice should jam the mirror Do not operate the control or scrape the mirror face. Use a spray de-icer to free the mirror. L/C200_U (OM60G31U)
  • Page 86: Opening And Closing The Windows And Moon Roof Power Windows

    1-4. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the following switches. Closing One-touch closing Opening One-touch opening : Pressing the switch in the opposite direction will stop window travel partway. Lock switch Press the switch down to lock passenger window switches.
  • Page 87 The “ENGINE START STOP” switch is in IGNITION ON mode. ■ Door lock linked window operation The following functions can be used if customized at your Toyota dealer. ● The power windows can be opened and closed using the mechanical key.
  • Page 88 1-4. Opening and closing the windows and moon roof CAUTION ■ Closing the windows Observe the following precautions. Failing to do so may result in death or serious injury. ● Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.
  • Page 89: Moon Roof

    1-4. Opening and closing the windows and moon roof Moon roof Use the overhead switches to open, close, and tilt the moon roof up and down. ■ Opening and closing Open Stops just before it is opened fully. Press the switch again to fully open.
  • Page 90 The “ENGINE START STOP” switch is in IGNITION ON mode. ■ Door lock linked moon roof operation The following functions can be used if customized at your Toyota dealer. ● The moon roof can be opened and closed using the mechanical key.
  • Page 91 1-4. Opening and closing the windows and moon roof ■ Moon roof open warning buzzer The buzzer sounds and message is shown on the multi-information display in the instrument panel when the “ENGINE START STOP” switch is turned OFF and the driver’s door is opened with the moon roof open. ■...
  • Page 92: 1-5. Refueling

    1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. ■ Before refueling the vehicle Turn the “ENGINE START STOP” switch OFF and ensure that all the doors and windows are closed. ■ Opening the fuel tank cap Pull the lever.
  • Page 93 1-5. Refueling Closing the fuel tank cap When replacing the fuel tank cap, turn it until a clicking sound is heard. After releasing your hand, the cap will turn slightly to the opposite direction. ■ Fuel types Use unleaded gasoline. (Octane Rating 87 [Research Octane Number 91] or higher) ■...
  • Page 94 ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Failure to do so may cause a fire or other incident which may result in death or serious injury.
  • Page 95 1-5. Refueling NOTICE ■ Refueling Do not spill fuel during refueling. Failing to do so may damage the vehicle, such as causing the exhaust sys- tems to operate abnormally or damaging fuel system components or the vehicle’s painted surface. L/C200_U (OM60G31U)
  • Page 96: Theft Deterrent System Engine Immobilizer System

    1-6. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. Vehicles with navigation system The indicator light flashes after the “ENGINE START STOP”...
  • Page 97 1-6. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type engine immobilizer system. ■ Conditions that may cause the system to malfunction ● If the key is in contact with a metallic object. ● If the key is in close proximity to or touching a key to the security system (key with a built-in transponder chip) of another vehicle.
  • Page 98: Alarm

    1-6. Theft deterrent system Alarm The system sounds the alarm and flashes lights when forcible entry is detected. ■ Triggering of the alarm The alarm is triggered in the following situations when the alarm is set: ● A locked door is unlocked or opened in any way other than by using the smart key system or wireless remote control.
  • Page 99 1-6. Theft deterrent system ■ Deactivating or stopping the alarm Do one of the following to deactivate or stop the alarm. ● Unlock the doors using the smart key system or the wireless remote control. ● Start the engine. (The alarm will be deactivated or stopped after a few seconds.) ■...
  • Page 100 1-6. Theft deterrent system ■ Triggering of the alarm The alarm may be triggered in the following situations. (Stopping the alarm deactivates the alarm system.) ● door unlocked using mechanical key. ● A person inside the vehicle opens a door or hood. ●...
  • Page 101 1-6. Theft deterrent system ■ When the battery is disconnected Be sure to cancel the alarm system. If the battery is disconnected before canceling the alarm, the system may be triggered when the battery is reconnected. ■ Alarm-operated door lock ●...
  • Page 102: Safety Information Correct Driving Posture

    1-7. Safety information Correct driving posture Drive with a good posture as follows: Sit upright and well back in the seat. (P. 52) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
  • Page 103 1-7. Safety information CAUTION ■ While driving ● Do not adjust the position of the driver’s seat. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
  • Page 104: Srs Airbags

    1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
  • Page 105 1-7. Safety information Side and curtain shield airbags Side airbags Can help protect the torso of the front and second outboard seat occupants. Curtain shield airbags Can help protect primarily the head of front seat occupants, sec- ond and third outboard seat occupants. L/C200_U (OM60G31U)
  • Page 106 1-7. Safety information Airbag system components Occupant detection system Side airbags (ECU & sensors) (second outboard seats) Knee airbags Driver airbag Curtain shield airbags Driver’s seat position sensor Front passenger airbag Driver’s seat belt buckle switch Front passenger occupant classification indicator light Floor sensor Side and curtain shield airbag Roll sensing of curtain shield...
  • Page 107 1-7. Safety information Your vehicle is equipped with ADVANCED AIRBAGS designed based on US motor vehicle safety standards (FMVSS208). The airbag sys- tem controls airbag deployment power for the driver and front pas- senger. The driver airbag system consists of the driver seat’s position sensor etc.
  • Page 108 1-7. Safety information ■ SRS airbag deployment conditions (SRS front airbags) ● The SRS front airbag will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approxi- mately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
  • Page 109 1-7. Safety information ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front, side and curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
  • Page 110 1-7. Safety information ■ Types of collisions that may not deploy the SRS airbag (side and curtain shield airbags) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
  • Page 111 1-7. Safety information ■ When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or...
  • Page 112 1-7. Safety information CAUTION ■ SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts.
  • Page 113 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are the safest for infants and children.
  • Page 114 1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not sit on the edge of the seat or lean against the dashboard. ITY17C021 ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
  • Page 115 1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not attach anything to or lean any- thing against areas such as the dash- board or steering wheel pad or lower portion of the instrument panel. These items can become projectiles when SRS driver, front passenger and knee airbags deploy.
  • Page 116 Wash off any residue as soon as possible to prevent skin irritation. ● If the areas where the SRS airbags are stored, such as the steering wheel pad and front, center and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. L/C200_U (OM60G31U)
  • Page 117 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbag may malfunction or deploy (inflate) accidentally, causing death or serious injury.
  • Page 118 1-7. Safety information Deactivating the curtain shield airbags in a vehicle rollover On/off (Hold for a few seconds) The “RSCA OFF” (roll sensing of curtain shield airbags off) indicator light turns on. (Only when the “ENGINE START STOP” switch is in IGNITION ON mode.) ■...
  • Page 119: Front Passenger Occupant Classification System

    1-7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for front passenger. SRS warning light AIR BAG OFF indicator light AIR BAG ON indicator light...
  • Page 120 1-7. Safety information Condition and operation in the front passenger occupant classi- fication system ■ Adult AIR BAG ON and AIR BAG OFF indicator lights Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Flashing Front passenger airbag and knee airbag Side airbag in the front passenger seat Devices Activated...
  • Page 121 1-7. Safety information ■ Unoccupied AIR BAG ON and AIR BAG OFF Not illumi- indicator lights nated Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag and knee airbag Deactivated Side airbag in the front passenger seat Devices Curtain shield airbag Activated...
  • Page 122 1-7. Safety information ■ System malfunction AIR BAG ON and AIR BAG OFF indicator lights Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag and knee airbag Deactivated Side airbag in the front passenger seat Devices Curtain shield airbag on the front passenger side...
  • Page 123 1-7. Safety information CAUTION ■ Front passenger occupant classification system precautions Observe the following precautions regarding front passenger occupant clas- sification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt tab has not been left inserted into the buckle before someone sits in the front passenger seat.
  • Page 124 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction in the detection system. In this case, contact your Toyota dealer immediately. ● Do not use a seat accessory, such as a cushion or seat cover, that covers the seat cushion surface.
  • Page 125: Child Restraint Systems

    1-7. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. now require the use of child restraint systems.
  • Page 126 1-7. Safety information Forward facing—Convertible seat Booster seat ■ When installing the child restraint system on the front passenger seat When you have to use a child restraint system on the front passenger seat, adjust the following: ● The seatback to the most upright posi- tion ●...
  • Page 127 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
  • Page 128 1-7. Safety information CAUTION ■ Child restraint precautions ● Do not use the seat belt extender when installing a child restraint system on the front or rear passenger seat. If installing a child restraint system with the seat belt extender connected to the seat belt, the seat belt will not securely hold the child restraint system, which could cause death or seri- ous injury to the child or other passengers in the event of a sudden stop, sudden swerve or accident.
  • Page 129: Installing Child Restraints

    1-7. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure the child restraints using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
  • Page 130 1-7. Safety information Installation with LATCH system Fold the seatback forward and STEP then adjust it as upright as possi- ble. Take off the covers between the STEP seat cushion and seatback, then confirm position LATCH anchors below the sym- bol in the seatback.
  • Page 131 1-7. Safety information Type A STEP Latch the hooks of the lower straps onto the LATCH anchors. STEP If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. ITY17C124 Type B STEP...
  • Page 132 1-7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing  Infant seat/convertible seat ■ Fold the seatback while pulling STEP the seatback angle lever. Return the seatback and secure it at the first lock position. (P.
  • Page 133 1-7. Safety information Fully extend the shoulder belt STEP and then allow it to retract slightly in order to activate the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing the child restraint STEP system down into the seat, allow the shoulder belt to retract until the child restraint system is securely in place.
  • Page 134 1-7. Safety information Forward-facing Convertible seat ■ Fold the seatback while pulling STEP the seatback angle lever. Return the seatback and secure it at the first lock position. (P. 54) Place the child restraint system STEP on the second or third seat fac- ing the front of the vehicle.
  • Page 135 1-7. Safety information Fully extend the shoulder strap STEP and then allow it to retract slightly into the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing the child restraint STEP system into the seat, allow the shoulder belt to retract until the child restraint system is securely in place.
  • Page 136 1-7. Safety information ■ Booster seat Fold the seatback while pulling STEP the seatback angle lever. Return the seatback and secure it at the first lock position. (P. 54) Place the child restraint system STEP on the seat facing the front of the vehicle.
  • Page 137 1-7. Safety information Removing a child restraint system installed with a seat belt Press the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap STEP Secure the child restraint system using a seat belt or LATCH anchors, and do the following.
  • Page 138 1-7. Safety information STEP Open the anchor bracket cover, latch the hook onto the anchor bracket and tighten the top tether strap. Outside Make sure the top tether strap is securely latched. Center Outside only: Adjust the head STEP restraint to the downmost posi- tion.
  • Page 139 1-7. Safety information ■ Laws and regulations pertaining to anchorages The LATCH system conforms to FMVSS225. Child restraint systems conforming to FMVSS213 specifications can be used. This vehicle is designed to conform to the SAE J1819. CAUTION ■ When installing a booster seat Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode: (P.
  • Page 140 1-7. Safety information CAUTION ■ When installing a child restraint system Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place. If the child restraint system is not correctly fixed in place, the child or other passengers may be seriously injured or even killed in the event of sudden braking, sudden swerving or an accident.
  • Page 141 1-7. Safety information CAUTION ■ When installing a child restraint system ● Ensure that the belt and tab are securely locked and the seat belt is not twisted. ● Push and pull the child restraint system from side to side and forward to be sure it is secure.
  • Page 142 1-7. Safety information L/C200_U (OM60G31U)
  • Page 143: When Driving

    When driving 2-1. Driving procedures 2-3. Operating the lights and wipers Driving the vehicle.... 144 Headlight switch....175 Engine (ignition) switch ..154 Fog light switch ....178 Automatic transmission..158 Windshield wipers and Turn signal lever ....163 washer ......179 Parking brake....
  • Page 144: 2-1. Driving Procedures

    2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. ■ Starting the engine (P. 154) ■ Driving STEP With the brake pedal depressed, shift the shift lever to “D”. (P. 158) STEP Release the parking brake.
  • Page 145 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodi- cally or whenever the parking brake shoes and/or drums are replaced. Have your Toyota dealer perform the bedding-down. ■ Operating your vehicle in a foreign country Comply with the relevant vehicle registration laws and confirm the availability of the correct fuel.
  • Page 146 Large amounts of exhaust in the vehi- cle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immediately. L/C200_U (OM60G31U)
  • Page 147 2-1. Driving procedures CAUTION ● Do not under any circumstances shift the shift lever to “P” or “R” while the vehicle is moving. Doing so can cause significant damage to the transmission and may result in a loss of vehicle control. ●...
  • Page 148 2-1. Driving procedures CAUTION ■ When driving on slippery road surfaces ● Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle, resulting in an accident. ● Sudden changes in engine speed, such as engine braking caused by up- shifting or down-shifting, may cause the vehicle to skid, resulting in an accident.
  • Page 149 2-1. Driving procedures CAUTION ■ When the vehicle is parked ● Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Failure to do so may result in the following: •...
  • Page 150 The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
  • Page 151 2-1. Driving procedures CAUTION ■ When braking the vehicle ● When the brakes are wet, drive more cautiously. Braking distance increases when the brakes are wet, and may cause one side of the vehicle to brake differently than the other side. Also the parking brake may not securely hold the vehicle.
  • Page 152 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have your Toyota dealer check and replace the brake pads as soon as pos- sible. The rotor damage can result if the pads are not replaced when needed.
  • Page 153 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following. ● Brake function ●...
  • Page 154: Engine (Ignition) Switch

    2-1. Driving procedures Engine (ignition) switch Performing the following operations when carrying the electronic key on your person starts the engine or changes “ENGINE START STOP” switch modes. ■ Starting the engine STEP Check that the parking brake is set. STEP Check that the shift lever is set in “P”.
  • Page 155 2-1. Driving procedures ■ Changing “ENGINE START STOP” switch mode Modes can be changed by pressing the “ENGINE START STOP” switch with the brake pedal released. (The mode changes each time the switch is pressed.) Emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can...
  • Page 156 ■ When the “ENGINE START STOP” switch indicator flashes in amber The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ Auto power off function If the vehicle is left in ACCESSORY mode for more than an hour with the shift lever in “P”, the “ENGINE START STOP”...
  • Page 157 2-1. Driving procedures CAUTION ■ When starting the engine Always start the engine while sitting in the driver’s seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. ■...
  • Page 158: Automatic Transmission

    2-1. Driving procedures Automatic transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever While the “ENGINE START STOP” switch is in IGNITION ON mode, depress the brake pedal and move the shift lever. ■ Shift position uses Shift position Function...
  • Page 159 2-1. Driving procedures ■ Selecting a driving mode The following patterns can be selected to suit current driving and operating conditions. Power mode For powerful acceleration and driving mountainous regions. Normal mode Second start mode For starting on slippery road surfaces, such as on snow.
  • Page 160 2-1. Driving procedures Changing shift ranges in “S” mode Shift the shift lever to the “S” position and operate the shift lever. Upshifting Downshifting ITY21C009 The initial shift range in “S” mode is automatically set to “5” or “4” according to the vehicle’s speed. However, the initial shift range may be set to “3”...
  • Page 161 2-1. Driving procedures ■ Shift ranges and their functions Shift range Function Automatically selecting gears between 1 and 6 according to vehicle speed and driving conditions. Automatically selecting gears between 1 and 5 according to vehicle speed and driving conditions. Automatically selecting gears between 1 and 4 according to vehicle speed and driving conditions.
  • Page 162 If the “S” indicator does not come on even after shifting the shift lever to “S” This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the vehicle will operate as if the shift lever is in “D”.) ■...
  • Page 163: Turn Signal Lever

