- Page 1 www.shsglobal.store STEALTH® v2 User’s Guide...
- Page 2 The Element Labs logo and STEALTH® are trademarks of Element Labs, Inc. Other trademarks and trade names may be used in this document to refer to products by other entities. Element Labs, Inc. claims no proprietary interest in trademarks and trade names owned by others.
-
Page 3: Table Of Contents
www.shsglobal.store ABLE OF ONTENTS C h a p t e r 1 : Introduction System Overview ___________________________________________________ C h a p t e r 2 : Processing Components VP1 - Video Processing Unit ___________________________________________ Front Panel Description ___________________________________________ Rear Panel Description ___________________________________________ SP1 –... - Page 4 www.shsglobal.store Appendix B : LedGuru Software Communication Setup _______________________________________________ Input Tab __________________________________________________________ Output Tab ________________________________________________________ Input Cropping _________________________________________________ DVI Output _____________________________________________________ 50 / 60 Hz Field Rates ________________________________________ Frame Rate Conversion _______________________________________ Picture Scaling __________________________________________________ Pattern Generator ___________________________________________________ File Load Save ______________________________________________________ Appendix C : Application Notes SP1 Vertical Offset...
-
Page 5: Chapter 1 : Introduction
www.shsglobal.store H A P T E R Chapter 1 NTRODUCTION This User’s Guide covers the typical STEALTH system and its various components in detail and illustrates sample configurations. Chapters in this manual are divided into the following topics: • Introduction, (p. 1-1) •... -
Page 6: System Overview
www.shsglobal.store Chapter 1 Introduction System Overview The STEALTH system is a modular LED display product that allows for full motion video to be displayed on high resolution STEALTH panels. The STEALTH panels are lightweight and rapidly deployable. A nearly 60 percent transparent design makes it easy for set pieces or even other display devices to remain visible behind it allowing for a number of different creative effects. - Page 7 www.shsglobal.store Chapter 1 Introduction The PDB-3 contains 2 DSUs, each with 4 outputs. The DSU handles the final conversion of the video signal into 16x80 blocks which connect to a column of 5 STEALTH panels. Each STEALTH panel is an individual array of 16x16 pixels. The following figure illustrates the basic signal flow of the STEALTH system.
-
Page 8: Chapter 2 : Processing Components
www.shsglobal.store H A P T E R Chapter 2 ROCESSING OMPONENTS This chapter provides details on the STEALTH System processing components and covers the following topics: • VP1 - Video Processing Unit (p. 2-2) • SP1 – Signal Processing Unit (p. -
Page 9: Vp1 - Video Processing Unit
www.shsglobal.store Chapter 2 Processing Components VP1 - Video Processing Unit The VP1 is a Video Processing Unit capable of accepting several video formats and outputting a 1024x768 pixel DVI-D signal. The VP1 is operated via serial control from a PC using the supplied LedGuru software. Refer to LedGuru Software, (p. -
Page 10: Rear Panel Description
www.shsglobal.store Chapter 2 Processing Components Rear Panel Description The following information describes the VP1 rear panel: Figure 2.2 VP1 Rear Panel Legend # Label Info AC Power Input 85~264 VAC, 50/60 Hz RS232 in Serial Control of VP1 from a PC RS232 out RS232 Output Signal Interface (unused) CVBS1,CVBS2... -
Page 11: Sp1 - Signal Processing Unit
www.shsglobal.store Chapter 2 Processing Components SP1 – Signal Processing Unit The SP1 is the main controller for the STEALTH system. The SP1 receives a DVI input (1024x768 @ 60 Hz) and processes the image to be displayed on up to two DD1s (DD1 –... -
Page 12: Rear Panel Description
www.shsglobal.store Chapter 2 Processing Components Legend # Item Function Indicator RS232 signal is being received lights RS232 signal is transsmitting Indicates presence of incoming DVI signal Power Powers on/off the SP1 Rear Panel Description The following information describes the SP1 rear panel connections: Figure 2.4 SP1 Rear Panel Legend #... - Page 13 www.shsglobal.store Chapter 2 Processing Components The SP1 menu structure has one main menu and five sub-menus outlined in the following table. Table 2.1 SP1 Menus & Value Ranges Menu Item Description Values/ Range Display Brightness Set the source of the brightness setting 1-10 and the setting value Gamma...
