UltraLine II VDSL Gateway – Draft 1
030-300237 Rev. A
8/8/06
U
L
II VDSL G
(M
826010)
LTRA
INE
ATEWAY
ODEL
U
G
SER
UIDE
Copyright © 2006 Westell, Inc.
030-300237 Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 826010 and is the answer not in the manual?

Questions and answers

Related Manuals for Westell 826010

Summary of Contents for Westell 826010

  • Page 1 UltraLine II VDSL Gateway – Draft 1 030-300237 Rev. A 8/8/06 II VDSL G 826010) LTRA ATEWAY ODEL UIDE Copyright © 2006 Westell, Inc. 030-300237 Rev. A...

  • Page 2: Table Of Contents

    UltraLine II VDSL – Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide TABLE OF CONTENTS 1. PRODUCT DESCRIPTION ..........................4 2. SAFETY INSTRUCTIONS ...........................4 3. REGULATORY INFORMATION ........................5 FCC Compliance Note ..........................5 Canada Certification Notice........................6 4.
  • Page 3 UltraLine II VDSL – Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 15.2 Port Forwarding Configuration........................39 15.3 Port Triggering Configuration .........................44 15.4 ALG Configuration..........................45 15.5 IGMP Service ............................47 15.6 LAN Configuration..........................49 15.6.1 DHCP for Private LAN..........................49 15.6.2 DNS .................................51...

  • Page 4: Product Description

    To experience the Internet using your UltraLine II VDSL Gateway, simply connect the hardware, apply power, and perform the simple software configuration for your Internet connection. Hereafter, the Westell® UltraLine II VDSL Gateway will be referred to as the “Gateway” or the “Modem.” 2. SAFETY INSTRUCTIONS The following important safety instructions should be applied when using your telephone equipment.

  • Page 5: Regulatory Information

    You will be advised of your right to file a complaint with the FCC if you believe such action is necessary. If you experience trouble with this equipment (Model 826010), do not try to repair the equipment yourself.

  • Page 6: Canada Certification Notice

    If you experience trouble with this equipment (Model 826010) do not try to repair the equipment yourself. The equipment cannot be repaired in the field and must be returned to the manufacturer. Repairs to certified equipment should be coordinated by a representative, and designated by the supplier.

  • Page 7: Networking Requirements

    UltraLine II VDSL – Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 4. NETWORKING REQUIREMENTS The following system specifications are required for optimum performance of the Gateway via 10/100 Base-T Ethernet or Wireless. CONNECTION TYPE MINIMUM SYSTEM REQUIREMENTS •...

  • Page 8: Hardware Features

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 5. HARDWARE FEATURES 5.1 LED Indicators This section explains the LED states and descriptions of your Gateway. LED indicators can be used to verify the Gateway’s operation and status.

  • Page 9: Cable Connectors And Switch Locations

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 5.2 Cable Connectors and Switch Locations • Wireless IEEE 802.11b/g SMA connector and antenna • VDSL connector (RJ-11) • (4) Ethernet connectors (RJ-45) •...

  • Page 10: Installing The Hardware

    • RJ-11 telephone cable • (2) SMA antennas • Westell CD-ROM containing User Guide in PDF format • Quick Start Guide 6.3 Microfilters DSL (Digital Subscriber Line) signals must be blocked from reaching each telephone, answering machine, fax machine, computer modem or any similar conventional device. Failure to do so may degrade telephone voice quality and DSL performance.

  • Page 11: Hardware Installations

    2. When using a Microfilter, confirm that the VDSL RJ-11 phone cable is connected to the DSL port of the DSL/HPN non-filtered jack. 3. Westell recommends the use of a surge suppressor to protect equipment attached to the power supply. Use only power supply provided with your kit.

  • Page 12: Connecting Pcs Via Wireless

    Gateway and your PC’s wireless network adapter. The default SSID for the Gateway is the serial number of the unit (located below the bar code on the bottom of the unit and also on the Westell shipping carton). Locate and run the utility software provided with your PC’s Wireless network adapter and enter the SSID value.

  • Page 13: Setting Up Macintosh Os X

    Hardware.” 7.1 Opening the System Preference Screen After you have connected the Westell Gateway to the Ethernet port of your Macintosh, click the “Apple” icon in the upper-right corner of the screen and select System Preferences. 7.2 Choosing the Network Preferences After selecting System Preferences…, from the previous screen, the System Preferences screen will be displayed.