    2-1. Driving procedures Turn signal lever Right turn Left turn Move and hold the lever partway to signal a lane change The right hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change The left hand signal will flash until you release the lever.
  • Page 164: Parking Brake

    2-1. Driving procedures Parking brake Sets the parking brake Fully set the parking brake while depressing the brake pedal. Releases the parking brake Slightly raise the lever and lower it completely while press- ing the button. ■ Usage in winter time See “Winter driving tips”...
  • Page 165: Horn

    2-1. Driving procedures Horn To sound the horn, press on or close to the mark. ITO21C031 L/C200_U (OM60G31U)
  • Page 166: 2-2. Instrument Cluster

    2-2. Instrument cluster Gauges and meters The following gauges, meters and display illuminate when the “ENGINE START STOP” switch is in IGNITION ON mode. Tachometer Displays the engine speed in revolutions per minute. Engine coolant temperature gauge Displays the engine coolant temperature. Fuel gauge Displays the quantity of fuel remaining in the tank.
  • Page 167 2-2. Instrument cluster Odometer and trip meter Odometer: Displays the total distance the vehicle has been driven. Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display different distances independently.
  • Page 168 While driving ● When the voltmeter indicates more than 19 V or less than 9 V, the battery may be malfunctioning. Have your vehicle checked at your Toyota dealer. ● When the engine oil pressure gauge does not work properly, immediately stop the engine and contact your Toyota dealer.
  • Page 169: Indicators And Warning Lights

    2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. Instrument cluster Center panel (vehicles with navigation system) Center panel (vehicles without navigation system) L/C200_U (OM60G31U)
  • Page 170 2-2. Instrument cluster ■ Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Roll sensing of curtain Turn signal indicator shield airbags off indica- (P. 163) tor (P. 118) Headlight high beam “PWR” mode indicator indicator (P.
  • Page 171 Have the vehicle inspected by your Toyota dealer immediately if this occurs. L/C200_U (OM60G31U)
  • Page 172: Multi-Information Display

    2-2. Instrument cluster Multi-information display The Multi-information display presents the driver with a variety of driving-related data. ● Trip information (P. 173) Displays driving range, fuel consumption and other cruis- ing-related information. ● Intuitive parking assist dis- play (P. 190) Automatically displayed when using intuitive parking assist.
  • Page 173 2-2. Instrument cluster Switch the display Display items can be switched by pressing the “DISP” button. Trip information ■ Current fuel consumption Displays the current rate of fuel consumption. ■ Average fuel consumption Displays the average fuel consumption since the vehicle was last refueled.
  • Page 174 2-2. Instrument cluster ■ Average vehicle speed Displays the average vehicle speed since the engine was started. ■ Driving distance Displays the driving distance since the engine was started. ■ Tire inflation pressure Displays inflation pressure of each tire. There is no correlation between the order of the displayed values and the tire positions.
  • Page 175: 2-3. Operating The Lights And Wipers

    2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. The side marker, park- ing, tail, license plate, daytime running lights and instrument panel lights turn on. The headlights and all lights listed above (except daytime run- ning lights) turn on.
  • Page 176 2-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever forward to turn on the high beams. Pull the lever back to the center position to turn the high beams off. Pull the lever toward you to turn on the high beams.
  • Page 177 2-3. Operating the lights and wipers ■ Automatic light off system ● When the headlights are on: The headlights and tail lights turn off 30 sec- onds after a door is opened and closed if the “ENGINE START STOP” switch has been switched to ACCESSORY or OFF mode. ●...
  • Page 178: Fog Light Switch

    2-3. Operating the lights and wipers Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. The fog lights can be used when the headlights are on low beam. ITO23C066 L/C200_U (OM60G31U)
  • Page 179: Windshield Wipers And Washer

    2-3. Operating the lights and wipers Windshield wipers and washer Intermittent wiper with interval adjuster Wiper intervals can be adjusted for intermittent operation (when is selected). Intermittent wiper operation Low speed wiper operation High speed wiper operation Temporary operation ITO23C071 Increases the intermittent windshield wiper frequency Decreases the intermittent...
  • Page 180 2-3. Operating the lights and wipers Washer/wiper dual opera- tion Wipers operate automatically. ITO23C081 Rain-sensing windshield wipers With “AUTO” selected, the wipers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume and vehicle speed.
  • Page 181 2-3. Operating the lights and wipers Sensor sensitivity (high) Sensor sensitivity (low) ITO23C080 Washer/wiper dual opera- tion Wipers operate automatically. (After operating several times, the wipers operate one more time after a short delay to pre- vent dripping.) ITO23C085 L/C200_U (OM60G31U)
  • Page 182 2-3. Operating the lights and wipers ■ The windshield wiper and washer can be operated when The “ENGINE START STOP” switch is in IGNITION ON mode. ■ Effects of vehicle speed on wiper operation (vehicles equipped with rain-sensing windshield wipers) Vehicle speed affects the wiper operation when the washer is being used (delay until drip prevention wiper sweep occurs) even when the wipers are not in “AUTO”...
  • Page 183 2-3. Operating the lights and wipers ■ Windshield wiper features The rear window and outside rear view mirror defoggers automatically turn on when you operate the wipers. CAUTION ■ Caution regarding the use of windshield wipers in “AUTO” mode The windshield wipers may operate unexpectedly if the sensor is touched or the windshield is subject to vibration in “AUTO”...
  • Page 184: Rear Window Wiper And Washer

    2-3. Operating the lights and wipers Rear window wiper and washer Intermittent window wiper operation Normal window wiper oper- ation Washer/wiper dual opera- tion Washer operation ITO23C088 ■ The rear window wiper and washer can be operated when The “ENGINE START STOP” switch is in IGNITION ON mode. NOTICE ■...
  • Page 185: Headlight Cleaner Switch

    2-3. Operating the lights and wipers  Headlight cleaner switch Washer fluid can be sprayed on the headlights. Press the switch to clean the headlights. ITY23C039 ■ The headlight cleaner can be operated when The “ENGINE START STOP” switch is in IGNITION ON mode and the head- light switch is turned on.
  • Page 186: Using Other Driving Systems Cruise Control

    2-4. Using other driving systems Cruise control Use the cruise control to maintain a set speed without using the accelerator. Indicator Cruise control switch ■ Set the vehicle speed STEP Press the “ON-OFF” button to operate the cruise control. Press the switch once more to deactivate the cruise control.
  • Page 187 2-4. Using other driving systems ■ Adjusting the speed setting Increase speed Decrease speed Hold the lever until the desired speed setting is obtained. Fine adjustment of the set speed (approximately 1.0 mph [1.6 km/h]) can be made by lightly pushing the lever up or down and releasing it.
  • Page 188 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Contact your Toyota dealer, and have your Toyota inspected. L/C200_U (OM60G31U)
  • Page 189 2-4. Using other driving systems CAUTION ■ To avoid operating the cruise control by mistake Keep the “ON-OFF” button off when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in control of the vehicle being lost and could cause an accident resulting in death or serious injury.
  • Page 190: Intuitive Parking Assist

    2-4. Using other driving systems  Intuitive parking assist Intuitive parking assist uses sensors in the corners and rear of the vehicle to detect the distance between the vehicle and any obsta- cles, and informs the driver of this distance using the multi-informa- tion display, the touch screen, and warning beeps.
  • Page 191 2-4. Using other driving systems ■ Multi-information display Front corner sensor detec- tion Rear corner sensor detec- tion Back sensor detection ITY24C017 ■ Touch screen (with navigation system) When the vehicle is moving forward The graphic is automatically displayed when an obstacle is detected.
  • Page 192 2-4. Using other driving systems Sensor detection display, obstacle distance ■ Corner sensors Multi- Touch screen Approximate information distance to obstacle Insert display display Front: 2.0 ft. (60 cm) to 1.6 ft. (47.5 cm) Rear: 2.0 ft. (60 cm) to (continuous) (continuous) (blinking)
  • Page 193 2-4. Using other driving systems ■ Back sensors Approximate distance Multi-information Touch screen to obstacle display (insert display) 4.9 ft. (150 cm) to 2.0 ft. (60 cm) (continuous) (blinking slowly) 2.0 ft. (60 cm) to 1.5 ft. (45 cm) (continuous) (blinking) 1.5 ft.
  • Page 194 2-4. Using other driving systems Beeps and obstacle distance A beep sounds when the corner sensors and back sensors are oper- ating. ● The beep sounds faster as the vehicle approaches an obstacle. When the vehicle comes within the following distance of the obsta- cle, the beep sounds continuously.
  • Page 195 Warning beep volume and touch screen settings (vehicles with navigation system only) You can change the warning beep volume and touch screen operat- ing conditions. STEP Press “SETUP” to display the “Setup” screen. STEP Touch “Vehicle”. STEP Touch “TOYOTA Park Assist”. L/C200_U (OM60G31U)
  • Page 196 2-4. Using other driving systems ■ Changing the warning beep volume STEP Touch “1” to “5” of “Alert Volume”. STEP Adjust the beep volume, then touch “Save”. ■ Display off setting Touch “On” or “Off” of “Display”. When an obstacle is detected while the rear view monitor is in use, the warning indicator will appear in the top right of the screen even “Off”...
  • Page 197 • If towing eyelet is installed on your vehicle. • The bumper or sensor receives a strong impact. • A non-genuine Toyota suspension (lowered suspension etc.) is installed. In addition to the examples above, there are instances in which, because of their shapes, signs and other objects may be judged by the sensor to be closer than they are.
  • Page 198 If a message is displayed on the multi-information display P. 513 ■ When there is a malfunction In the following cases, have the vehicle inspected by your Toyota dealer. ● If the bumper is damaged ● If the intuitive parking assist indicator light remains on without a beep sounds.
  • Page 199: Four-Wheel Drive System

    2-4. Using other driving systems Four-wheel drive system Use the four-wheel drive control switch and center differential lock/ unlock switch to select the following transfer and center differential modes. ■ Four-wheel drive control switch “H4” (high speed position) Normal driving on all types of roads.
  • Page 200 2-4. Using other driving systems Shifting between “H4”and “L4” ■ Shifting from “H4” to “L4” STEP Stop the vehicle completely. STEP Shift the shift lever to “N”. STEP Push and turn the four-wheel drive control switch fully clock- wise. Maintain this condition until the low speed four-wheel drive indica- tor light turns on.
  • Page 201 2-4. Using other driving systems ■ The four-wheel drive control switch can be operated when ● The “ENGINE START STOP” switch is in IGNITION ON mode. ● The shift lever is in the “N” position. ● The vehicle is stopped completely. ■...
  • Page 202 In this case, you may not be able to shift between “H4” and “L4”, and the center differential lock may not be operable. Have the vehicle inspected by your Toyota dealer immediately. L/C200_U (OM60G31U)
  • Page 203 2-4. Using other driving systems CAUTION ■ While driving Never move the four-wheel drive control switch if the wheels have lost trac- tion. Doing so may cause an accident resulting in death or serious injury. ■ When the vehicle is parked If the shift lever is moved before the low speed four-wheel drive indicator turns on/off, the transfer mode may not be shifted completely.
  • Page 204: Crawl Control

    2-4. Using other driving systems Crawl Control Allows travel on extremely rough off-road surfaces at a fixed low speed without pressing the accelerator or brake pedal. Minimizes loss of traction or vehicle slip when driving on slippery road sur- faces, allowing for stable driving. ■...
  • Page 205 2-4. Using other driving systems When the system is turned off If the system is turned off when Crawl Control is operating, the slip indicator turns off, and the Crawl Control indicator flashes until the system has turned off completely. When turning off Crawl Control while traveling, stop the vehicle before the Crawl Control indicator turns off, or drive extremely carefully.
  • Page 206 2-4. Using other driving systems ■ Function limitations ● In the following situations, brake control can be used to drive downhill at a constant speed. However, engine control is not available when driving uphill at a constant speed. • When switched to second start mode •...
  • Page 207 2-4. Using other driving systems CAUTION ■ When using Crawl Control Do not rely solely on the Crawl Control. This function does not extend the vehicle’s performance limitations. Always thoroughly check the road condi- tions, and drive safely. ■ These conditions may cause the system not to operate properly When driving on the following surfaces, the system may not be able to main- tain a fixed low speed, which may result in an accident: ●...
  • Page 208: Driving Assist Systems

    2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
  • Page 209 2-4. Using other driving systems When the VSC/Active TRAC/hill-start assist control systems are operating If the vehicle is in danger of slip- ping, rolling backwards when starting on an incline, or if the rear wheels spin, the slip indica- tor light flashes to indicate that the VSC/Active TRAC/hill-start assist control...
  • Page 210 2-4. Using other driving systems To disable Active TRAC and/or VSC system If the vehicle gets stuck in fresh snow or mud, Active TRAC and VSC system may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it.
  • Page 211 2-4. Using other driving systems ■ Active TRAC can be turned off when The four-wheel drive control switch is in “H4” and the center differential is unlocked. ■ Automatic reactivation of Active TRAC and VSC Turning the “ENGINE START STOP” switch off after turning off the Active TRAC and VSC systems will automatically re-enable them.
  • Page 212 2-4. Using other driving systems CAUTION Any of the following conditions may result in an accident which could cause death or serious injury: ■ The Multi Terrain ABS does not operate effectively when ● The limits of tire gripping performance have been exceeded. ●...
  • Page 213 In the following situations, there is the possibility that a system malfunction has occurred, and drive comfort and the vehicle’s ability to travel on poor road surfaces may be reduced. Take the vehicle to your Toyota dealer imme- diately. ●...
  • Page 214: Pre-Collision System

    2-4. Using other driving systems  Pre-Collision System The system detects emergency braking from the speed and force with which the driver presses the brake pedal, and quickly tightens the seat belt to improve the effectiveness of the seat belt pretension- ers (P.
  • Page 215: Driving Information Off-Road Precautions

    2-5. Driving information Off-road precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications.
  • Page 216 2-5. Driving information CAUTION ■ Off-road vehicle precautions Always observe the following precautions to help minimize the risk of serious personal injury or damage to your vehicle: ● In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
  • Page 217 2-5. Driving information Off-road driving When driving your vehicle off-road, please observe the following pre- cautions to ensure your driving enjoyment and to help prevent the closure of areas to off-road vehicles. ● Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
  • Page 218 2-5. Driving information CAUTION ■ Off-road driving precautions Always observe the following precautions to help minimize the risk of serious personal injury or damage to your vehicle: ● Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places.
  • Page 219 2-5. Driving information NOTICE ■ To prevent the water damage Take all necessary safety measures to ensure that water damage to the engine or other components does not occur. ● Water entering the engine air intake will cause severe engine damage. ●...
  • Page 220: Cargo And Luggage

