Atec NEOVIEW AL181 User Manual

18.1 inch tft lcd monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
N E OVIEW AL181
USER MANUA L
18.1 TFT LCD MONITOR
ANALOG / DIGITAL
[ FOR EXPORT ]
LCD PC No.1 Company
#1451-78, Seocho-Dong, Seocho-Gu,Seoul,
137-867, Korea
TEL : 82-2-2190-5000 FAX : 82-2-2190-5009
h t tp:// w w w . a t e c h . c o . k r
Rev 2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NEOVIEW AL181 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Atec NEOVIEW AL181

Summary of Contents for Atec NEOVIEW AL181

  • Page 1 N E OVIEW AL181 USER MANUA L 18.1 TFT LCD MONITOR ANALOG / DIGITAL [ FOR EXPORT ] LCD PC No.1 Company #1451-78, Seocho-Dong, Seocho-Gu,Seoul, 137-867, Korea TEL : 82-2-2190-5000 FAX : 82-2-2190-5009 h t tp:// w w w . a t e c h . c o . k r Rev 2.0...
  • Page 2 F o u n d a t i o n VGA Signal Cable DC Power Supply Unit User Manual ▼ ▼ ▼ Monitor Driver Power Cord Audio Cable ▼ ▼ ▼ O p t i o n D V I DVI to VGA ADAPTOR (Digital Video Interface) ▼...

  • Page 3: Fcc Compliance Statement

    FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation.
  • Page 4 CE Conformity Notice The Product herewith complies with the requirements of the Low Voltage Directive 73/23/EEC and the EMC Directive 89/336/EEC and carries the "CE" mark a c c o r d i n g l y . Confirms to the following harmonized European standards have been applied: EMC : EN 55022 Class B: 1998 EN 55024: 1998 (EN 61000-4-2: 1995, A1: 1998, EN 61000-4-3:1996, EN 61000-4-4: 1995, EN 61000-4-5: 1995, EN 61000-4-6: 1996,...

  • Page 5: Table Of Contents

    B e fo re Use F e a t u r e s Installing Monitor Driver Instructions for Safety H ow do I use the Monitor ? How do I Connect the Computer Cables ? How do I Connect with the IBM computer ? Parts and Functions of ANALOG and MONITOR Front view Back view...

  • Page 6: Fe At U Re S

    ( 2 W ) . D E S I G N •It is outstanding that Atec system has strategically planned and laid out a beautiful design that meets the taste of the new generation, super-slim model.

  • Page 7: Installing Monitor Driver

    Installing Monitor Drive r Manual installation method in Display Properties of Win 98 or Win 98SE 1. Insert a Diskette to A: Drive. 2. As clicking on My Computer in windows screen, follow the directions below. ② Click on ‘ D i s p l a y’ ①...
  • Page 8 "List all Device", then select one of them. Click on "OK" ⑨ Click on ‘ O K’ ⑩ Select ‘ATEC NEOVIEW A L 1 8 1’ , then click on ‘ N e x t’ ⑫ Click on ‘ F i n i s h’...
  • Page 9 Installing Monitor Drive r Windows 2000 Monitor Driver Installation The followings are the way to install monitor driver in Windows 2000 Manual Installation in Display Properties. ❶ Press "Start", click "Settings" and "Control Panel". ❷ Click "Display" in "Control Panel". ❸...
  • Page 10 Installing Monitor Drive r Configuring Monitor in Linux It is the direction for installing monitor in Linux. ❶ You'd make xf86config file to run X-WINDOW. Your monitor is surely and easily configured with this file. This file will be made as running xf86config. ❷...

  • Page 11: Instructions For Safety

    I n s t ructions for Safe t y ※The sign on the product ▶Matters that demand special attention are divided into and userguide instructs ‘W a r n i n g’and ‘C a u t i o n’ , and are detailed a follows as following.

  • Page 12: Parts And Functions Of Digital And Monitor 1

    Wa rn i n g Please be careful to keep the Please insert the two pins of the panel from being scratched or plug completely so that the damaged when you transport power supply unit can be the monitor. connected tightly. The panel may be Unsafe power damaged,...

  • Page 13: Digital Osd (On Screen Display) Display 1

    Wa rn i n g Never touch the power plug with D o n’ t use a power cord or plug wet hands. that is damaged or has a loose connection. An electric shock accident may occur. An electric shock or ignition may be caused.
  • Page 14 Wa rn i n g You must switch the power off and Pull the power cord out when the pull the power cord out before monitor is not used for a long moving the monitor. You should time, or while you are away. also check as to whether external connection cords - such as the A dust covering may...

  • Page 15: How Do I Connect The Computer Cables

    H ow do I connect the computer cabl e s ? How do I connect with the IBM computer ? ▶ R e f e r e n c e ◈ In case of the monitor aiding ANALOG (VGA) No Input signal message Ensure that the computer, monitor and peripheral equipment power is It is a message appeared in turned off.
  • Page 16 H ow do I connect the computer cabl e s ? How do I connect with the IBM computer ? ◈ In case of the monitor aiding DIGITAL (DVI) Ensure that the computer, monitor and peripheral equipment power is turned off. Connect Signal Cable.

