Summary of Contents for Atec AL170

  • Page 2: Before Use

    Before Use This user manual contains proprietary information that is protected by copyright. ● All rights are reserved. No part of this user manual may be reproduced, photocopied, nglish transcribed, translated or transmitted in whatsoever from without the prior permission of the manufacturer.

  • Page 3: Fcc Compliance Statement

    CE Conformity Notice nglish The Product herewith complies with requirements of the Low Voltage Directive 73/23/EEC and the EMC Directive 89/336/EEC and carries the ‘CE’ mark accordingly. Confirms to the following hamonized European standards have been applied: EMC : EN 55022 Class B : 1998 EN 55024 : (EN 61000-4-2 : 1995, A1 : 1998, EN61000-4-3 : 1996, EN 61000-4-4: 1995, EN61000-4-5 : 1995, EN61000-4-4 : 1996, EN61000-4-8 : 1993 and EN61000-4-11 : 1994)
  • Page 4 Unpacking After opening the box, make sure the following items are provided with the monitor. nglish If you find that any of these items is missing or appears damaged, contact your dealer immediately. Monitor User Manual DC Adapter Power Cord Audio Cable Diskette VGA Signal Cable...
  • Page 5 Instructions for Safety nglish ▶ Matters that demand special attention are divided into ‘Warning’ and ‘Caution’, and are detailed a follows. In case of the possibility that a serious injury or death may occur during a violation of the instructions. In case of the possibility that a slight injury or product damage may occur during a violation of the instructions.
  • Page 6 nglish Keep the power cord from proximity to a heating instrument. ● The covering material of the cord may melt, causing a fire or electric shock. Grasp the power plug at the base to remove it from the ● wall, and pull firmly but gently. If you yank at the cord, the wire may be broken, causing ignition or heat generation.
  • Page 7 nglish Don’t block or obstruct the air-flow holes of the monitor. ● A fire or damage of the monitor may be caused due to an increase in internal temperature. Don’t spill liquids such as chemicals, water on the monitor. ● A fire or electric shock accident may be caused.
  • Page 8 nglish Place the monitor on a stable and secure surface. ● Fall or displacement of the monitor may cause an injury. Turn off the monitor and disconnect all cables from the ● monitor before moving the monitor. Be careful with the shock when moving the monitor. ●...

  • Page 9: Table Of Contents

    CONTENTS nglish Installing the Monitor Features …………………………………………………………… 1 Installing and Removing the Support ……………………………… 2 Installing the Support ……………………………………………………… 2 Removing the Support …………………………………………………… 2 Monitor Overview ………………………………………………… 3 Front Side …………………………………………………………… 3 Rear Side …………………………………………………………… 4 Connecting the Peripheral Devices …………………………… 5 Installing the Monitor Driver Installing the Monitor Driver Under Windows ……………………...

  • Page 10: Features

    1.1 Features Adopt the 17.0 TFT LCD Narrow Bezel Panel Adopt the 17.0 LCD(Liquid Crystal Display) narrow bezel panel which allows you efficient use in a small space due to the slim design with wide screen. AUDIO It gives user an amplified stereo sound through internally installed speakers (2 W). Power Consumption Economy Function The VESA DPMS(Display Power Management Signaling) function is available to reduce power consumption by automatically switching the computer into the power saving mode if...

  • Page 11: Installing And Removing The Support

    1.2 Installing and Removing the Support Installing the Support Lay a soft cloth and place the monitor on it with the screen facing downwards. (Take caution not to cause scratches to the LCD display.) Latch Push in the support in the direction of the arrow.

  • Page 12: Monitor Overview

    1.3 Monitor Overview This section identifies the name of each component of the monitor and briefly describes the function of each component. Front Side LEFT Button Decreases the value of the TFT LCD Display selected item. (Decreases the Displays the current contents volume without pressing the of the display.