    2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. ● Stow cargo and luggage in the luggage compartment when- ever possible. Be sure all items are secured in place. ●...
  • Page 221 2-5. Driving information Adjusting the position of cross rails Turn the knobs counterclockwise STEP to release the cross rails. ITY25C040 Slide the cross rails to the appro- STEP priate position for loading lug- gage turn knobs clockwise to tighten the cross rails securely.
  • Page 222 2-5. Driving information Capacity and distribution Cargo capacity depends on the total weight of the occupants. (Cargo capacity) = (Total load capacity) — (Total weight of occupants) Steps for Determining Correct Load Limit— (1) Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.”...
  • Page 223 2-5. Driving information Example on your vehicle Cargo capacity Total load capacity When 2 people with the combined weight of 366 lb. (166 kg) are riding in your vehicle, which has a total load capacity of 1235 lb. (560 kg), the available amount of cargo and luggage load capacity will be as follows: 1235 lb.
  • Page 224 2-5. Driving information CAUTION ■ Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compart- ment. ● Receptacles containing gasoline ● Aerosol cans ■ Storage precautions Observe the following precautions. Failing to do so may result in death or serious injury.
  • Page 225 Roof luggage carrier precautions To use the roof rails as a roof luggage carrier, you must fit the roof rails with two or more genuine Toyota cross rails or their equivalent. When you load cargo on the roof luggage carrier, observe the following: ●...
  • Page 226 2-5. Driving information CAUTION ■ Cross rail adjustment Make sure the cross rails are locked securely by pushing forward and rearward them. Failure to do so may cause an accident or severe injury in the event of emergency braking or a collision. NOTICE ■...
  • Page 227: Vehicle Load Limits

    2-5. Driving information Vehicle load limits Vehicle load limits include total load capacity, seating capacity, towing capacity and cargo capacity. ■ Total load capacity: 1235 lb. (560 kg) Total load capacity means the combined weight of occupants, cargo and luggage. ■...
  • Page 228: Winter Driving Tips

    2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tem- peratures.
  • Page 229 2-5. Driving information ■ Before driving the vehicle Perform the following according to the driving conditions. ● Do not try to forcibly open a window or move a wiper that is frozen. Pour warm water over the frozen area to melt the ice. Wipe away the water immediately to prevent it from freezing.
  • Page 230 2-5. Driving information Selection tire chains Use the correct tire chain size when mounting the tire chains. Chain size is regulated for each tire size. Side chain (0.20 in. [5 mm] in diameter) Cross chain (0.25 in. [6.3 mm] in diameter) ITY25C045 Regulations on the use of tire chains ●...
  • Page 231 2-5. Driving information CAUTION ■ Driving with snow tires Observe the following precautions to reduce the risk of accidents. Failing to do so may result in a loss of vehicle control and cause death or serious injury. ● Use tires of the size specified for your vehicle. ●...
  • Page 232 NOTICE ■ Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota deal- ers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the operation of the tire pressure warning valves and transmitters.
  • Page 233: Trailer Towing

    The vehicle stability and braking performance are affected by trailer stability, brake setting and performance, and the hitch. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Toyota dealer for further information about additional requirements such as a towing kits, etc.
  • Page 234 2-5. Driving information Weight limits Confirm that the gross trailer weight, gross combined weight, gross vehicle weight, gross axle weight and trailer tongue load are all within the limits. ● The gross trailer weight must never exceed 8500 lb. (3856 kg). ●...
  • Page 235 2-5. Driving information Towing related term Towing related term Meaning The maximum allowable gross vehicle weight. The gross vehicle weight is the total weight of the vehicle. When towing GVWR (Gross Vehicle Weight a trailer, it is the sum of the vehicle Rating) weight (including the occupants, cargo and any optional equipment installed on...
  • Page 236 2-5. Driving information Trailer tongue load ● A recommended tongue load varies in accordance with the types of trailers or towing as described below. ● In order to ensure the recommended values shown below, the trailer must be loaded by referring to the following instructions. The trailer cargo load should be distributed so that the tongue load is 9 to 11 %.
  • Page 237 2-5. Driving information Removing hitch cover Remove the clip. STEP Grasp the lower edge of the hitch STEP cover and raise the cover. When reattaching cover, reverse the steps listed. ITY25C047 L/C200_U (OM60G31U)
  • Page 238 2-5. Driving information Selecting trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer coupler. Most couplers stamped with the required trailer ball size.
  • Page 239 2-5. Driving information Trailer towing tips Your vehicle will handle differently when towing a trailer. In order to avoid accident, death or serious injury, keep the following in mind when towing: ● Before starting out, check the trailer lights and the vehicle-trailer connections.
  • Page 240 2-5. Driving information ● Note that when making a turn, the trailer wheels will be closer than the vehicle wheels to the inside of the turn. Compensate by making a larger than normal turning radius. ● Crosswinds and rough roads will adversely affect handling of your vehicle and trailer, causing sway.
  • Page 241 2-5. Driving information ● Always place wheel blocks under both the vehicle and the trailer wheels when parking. Apply the parking brake firmly, and put the transmission in “P”. Avoid parking on a slope, but if unavoidable, do so only after performing the following: STEP Apply the brakes and keep them applied.
  • Page 242 ■ Break-in schedule Toyota recommends that you do not use a new vehicle or a vehicle with any new power train components (engine, transmission, differential, wheel bear- ings, etc.) to tow a trailer for the first 500 miles (800 km) of driving.
  • Page 243 2-5. Driving information CAUTION ■ Trailer towing precautions ● Follow all the instructions described in this section. Failure to do so could cause an accident resulting in death or serious injury. ● Exceeding the towing capacity, GVWR, GCWR and GAWR can cause an accident resulting in death or serious personal injuries.
  • Page 244 ■ When installing a trailer hitch ● Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ● Do not use axle-mounted hitches, as they can cause damage to the axle housing, wheel bearings, wheels or tires.
  • Page 245: Dinghy Towing

    2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground. L/C200_U (OM60G31U)
  • Page 246: Interior Features

    Interior features 3-1. Using the air conditioning system and defogger Front air conditioning system ......248 Rear air conditioning system ......258 Rear window and outside rear view mirror defoggers ....... 262 Windshield wiper de-icer ......263 3-2. Using the audio system Audio system type....
  • Page 247 Interior features ® 3-3. Using the Bluetooth audio 3-6. Using the storage features system List of storage features ..374 ® • Glove box....... 375 Bluetooth • Console box ....376 audio system....313 • Overhead console..377 ® Using the Bluetooth •...
  • Page 248: Using The Air Conditioning System And Defogger Front Air Conditioning System

    3-1. Using the air conditioning system and defogger  Front air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner’s Manual”. Without navigation system Driver’s side temperature control Passenger’s side temperature control...
  • Page 249 3-1. Using the air conditioning system and defogger Using the automatic mode STEP Press The air conditioning system will begin to operate. Air outlets and fan speed are automatically adjusted according to the temperature set- ting. STEP Press “” to increase the temperature and “” to decrease the temperature on The temperature for the driver’s and front passenger’s seats can be set separately.
  • Page 250 3-1. Using the air conditioning system and defogger Adjusting the settings ■ Adjusting the temperature setting Press “” to increase the temperature and “” to decrease the tem- perature on The air conditioning system switches between individual and simul- taneous modes each time is pressed.
  • Page 251 3-1. Using the air conditioning system and defogger ■ Changing the air outlets Press For driver’s seat For front passenger’s seat The air outlets switch each time the button is pressed. Different air outlets for the driver’s and front passenger’s seats can be chosen.
  • Page 252 3-1. Using the air conditioning system and defogger Air flows to the feet. : Depending on the rear air con- ditioning setting. Air flows to the feet and the windshield defogger operates. ITY31C014 ■ Switching between outside air and recirculated air modes Vehicles with windshield wiper de-icer Press The mode switches between outside air mode (indicator off) and...
  • Page 253 3-1. Using the air conditioning system and defogger Changing the rear seat settings from the front seat ■ Adjusting the temperature setting STEP Press STEP Press “” to increase the temperature and “” to decrease the temperature on (for left-hand rear seat) and (for right-hand rear seat).
  • Page 254 3-1. Using the air conditioning system and defogger ■ Changing the air outlets STEP Press STEP Press The air outlets switch each time the button is pressed. (P. 251) Defogging the windshield Press The air conditioning system con- trol operates automatically. Recirculated air mode will auto- matically switch to outside air mode.
  • Page 255 3-1. Using the air conditioning system and defogger Adjusting the position and opening and closing the air outlets Front center outlets Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. ITY31C030 Front side outlets Direct air flow to the left or...
  • Page 256 3-1. Using the air conditioning system and defogger ■ Using the automatic mode Fan speed is adjusted automatically in accordance with the temperature set- ting and ambient conditions. As a result, the following may occur. ● Immediately after is pressed, the fan may stop for a while until warm or cool air is ready to flow.
  • Page 257 • The start timing of the blower may be delayed for a short period of time immediately after the air conditioning system is started in automatic mode. ■ Customization that can be configured at Toyota dealer Settings (e.g. A/C Auto switch operation) can be changed. (Customizable features P. 573) CAUTION ■...
  • Page 258: Rear Air Conditioning System

    3-1. Using the air conditioning system and defogger Rear air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. Fan speed display Airflow display Left side temperature setting display Right side temperature setting display Right side temperature control Left side temperature control Changes the air...
  • Page 259 3-1. Using the air conditioning system and defogger Adjusting the settings ■ Adjusting the temperature setting Press “” to increase the temperature and “” to decrease the tem- perature on The temperature for the right-hand and left-hand rear seats can be set separately.
  • Page 260 3-1. Using the air conditioning system and defogger Air flows to the upper body. ITY31C020 Air flows to the upper body and feet. ITY31C021 Air flows to the feet. ITY31C022 L/C200_U (OM60G31U)
  • Page 261 3-1. Using the air conditioning system and defogger Adjusting the position and opening and closing the air outlets Rear center outlets Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. Roof side outlets Direct air flow to the left or right, up or down.
  • Page 262: Rear Window And Outside Rear View Mirror Defoggers

    3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers These features are used to defog the rear window, and to remove raindrops, dew and frost from the outside rear view mirrors. With navigation system On/off The operation time changes according to the ambient tem-...
  • Page 263: Windshield Wiper De-Icer

    3-1. Using the air conditioning system and defogger  Windshield wiper de-icer This feature is used to prevent ice from building up on the wind- shield and wiper blades. With navigation system On/off The windshield wiper de-icer will automatically turn off after approximately minutes.
  • Page 264: 3-2. Using The Audio System

    3-2. Using the audio system Audio system type With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner’s Manual”. Without navigation system CD player with changer and AM/FM radio. ● Type A L/C200_U (OM60G31U)
  • Page 265 3-2. Using the audio system ● Type B Title Page Using the radio P. 267 Using the CD player P. 276 Playing back MP3 and WMA discs P. 284 Operating an iPod P. 291 Operating a USB memory P. 298 Optimal use of the audio system P.
  • Page 266 3-2. Using the audio system ■ Using cellular phones Interference may be heard through the audio system’s speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating. CAUTION ■ For vehicles sold in the U.S.A. ●...
  • Page 267: Using The Radio

    3-2. Using the audio system Using the radio Type A Station selector Traffic information Seeking the frequency Adjusting the frequency Scanning for receivable stations AM·FM/SAT mode buttons Changing the program type Power Volume L/C200_U (OM60G31U)
  • Page 268 3-2. Using the audio system Type B Station selector Traffic information Seeking the frequency Adjusting the frequency Scanning for receivable stations AM·FM mode buttons Changing the program type Power Volume L/C200_U (OM60G31U)
  • Page 269 3-2. Using the audio system ® Setting station presets (excluding XM Satellite Radio) STEP Search for desired stations by turning or pressing “” or “” on STEP Press and hold the button (from ) the sta- tion is to be set to, and you hear a beep. ®...
  • Page 270 3-2. Using the audio system ® Satellite Radio (type A) ■ ® Receiving XM Satellite Radio STEP Press The display changes as follows each time the button is pressed. “SAT1”  “SAT2”  “SAT3” STEP Turn to select a desired channel from all the categories or press “”...
  • Page 271 3-2. Using the audio system RDS (Radio Data System) This feature allows your radio to receive station identification informa- tion and program information (classical, jazz, etc.) from radio stations which broadcast this information. ■ Receiving RDS broadcasts STEP Press “” or “” on the during FM reception.
  • Page 272 3-2. Using the audio system ■ Displaying radio text messages Press If MSG is shown on the display, a text message will be displayed. If the text continues past the end of the display, is displayed. Press and hold until you hear a beep. ■...
  • Page 273 3-2. Using the audio system ■ ® Receiving XM Satellite Radio ® An XM Satellite Radio is a tuner designed exclusively to receive broadcasts provided under a separate subscription. Availability is limited to the 48 con- tiguous states and some Canadian provinces. ●...
  • Page 274 XM antenna cable is attached securely. ANTENNA There is a short-circuit in the antenna or the sur- rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to XM Satellite Radio. The radio is being updated with the latest encryp- ®...
  • Page 275 3-2. Using the audio system There is no song/program title or artist name/fea- ----- ture associated with the channel at that time. No action needed. The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to CH UNAVL the previous channel or “CH001”.
  • Page 276: Using The Cd Player

    3-2. Using the audio system Using the CD player Display text message Playback/pause Repeat play CD slot CD insert CD eject Random playback Playback Search playback Selecting a track, fast forwarding CD selection or reversing Power Volume Loading a CDs ■...
  • Page 277 3-2. Using the audio system ■ Loading multiple CDs STEP Press and hold until you hear a beep. “WAIT” appears on the display. STEP Insert a CD when the indicator on the slot turns from amber to green. The display changes from “WAIT” to “LOAD”. The indicator on the slot turns to amber when the CD is inserted.
  • Page 278 3-2. Using the audio system Selecting a CD ■ To select a CD to play Press “” or “” on until the desired CD number appears on the display. ■ To scan loaded CDs STEP Press and hold until you hear a beep. The first 10 seconds of the first track on each CD will be played.
  • Page 279 3-2. Using the audio system Random playback ■ Current CD Touch (RAND). Tracks are played in random order until the button is pressed once again. ■ All CDs Press and hold (RAND) until you hear a beep. Tracks on all loaded CDs are played in random order until the button is pressed once again.
  • Page 280 3-2. Using the audio system ■ Display Up to 12 characters can be displayed at a time. If there are 13 characters or more, pressing and holding for 1 sec- ond or more will display the remaining characters. A maximum of 24 characters can be displayed. is pressed for 1 second or more again or has not been pressed for 6 seconds or more, the display will return to the first 12 characters.
  • Page 281 3-2. Using the audio system ■ Discs that can be used Discs with the marks shown below can be used. Playback may not be possible depending on recording format or disc fea- tures, or due to scratches, dirt or deterioration. CDs with copy-protect features may not play correctly.
  • Page 282 3-2. Using the audio system NOTICE ■ CDs and adapters that cannot be used Do not use the following types of CDs, 3 in. (8 cm) CD adapters or Dual Disc. Doing so may damage the player and/or the CD insert/eject function. ●...
  • Page 283 3-2. Using the audio system NOTICE ■ Player precautions Failure to follow the precautions below may result in damage to the CDs or the player itself. ● Do not insert anything other than CDs into the CD slot. ● Do not apply oil to the player. ●...
  • Page 284: Playing Back Mp3 And Wma Discs