- Page 14 www.shsglobal.store Chapter 2 Processing Components Table 2.1 SP1 Menus & Value Ranges Menu Item Description Values/ Range Pat Selects DSU test patterns under PATTERN Black, White, mode Red, Green, Blue, Pattern1, Pattern2, Pattern3, Pattern4, Column1, Column2, Row1, Row2, All W.B. Set scan board white balance individually R=0-255 for Red, Green, and Blue components...
-
Page 15: Dd1 - Data Distribution Unit
www.shsglobal.store Chapter 2 Processing Components DD1 – Data Distribution Unit The following is a list of DD1 features: • fiber optic input from SP1 • 1024x256 pixels (96 columns x 16 rows) maximum display area • six output ports 400x80 pixels (25 columns x 5 rows) •... -
Page 16: Front Panel Description
www.shsglobal.store Chapter 2 Processing Components PDB-3 – Power and Data Distribution The PDB-3 handles the distribution of power and data to the STEALTH panels. Each PDB-3 includes the following features: • Two x 1U High Data Supply Units (DSU) • DC Output Panel, 1U High •... -
Page 17: Rear Panel Description
www.shsglobal.store Chapter 2 Processing Components The following diagram illustrates basic connections: PDB to STEALTH Power Figure 2.8 PDB Power Connection Diagram Rear Panel Description The following information describes the rear of the PDB-3: Figure 2.9 PDB-3 Rear Panel Legend # Item Power Input Connector (see below) Removable Power Supplies... - Page 18 www.shsglobal.store Chapter 2 Processing Components Each PDB-3 is configured with either a NEMA L6-30 (North America, 30 amp) or IEC 60309 - CEE 17 (EU, 32 amp) power input connector mounted on the rear of the chassis for main power input. Item Wire Color Info...
-
Page 19: Dsu - Data Supply Unit
www.shsglobal.store Chapter 2 Processing Components DSU – Data Supply Unit The DSU handles the final data output to the STEALTH panels. Each DSU contains four Scan Boards (SB) which must be addressed properly to match your configuration. For example, if you are going to use 8 columns of STEALTH panels the DIP switches for the first 4 SBs must be set to 1-4. - Page 20 www.shsglobal.store Chapter 2 Processing Components The following table lists the individual DIP switch values along with an image of how the DIP switch should be set: Table 2.2 DIP Switch Values Value Image Value Image Value Image As an example, using Table 2.2 above, #7 has switches 1, 2, and 3 in the up position.
-
Page 21: Front Panel Description
www.shsglobal.store Chapter 2 Processing Components Front Panel Description The following information describes the DSU Front Panel: Figure 2.13 DSU Front Panel Legend # Function Data Output 1-4 Coaxial In Coaxial Out Data output from each DSU is made through the front mounted, 4 pin, female XLR connector. - Page 22 www.shsglobal.store Chapter 2 Processing Components The following diagrams illustrate basic DSU signal and control connections: Figure 2.14 DSU Signal and Control Connection Diagram #1 STEALTH® v2 User’s Guide 2-15...
- Page 23 www.shsglobal.store Chapter 2 Processing Components Figure 2.15 DSU Signal and Control Connection Diagram #2 STEALTH® v2 User’s Guide 2-16...
-
Page 24: Chapter 3 : Rigging And Mechanical
www.shsglobal.store H A P T E R Chapter 3 IGGING AND ECHANICAL This chapter introduces you to the rigging and mechanical aspects of the STEALTH System and covers the following topics: • Overview, (p. 3-2) • Header Assembly, (p. 3-3) •... -
Page 25: Overview
www.shsglobal.store Chapter 3 Rigging and Mechanical Overview Each STEALTH panel measures 398.5 mm (15.69”) long by 38.5 mm (1.52”) wide by 400 mm (15.75”) high and contains 256 LEDs in a 16 x 16 array. Multiple panels can be assembled together to attain the desired screen size. N O T E The maximum # of panels that can be connected vertically is 60. -
Page 26: Header Assembly
www.shsglobal.store Chapter 3 Rigging and Mechanical Header Assembly The header assembly provides an easy way to hang STEALTH panels. Common rigging hardware is used to allow for flexible installation adjustments. Description The following information describes the STEALTH header: Figure 3.2 STEALTH Header Detail Legend # Function... -
Page 27: Connecting Multiple Headers
www.shsglobal.store Chapter 3 Rigging and Mechanical The following illustration offers more details of the STEALTH header. Header 400 mm Remove this “L” bracket for use with another Flush with Flush with header to the right. Outside of “L” Inside of “L” Figure 3.3 STEALTH Header More Details N O T E S... -
Page 28: Stealth Panel
www.shsglobal.store Chapter 3 Rigging and Mechanical STEALTH Panel Each STEALTH panel measures 398.5 mm (15.69”) long by 38.5 mm (1.52”) wide by 400 mm (15.75”) high and contains 256 LEDs in a 16 x 16 array. Multiple panels can be attached together to attain the desired screen size. The following information describes a STEALTH panel: Figure 3.5 STEALTH Panel Detail... -
Page 29: Connecting Multiple Stealth Panels
Multiple STEALTH panels can be easily connected via the included hinge assembly. Once connected, you can snap in/out individual panels as needed and even fold up the entire STEALTH curtain for transport. The following information describes the STEALTH v2.5 hinge assembly (a detailed illustration of the hinge connection follows): Legend #... - Page 30 Chapter 3 Rigging and Mechanical The following information describes the STEALTH v2.5 hinge connection assembly: Collar Slides Up to Accept Mating Pin Mating pin slides and locks in place. Figure 3.7 STEALTH Panel Hinge Connection Detail STEALTH® v2 User’s Guide...