  • Page 13: Rear Side

    Rear Side AUDIO IN Connects the audio cable to the LINE OUT jack on the computer or the stereo jack on the camcorder/VTR. AUDIO OUT Connects a set of headphones or external speakers. ANALOG Connector Connects the VGA signal cable to the ANALOG connector on the computer.

  • Page 14: Connecting The Peripheral Devices

    1.4 Connecting the Peripheral Devices Turn off the monitor, computer and other peripheral devices before connecting the monitor and peripheral devices. Connecting the power Plug into the power outlet at 220V or 110V. (The voltage is set automatically.) DC-IN Jack DC Adapter Power Cord Connecting the computer...
  • Page 15 Connecting Audio Devices Connect the audio cable to the AUDIO IN on the monitor and the LINE OUT on the computer or connect the audio cable (RCA) cable to the AUDIO IN on the monitor and the stereo on the camcorder/TV and connect a set of headphones or external speakers to the AUDIO OUT.

  • Page 16: Installing The Monitor Driver Under Windows

    2.1 Installing the Monitor Driver Under Windows This section shows how to install the monitor driver under Windows or Linux by using the monitor driver diskette provided. To install the monitor driver, please refer to your OS in this section. Windows 98/Me Turn on the computer and the monitor.

  • Page 17: Windows 2000

    Windows 2000 Turn on the computer and the monitor. Insert the monitor driver diskette into the FDD on the computer. Click the Start button on the Windows display and select Control Panel. Double click the Display icon in the Control Panel window. In the Display Properties window, click the Setting tab and then select Advanced.

  • Page 18: Windows Xp

    Windows XP Turn on the computer and the monitor. Insert the monitor driver diskette into the FDD on the computer. Click the Start button on the Windows display and select Control Panel. Double click the Display icon in the Control Panel window. In the Display Properties window, click the Setting tab and then select Advanced.

  • Page 19: Installing The Monitor Driver Under Linux

    2.2 Installing the Monitor Driver Under Linux Linux You’d make xf86config file to run X-Window. Your monitor is surely and easily configured with this file. This file will be made as running xf86config. Press Enter in the first and second window after running xf86config file. In third window, we come up with the mouse setting window.

  • Page 20: Selecting And Adjusting The Osd(On Screen Display) Menu

    3.1 Selecting and Adjusting the OSD(On Screen Display) Menu You can select the OSD menu in the OSD window by using all the control buttons under the display. To change the current settings or adjust it to what you prefer, please follow these steps. Selecting and Adjusting the OSD Menu MENU UP/DOWN...

  • Page 21: Exclusive Analog Monitor Osd Menus

    3.2 Exclusive ANALOG Monitor OSD Menus The exclusive ANALOG monitor can use only ANALOG signals as input signals. Main Menu Software Version Screen Resolution Screen Frequency BRIGHTNESS/CONTRAST Controls the brightness and contrast of the display. BRIGHTNESS : Controls the brightness of the display.
  • Page 22 POSITION Adjusts the position of the display. HORIZONTAL : Adjusts the horizontal position of the display. VERTICAL : Adjusts the vertical position of the display. CLOCK : Increases or decreases the number of pixel to adjust the horizontal size. PHASE : Adjusts the focus and clarity of the display. EXIT : Exits POSITION menu.

  • Page 24: Troubleshooting

    A.1 Troubleshooting Please check the below particulars before you contact the service center to notify an abnormality of the monitor. The window Is the monitor power cord inserted? Please connect the power cord correctly to the concent. doesn’t show Is the power turned off? anything Please press the power button.

  • Page 25: Specification

    A.2 Specification The details of LCD Panel Type a-Si active matrix TFT-LCD product Size 17.0 (459,74 mm) specification can Pixel Pitch 0.264 mm x 0.264 mm be changed Color depth 8 bit(16,777, 216 colors) without notice to Video Signal Recommended Resolution 1280 x 1024 improve the Horizontal frequency 31.5 ~ 80 KHz...