    3-2. Using the audio system Playing back MP3 and WMA discs Display text message Folder selection Repeat play CD slot CD eject CD insert Playback/pause Random playback Playback File selection Selecting a file, Search playback CD selection fast forwarding or reversing Power Volume Loading and ejecting MP3 and WMA discs...
  • Page 285 3-2. Using the audio system Selecting and scanning a folder ■ Selecting folders one at a time Press () or () to select the desired folder. To return to the first folder, press and hold () until you hear a beep.
  • Page 286 3-2. Using the audio system Random playback ■ To play files from a particular folder in random order Press (RAND). ■ To play all of the files on a disc in random order Press and hold (RAND) until you hear a beep. Repeating a file or a folder ■...
  • Page 287 3-2. Using the audio system ■ Display P. 280 ■ Canceling random, repeat and scan playback Press (RAND), (RPT) or again. ■ Error messages “ERROR”: This indicates a trouble either in the CD or inside the player. The CD may be dirty, damaged or inserted up-side down. “NO MUSIC”: This indicates that the MP3/WMA file is not included in the ■...
  • Page 288 3-2. Using the audio system ■ Lens cleaners Do not use lens cleaners. Doing so may damage the CD player. ■ MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression.
  • Page 289 3-2. Using the audio system ● Compatible media Media that can be used for MP3 and WMA playback are CD-Rs and CD- RWs. Playback in some instances may not be possible, depending on the status of the CD-R or CD-RW. Playback may not be possible or the audio may jump if the disc is scratched or marked with fingerprints.
  • Page 290 3-2. Using the audio system ● MP3 and WMA playback When a disc containing MP3 or WMA files is inserted, all files on the disc are first checked. Once the file check is finished, the first MP3 or WMA file is played.
  • Page 291: Operating An Ipod

    3-2. Using the audio system Operating an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. ■ Connecting an iPod Open the cover and connect STEP an iPod using an iPod cable. Turn on the power of the iPod if it is not turned on.
  • Page 292 3-2. Using the audio system Selecting a play mode STEP Press to select iPod menu mode. STEP Turning changes the play mode in the following order: “PLAYLISTS”“ARTISTS”“ALBUMS”“SONGS” “PODCASTS”“GENRES”“COMPOSERS” “AUDIOBOOKS” STEP Press to select the desired play mode. L/C200_U (OM60G31U)
  • Page 293 3-2. Using the audio system ■ Play mode list First Second Third Fourth Play mode selection selection selection selection Playlists Songs “PLAYLISTS” select select Albums Songs “ARTISTS” Artists select select select Albums Songs “ALBUMS” select select Songs “SONGS” select Albums Songs Albums “PODCASTS”...
  • Page 294 3-2. Using the audio system Selecting songs Turn or press “” or “” on to select the desired song. Playing and pausing songs To play or pause a song, press Fast-forwarding and rewinding songs  To fast-forward or rewind, press and hold “ ”...
  • Page 295 3-2. Using the audio system Switching the display Press Each time the button is pressed, the display changes in the following order: Elapsed time  Album title  Track title  Artist name Adjusting sound quality and volume balance STEP Press to enter iPod menu mode.
  • Page 296 3-2. Using the audio system ■ Display P. 280 ■ Error messages “ERROR”:This indicates a problem in the iPod or its connection. “NO MUSIC”:This indicates that there is no music data in the iPod. “EMPTY”: This indicates that an empty playlist is selected. “UPDATE”: This indicates that the version of the iPod is not compatible.
  • Page 297 3-2. Using the audio system CAUTION ■ While driving Do not connect iPod or operate the controls. NOTICE ■ To prevent damage to iPod ● Do not leave iPod in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the player. ●...
  • Page 298: Operating A Usb Memory

    3-2. Using the audio system Operating a USB memory Connecting a USB memory enables you to enjoy music from the vehicle speakers. ■ Connecting a USB memory Open the cover and connect a STEP USB memory. Turn on the power of the USB memory if it is not turned on.
  • Page 299 3-2. Using the audio system Selecting and scanning a folder ■ Selecting folders one at a time Press () or () to select the desired folder. ■ Returning to the first folder Press and hold () until you hear a beep. ■...
  • Page 300 3-2. Using the audio system Fast-forwarding and rewinding files  To fast-forward or rewind, press and hold “ ” or “” on until you hear a beep. Random playback ■ Playing files from a folder in random order Press (RAND). To cancel, press (RAND) again.
  • Page 301 3-2. Using the audio system Switching the display Press Each time the button is pressed, the display changes in the following order: Elapsed time  Folder name  File name  Album title  Track title  Artist name ■ When using the USB port You may be unable to use the instrument panel power outlet if a device is connected to the USB port at the same time.
  • Page 302 3-2. Using the audio system ■ USB memory ● Compatible devices USB memory that can be used for MP3 and WMA playback ● Compatible device formats The following device formats can be used: • USB communication formats: USB2.0 FS (12mbps) •...
  • Page 303 3-2. Using the audio system ● MP3 file compatibility • Compatible standards MP3 (MPEG1 AUDIO LAYERII, III, MPEG2 AUDIO LAYERII, III, MPEG2.5) • Compatible sampling frequencies MPEG1 AUDIO LAYERII, III: 32, 44.1, 48 (kHz) MPEG2 AUDIO LAYERII, III: 16, 22.05, 24 (kHz) MPEG2.5: 8, 11.025, 12 (kHz) •...
  • Page 304 3-2. Using the audio system ● MP3 and WMA playback • When a device containing MP3 or WMA files is connected, all files in the USB memory device are checked. Once the file check is finished, the first MP3 or WMA file is played. To make the file check finish more quickly, we recommend that you do not include any files other than MP3 or WMA files or create any unnecessary folders.
  • Page 305 3-2. Using the audio system NOTICE ■ To prevent damage to USB memory ● Do not leave USB memory in the vehicle. The temperature inside the vehi- cle may become high, resulting in damage to the player. ● Do not push down on or apply unnecessary pressure to the USB memory while it is connected as this may damage the USB memory or its terminal.
  • Page 306: Optimal Use Of The Audio System

    3-2. Using the audio system Optimal use of the audio system Displays the current mode Changes the following set- tings • Sound quality and vol- ume balance The sound quality and bal- ance setting changed to produce the best sound. •...
  • Page 307 3-2. Using the audio system ■ Adjusting sound quality Turning adjusts the level. Sound quality Mode Turn to the Turn to the Level mode displayed left right Low-pitched -5 to 5 tones Mid-pitched -5 to 5 High tones High pitched -5 to 5 tones Front/rear...
  • Page 308: Using The Aux Port

    3-2. Using the audio system Using the AUX port This port can be used to connect a portable audio device and listen to it using the vehicle’s speakers. Open the cover and connect STEP the portable audio device. STEP Press ■...
  • Page 309: Using The Steering Switches

    3-2. Using the audio system Using the steering switches Some audio features can be controlled using the switches on the steering wheel. Volume Radio mode: Selects a radio station CD mode: Selects track, file (MP3 MODE and WMA) and disc ITY32C014 ®...
  • Page 310 3-2. Using the audio system Changing the audio source Press when the audio system is turned on. The audio source changes as follows each time the button is pressed. If a mode cannot be used, it will be skipped. Type A: FM1 ...
  • Page 311 3-2. Using the audio system Selecting a track/file or song ® STEP Press to select CD, Bluetooth audio, iPod or USB memory mode. STEP Press “” or “” on to select the desired track/file or song. Selecting an album ® STEP Press to select Bluetooth...
  • Page 312 3-2. Using the audio system ■ Canceling automatic selection of a radio station Press again. CAUTION ■ To reduce the risk of an accident Exercise care when operating the audio switches on the steering wheel. L/C200_U (OM60G31U)
  • Page 313: Using The Bluetooth Audio System

    ® 3-3. Using the Bluetooth audio system ® Bluetooth audio system ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehicle speakers via wireless communication. ® This audio system supports Bluetooth , a wireless data system capable of playing portable audio music without cables.
  • Page 314 ® 3-3. Using the Bluetooth audio system ■ When transferring ownership of the vehicle Be sure to initialize the system to prevent personal data from being improp- erly accessed. (P. 361) ■ ® About Bluetooth Bluetooth is a registered trademark of Bluetooth SIG.
  • Page 315 ® 3-3. Using the Bluetooth audio system CAUTION ■ FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radio Frequency Radiation Exposure. This equipment complies with FCC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65.
  • Page 316: Using The Bluetooth Audio System

    ® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system ■ Audio unit Display A message, name, number, etc. is displayed. Lower-case characters and special characters cannot be displayed. Displays information that is too long to be displayed at one time on the display (press and hold) Selects items such as menu...
  • Page 317 ® 3-3. Using the Bluetooth audio system Operating the system using voice commands By following voice guidance instructions output from the speaker, ® voice commands enable to the operation of the Bluetooth audio sys- tem without the need to check the display or operate ■...
  • Page 318 ® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system for the first time ® Before using the Bluetooth audio system, it is necessary to register ® a Bluetooth enabled portable player in the system. Follow the proce- dure below to register (pair) a portable player: STEP Press...
  • Page 319 ® 3-3. Using the Bluetooth audio system STEP Select “Confirm” using a voice command or A passkey is displayed and heard, and a voice guidance instruction for inputting the passkey into the portable player is heard. STEP Input the passkey into the portable player. Refer to the manual that comes with the portable player for the oper- ation of the portable player.
  • Page 320 ® 3-3. Using the Bluetooth audio system ® Menu list of the Bluetooth audio system ■ Normal operation Second First menu Third menu Operation detail menu “Pair Audio” Registering a portable player Selecting a portable player to “Connect” be used Changing the registered “Change Name”...
  • Page 321 ® 3-3. Using the Bluetooth audio system ■ When using a voice command For numbers, say a combination of single digits from zero to nine. Say the command correctly and clearly. ■ Situations that the system may not recognize your voice ●...
  • Page 322: Operating A Bluetooth

    ® 3-3. Using the Bluetooth audio system ® Operating a Bluetooth enabled portable player Repeat play Random playback Playback/pause Text button Selecting an album Search playback Playback Selecting a track BT•A menu knob Power Volume Selecting an album To select the desired album, press () or ().
  • Page 323 ® 3-3. Using the Bluetooth audio system Playing and pausing tracks To play or pause a track, press Fast-forwarding and rewinding tracks  To fast-forward or rewind, press and hold “ ” or “” on until you hear a beep. Random playback Press (RAND).
  • Page 324 ® 3-3. Using the Bluetooth audio system Switching the display Press Each time the button is pressed, the display changes in the following order: Elapsed time  Album title  Track title  Artist name Using the steering wheel audio switches P.
  • Page 325: Setting Up A Bluetooth Enabled Portable Player

    ® 3-3. Using the Bluetooth audio system ® Setting up a Bluetooth enabled portable player ® Registering a portable player in the Bluetooth audio system allows the system to function. The following functions can be used for reg- istered portable players: ■...
  • Page 326 ® 3-3. Using the Bluetooth audio system Pattern B STEP Press to select “BT•A MENU”. STEP Press the talk switch or select “BT•A Setup” using STEP Select one of the following functions using a voice com- mand or ● Registering a portable player “Pair Audio Player (Pair Audio)”...
  • Page 327 ® 3-3. Using the Bluetooth audio system Registering a portable player Select “Pair Audio Player (Pair Audio)” using a voice command or , and perform the procedure for registering a portable player. (P. 318) Selecting a portable player to be used STEP Select “Connect Audio Player (Connect)”...
  • Page 328 ® 3-3. Using the Bluetooth audio system Pattern A STEP Press the talk switch and say “From Car” or “From Audio player”, and select “Confirm” by using a voice command or Pattern B STEP Select “From Car” or “From Audio”, using If “From Car”...
  • Page 329 ® 3-3. Using the Bluetooth audio system Pattern B STEP Select the desired portable player name to be changed using STEP Press the talk switch or select “Record Name” using and say the new name. STEP Select “Confirm” using a voice command or Listing the registered portable players Select “List Audio Players (List Audios)”...
  • Page 330 ® 3-3. Using the Bluetooth audio system Changing the passkey STEP Select “Set Passkey” using a voice command or Pattern A STEP Press the talk switch, say a 4 to 8-digit number, and select “Confirm” using a voice command or Pattern B STEP Select a 4 to 8-digit number using...
  • Page 331 ® 3-3. Using the Bluetooth audio system Pattern A STEP Select the portable player to be deleted by either of the follow- ing methods and select “Confirm” using a voice command or a. Press the talk switch and say the name of the desired por- table player.
  • Page 332: Bluetooth ® Audio System Setup

    ® 3-3. Using the Bluetooth audio system ® Bluetooth audio system setup ■ System setup items and operation procedures Pattern A To enter the menu for each function, follow the steps below using a voice command or (P. 356) Pattern B STEP Press to select “BT•A MENU”.
  • Page 333: Using The Hands-Free System (For Cellular Phone)

    3-4. Using the hands-free system (for cellular phone) Hands-free system (for cellular phone) The hands-free system is a function that allows you to use your cel- lular phone without touching it. ® This system supports Bluetooth , which allows you to make or receive calls without using cables to connect a cellular phone and the system, and without operating the cellular phone.
  • Page 334 3-4. Using the hands-free system (for cellular phone) ■ Conditions under which the system will not operate ● ® If using a mobile phone that does not support Bluetooth ● If the mobile phone is switched off ● If you are outside service range ●...
  • Page 335 3-4. Using the hands-free system (for cellular phone) ■ ® About Bluetooth Bluetooth is a registered trademark of Bluetooth SIG. Inc. ■ Compatible models Compatible with HFP (Hands Free Profile) Ver. 1.5 and OPP (Object Push Profile) Ver. 1.1. ® If your cellular phone does not support HFP, you cannot enter the Bluetooth phone.
  • Page 336 3-4. Using the hands-free system (for cellular phone) CAUTION ■ FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radio Frequency Radiation Exposure. This equipment complies with FCC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65.
  • Page 337: Using The Hands-Free System

    3-4. Using the hands-free system (for cellular phone) Using the hands-free system ■ Audio unit Display A message, name, phone number, etc. is displayed. Lower-case characters and special characters cannot be displayed. Displays information that is too long to be displayed at one time on the display (press and hold) Selects speed dials...
  • Page 338: Talk Switch *

