Osaki Power Tools IDH013 Operator's Manual

OSA-279-9660K_Instructions.qxd 11/11/2010
Model Number IDH013
Order Code OSA-279-9660K
Motor Input Capacity
Motor Supply Voltage 230V-240V/50Hz
No Load Speed 0-1100 & 0-3000RPM
Chuck Size 13mm (
Drilling Capacities Steel 13mm/
Concrete 16mm / Wood 30mm
• Product details may vary due to product development.
• We reserve the right to change specifications without notice.
DECLARATION OF CONFORMITY
We hereby certify that OSAKI Impact Drill 1050W - IDH013
complies with all the relevant provisions of the following directives:
Electromagnetic Compatibility 2004/108/EC, Low Voltage 2006/95/EC and Machinery 2006/42/EC.
EN 60745-2-1/A1: 2003+A11: 2007+A1: 2009+A12: 2009, EN 60745-1: 2006, EN 60745-2-1: 2003+A11: 2007,
EN 61000-3-3: 1995/+A1: 2001/+A2: 2005, EN 61000-3-2: 2006, EN 55014-1: 2006,
EN55014-2: 1997/+A1: 2001,
Official Agent: KENNEDY TOOLS, Wigston, Leicester, England.
ISO 9001 REGISTERED COMPANY
QUALITY GUARANTEE & WARRANTY
OSAKI POWER TOOLS carry a one year manufacturers warranty.
OSAKI POWER TOOLS are designed & produced to the highest standards & specifications.
OSAKI POWER TOOLS are fully guaranteed against faulty materials & workmanship.
Should they be found to be defective, they will either be repaired or replaced free of charge
(fair wear and tear and/or misuse excepted). This does not affect your legal rights.
Please retain supplier invoice as proof of purchase.
OSAKI POWER TOOLS are designed for DIY and hobby use only.
They are not covered by an industrial warranty. Industrial use will invalidate this guarantee.
OSAKI TOOLS Official Agents - JAPAN: MIKI TOOL TRADING CO. MIKI CITY, JAPAN.
EUROPE, MIDDLE EAST, AMERICA & AFRICA: KENNEDY TOOLS, WIGSTON, ENGLAND.
Specifications may change without prior notice. E&EO
Osaki, Osaki Xtra-plus and the round Mitsudomoe logo are trade marks of Osaki Tools.
© The Kennedy Group Ltd. 08/10
14:11 Page 1
SPECIFICATIONS
Vibration Level
Sound Level
1050W Sound Power
Protection Class
Overall Size (HxWxD) 360 x 260 x 100mm
1/ 2 ") Net Weight
DECLARATION
Standards applied:
<0.3m/s 2
93dB(A)
104dB(A)
IP20
3.4kg
IMPACT DRILL 1050W 13MM CHUCK
Suitable for DIY & hobby use.
Powerful 1050W motor, 230-240V/50Hz supply.
13mm Chuck capacity.
Variable speed forward and reverse.
Heavy duty 2 speed gearbox.
Switches easily from rotary to impact action.
Locking side handle with integral metal depth stop.
Drilling Capacities:
Steel 13mm
Concrete 16mm
Wood 30mm.
READ and UNDERSTAND the manual before using. Failure to follow
all instructions may result in electric shock, fire and/or serious personal injury.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
ORDER CODE: OSA-279-9660K
OPERATORS MANUAL
WARNING:
MODEL: IDH013
