Summary of Contents for Kunz Till-Ease 543
- Page 1 43” FIELD CULTIVATOR / CHISEL PLOW OWNER’S MANUAL With Assembly Instructions For Model: 543 KUNZ ENGINEERING, INC. / MENDOTA, IL 61342 / PH (815) 539-6954 1/18...
- Page 2 sdfdsfsdfsdfds...
-
Page 3: Safety Introduction
SAFETY INTRODUCTION Your safety, and the safety of others, is very important. To help you make informed decisions about safety, we have provided operating procedures and other information in this manual. This information alerts you to potential hazards that could hurt you or others. This safety alert symbol is used to indicate safety instructions. -
Page 4: Important Safety Information
WARNING: Follow all safety precautions outlined by the manufacturer of the tow vehicle being used to pull this product. This entire manual is filled with important safety information. Please read it carefully. FOR QUESTIONS, COMMENTS OR TROUBLESHOOTING PLEASE CONTACT KUNZ ENGINEERING INC. AT (815) 539-6954... -
Page 5: Assembly Instructions
ASSEMBLY INSTRUCTIONS Read the complete assembly instructions before starting the assembly. You should have: - one tillage tool assembly - one lift control wiring assembly - five 9” cultivator sweeps with five bevel washer spacers A. ASSEMBLY OF TONGUE CAUTION: Steps 1 and 2 should be performed with caution. Care should be taken to prevent back injuries or other lifting related injuries. - Page 6 2. Position the tillage tool assembly upright on the tires. 3. Measure the hitch height on your tow vehicle. For hitch heights of 11” or less use the lower tongue mounting holes. For hitch heights of greater than 11” use the upper tongue mounting holes.
-
Page 7: Operations And Adjustments
OPERATIONS AND ADJUSTMENTS This safety alert symbol is used to indicate safety instructions. Follow these instructions to avoid personal injury and/or property damage. Read and follow all instructions in this manual. WARNING: Do not allow anyone to operate this equipment who has not fully read and comprehended the safety manual and who has not been properly trained in the safe operation of the equipment. - Page 8 B. COULTER FUNCTION This model is equipped with five separate coulters. The coulters serve as cutting blades and are meant for light debris cutting, ground scoring for better ground shatter and aiding in reducing clod size. If the debris is not cut the shanks tend to collect debris and act as a rake. This in turn will prevent normal operation.
- Page 9 D. ADJUSTING THE SHANKS AND COULTER SHANKS – Refer to Figure 4. The shanks and coulter shanks have been designed for quick adjustments. Both removal or maximum depth adjust changes can be made very quickly. The shanks can be set at a maximum depth of 2”, 4”...
- Page 10 Heavy Debris Covered Ground It is recommended these conditions be mowed first if possible to help chop up the debris. In heavy debris covered conditions, additional weight is recommended to help the coulters penetrate and cut debris. This tillage tool has been equipped with weight racks. These weight racks will easily allow for several hundred pounds to be added to the tool.
- Page 11 Rock Covered Ground In most cases reversible point chisel sweeps will have the best chance of working in heavily rock covered ground on the initial pass. These sweeps will provide the least resistance. It may be necessary to raise or remove the coulters. If the coulters are being forced out of the ground due to rocks, it may be difficult to get adequate sweep penetration.
- Page 12 Field Cultivator Set-Up with Optional Drag Harrow Optional Field Cultivator Sweep Configuration Figure 7. – Field Cultivator Configurations...
- Page 13 259005 Turning Shovel Optional 259006 Coulter Blade, 13.5" 264006 Fuse Holder 264008 Rocker Switch 275018 Till-Ease Name Decal 275019 Kunz Decal 275020 Lift Control Decal 277030 Fixed Diameter Cable Clamp 500007 Shank 500008 Coulter Shank 500009 Axle Clamp 500010 Control Panel...
- Page 14 MODEL 543 PARTS...