    3-4. Using the hands-free system (for cellular phone) ■ Steering wheel Volume The voice guidance volume cannot be adjusted by using this button. Off-hook switch Turns the hands-free sys- tem on/start a call On-hook switch Turns the hands-free sys- tem off/ends a call/refuse a call Talk switch Turns the voice command...
  • Page 339 3-4. Using the hands-free system (for cellular phone) Operating the system by using a voice command By following voice guidance instructions output from the speaker, voice commands enable to the operation of the hands-free system without need to check the display or operate ■...
  • Page 340 3-4. Using the hands-free system (for cellular phone) STEP Press the off-hook switch or the talk switch. The introductory guidance and phone name registration instructions are heard. STEP Select “Pair Phone” using a voice command or STEP Register a phone name by either of the following methods. a.
  • Page 341 3-4. Using the hands-free system (for cellular phone) Menu list of the hands-free system ■ Normal operation Second First menu Third menu Operation detail menu Dialing a number stored in   Callback the incoming call history memory Dialing a number stored in ...
  • Page 342 3-4. Using the hands-free system (for cellular phone) Second First menu Third menu Operation detail menu Set PIN Setting a PIN code Security Phbk Lock Locking the phone book Phbk Unlock Unlocking the phone book Registering a cellular phone Pair Phone to be used Selecting a cellular phone to Connect...
  • Page 343 3-4. Using the hands-free system (for cellular phone) ■ Using a short cut key First menu Second menu Operation detail Dialing a number registered  Dial “XXX (name)” in the phone book Phone book add  Adding a new number entry Phone book change Changing a name of a phone...
  • Page 344 3-4. Using the hands-free system (for cellular phone) ■ Automatic volume adjustment When vehicle speed reaches 50 mph (80 km/h) or more, the volume auto- matically increases. The volume returns to the previous volume setting when vehicle speed drops to 43 mph (70 km/h) or less. ■...
  • Page 345: Making A Phone Call

    3-4. Using the hands-free system (for cellular phone) Making a phone call ■ Making a phone call ● Dialing by inputting a number “Dial by number” ● Dialing by inputting a name “Dial by name” ● Speed dialing ● Dialing a number stored in the outgoing history memory “Redial”...
  • Page 346 3-4. Using the hands-free system (for cellular phone) Dialing by inputting a number STEP Press the talk switch and say “Dial by number”. STEP Press the talk switch and say the phone number. STEP Dial by one of the following methods: a.
  • Page 347 3-4. Using the hands-free system (for cellular phone) Speed dialing STEP Press the off-hook switch. STEP Press the preset button in which the desired number is regis- tered. STEP Press the off-hook switch. When receiving a phone call ■ Answering the phone Press the off-hook switch.
  • Page 348 3-4. Using the hands-free system (for cellular phone) Call waiting When a call is interrupted by an incoming call from a third party, the following options will become available: ● Answer the incoming call: Press the off-hook switch. (Press the off- hook switch again as necessary to switch back and forth between calls.) ●...
  • Page 349 3-4. Using the hands-free system (for cellular phone) STEP The following operations can be performed: Dialing: Press the off-hook switch or select “Dial” using a voice command or Storing the number in the phone book: Select “Store” and then “Confirm” using a voice command or Deleting: Select “Delete”...
  • Page 350: Setting A Cellular Phone

    3-4. Using the hands-free system (for cellular phone) Setting a cellular phone Registering a cellular phone in the hands-free system allows the system to function. The following functions can be used for regis- tered cellular phones: ■ Functions and operation procedures To enter the menu for each function, follow the steps below.
  • Page 351 3-4. Using the hands-free system (for cellular phone) Registering a cellular phone Select “Pair Phone” using a voice command or , and perform the procedure for registering a cellular phone. (P. 339) Selecting a cellular phone to be used STEP Select “Connect Phone (Connect)”...
  • Page 352 3-4. Using the hands-free system (for cellular phone) Changing the registered name of a cellular phone STEP Select “Change Name” using a voice command or Pattern A STEP Select a name of cellular phone to be changed by either of the following methods, and select “Confirm”...
  • Page 353 3-4. Using the hands-free system (for cellular phone) Listing the registered cellular phones Selecting “List Phones” using a voice command or . The list of registered cellular phones to be read aloud. When listing is complete, the system returns to “Phone Setup”. Pressing the talk switch while a name of cellular phone is being read selects the cellular phone, and the following functions will become available:...
  • Page 354 3-4. Using the hands-free system (for cellular phone) Changing the passkey STEP Select “Set Passkey” using a voice command or Pattern A STEP Press the talk switch, say a 4 to 8-digit number, and select “Confirm” using a voice command or Pattern B STEP Select a 4 to 8-digit number using...
  • Page 355 3-4. Using the hands-free system (for cellular phone) Deleting a registered cellular phone STEP Select “Delete Phone” using a voice command or Pattern A STEP Select the cellular phone to be deleted by either of the follow- ing methods and select “Confirm” using a voice command or a.
  • Page 356: Security And System Setup

    3-4. Using the hands-free system (for cellular phone) Security and system setup ■ Security setting items and operation procedure To enter the menu for each function, follow the steps below. STEP Press the off-hook switch and select “Setup” using voice command or STEP Select “Security”...
  • Page 357 3-4. Using the hands-free system (for cellular phone) ■ System setup items and operation procedure To enter the menu for each function, follow the steps below. STEP Press the off-hook switch and select “Setup” using STEP Select “System Setup” using STEP Select one of the following items using ●...
  • Page 358 3-4. Using the hands-free system (for cellular phone) Setting or changing the PIN ■ Setting a PIN STEP Select “Set PIN” using a voice command or STEP Enter a PIN using a voice command or When using , input the code 1 digit at a time. ■...
  • Page 359 3-4. Using the hands-free system (for cellular phone) Locking or unlocking the phone book STEP Select “Phonebook Lock (Phbk Lock)” or “Phonebook Unlock (Phbk Unlock)” using a voice command or STEP Input the PIN by either of the following methods and select “Confirm”...
  • Page 360 3-4. Using the hands-free system (for cellular phone) ® Displaying the Bluetooth device address and name STEP Select “Device Name” using ® STEP Turn to display the Bluetooth device address and name. STEP Select “Go Back” using to return to “System Setup”. Initializing the system STEP Select “Initialize”...
  • Page 361 3-4. Using the hands-free system (for cellular phone) ■ Initialization ● The following data in the system can be initialized: • Phone book • Outgoing and incoming call history • Speed dials • Registered cellular phone data • Security code ®...
  • Page 362: Using The Phone Book

    3-4. Using the hands-free system (for cellular phone) Using the phone book To enter the menu for each function, follow the steps below. STEP Press the off-hook switch and select “Phonebook” using voice command or STEP Select one of the following items using voice command or ●...
  • Page 363 3-4. Using the hands-free system (for cellular phone) Adding a new phone number The following methods can be used to add a new phone number: ● Inputting a phone number using a voice command ● Transferring data from the cellular phone ●...
  • Page 364 3-4. Using the hands-free system (for cellular phone) Transferring data from the cellular phone STEP2-1 Select “By Phone” and then “Confirm” using a voice command or STEP2-2 Transfer the data from the cellular phone. Refer to the manual that comes with the cellular phone for the details of transferring data.
  • Page 365 3-4. Using the hands-free system (for cellular phone) Selecting a phone number from outgoing or incoming call history STEP2-1 Select “Call History” using a voice command or STEP2-2 Select “Outgoing” or “Incoming” using a voice com- mand or STEP2-3 Select the data to be registered by either of the fol- lowing methods: a.
  • Page 366 3-4. Using the hands-free system (for cellular phone) STEP Select “Confirm” using a voice command or again. , selecting “Set Speed Dial (Speed Dial)” instead of “Con- STEP firm” registers the newly added phone number as speed dial. Changing the registered name in the phone book STEP Select “Change Name”...
  • Page 367 3-4. Using the hands-free system (for cellular phone) Listing the registered data Select “List names” using a voice command or . The list of the registered data will be read aloud. When listing is complete, the system returns to “Phonebook”. Pressing the talk switch while the desired data is being read aloud selects the data, and the following function will become available.
  • Page 368 3-4. Using the hands-free system (for cellular phone) Pattern A STEP Select the data to be registered as a speed dial by either of the following methods, and select “Confirm” using a voice command or a. Press the talk switch, say desired name. b.
  • Page 369 3-4. Using the hands-free system (for cellular phone) Deleting the registered data STEP Select “Delete Entry” using a voice command or Pattern A STEP Select the data to be deleted by either of the following meth- ods, and select “Confirm” using a voice command or a.
  • Page 370 3-4. Using the hands-free system (for cellular phone) Deleting speed dials STEP Select “Delete Speed Dial (Del Spd Dial)” using a voice com- mand or STEP Press the preset button in which the desired speed dial is reg- istered, and select “Confirm” using a voice command or ■...
  • Page 371: 3-5. Using The Interior Lights

    3-5. Using the interior lights Interior lights list Your Toyota is equipped with an illuminated entry system to assist in entering the vehicle. Owing to the function of the system, the lights shown in the following illustration automatically turn on/off accord-...
  • Page 372: Interior Lights

    3-5. Using the interior lights Interior lights ■ To prevent the battery from being discharged If the interior lights and “ENGINE START STOP” switch light remain on when the door is not fully closed and the interior light switch is in the door position, the lights will go off automatically after 20 minutes.
  • Page 373: Personal Lights

    3-5. Using the interior lights Personal lights Personal lights Front On/off Rear (type A) On/off Rear (type B) On/off ITY33C014 L/C200_U (OM60G31U)
  • Page 374: 3-6. Using The Storage Features

    3-6. Using the storage features List of storage features ITY34C001 Card holders Door pockets Overhead console Auxiliary box Glove box Console box/cool box Bottle holders Cup holders CAUTION ■ Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ●...
  • Page 375: Glove Box

    3-6. Using the storage features Glove box Glove box Open (push button) Lock with the mechanical key Unlock with the mechanical ITY34C003 ■ Glove box light The glove box light turns on when the tail lights are on. CAUTION ■ While driving Keep the glove box closed.
  • Page 376: Console Box

    3-6. Using the storage features Console box Console box Your vehicle is equipped with either a lower console box or cool box. For vehicles with the cool box, refer to page 382. Upper console box Press the tab to open. ITY34C005 Lower console box (if equipped) Lift the lever to open.
  • Page 377: Overhead Console

    3-6. Using the storage features Console box and overhead console CAUTION ■ While driving Keep the console box closed. Injuries may result in the event of sudden braking, sudden swerving or an accident. Overhead console Press the button. The overhead console is useful temporarily storing small...
  • Page 378: Cup Holders

    3-6. Using the storage features Cup holders Cup holders Front Press down and release the lid. You can adjust or remove the separator inside. ITY34C011 Rear STEP Pull the armrest down. (P. 395) Press the button. STEP ITY34C015 L/C200_U (OM60G31U)
  • Page 379: Bottle Holders

    3-6. Using the storage features Cup holders and bottle holders CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
  • Page 380 3-6. Using the storage features Bottle holders For second seats ITY34C024 For third seats NOTICE ■ Items that should not be stowed in the bottle holders Put the cap on before stowing a bottle. Do not place open bottles in the bot- tle holders, or glasses and paper cups containing liquid.
  • Page 381: Card Holders

    3-6. Using the storage features Card holders and auxiliary box Card holders Sun visor Instrument panel Auxiliary box ITY34C023 L/C200_U (OM60G31U)
  • Page 382: 3-7. Other Interior Features

    3-7. Other interior features  Cool box While the engine is running, the cool box, which is cooled by the air conditioning, can be used. Lift the lever to open. STEP ITY34C029 On/off STEP COOL When on, the indicator light comes on.
  • Page 383 3-7. Other interior features CAUTION ■ While driving Keep the cool box closed. Injuries may result in the event of sudden braking, sudden swerving or an accident. NOTICE ■ To prevent battery discharge Do not leave the cool box on longer than necessary when the engine is stopped.
  • Page 384: Sun Visors

    3-7. Other interior features Sun visors Main sun visor Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Side extender: Place in side position, then slide backwards. Sub-sun visor Flip down with the main sun visor in position L/C200_U (OM60G31U)
  • Page 385: Vanity Mirror

    3-7. Other interior features Vanity mirror Slide the cover. The light turns on when the cover is opened. L/C200_U (OM60G31U)
  • Page 386: Clock

    3-7. Other interior features Clock With navigation system Refer to “Navigation System Owner’s Manual”. Without navigation system Adjust hours. Adjust minutes. Round the nearest hour. :e.g. 1:00 to 1:291:00 1:30 to 1:592:00 ITY35C003 ■ The clock is displayed when The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode.
  • Page 387: Outside Temperature Display

    The “ENGINE START STOP” switch is in IGNITION ON mode. ■ When --- is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer. ■ Display In the following situations, the correct outside temperature may not be dis- played, or the display may take longer than normal to change.
  • Page 388: Ashtrays

    3-7. Other interior features Ashtrays Front Press in and release the lid to open. Press down on the lock spring plate to remove. Push the lid to close. Rear Pull the ashtray lid to open. Pull the ashtray upwards to remove.
  • Page 389 3-7. Other interior features CAUTION ■ When not in use Keep the ashtray closed. Injuries may result in the event of sudden braking, sudden swerving or an accident. ■ To prevent fire ● Fully extinguish matches and cigarettes before putting them in the ashtray, then make sure the ashtray is fully closed.
  • Page 390: Cigarette Lighter

    3-7. Other interior features Cigarette lighter Push the cigarette lighter in. The cigarette lighter will pop up when ready for use. ■ The cigarette lighter can be used when The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode.
  • Page 391: Power Outlets

    3-7. Other interior features Power outlets The power outlets can be used for a following component. Instrument panel (12V): Accessories that run on less than 10A. Luggage compartment (115V AC): Accessories that use less than 100W. Instrument panel (12V) Luggage compartment (115V AC) L/C200_U (OM60G31U)
  • Page 392 3-7. Other interior features ■ The power outlets can be used when 12V: The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. 115V: The “ENGINE START STOP” switch is in IGNITION ON mode. ■ When using the instrument panel power outlet You may be unable to use the USB port if a device is connected to the instru- ment panel power outlet at the same time.
  • Page 393: Seat Heaters

    3-7. Other interior features Seat heaters For front seats For driver’s seat Pops the switch out. For front passenger’s seat Pops the switch out. The indicator light comes on. Adjusts the seat tempera- ture The further you turn the knob clockwise, the warmer the seat becomes.
  • Page 394 3-7. Other interior features ■ The seat heaters can be used when The “ENGINE START STOP” switch is in IGNITION ON mode. CAUTION ■ Burns ● Use caution when seating the following persons in a seat with the seat heater on to avoid the possibility of burns: •...
  • Page 395: Armrest

    3-7. Other interior features Armrest Pull the armrest down for use. ITY35C052 NOTICE ■ To prevent damage to the armrest Do not place too much strain on the armrest. L/C200_U (OM60G31U)
  • Page 396: Floor Mats

    When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
  • Page 397: Luggage Compartment Features

    3-7. Other interior features Luggage compartment features ■ Cargo hooks Cargo hooks are provided for securing loose items. ITY35C022 ■ Cargo net hooks To hang the cargo net, use the cargo net hooks and rear tie- down hooks. The cargo net itself is not included as an original equip- ment.
  • Page 398 3-7. Other interior features ■ Warning reflector holder Hold the warning reflector with a band. The warning reflector itself is not included as an original equipment. ITY35C025 ■ First-aid kit holder Hold the first-aid kit with a band. The first-aid kit itself is not included as an original equip- ment.
  • Page 399: Garage Door Opener