-
Page 31: Folding Stealth Panels
www.shsglobal.store Chapter 3 Rigging and Mechanical Folding STEALTH Panels panels can be folded together as shown in If you are using the cable hinge, STEALTH the following illustration. Figure 3.8 Folding STEALTH Panel Assembly STEALTH® v2 User’s Guide... -
Page 32: Power & Data Connections
www.shsglobal.store Chapter 3 Rigging and Mechanical Power & Data Connections The power and data connections from the PDB-3 (PDB-3 – Power and Data Distribution, p. 2-9) to each STEALTH panel are daisy-chained within each column or row, depending upon your type of configuration. The first data connection is plugged into the top of a panel via the pigtail with the smaller LTW connector. -
Page 33: Appendix A : Specifications
www.shsglobal.store P P E N D I X PECIFICATIONS Appendix A This chapter covers the STEALTH system specifications and is divided into the following sections: • VP1 Specifications (p. A-2) • SP1 Specifications (p. A-3) • DD1 Specifications (p. A-4) •... -
Page 34: Vp1 Specifications
www.shsglobal.store Appendix A Specifications VP1 Specifications The following table lists the VP1 (Video Processing Unit) specifications: Item Specification Inputs Format Resolution 1024x768 SD-SDI 720x486 HD-SDI 720x486 Component 640x480 S-Video 720x486 Composite 640x480 Outputs 2xDVI 1024x768 Vertical Frequency 60 Hz Dimensions (H) 44.45 mm (1.75”/1U) (W) 482.6 mm (19”) (D) 266.7 mm (10.5”) -
Page 35: Sp1 Specifications
www.shsglobal.store Appendix A Specifications SP1 Specifications The following table lists the SP1 (Signal Processing Unit) specifications: Item Specification Inputs Format Resolution 1024x768 Outputs 2xFiber DVI (loop through) Vertical Frequency 60 Hz Dimensions (H) 44.45 mm (1.75”/1U) (W) 482.6 mm (19”) (D) 285.75 mm (11.25”) Weight 5.03 kg (11.1 lbs) -
Page 36: Dd1 Specifications
www.shsglobal.store Appendix A Specifications DD1 Specifications The following table lists the DD1 (Data Distribution Unit) specifications: Item Specification Input Fiber Outputs 6x Coaxial BNC 192,000 pixels (max) Dimensions (H) 44.45 mm (1.75”/1U) (W) 482.6 mm (19”) (D) 266.7 mm (10.5”) Weight 4.13 kg (9.1 lbs) Power... -
Page 37: Pdb-3 Specifications
www.shsglobal.store Appendix A Specifications PDB-3 Specifications The following table lists the PDB-3 (Power and Data Distribution) specifications: Item Specification DSU Specifications Inputs (data) (p. A-6) DSU Specifications Outputs (data) (p. A-6) Connectors (chassis mounted) Outputs (power) 48VDC via 4xSpeakon 2xLTW Connectors (via breakout cable) Max Cable Length 8 meters (between PDB-3 and STEALTH panel) (power &... -
Page 38: Dsu Specifications
www.shsglobal.store Appendix A Specifications DSU Specifications The following table lists the DSU (Data Supply Unit) specifications: Item Specification Inputs Coaxial via BNC Outputs Coaxial via BNC (loop through) 4xXLR (4 pin female) Dimensions (H) 44.45 mm (1.75”/1U) (W) 482.6 mm (19”) (D) 406.4 mm (16”) Weight 3.63 kg (8 lbs) -
Page 39: Stealth Panel Specifications
www.shsglobal.store Appendix A Specifications STEALTH Panel Specifications The following table lists the STEALTH panel specifications: STEALTH panel specifications Table 3.1 Item Specification Resolution 25 mm pixel pitch Colors Trillions (48-bit) Power 70 watts / panel Output 2400 nits (average) Transparency 60% (Aperture Ratio) Bezel Color Black or White... - Page 40 www.shsglobal.store P P E N D I X OFTWARE Appendix B This chapter covers the LedGuru software used for control of the STEALTH Video Processing Unit (VP1). This appendix is divided into the following major categories: • Communication Setup (p. B-2) •...