  • Page 14: Creating A New Location

    7.4 Naming the New Location After selecting New Location from the Network screen, the following screen will be displayed. In the field labeled Name your new location:, change the text from “Untitled” to “Westell.” Click OK. 030-300237 Rev. A August 2006...

  • Page 15: Selecting The Ethernet Configuration

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 7.5 Selecting the Ethernet Configuration If you clicked OK in the preceding screen, the Network screen will be displayed. The Network screen shows the settings for the newly created location.

  • Page 16: Accessing The Gateway's User Interface

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 7.7 Accessing the Gateway’s User Interface To access your Gateway’s user interface from your Macintosh, first start your web browser. Next, type http://dslrouter/ in the browser’s address bar and press Enter on your keyboard.

  • Page 17: Configuring Your Gateway For Internet Connection

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 8. CONFIGURING YOUR GATEWAY FOR INTERNET CONNECTION This section explains the procedures for accessing your VDSL Gateway, setting up you connection profile, and establishing a WAN connection with you Internet service provider (ISP).

  • Page 18: Confirming Your Vdsl Sync

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 8.2 Confirming Your VDSL Sync Your Gateway must first establish a VDSL sync with your service provider’s equipment in order to have Internet access.

  • Page 19: Setting Up Your Connection Profile

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 8.3 Setting Up Your Connection Profile After you have confirmed your VDSL sync, you are ready to set up your connection profile. When connecting to the Internet via PPP, you will use your connection profile to identify yourself to your ISP.

  • Page 20: 030-300237 Rev. A

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide At the Edit Connection screen, complete the following steps to set up your connection profile: 1. Type your Connection Name, Account ID and Account Password in the fields provided. The Account Password field will be masked with asterisks for security.

  • Page 21: 030-300237 Rev. A

    Connection Edit Connection Factory Default = MainPPP The name of the default connection profile. Westell recommends that you use the Default parameter. Connection Name This field allows you to enter a new connection name of your choice (up to 64 characters).

  • Page 22: Establishing A Wan Connection

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 8.4 Establishing a WAN Connection If you clicked Save (to save your connection profile) and then clicked Back in the preceding Connection screen, the following Enter Network Password screen will be displayed.

  • Page 23: 030-300237 Rev. A

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide The following screen displays Up in the PPP Status field. This indicates that MainPPP is the active connection profile and that you have established a PPP session with your ISP.

  • Page 24: 030-300237 Rev. A

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide After a PPP session has been established, you can browse the Internet. For example, to visit BellSouth’s home page, type http://bellsouth.com in your browser’s address bar, and then press Enter on your keyboard.

  • Page 25: Disconnecting Your Wan Connection

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 8.5 Disconnecting Your WAN Connection If you have finished browsing the Internet and want to disconnect from your Internet service provider, click Disconnect in the Connection screen.

  • Page 26: Basic Mode

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 9. BASIC MODE The following sections explain the basic configurations of your Gateway. The Gateway’s web pages contain a main navigation menu, displayed at the top of the screens. As you navigate through the various pages of the Gateway, the active page that you have selected from the menu options will appear in the left corner of the screen.

  • Page 27: Home

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 10. HOME 10.1 Connection The following screen will be displayed if you select Home > Connection from main menu. The Connection screen provides information about your Gateway’s connections. As explained in section 8, when the VDSL and WAN connection fields display UP, you have established a connection with your ISP and can browse the Internet, NOTE: The values displayed in this User Guide might differ from the actual values reported by your Gateway.

  • Page 28: Connection Summary

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 10.2 Connection Summary The following screen will be displayed if you select Home > Connection Summary from the menu options. Refer to this screen for information about your Gateway’s connections.

  • Page 29: Status

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 11. STATUS 11.1 About The following screen will be displayed if you select Status > About from the menu options. This screen displays the manufacturer’s information about your Gateway.

  • Page 30: Lan Devices

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 11.2 LAN Devices The following screen will be displayed if you select Status > LAN Devices from the menu options. This screen displays all the devices connected to your LAN.

  • Page 31: Wireless Stations

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 11.3 Wireless Stations The following screen will be displayed if you select Status > Wireless Stations from the menu options. This screen displays the information about the wireless stations that are associated with your Gateway.