    3-7. Other interior features Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, secu- rity systems, and other devices.  The garage door opener (HomeLink Universal Transceiver) is manufac- ...
  • Page 400 3-7. Other interior features  ■ Programming HomeLink Point the remote control trans- STEP mitter for the device 1 to 3 in. (25  to 75 mm) from the HomeLink buttons.  Keep the HomeLink indicator light in view while programming. Press and hold one of the STEP ...
  • Page 401 3-7. Other interior features  Test the HomeLink operation STEP by pressing the newly pro- grammed button.  If a HomeLink button has been programmed for a garage door, check to see if the garage door opens and closes. If the garage door does not operate, see if your remote control transmitter is of the rolling code type.
  • Page 402 3-7. Other interior features ■ Programming a rolling code system If your device is rolling code equipped, follow the steps under the  heading “Programming HomeLink ” before proceeding with the steps listed below. STEP Locate the learn button on the ceiling mounted garage door opener motor.
  • Page 403  the remaining HomeLink buttons. ■ Programming other devices To program other devices such as home security systems, home door locks or lighting, contact your authorized Toyota dealer for assistance. ■ Reprogramming a button  The individual HomeLink buttons cannot be erased but can be reprogrammed.
  • Page 404 3-7. Other interior features  Operating HomeLink   Press the appropriate HomeLink button. The HomeLink indicator light should come on.  The HomeLink compatible transceiver in your vehicle continues to send a signal for up to 20 seconds as long as the button is pressed. ...
  • Page 405 3-7. Other interior features ■ Before programming ● Install a new battery in the remote control transmitter. ● The battery side of the remote control transmitter must be pointed away  from the HomeLink button. ■ Certification for the garage door opener FCC ID: CB2070NHL4 This device complies with FCC rules part 15 and Industry Canada RSS-210.
  • Page 406: Safety Connect

    Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Toyota.com. All use of the Safety Con- nect service is subject to such then-applicable Terms and Condi- tions.
  • Page 407 After you have signed the Telematics Subscription Service Agreement and are enrolled, you can begin receiving services. A variety of subscription terms is available for purchase. Contact your Toyota dealer, call 1-800-331-4331, or push the “SOS” but- ton in your vehicle for further subscription details. L/C200_U (OM60G31U)
  • Page 408 Safety Connect. ● Safety Connect is available beginning Fall 2009 on select Toyota models. Contact with the Safety Connect response center is dependent upon the telematics device being in operative condition, cellular connection avail- ability, and GPS satellite signal reception, which can limit the ability to reach the response center or receive emergency service support.
  • Page 409 ● Green indicator light flashing = Safety Connect call in process ● Red indicator light (except at vehicle start-up) = System malfunc- tion (contact your Toyota dealer) ● No indicator light (off) = Safety Connect service not active Safety Connect services ■...
  • Page 410 In addition to assisting law enforcement with recovery of a stolen vehicle, Safety-Connect-equipped vehicle location data may, under certain circumstances, be shared with third parties to locate your vehicle. Further information is available at Toyota.com. ■ Emergency Assistance Button (“SOS”) In the event of an emergency on the road, push the “SOS”...
  • Page 411 3-7. Other interior features Safety information for Safety Connect Important! Read this information before using Safety Connect. ■ Exposure to radio frequency signals The Safety Connect system installed in your vehicle is a low-power radio transmitter and receiver. It receives and also sends out radio frequency (RF) signals.
  • Page 412 3-7. Other interior features ■ License Licensed by QUALCOMM Incorporated under one or more of the following United States Patents and/or their counterparts in other nations: 4,901,307 5,490,165 5,056,109 5,504,773 5,101,501 5,506,865 5,109,390 5,511,073 5,228,054 5,535,239 5,267,261 5,544,196 5,267,262 5,568,483 5,337,338 5,600,754 5,414,796 5,657,420 5,416,797 5,659,569 5,710,784 5,778,338 ■...
  • Page 413: Maintenance And Care

    Maintenance and care 4-1. Maintenance and care Cleaning and protecting the vehicle exterior..414 Cleaning and protecting the vehicle interior..417 4-2. Maintenance Maintenance requirements ....420 General maintenance..422 Emission inspection and maintenance (I/M) programs ....425 4-3. Do-it-yourself maintenance Do-it-yourself service precautions ....
  • Page 414: Cleaning And Protecting The Vehicle Exterior

    4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
  • Page 415 4-1. Maintenance and care ■ Aluminum wheels ● Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or abrasive cleaners. Do not use strong or harsh chemical cleaners. Use the same mild detergent and wax as used on the paint. ●...
  • Page 416 4-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
  • Page 417: Cleaning And Protecting The Vehicle Interior

    4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: ■ Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
  • Page 418 4-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
  • Page 419 4-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces. • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, or bleach.
  • Page 420: Maintenance Maintenance Requirements

    It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
  • Page 421 4-2. Maintenance ■ Allow inspection and repairs to be performed by a Toyota dealer ● Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.
  • Page 422: General Maintenance

    “Owner’s Warranty Informa- tion Booklet” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items...
  • Page 423 4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be hold securely Automatic transmission “Park” on an incline with the shift lever in mechanism “P”? • Moves smoothly? •...
  • Page 424 4-2. Maintenance Vehicle exterior Items Check points Doors • Operate smoothly? Engine hood • The lock system works properly? • Is there any leakage after park- Fluid leaks ing? • Inflation pressure is correct? • Tire surfaces not worn or dam- aged? Tire •...
  • Page 425: Emission Inspection And Maintenance (I/M) Programs

    If the malfunction indicator lamp comes on The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. ■...
  • Page 426: Do-It-Yourself Maintenance Do-It-Yourself Service Precautions

    Brake fluid level (P. 438) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid Engine coolant level (P.
  • Page 427 4-3. Do-it-yourself maintenance Items Parts and tools • Automatic transmission fluid ® DEXRON II or III Power steering fluid (P. 440) • Rag or paper towel • Funnel (used only for adding power steering fluid)  Radiator and condenser (P. 437) •...
  • Page 428 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury. ■ When working on the engine compartment ● Keep hands, clothing, and tools away from the moving fan and engine drive belt.
  • Page 429: Hood

    4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. STEP The hood will pop up slightly. Lift the hood catch and lift the STEP hood. CAUTION ■ Pre-driving check Check that the hood is fully closed and locked.
  • Page 430: Engine Compartment

    4-3. Do-it-yourself maintenance Engine compartment Power steering fluid reser- Brake fluid reservoir voir (P. 440) (P. 438) Engine oil level dipstick Fuse box (P. 466) (P. 432) Washer fluid tank Engine coolant reservoir (P. 444) (P. 436) Battery (P. 441) Cooling fans Condenser (P.
  • Page 431 4-3. Do-it-yourself maintenance Engine compartment cover ■ Removing the engine compartment cover ■ Installing the clips Push up center portion Insert Press L/C200_U (OM60G31U)
  • Page 432 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil STEP Park the vehicle on level ground. After turning off the engine, wait more than 5 minutes for the oil to drain back into the bot- tom of the engine.
  • Page 433 4-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. ITY43C011 Make sure to check the oil type and prepare the items needed before adding oil.
  • Page 434 1000 km) ● If you consume more than 1.1 qt. (1.0 L, 0.9 lmp.qt.) every 600 miles (1000 km), contact your Toyota dealer. ■ Resetting the engine oil maintenance data The oil change system should be reset. Perform the following procedures: STEP Switch the display to the trip meter A when the engine is running.
  • Page 435 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. ●...
  • Page 436 If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer pressure test the cap and check for leaks in the cooling system. ■...
  • Page 437 Radiator and condenser Check the radiator and condenser and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION ■...
  • Page 438 4-3. Do-it-yourself maintenance Brake fluid ■ Checking fluid level The brake fluid level should be between the “MAX” and “MIN” lines on the tank. ITY43C069 Make sure to check the fluid type and prepare the necessary items. ■ Adding fluid Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items...
  • Page 439 4-3. Do-it-yourself maintenance ■ Brake fluid can absorb moisture from the air Excess moisture in the fluid can cause a dangerous loss of braking effi- ciency. Use only newly opened brake fluid. CAUTION ■ When filling the reservoir Take care because brake fluid can harm your hands or eyes and damage painted surfaces.
  • Page 440 4-3. Do-it-yourself maintenance Power steering fluid ■ Fluid level The fluid level should be within the appropriate range. Full (when hot) Add fluid (when hot) Full (when cold) Add fluid (when cold) ITY43C070 Hot: Vehicle has been driven around 50 mph (80 km/h) for 20 minutes, or slightly longer in frigid temperatures.
  • Page 441 4-3. Do-it-yourself maintenance CAUTION ■ When checking the reservoir Take care, as the reservoir may be hot. NOTICE ■ When adding fluid Avoid overfilling, or the power steering may be damaged. ■ After replacing the reservoir cap Check the steering box case, vane pump and hose connections for leaks or damage.
  • Page 442 Check the battery condition using the indicator color. Good condition Type A Type B Charging is necessary. Green Blue Have the vehicle inspected by your Toyota dealer. Not working properly, have the Dark White battery checked your Toyota dealer. Clear or light yellow ITY43C100 ■...
  • Page 443 4-3. Do-it-yourself maintenance CAUTION ■ Chemicals in the battery A battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near bat- tery: ●...
  • Page 444 4-3. Do-it-yourself maintenance NOTICE ■ When recharging the battery Never recharge the battery while the engine is running. Also, be sure all accessories are turned off. Washer fluid If any washer does not work or the warning message appears on the multi-information display, the washer tank may be empty.
  • Page 445: Tires

    ■ The tire pressure warning system Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (P. 505) L/C200_U (OM60G31U)
  • Page 446 Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (P. 446, 448) Initializing the tire pressure warning system ■...
  • Page 447 4-3. Do-it-yourself maintenance ■ How to initialize the tire pressure warning system STEP Park the vehicle in safe place and turn the “ENGINE START STOP” switch to OFF. While the vehicle is moving, initialization is not performed. STEP Adjust the tire inflation pressure to the specified cold tire infla- tion pressure level.
  • Page 448 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
  • Page 449 4-3. Do-it-yourself maintenance ■ Maximum load of tire Check that the number given by dividing the maximum load by 1.10 of the replacement tire is greater than 1/2 of the Gross Axle Weight Ratings (GAWR) of either the front axle or the rear axle, whichever is greater. For the GAWR, see the Certification Label.
  • Page 450 Initialization can be completed in a few minutes. However, in the follow- ing cases, the settings have not been recorded and the system will not operate properly. If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ●...
  • Page 451 4-3. Do-it-yourself maintenance ■ Tire pressure warning system certification FCC ID: PAXPMV107J FCC ID: HYQ13BCX This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 452 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
  • Page 453 ● When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled cor- rectly.
  • Page 454: Tire Inflation Pressure

    4-3. Do-it-yourself maintenance Tire inflation pressure ■ Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (P. 556) L/C200_U (OM60G31U)
  • Page 455 4-3. Do-it-yourself maintenance ■ Inspection and adjustment procedure Tire valve Tire pressure gauge STEP Remove the tire valve cap. STEP Press the tip of the tire pressure gauge onto the tire valve. STEP Read the pressure using the graduations of the gauge. STEP If the tire inflation pressure is not within the recommended levels, adjust tire pressure.
  • Page 456 Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
  • Page 457 4-3. Do-it-yourself maintenance CAUTION ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. ● Excessive wear ● Uneven wear ●...
  • Page 458: Wheels

    ● Bent wheels that have been straightened ■ Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
  • Page 459 ■ When replacing wheels The wheels of your Toyota are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advanced warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, the tire pressure warning valves and transmitters must be installed.
  • Page 460: Air Conditioning Filter

    4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be cleaned or changed regularly to maintain air conditioning efficiency. ■ Removal method STEP Turn the “ENGINE START STOP” switch IGNITION ON mode and switch to recirculated air mode, then turn the “ENGINE START STOP”...
  • Page 461 2 minutes at 72 psi (500 kPa, 5.0 kgf/cm bar). If it is not available, have the filter cleaned by your Toyota dealer. ■ Replacement method Remove the air conditioning filter and replace it with a new one.
  • Page 462 4-3. Do-it-yourself maintenance ■ Checking interval Inspect, clean and replace the air conditioning filter according to the mainte- nance schedule. In dusty areas or areas with heavy traffic flow, more fre- quent cleaning or early replacement may be required. (For scheduled maintenance information, read the “Scheduled Maintenance Guide”, “Owner’s Manual Supplement”.) ■...
  • Page 463: Electronic Key Battery

    4-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is discharged. ■ You will need the following items: ● Flathead screwdriver (To prevent damage to the key, cover the tip of the screwdriver with rag.) ●...
  • Page 464 ● The operational range is reduced. ■ Use a CR1632 lithium battery ● Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. ● Replace only with the same or equivalent type recommended by a Toyota dealer. ●...
  • Page 465 4-3. Do-it-yourself maintenance CAUTION ■ Removed battery and other parts Keep away from children. These parts are small and if swallowed by a child, they can cause choking. Failure to do so could result in death or serious injury. NOTICE ■...
  • Page 466: Checking And Replacing Fuses

    4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. STEP Turn the “ENGINE START STOP” switch OFF. STEP Open the fuse box cover.
  • Page 467 4-3. Do-it-yourself maintenance Passenger’s side instrument panel Remove the cover. ITY43C033 Remove the lid. ITY43C034 STEP After a system failure, see “Fuse layout and amperage rat- ings” (P. 470) for details about which fuse to check. Remove the fuse with the pull- STEP out tool.
  • Page 468 4-3. Do-it-yourself maintenance STEP Check if the fuse has blown. Type A and B Normal fuse Type A Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. ITY42C012 Type B ITY42C013...
  • Page 469 4-3. Do-it-yourself maintenance Type C and D Normal fuse Type C Blown fuse Contact your Toyota dealer. ITY42C014 Type D ITY42C015 L/C200_U (OM60G31U)
  • Page 470 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment Fuse Ampere Circuit 15 A A/F heater 10 A HORN Horn 25 A EFI MAIN EFI, A/F heater 30 A IG2 MAIN INJ, IGN, MET 50 A RR A/C No circuit 25 A SEAT-A/C LH...
  • Page 471 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Stoplights, high mounted stop- light, brake controller, towing 15 A STOP converter, ABS, VSC, main body ECU, EFI, trailer 30 A TOW BRK Brake controler 50 A RR AUTO A/C Rear air conditioning system 50 A PTC-1 PTC heater...
  • Page 472 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Driving position memory sys- ECU-B2 30 A AMP 2 Audio system 7.5 A Rear seat entertainment 30 A TOWING Towing 25 A DOOR NO.2 Main body ECU 20 A STR LOCK Steering lock system Meter, front turn signal lights, 15 A TURN-HAZ...
  • Page 473 4-3. Do-it-yourself maintenance Fuse Ampere Circuit 15 A HEAD RL Headlight low beam (right) Air injection system, air flow 7.5 A EFI NO.2 meter 7.5 A RR A/C NO.2 No circuit Outside rear view mirror defog- DEF NO.2 gers L/C200_U (OM60G31U)
  • Page 474 4-3. Do-it-yourself maintenance ■ Driver’s side instrument panel Fuse Ampere Circuit 15 A Cigarette lighter BK/UP LP 10 A Back-up lights, trailer Audio system, multi-display assembly, gateway ECU, main 7.5 A body ECU, mirror ECU, rear seat entertainment, smart key system, clock Four-wheel drive system, ash- tray, cigarette lighter, brake...
  • Page 475 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Air conditioning system, heater, overhead module, ABS, VSC, steering sensor, ECU-IG NO.2 10 A yaw rate & G sensor, main body ECU, stoplights, moon roof, clock, EC mirror WINCH No circuit Cool box, condenser fan, cooler compressor, rear win- A/C IG 10 A...
  • Page 476 4-3. Do-it-yourself maintenance Fuse Ampere Circuit RR DOOR RH 20 A Power windows Mirror ECU, outside rear view 15 A mirror defoggers RR DOOR LH 20 A Power windows FR DOOR LH 20 A Power windows FR DOOR RH 20 A Power windows RR FOG 7.5 A...
  • Page 477 4-3. Do-it-yourself maintenance ■ Passenger’s side instrument panel Fuse Ampere Circuit RSF LH 30 A No circuit B/DR CLSR RH 30 A No circuit B/DR CLSR LH 30 A No circuit RSF RH 30 A No circuit DOOR DL 15 A No circuit AHC-B 20 A...
  • Page 478 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. ● Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix. This can cause extensive damage or even fire.
  • Page 479: Light Bulbs