  • Page 17: Parts And Functions Of Analog And Monitor

    Pa rts and Functions of ANA LO G and MONITO R Front View Power Pilot Lamp POWER Button MENU Button SELECT Button AUTO Button DOWN Button UP Button Back View 1. DC 12V INPUT (connected to adaptor) 2. VGA(Analog) or DVI(Digital) INPUT [DVI is OPTION] 3.

  • Page 18: The Name And Function Of Each Individual Part

    Parts and Functions of ANALOG and M O N I TO R The Name and Function of Each Individual Part in the Screen Adjusting Block Power Pilot Lamp Lights up during the opera- tion but goes out if you turn the power off.

  • Page 19: Selection And Control

    ANALOG OSD Display (On Screen Display) Selection and Control AUTO Function Use the OSD adjustable buttons on the side of the monitor to set/adjust to the best screen and operating environment. If you select the AUTO button before using the OSD menu, the screen is If you have to adjust the screen, automatically adjusted to...

  • Page 20: Display Adjust

    ANALOG OSD Display (On Screen Display) Selection and Control Descriptions of OSD Adjustment and Functions DISPLAY ADJUST • B R I G H T N E S S - It is used to adjust brightness of the screen. • C O N T R A S T - It is used to adjust distinction.
  • Page 21 ANALOG OSD Display (On Screen Display) Selection and Control Descriptions of OSD Adjustment and Functions OSD ADJUST • H-POS (OSD horizontal position) - Horizontal position in OSD menu is adjusted as controlling the numerical value of it. • V-POS (OSD vertical position) - Vertical position in OSD menu is adjusted as controlling the numerical value of it.
  • Page 22 D I G I TAL OSD Display (On Screen Display) Selection and Control The Name and Function of Each Individual Part in the Screen Adjusting Block Power Pilot Lamp Lights up during the opera- tion but goes out if you turn the power off.

  • Page 23: Osd Display

    D I G I TAL OSD Display (On Screen Display) Selection and Control Descriptions of OSD Adjustment and Functions OSD Display ▶ Function Description ▶ Mode Information ▶ R e f e r e n c e ❶ When you press the MENU button without OSD display, the display shown above will appear.

  • Page 24: In Case The Connection Is Made By Vga Signal

    D I G I TAL OSD Display (On Screen Display) Selection and Control Descriptions of OSD Adjustment and Functions In case the connection is made by VGA Signal ▶ Control the Screen Brightness ▶ Control the Screen's Shade of C o l o r ▶...

  • Page 25: In Case The Connection Is Made By Composite And S-Video

    D I G I TAL OSD Display (On Screen Display) Selection and Control Descriptions of OSD Adjustment and Functions In case the connection is made by VGA Signal ▶ R e f e r e n c e ◈ No need to press AUTO CONFIGURATION button ▶...
  • Page 26 D I G I TAL OSD Display (On Screen Display) Selection and Control Descriptions of OSD Adjustment and Functions In case the connection is made by COMPOSITE and S-VIDEO ▶ S H A R P N E S S : Control Screen Distinction C O L O R : Control Screen's Depth of Color T I N T : Control Screen's Tint of Color ▶...
  • Page 27 D I G I TAL OSD Display (On Screen Display) Selection and Control Descriptions of OSD Adjustment and Functions In Case when a Connection is made with TV (Tuner) Signal ▶ R e f e r e n c e ◈...
  • Page 28 D I G I TAL OSD Display (On Screen Display) Selection and Control Descriptions of OSD Adjustment and Functions In Case when a Connection is made with TV (Tuner) Signal ▶ AIR / CATV : Air Wave, Cable TV Selection ▶...

  • Page 29: On Screen Display

    D I G I TAL OSD Display (On Screen Display) Selection and Control I N F O R M ATION (Comparison between ANALOG and ADAPTO R ) Pin Arrangement Description - Input Signal : ANALOG Formula - Input Signal : Digital Formula - Connector : 15 Pin VGA Signal - Connector : DVI-D model Cable C a b l e...

  • Page 30: Tr O U B L E S H O O T I N G

    Tr o u b l e s h o o t i n g Please check the below particulars before you contact the service center to notify an abnormality of the monitor. Check these points Take these respective actions Is the monitor power cord Please connect the power cord inserted ? correctly to the concent.
  • Page 31 Tr o u b l e s h o o t i n g Please check the below particulars before you contact the service center to notify an abnormality of the monitor. Check these points Take these actions This symptom can be discovered Has a discoloration (into 16 Set the number of colors to more...
  • Page 32 Tr o u b l e s h o o t i n g Please check the below particulars before you contact the service center to notify an abnormality of the monitor. Check these points Take these actions Is the positional adjustment Push the 'AUTO' Button, then the screen will beadjusted automati- made correctly?

  • Page 33: Product Specification

    Product Specification The details of product specification can be changed without notice to improve the product. a-Si active matrix TFT-LCD panel type LCD Panel 18.1 (459.14mm) diagonal screen size 0.2805mm x 0.2805mm pixel size 2 5 0 : 1 ( T y p i c a l ) contrast 8-bit(16,777,216 Colors) color...
  • Page 34 Product Specification Factory-specified Mode Horizontal Vertical Factory-specified Mode F r e q u e n c y ( k H z ) F r e q u e n c y ( H z ) V G A 3 1 . 4 7 640 ×3 5 0 V G A 640 ×4 8 0...