  • Page 32: Diagnostics

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 12. DIAGNOSTICS The following screen will be displayed if you select Diagnostics from the menu options. This screen allows you to run diagnostic tests on your Gateway.

  • Page 33: 030-300237 Rev. A

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide If you click Test All, the following screen will be displayed, and the results will be displayed in the window labeled Test Results.

  • Page 34: 030-300237 Rev. A

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide Possible responses are: Success: The Router has successfully obtained the resolved address. The IP address is shown below the host name input box.

  • Page 35: Restart

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 13. RESTART The following screen will be displayed if you select Restart from the menu options. • To erase your stored configuration settings, click the check box labeled Reset device to configuration to factory defaults (a check mark will appear in the box).

  • Page 36: 030-300237 Rev. A

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide If you clicked OK in the preceding pop-up screen, the following screen will be displayed. Please wait a brief moment for your Gateway to restart. After your Gateway has restarted, the Edit Connection screen will be displayed.

  • Page 37: Advanced Mode

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 14. ADVANCED MODE The basic operations of your Gateway were discussed earlier in this User Guide and provided details on the Home, Status, Diagnostics, and Restart features. For instructions on configuring any of these features, refer to the Basic Mode sections (beginning with section 9).

  • Page 38: Configuration

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 15. CONFIGURATION 15.1 Firewall Configuration The following screen will be displayed if you select Configuration > Firewall from the menu options. If you change any settings in this screen, you must click Save to save the settings.

  • Page 39: Port Forwarding Configuration

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide If Enabled (box is checked), this function will be activated. Log all permitted outbound Factory Default = Disabled traffic If Enabled (box is checked), this function will be activated.

  • Page 40: 030-300237 Rev. A

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide To set up port forwarding, select a service from the Service Name drop-down menu. NOTE: You may add an unlimited numbers of services to your connection profile.

  • Page 41: 030-300237 Rev. A

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide Application Protocol The IP Protocol type that is assigned to this service. Start Port The start port that is assigned to the service...

  • Page 42: 030-300237 Rev. A

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide If you clicked the Details button, the following screen will be displayed. After viewing the details, click Back to return to the preceding Port Forwarding screen.

  • Page 43: 030-300237 Rev. A

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide If you clicked Delete in the preceding screen, a pop-up screen will prompt you to confirm your decision to delete the selected service. Click OK in the pop-up screen; the service will be removed from the list of selected services. Click Cancel if you do not want to delete the service.

  • Page 44: Port Triggering Configuration

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 15.3 Port Triggering Configuration The following screen will be displayed if you select Configuration > Port Triggering from the menu options. To create a trigger port, click New.

  • Page 45: Alg Configuration

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide Port Triggering Configuration Outgoing Protocol Factory Default = TCP The outgoing protocol for the triggered ports. Possible Responses: TCP – Transmission Control Protocol UDP –...

  • Page 46: 030-300237 Rev. A

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide If you clicked Edit, the following page will be displayed. To enable SIP ALG service configuration, click the box labeled Enable (a check mark will appear in the box). Next, enter the desired values in the fields provided and click Save to save your settings.

  • Page 47: Igmp Service

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide 15.5 IGMP Service The following screen will be displayed if you select Configuration > IGMP from the menu options. This screen enables you to configure the IGMP services for your Gateway. Enter the appropriate settings and then click Save Settings to save the settings.

  • Page 48: 030-300237 Rev. A

    UltraLine II VDSL– Draft 1 030-300237 Rev. A 8/8/06 UltraLine II VDSL Gateway (Model 826010) User Guide Unsolicited Report Interval The interval between unsolicited reports on a WAN when first going a group (1- 100, in tenths of a second).

  • Page 49: Lan Configuration

    Gateway interacts with local devices to which it is connected. NOTE: Westell recommends that you do not change these settings unless your service provider instructs you to do so. To enable DHCP for Private LAN, do the following: 1.

  • Page 50: 030-300237 Rev. A

    This setting allows the Gateway to automatically assign IP addresses to local devices connected on the LAN. Westell advises setting this to Enabled for the private LAN. Note: When Enabled (box is checked), DHCP addresses will be saved into the Private LAN configuration.