    You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
  • Page 480 4-3. Do-it-yourself maintenance ■ Rear bulb locations Rear turn signal Back-up light light License plate lights ITY43C075 Replacing light bulbs ■ Headlight low beam Turn the bulb base counterclock- STEP wise. ITY43C038 L/C200_U (OM60G31U)
  • Page 481 4-3. Do-it-yourself maintenance Unplug connector while STEP depressing the lock release. ITY43C039 ■ Headlight high beam and daytime running light Turn the bulb base counterclock- STEP wise. ITY43C040 Unplug connector while STEP depressing the lock release. ITY43C041 L/C200_U (OM60G31U)
  • Page 482 4-3. Do-it-yourself maintenance ■ Front fog light Remove the fender liner bolts, STEP loose the fender liner nut and remove the fender liner. Fender liner nut Fender liner bolts Turn the bulb base counterclock- STEP wise. ITY43C042 Unplug the connector while pull- STEP ing the lock release.
  • Page 483 4-3. Do-it-yourself maintenance ■ Parking light Turn the bulb base counterclock- STEP wise. ITY43C048 Remove the light bulb. STEP ITY43C049 L/C200_U (OM60G31U)
  • Page 484 4-3. Do-it-yourself maintenance ■ Front turn signal light For the left side only: Remove STEP the securing bolt and move the washer fluid filler opening. ITY43C012 Turn the bulb base counterclock- STEP wise. ITY43C044 Remove the light bulb. STEP ITY43C045 L/C200_U (OM60G31U)
  • Page 485 4-3. Do-it-yourself maintenance ■ Front side marker light For the left side only: Remove STEP the securing bolt and move the washer fluid filler opening. ITY43C012 Turn the bulb base counterclock- STEP wise. ITY43C050 Remove the light bulb. STEP ITY43C051 L/C200_U (OM60G31U)
  • Page 486 4-3. Do-it-yourself maintenance ■ Back-up light Open the back door and remove STEP the nuts and lamp assembly. ITY43C052 Turn the bulb bases counter- STEP clockwise. ITY43C053 Remove the light bulb. STEP ITY43C054 L/C200_U (OM60G31U)
  • Page 487 4-3. Do-it-yourself maintenance ■ Rear turn signal light Open the back door and remove STEP the bolts and lamp assembly. ITY43C058 Turn the bulb bases counter- STEP clockwise. ITY43C059 Remove the light bulb. STEP ITY43C060 L/C200_U (OM60G31U)
  • Page 488 4-3. Do-it-yourself maintenance ■ License plate light Open the back door and remove STEP the license plate light unit. Turn the bulb base counterclock- STEP wise. ITY43C067 Remove the light bulb. STEP ITY43C068 L/C200_U (OM60G31U)
  • Page 489 Water has built up inside the headlight. ■ LED lights The stop/tail, tail, rear side marker lights and high mounted stoplight consist of a number of LEDs. If any LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. L/C200_U (OM60G31U)
  • Page 490 4-3. Do-it-yourself maintenance CAUTION ■ Replacing light bulbs ● Turn off the headlights. Do not attempt to replace the bulb immediately after turning off the headlights. The bulbs become very hot and may cause burns. ● Do not touch the glass portion of the light bulb with bare hands. Hold the bulb by the plastic or metal portion.
  • Page 491: When Trouble Arises

    When trouble arises 5-1. Essential information 5-2. Steps to take in an emergency Emergency flashers ..492 If a warning light turns on If your vehicle needs or a warning sounds..502 to be towed ....493 If a warning message If you think something is displayed ....
  • Page 492: Essential Information Emergency Flashers

    5-1. Essential information Emergency flashers Use the emergency flashers if vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. ITO51C056 NOTICE ■ To prevent battery discharge Do not leave the emergency flashers on longer than necessary when the engine is not running.
  • Page 493: If Your Vehicle Needs To Be Towed

    If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
  • Page 494 5-1. Essential information ■ Emergency towing procedure STEP The engine must be in ACCESSORY mode (engine off) or IGNI- TION ON mode (engine running). STEP Put the four-wheel drive control switch in “H4”. (The center differen- tial is unlocked.) STEP Put the shift lever in “N”.
  • Page 495 5-1. Essential information Towing with a sling-type truck NOTICE ■ To prevent body damage Do not tow with a sling type truck, either from the front or rear. L/C200_U (OM60G31U)
  • Page 496 5-1. Essential information Towing with a wheel lift-type truck From front Use a towing dolly under the rear wheels. From rear Use a towing dolly under the front wheels. NOTICE ■ To prevent causing serious damage to the transmission Never tow this vehicle wheels on the ground. ■...
  • Page 497 5-1. Essential information Using a flat bed truck If your Toyota is transported by a flat bed truck, it should be tied down at the locations shown in the illustration. When attaching the hooks to the rear of the vehi- cle, make sure to attach them to the inside of the vehicle.
  • Page 498: If You Think Something Is Wrong

    5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
  • Page 499: Fuel Pump Shut Off System

    5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an air- bag inflates upon collision, the fuel pump shut off system stops sup- plying fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
  • Page 500: Event Data Recorder

    5-1. Essential information Event data recorder Your vehicle has computers that monitor and control certain aspects of your vehicle. These computers assist in driving and maintaining optimal vehicle performance. Besides storing data useful for troubleshooting, there is a system to record data in a crash or a near car crash event.
  • Page 501 5-1. Essential information Disclosure of the data Toyota will not disclose the data recorded in an EDR to a third party except when: ● An agreement from the vehicle’s owner (or the leasing company for a leased vehicle) is obtained ●...
  • Page 502: Steps To Take In An Emergency If A Warning Light Turns On Or A Warning Sounds

    Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake sys- tem. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Brake system warning light (warning buzzer) •...
  • Page 503 Charging system warning light Indicates a malfunction in the vehicle’s charging system. Have the vehicle inspected by your Toyota dealer immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident.
  • Page 504 5-2. Steps to take in an emergency Warning light Warning light/Details ABS warning light Malfunction in: • The ABS; or • The brake assist system. Pre-collision system warning light (if equipped) Malfunction in the pre-collision system. Have the malfunction repaired immediately. After taking the specified steps to correct the suspected problem, check that the warning light turns off.
  • Page 505 Low tire inflation pressure. pressure. When the light comes on after blinking for 1 minute: Have the system checked Malfunction in the tire by your Toyota dealer. pressure warning system. Unengaged “Park” warn- ing light Shift four-wheel drive con- The transmission “Park”...
  • Page 506 5-2. Steps to take in an emergency Warning light Warning light/Details Correction procedure Low fuel level warning light Indicates that remaining Refuel the vehicle. fuel is about 4.0 gal. (15.0 L, 3.3 Imp. gal.) or less. Master warning light A buzzer sounds and the Take appropriate action in warning light comes on accordance with the mes-...
  • Page 507 In this case, you may not be able to transfer between “H4” and “L4” modes, and the center differential lock may not be able to be locked or unlocked. Have the vehicle inspected by your Toyota dealer imme- diately.
  • Page 508 5-2. Steps to take in an emergency ■ SRS warning light This warning light system monitors the following: ● The airbag sensor assembly ● Front airbag sensors ● The curtain shield airbag sensors ● The side and curtain shield airbag sensors ●...
  • Page 509 If there is a lot of snow or ice on the vehicle, in particular around the wheels or wheel housings. ● If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
  • Page 510 If the tire pressure warning light comes on after blinking for 1 minute fre- quently when the “ENGINE START STOP” switch is turned to IGNITION ON mode, have it checked by Toyota dealer. CAUTION ■ If the tire pressure warning light comes on Be sure to observe the following precautions.
  • Page 511 5-2. Steps to take in an emergency CAUTION ■ Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
  • Page 512 5-2. Steps to take in an emergency CAUTION Your vehicle has also been equipped with a TPMS (tire pressure warning system) malfunction indicator to indicate when the system is not operat- ing properly. The TPMS (tire pressure warning system) malfunction indi- cator is combined with the low tire pressure telltale (tire pressure warning light).
  • Page 513: If A Warning Message Is Displayed

    Multi-information display If any of the warning messages is shown again after its correction procedure has been performed, contact your Toyota dealer. Messages and warnings The warning lights and warning buzzers operate as follows depend- ing on the content of the message. If a message indicates the need for inspection by a dealer, have the vehicle inspected immediately by your Toyota dealer.
  • Page 514 5-2. Steps to take in an emergency System Warning warning Warning buzzer light Indicates an important situation, such as when a system related to  Comes on Sounds driving is malfunctioning or that danger may result if the correction procedure is not performed. Indicates an important situation, Comes such as when the system shown...
  • Page 515 After adjusting the tire inflation pressure, be sure to initialize the data. (P. 446) If the message remains on, the system may have malfunctioned. Have the vehicle inspected by your Toyota dealer as soon as possible. NOTICE ■ Engine oil maintenance message The warning message is based on the projected driving range after engine oil maintenance message is reset.
  • Page 516: If You Have A Flat Tire

    5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ● Set the parking brake. ●...
  • Page 517 5-2. Steps to take in an emergency Taking out the jack Remove the cover. STEP Loosen STEP Tighten Loosen and remove the jack. L/C200_U (OM60G31U)
  • Page 518 5-2. Steps to take in an emergency Taking out the tool box Remove the cover. STEP Take out the tool box. STEP L/C200_U (OM60G31U)
  • Page 519 5-2. Steps to take in an emergency Taking out the spare tire STEP STEP Assembling the jack handle. Remove the jack handle and the jack extension bar from the tool box and assemble by following these steps. Loosen the screw using a screwdriver.
  • Page 520 5-2. Steps to take in an emergency Insert the jack handle extension STEP into the lowering screw. Lower Raise Place a rag under the jack handle extension to protect the back door. ITY51C030 Lower the spare tire completely STEP to the ground. ITY51C031 Pull out the spare tire and STEP...
  • Page 521 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Flat tire Wheel chock position Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
  • Page 522 5-2. Steps to take in an emergency Pry off the wheel ornament, STEP using the beveled end of the wheel ornament remover as shown. Slightly loosen the wheel nuts STEP (one turn). L/C200_U (OM60G31U)
  • Page 523 5-2. Steps to take in an emergency STEP Assembling the jack handle. Remove the jack handle, jack extension bar and jack handle bar from the tool box and assemble by following these steps. Loosen the bolts and the screw using either the jack handle or a screwdriver.
  • Page 524 5-2. Steps to take in an emergency Position the jack at the jack STEP points as shown. Front - Under the chassis frame side rail Rear - Under the rear axle hous- Raise the vehicle until the tire is STEP slightly raised off the ground.
  • Page 525 5-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
  • Page 526 5-2. Steps to take in an emergency Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque: 97 ft•lbf (131 N•m, 13.4 kgf•m) Reinstall the wheel ornament. STEP Stowing the flat/spare tire, jack and tools Lay down the tire with the outer STEP side facing up, and install the...
  • Page 527 5-2. Steps to take in an emergency ■ After completing the tire change The tire pressure warning system must be reset. (P. 446) CAUTION ■ Using the tire jack Improper use of the tire jack may lead to death or serious injuries due to the vehicle suddenly falling off the jack.
  • Page 528 5-2. Steps to take in an emergency CAUTION ■ Replacing a flat tire Observe the following precautions to reduce the risk of death or serious injury. ● Lower the spare tire completely to the ground before removing it from under the vehicle. ●...
  • Page 529 ■ When replacing the tires When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. ■...
  • Page 530: If The Engine Will Not Start

    5-2. Steps to take in an emergency If the engine will not start If the engine still does not start after following the correct starting procedure (P. 154) or releasing the steering lock (P. 156), confirm the following points. ■ The engine will not start when the starter motor operates normally.
  • Page 531 ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (P. 538) ● There may be a malfunction in the steering lock system. Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function When the engine does not start, the following steps can be used as an interim measure to start the engine if the “ENGINE START STOP”...
  • Page 532: If The Shift Lever Cannot Be Shifted From P

    (a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
  • Page 533: If You Lose Your Keys

    5-2. Steps to take in an emergency If you lose your keys New genuine Toyota keys can be made by your Toyota dealer using one of the other keys and the key number stamped on your key num- ber plate.
  • Page 534: If You Cannot Operate Back Door Opener

    If the back door opener does not operate, there may be a problem with the back door opener system. Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the back door can be opened from the inside.
  • Page 535: If The Electronic Key Does Not Operate Properly

    (turn and hold) Unlocks all doors Turning rearward unlocks driver’s door. Turning the key once again unlocks the other doors. Opens the windows/moon roof (turn and hold) : This setting must be customized at your Toyota dealer. L/C200_U (OM60G31U)
  • Page 536 5-2. Steps to take in an emergency Changing “ENGINE START STOP” switch modes and starting the engine STEP Shift the shift lever to “P” and apply the brakes. Touch the Toyota emblem side of STEP electronic “ENGINE START STOP” switch. An alarm will sound to indicate...
  • Page 537 5-2. Steps to take in an emergency ■ Stopping the engine Shift the shift lever to “P” and press the “ENGINE START STOP” switch as you normally do when stopping the engine. ■ Replacing the key battery As this above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery depletes.
  • Page 538: If The Battery Is Discharged

    You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12 volt battery, you can jump start your Toyota following the steps below.
  • Page 539 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. ■ Starting the engine when the battery is discharged The engine cannot be started by push-starting.
  • Page 540 5-2. Steps to take in an emergency CAUTION ■ Avoiding battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery. ● Make sure the jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any part other than the intended termi- nal.
  • Page 541: If Your Vehicle Overheats

