48", 60" & 72" CULTIPACKER
Standard Pull Type
With Wheel Kit
Base Unit
With 3-Point Kit
OWNER'S MANUAL
With Assembly Instructions
For Model: TP2148, TP2760 & TP3272
KUNZ ENGINEERING, INC. / MENDOTA, IL 61342 / PH (815) 539-6954
1/18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Till-Ease TP2148 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kunz Till-Ease TP2148

  • Page 1 48”, 60” & 72” CULTIPACKER Standard Pull Type With Wheel Kit Base Unit With 3-Point Kit OWNER’S MANUAL With Assembly Instructions For Model: TP2148, TP2760 & TP3272 KUNZ ENGINEERING, INC. / MENDOTA, IL 61342 / PH (815) 539-6954 1/18...
  • Page 3: Safety Introduction

    SAFETY INTRODUCTION Your safety, and the safety of others, is very important. To help you make informed decisions about safety, we have provided operating procedures and other information in this manual. This information alerts you to potential hazards that could hurt you or others. This safety alert symbol is used to indicate safety instructions.
  • Page 4: Important Safety Information

    IMPORTANT SAFETY INFORMATION CAUTION: Do not allow anyone to operate this equipment who has not fully read and comprehended the safety manual and who has not been properly trained in the safe operation of the equipment. CAUTION: Operator should be familiar with all functions of the unit. WARNING: Keep bystander clear while operating equipment.
  • Page 5: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Read the complete assembly instructions before starting the assembly. You should have: - one cultipacker assembly - one wheel kit (optional) - one 3-point kit (optional) The standard pull type Model TP2148, TP2760 and TP3272 Cultipackers are fully assembled and ready for use after uncrating.
  • Page 6 ASSEMBLY OF OPTIONAL 3-POINT KIT (See Figure 2) 1. Remove the two 1/2” nuts, lock washers and bolts from each lower 3-point pin bracket. 2. Install each lower 3-point pin bracket on the cultipacker frame as shown in Figure 2. Fasten securely with the 1/2”...
  • Page 7: Using The Tool

    OPERATIONS AND MAINTENENCE This safety alert symbol is used to indicate safety instructions. Follow these instructions to avoid personal injury and/or property damage. Read and follow all instructions in this manual. CAUTION: Do not allow anyone to operate this equipment who has not fully read and comprehended the safety manual and who has not been properly trained in the safe operation of the equipment.
  • Page 8: Maintenance

    B. MAINTENANCE There are two grease points on the cultipacker. There is a bearing on each end of the packer wheel shaft. It is recommended that these bearings be greased at least every 4 hours. In dusty conditions more frequent greasing may be necessary.
  • Page 9 Packer Wheel (1-3/4" Shaft, 9-1/2" Dia.) - Model TP2760 259007 Packer Wheel (1-3/4" Shaft, 9-1/2" Dia.) - Model TP3272 275018 Till-Ease Name Decal 275019 Kunz Decal 500053 3-Point Bracket - (3-Point Kit Only) 500054 Connector Plate 500055 Cultipacker Frame - Model TP3272...
  • Page 10 MODEL TP2148, TP2760 & TP3272 PARTS...