-
Page 41: Appendix B Ledguru Software
www.shsglobal.store Appendix B LedGuru Software Communication Setup The following is a list of the requirements for using LedGuru software: • Microsoft Windows-Compatible OS • Serial Port • Serial Cable A USB high speed serial adapter cable, such as the Keyspan model #USA-19HS, can be used to connect your computer to the VP1. -
Page 42: Input Tab
www.shsglobal.store Appendix B LedGuru Software Input Tab The LedGuru Input tab allows the user to select inputs and adjust various input parameters. Figure 3.10 LedGuru Input Tab The VP1 will accept three active video inputs simultaneously: analog, SDI and DVI. Any two of these inputs can be displayed simultaneously using the Main and Picture-in-Picture scaling channels. -
Page 43: Output Tab
www.shsglobal.store Appendix B LedGuru Software Output Tab The LedGuru Output tab lets the user adjust output image parameters. Figure 3.11 LedGuru Output Tab The following table describes the PDB-3 front panel functionality: Table 3.2 PDB-3 Front Panel Connector Info Legend # Item Input Cropping Adjustments Picture Scaling Adjustments... -
Page 44: Dvi Output
www.shsglobal.store Appendix B LedGuru Software The PAL and NTSC buttons can be used to set default crop values for these input sources. Figure 3.12 LedGuru Input Crop Settings N O T E Care should be taken to ensure that you do not attempt to select an area which is outside the boundaries of the input image since this will cause a corrupt output. -
Page 45: Frame Rate Conversion
www.shsglobal.store Appendix B LedGuru Software N O T E If the video input is changed from 50Hz to 60Hz you may at first see a juddering or corrupt output. It is necessary to select the appropriate DVI Output field rate – to match the input. -
Page 46: Pattern Generator
www.shsglobal.store Appendix B LedGuru Software Pattern Generator The internal pattern generator can be used to display various test patterns to help identify and locate screen faults. Most of the controls are self-explanatory. Figure 3.16 LedGuru Pattern Generator Tab When Probe Video Level is selected only the parts of the video image which have an 8-bit video data value equal to the current Level slider setting will be displayed at max video level (255). -
Page 47: File Load Save
www.shsglobal.store Appendix B LedGuru Software File Load Save The File Load/Save page allows the user to load and save VP1 setups to disk or internal memory. The VP1 stores all settings and adjustments in an active internal memory. This memory is automatically restored when the VP1 boots up. All user adjustments are automatically stored in the active memory. -
Page 48: Appendix C : Application Notes
www.shsglobal.store P P E N D I X PPLICATION OTES Appendix C This chapter offers you some hints and notes on using STEALTH. The following information is discussed: • SP1 Vertical Offset, (p. C-2) STEALTH® v2 User’s Guide... -
Page 49: Sp1 Vertical Offset
www.shsglobal.store Appendix C Application Notes SP1 Vertical Offset The SP1 provides 2 fiber outputs, each with a resolution of 1024x256. The vertical offsets for each fiber output port is limited by the lowest offset of it’s corresponding DD1 output channel. Vertical offsets are changed via the SP1 front panel menus. If any of the DD1 channels are set to a vertical offset of 0, whether they are used or not, that fiber output will only display the first 256 vertical pixels. - Page 50 www.shsglobal.store NDEX Numerics DVI, 1-2, 2-2, In, 2-3, 48VDC, Monitor, Out, 2-3, Aperture Ratio, DVI-D, Basic Signal Flow, EU 240V Power, 2-11 Bezel Color, Block Size, Fiber In, Brightness, 2-4, Fiber Optic, Fiber Optic Cable, Cable Attachment, Fiber Out, 2-5, CEE 17, 2-11 Flashing Red LED,...