    If the fan is operating: Wait until the engine coolant temperature gauge begins to fall and then stop the engine. If the fan is not operating: Stop the engine immediately and call your local Toyota dealer. After the engine has cooled STEP...
  • Page 542 Water can be used in an emer- gency measure if coolant is unavailable. (P. 552) TY51C047 Have the vehicle checked at nearest Toyota dealer as soon as pos- sible. ■ Overheating In the following situations, your vehicle may be overheating.
  • Page 543 5-2. Steps to take in an emergency NOTICE ■ When adding engine coolant Wait until the engine has cooled down before adding engine coolant. When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly can cause damage to the engine. L/C200_U (OM60G31U)
  • Page 544: If The Vehicle Becomes Stuck

    5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. STEP Stop the engine. Set the parking brake and shift the shift lever in “P”.
  • Page 545: If Your Vehicle Has To Be Stopped In An Emergency

    5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: STEP Steadily step on the brake pedal with both feet and firmly...
  • Page 546 5-2. Steps to take in an emergency CAUTION ■ If the engine has to be turned off while driving Power assist for the brakes and steering wheel will be lost, making the brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the engine.
  • Page 547: Vehicle Specifications

    Vehicle specifications 6-1. Specifications Maintenance data (fuel, oil level, etc.) ..548 Fuel information ....558 Tire information ....561 6-2. Customization Customizable features ..573 6-3. Initialization Items to initialize ....582 L/C200_U (OM60G31U)
  • Page 548: 6-1. Specifications

    6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Overall length 194.9 in. (4950 mm) Overall width 77.6 in. (1970 mm) Overall height 74.0 in. (1880 mm) Wheelbase 112.2 in. (2850 mm) Front 64.6 in. (1640 mm) Tread Rear 64.4 in.
  • Page 549 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
  • Page 550 6-1. Specifications Engine Model 3UR-FE Type 8-cylinder V type, 4-cycle, gasoline 3.70  4.02 in. (94.0  102.0 mm) Bore and stroke Displacement 345.6 cu.in. (5663 cm Valve clearance Automatic adjustment (engine cold) Drive belt tension Automatic adjustment Fuel Fuel type Unleaded gasoline only Octane rating 87 (Research octane number 91) or higher...
  • Page 551 (Location of the marker: P. 432) ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC multigrade engine oil...
  • Page 552 Cooling system Capacity 17.6 qt. (16.7 L, 14.7 lmp.qt.) Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non- Coolant type silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technol- Do not use plain water alone.
  • Page 553 6-1. Specifications Ignition system Spark plug Make DENSO SK20HR11 0.043 in. (1.1 mm) NOTICE ■ Iridium-tipped spark plugs Use only iridium-tipped spark plugs. Do not adjust gap when tuning engine. Electrical system Battery 12.6  12.8 V Fully charged Open voltage at 12.2 ...
  • Page 554 Toyota Genuine Differential gear oil LT viscosity 75W-85 GL-5 or equivalent “Toyota Genuine Differential Oil” is filled in your Toyota vehicle at factory fill. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification. Please contact your Toyota dealer for further details.
  • Page 555 6-1. Specifications Transfer Oil capacity 1.53 qt. (1.45 L, 1.28 lmp.qt.) Oil type Gear oil API GL-5 Recommended oil viscosity SAE 75W-90 Brakes Pedal clearance 3.62 in. (92 mm) Min.  0.24 in. (1.0  6.0 mm) Pedal free play 0.04 Brake pad wear limit 0.04 in.
  • Page 556 6-1. Specifications Steering Free play Less than 1.18 in. (30 mm) ® Automatic transmission fluid DEXRON Power steering fluid type or III Tires and wheels Tire size P285/60R18 114V Normal driving Front tires: 33 psi (230 kPa, 2.3 kgf/cm or bar) Rear tires: 33 psi (230 kPa, 2.3 kgf/cm or bar)
  • Page 557 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights  Low beam High beam 9005 Front turn signal lights 3457  Parking lights Exterior  Front side marker lights Front fog lights 9006  Rear turn signal lights Back-up lights ...
  • Page 558: Fuel Information

    ASTM D4814 in the U.S.A. ■ Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. ■ If your engine knocks ●...
  • Page 559 Toyota allows the use of oxygenate blended gasoline where the oxygen- ate content is up to 10% ethanol or 15% MTBE. ● If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 87. ●...
  • Page 560 Toyota does not recommend gasoline containing MMT Some gasoline contains octane enhancing additive called MMT (Methylcy clopentadienyl Manganese Tricarbonyl). Toyota DOES NOT recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
  • Page 561: Tire Information

    6-1. Specifications Tire information Typical tire symbols ITY61C010 Tire size (P. 563) Summer tire or all season tire (P. 449) An all season tire has “M+S” on the sidewall. A tire not marked “M+S” is a summer tire. Uniform tire quality grading For details, see “Uniform Tire Quality Grading”...
  • Page 562 6-1. Specifications Maximum cold tire inflation pressure (P. 566) This means the pressure to which a tire may be inflated. TUBELESS or TUBE TYPE A tubeless tire does not have a tube and air is directly filled in the tire. A tube type tire has a tube inside the tire and the tube main- tains the air pressure.
  • Page 563 6-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use P285/60R18 114V (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio ITY61C011 (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 or 3 digits)
  • Page 564 U.S.A. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades.
  • Page 565 6-1. Specifications ■ Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci- fied government test course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on the government course as a tire graded 100.
  • Page 566 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either sepa- rately or in combination, can cause heat buildup and possible tire fail- ure.
  • Page 567 6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb.
  • Page 568 6-1. Specifications Tire related term Meaning The load on an individual tire that is determined by distributing to each axle its share of curb Vehicle normal load weight, accessory weight, and normal occu- on the tire pant weight (distributed in accordance with Table 1 below), and dividing by two The surface area of the rim not covered by the...
  • Page 569 6-1. Specifications Tire related term Meaning A tire designed to operate at higher loads and Extra load tire at higher inflation pressures than the corre- sponding standard tire Groove The space between two adjacent tread ribs The layer(s) forming the inside surface of a Innerliner tubeless tire that contains the inflating medium within the tire...
  • Page 570 6-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, including eleva- Overall width tions due to labeling, decorations, or protective bands or ribs A tire intended for use on passenger cars, mul- tipurpose passenger vehicles, and trucks, that Passenger car tire have a gross vehicle weight rating (GVWR) of...
  • Page 571 6-1. Specifications Tire related term Meaning A tire that attains a traction index equal to or greater than 110, compared to the ASTM E- 1136 Standard Reference Test Tire, when using the snow traction test as described in ASTM F-1805-00, Standard Test Method for Snow tire Single Wheel Driving Traction in a Straight Line on Snow-and Ice-Covered Surfaces, and which...
  • Page 572 6-1. Specifications : Table 1  Occupant loading and distribution for vehicle normal load for various designated seating capacities Designated seating Occupant distribution in Vehicle normal load, capacity, Number of a normally loaded Number of occupants occupants vehicle 2 through 4 2 in front 2 in front, 1 in second 5 through 10...
  • Page 573: Customization Customizable Features

    Customizable features Your vehicle includes a variety of electronic features that can be per- sonalized to your preferences. Programming of these preferences can be performed by your Toyota dealer. For vehicles with the navigation system, it is also possible to cus- tomize certain vehicle features yourself using the touch screen.
  • Page 574 6-2. Customization Customizable features Vehicle customization settings can be changed at your Toyota dealer. For vehicles with the navigation system, some settings can be changed using the touch screen. Settings that can be changed using the touch screen Settings that can be changed using the vehicle switches Settings that can be changed by your Toyota dealer Definition of symbols: O= Available, —...
  • Page 575 6-2. Customization Default Customized Item Function setting setting Wireless remote — — O control Open door warn- ing function — — O Wireless (when locking the remote vehicle) control Driver’s door (P. 39) unlocked in All doors Unlocking opera- one step, all unlocked in O —...
  • Page 576 6-2. Customization Default Customized Item Function setting setting Driver’s door unlocked in All doors Unlocking using a one step, all unlocked in O — O doors one step unlocked in two steps Speed-detecting automatic door O O O lock function Door lock Shifting the shift (P.
  • Page 577 6-2. Customization Default Customized Item Function setting setting Mechanical key linked operation — — O (open) Mechanical key linked operation — — O (close) Linked operation of components Slide only Tilt only — — O when door key is Moon roof Wireless remote (P.
  • Page 578 6-2. Customization Default Customized Item Function setting setting Time period before the interior 15 seconds 7.5 seconds O — O lights turn off 30 seconds Time period before the exte- 15 seconds 7.5 seconds O — O rior lights turn off 30 seconds Operation after the “ENGINE...
  • Page 579 6-2. Customization Default Customized Item Function setting setting Light sensor sen- Standard -2 to 2 O — O sitivity Daytime running O — O Automatic light system light control system Time elapsed before head- (P. 177) lights automati- 30 seconds 60 seconds O —...
  • Page 580 6-2. Customization ■ Vehicle customization ● If the smart key system is turned “OFF”, unlock door cannot be selected. ● If the doors are not opened after locking and are then automatically re- locked, a signal will be given if “Operation signal (Emergency flashers)” or “Operation signal (Buzzer)”...
  • Page 581 6-2. Customization CAUTION ■ During customization As the engine needs to be running during customization, ensure that the vehicle is parked in a place with adequate ventilation. In a closed area such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect and enter the vehicle.
  • Page 582: Initialization Items To Initialize

    6-3. Initialization Items to initialize The following items must be initialized for normal system operation in cases such as after the battery is reconnected, or maintenance is performed on the vehicle. Item When to initialize Reference Engine oil mainte- After changing engine oil P.
  • Page 583: For U.s. Owners

    For U.S. owners Reporting safety defects for U.S. owners ....584 L/C200_U (OM60G31U)
  • Page 584: Reporting Safety Defects For U.s. Owners

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
  • Page 585: Index

    Index Abbreviation list ..... 586 Alphabetical index....588 What to do if......596 For details of equipment related to the navigation sys- tem and touch screen, such as the air conditioning and audio systems, refer to the “Navigation System Owner’s Manual”. L/C200_U (OM60G31U)
  • Page 586: Abbreviation List

    Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Air conditioning Anti-lock Brake System Automatic Locking Retractor Auxiliary Child Restraint System DISP Display Electronic Controlled Transmission Electronic Control Unit Event Data Recorder Emergency Locking Retractor GAWR Gross Axle Weight Rating GVWR Gross Vehicle Weight Rating Emission inspection and maintenance Intermittent KDSS...
  • Page 587 Abbreviation list ABBREVIATIONS MEANING Mud and Snow MTBE Methyl Tertiary Butyl Ether On Board Diagnostics Pre-Collision System Power RSCA Roll Sensing of Curtain Shield airbag Supplemental Restraint System Tire Identification Number TPMS Tire Pressure Warning System TRAC Traction Control Vehicle Identification Number Vehicle Stability Control L/C200_U (OM60G31U)
  • Page 588: Alphabetical Index

    Alphabetical index Alphabetical index Audio input ......308 Air conditioning filter....460 AUX port ....... 308 Automatic air conditioning CD player/changer ....276 system ........248 iPod........291 ABS ...........208 MP3/WMA disc .....284 Active traction control.....208 Optimal use......306 Air conditioning filter....460 Portable audio device ...308 Air conditioning system Radio........267 Air conditioning filter....460...
  • Page 589 Alphabetical index Brake assist ......208 Installing child restraints..129 Break-in tips ......145 Moon roof precautions ....91 Brightness control Power window lock switch..86 Instrument light control ..167 Power window precautions ..88 Removed key battery precautions ......463 Care Seat belt extender Exterior .........
  • Page 590 Alphabetical index Do-it-yourself maintenance..426 If you have a flat tire .....516 Door courtesy lights If you lose your keys .....533 Door courtesy lights ....333 If you think something is Wattage.........557 wrong........498 Door lock If your vehicle becomes Back door ........47 stuck ........544 Side door.........42 If your vehicle has to be...
  • Page 591 Alphabetical index Fluid Glove box........375 Brake ........438 Glove box light ......375 Power steering ..... 440 Washer ......... 444 Hazard lights Fog lights Switch........492 Replacing light bulbs .... 479 Head restraints Switch........178 Adjusting .........67 Wattage ........ 557 Headlight cleaner .....185 Four-wheel drive system ..
  • Page 592 Alphabetical index Jack Maintenance Vehicle-equipped jack ...516 Do-it-yourself maintenance ...426 Jack handle ......516 General maintenance.... 422 Maintenance data ....548 Maintenance requirements ...420 KDSS .........208 Meter Keyless entry......26 Instrument panel light Keys control......... 167 Electronic key......24 Meters ........166 If you lose your keys .....533 Micro dust and pollen filter..254 If your electronic key Mirrors...
  • Page 593 Alphabetical index Parking brake ......164 Safety Connect......406 Parking lights Seat belts Replacing light bulbs .... 479 Adjusting the seat belt.....72 Switch........175 Automatic Locking Wattage ........ 557 Retractor .......74 PCS........... 214 Child restraint system Personal lights installation......129 Personal lights...... 373 Cleaning and maintaining Switch........
  • Page 594 Alphabetical index Side airbags......104 Fog light switch .....178 Side marker lights Hazard light switch....492 Replacing light bulbs .....479 Ignition switch ....... 154 Switch........175 Light switches ....... 175 Wattage.........557 Power door lock switch ... 42 Side mirror Power window switch....86 Adjusting and folding....83 Rear window wiper and Mirror position memory ...63...
  • Page 595 Alphabetical index Total load capacity....227 Seat belt reminder....505 Towing SRS airbags ......503 Dinghy towing....... 245 Tire pressure ......505 Emergency towing....493 Unengaged “Park”....505 Trailer towing......233 Warning messages ....513 TRAC ........208 Warning reflector holder ..397 Traction control....... 208 Washer Trailer towing......
  • Page 596: What To Do If

    What to do if... What to do if... A tire punctures If you have a flat tire P. 516 P. 96 Engine immobilizer system The engine does not start P. 530 If the engine will not start P. 538 If the battery is discharged The shift lever cannot be If the shift lever cannot be shifted P.
  • Page 597 What to do if... STRT CRUISE RSCA A/T P ITYPC053 ■Warning lights Brake system warning Driver’s seat belt reminder light light P. 502 P. 505 Front passenger’s seat ABS warning light belt reminder light P. 504 SRS warning light P. 503 P.
  • Page 598 What to do if... L/C200_U (OM60G31U)
  • Page 599 What to do if... L/C200_U (OM60G31U)
  • Page 600: Gas Station Information

    (Drain and refill — reference) Without filter 7.0 (6.6, 5.8) 7.5 (7.1, 6.2) “Toyota Genuine Motor Oil” or equivalent Engine oil type Oil grade: ILSAC multigrade engine oil P. 551 : Vehicles with a blue-markered dipstick handle : Vehicles with a green-markered dipstick handle (Location of the marker: P.
