NAVIGATOR NVR750c
MAINTENANCE/SERVICE MANUAL
INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Navigator NVR750c and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MGI Navigator NVR750c

  • Page 1 NAVIGATOR NVR750c MAINTENANCE/SERVICE MANUAL INSTRUCTION MANUAL...
  • Page 2: Table Of Contents

    The Front Wheel and Suspension System Top Handle Control Box Features Transmitter Features The Navigation System – How it works Cart Tracking Useful Hints in Operating the Navigator NVR750c Understanding your Buggy and Suggestions for Dealing with unusual Situations Frequently Asked Questions...
  • Page 3: Foreword

    MGI on 1300 644 523 Warranty Policy MGI NVR750c - For a period of 12 months in respect of the electronics, wheels, clutches, drive dogs, axles, battery and charger and 24 months in respect of the frame, motor and gearbox, MGI...
  • Page 4 If the work to be carried out is part of warranty, MGI will bear the cost.
  • Page 5 Rear Wheel Axles [See Maintenance Schedule] The rear wheel stub axles need to be lubricated regularly. Remove the rear wheels by depressing the spring clip and at the same time pull off the wheel. Apply Petroleum Jelly or light grease to the stub axles.
  • Page 6: Important

    It is the owner’s responsibility to ensure that all periodical checks, necessary adjustments and services are carried out. If in doubt please contact the MGI service centre on 1300 644 523. Any work performed on your buggy should be recorded on your service record (see page 9) regardless of the work.
  • Page 7: Service Record

    Service Record For NVR750c DATE: SERVICED BY: SIX MONTH INSPECTION INVOICE NO: SIGNATURE: DATE: SERVICED BY: ONE YEAR INSPECTION INVOICE NO: SIGNATURE: DATE: SERVICED BY: 1½ YEAR INSPECTION INVOICE NO: SIGNATURE: DATE: SERVICED BY: TWO YEAR INSPECTION INVOICE NO: SIGNATURE: DATE: SERVICED BY: 2½...
  • Page 8: Most Important Points To Read Prior To Using Your Buggy

    INSTRUCTION MANUAL Most Important points to read prior to using your buggy: a. Charging and care of the battery [see below] b. Assemble the buggy placing the rear wheels on their correct side [see page 10] c. Programme your Navigator for the chosen handle height [see page 11] Charging and care of the battery a.
  • Page 9: Fitting The Battery

    Fitting the battery Once charged, the battery can be fitted to the buggy. The battery comes with a battery cover, carry handle and battery leads. a. Place your battery in the tray with the leads facing to the front of the buggy. b.
  • Page 10: Attaching / Removing Wheels

    Attaching / Removing Wheels If your buggy comes with the wheels off, they should be placed in position prior to unfolding. To put the wheels on you will need to align the four slots on the inside of the wheel with the same four on the drive dog on the axle.
  • Page 11: Understanding The Electronics Of The Nvr750C

    Understanding the Electronics of the NVR750c Your new Navigator NVR750c uses a highly sophisticated and patented electronic gyroscope as the navigation system to steer the buggy when in ‘Nav On’ mode. The gyroscope is tilt compensated to enable true steering over a wide range of grades, which you could expect to encounter on the average golf course.
  • Page 12 Folding/unfolding your buggy Practice unfolding and folding the buggy using the steps below. This means when you go to play golf you will be somewhat familiar with this task. 1. Press the button on the lower folding mechanism and fold the lower handle 2.
  • Page 13: Fitting Your Golf Bag

    Place the seat stem into its position in the seat stem bracket on the right hand side of the buggy. MOST IMPORTANT: DEPRESS THE SEAT WITH YOUR HAND BEFORE SITTING. DO NOT USE THE SEAT ON UNEVEN SURFACES. Please note MGI does not warrant any seat support brackets that are damaged or bent.
  • Page 14: Assembling The Umbrella Holder

    Assembling the Umbrella Holder Your buggy comes with an umbrella holder. The umbrella holder needs to be bolted into position. Simply follow the pictures above. When not in use the umbrella holder can be turned to its side. If you take your buggy home in your car, you may need to do that prior to folding the buggy down. Your umbrella holder can be adjusted both to the side and backwards and forwards.
  • Page 15: The Front Wheel And Suspension System

    Engaging the 4 Wheel Important: To avoid damage to your buggy always engage the 4 wheel prior to playing golf, regardless of the terrain you are playing on. To engage the 4 wheel, pull on the spring loaded locking pin, begin to slide the 4 wheel back release the locking pin and continue sliding the 4 wheel back until the locking pin locates itself...
  • Page 16: Top Handle Control Box Features

    Top Handle Control Box Features a. On/Off – Press the on/off button to turn the buggy on and off b. Forward Arrow – Press to accelerate the buggy. The longer you depress the button, the faster the buggy travels c. Down Arrow – This enables you to decrease the speed and also to operate the NVR700 in reverse.
  • Page 17: Transmitter Features

    Soft Braking - the Navigator NVR750c is equipped with electronic soft braking. This means when you apply a left or right turn for less than a second, braking will be soft.
  • Page 18: The Navigation System – How It Works

    Transmitter range and Heart Beat: The range of the NVR750c is up to 200 metres [220 yards]. Your NVR750c also has a heart beat between the transmitter and receiver. This means that they stay on contact with each other at all times. If for some reason the buggy was to go out of range of the transmitter your NVR750c will stop automatically.
  • Page 19: Cart Tracking

    Cart Tracking Your Navigator is designed to track straight on level ground in the “Nav Off” mode. The twin motors are synchronized with your buggy at production. If for some reason (for example, your golf bag is not evenly weighted) your buggy does not track straight, adopt the following procedure to get the buggy to do that.
  • Page 20: Useful Hints In Operating The Navigator Nvr750C

    Understanding your Buggy and Suggestions for Dealing with unusual Situations The Navigator NVR750c is the product of many years of research and development and the result of many years of evolution on the golf course. We have listed some unusual buggy behaviours and given suggestions to check and correct.
  • Page 21 If OK, re-connect the battery and check the buggy’s operation again. If the remote still does not operate, contact your MGI service agent. Situation 2: The buggy remote range is not up to expectation or has reduced over time.
  • Page 22: Frequently Asked Questions

    Frequently Asked Questions and Answers: Question: Is it important to register my purchase for warranty purposes? Answer: You must register your purchase as soon as possible with MGI. You can register on line at www.mgikaddy.com or through the mail. The serial number for your buggy is located underneath the top handle scorecard compartment.
  • Page 23 MGI invests large amounts of capital into advancing the mechanical and electronic features of its range of buggies. Should you have any feedback or suggestion, which would further enhance the performance of our buggies, we would welcome your correspondence. If you have any concerns relating to the use of your motorised golf buggy do not hesitate to call us at 1300 644 523.
