  • Page 1 Security Board BNX-H110 Always at the forefront of innovation User Manual...

  • Page 2: Copyright

    Copyright This publication contains information that is protected by copyright. No part of it may be reproduced in any form or by any means or used to make any transformation adaptation without the prior written permission from the copyright holders. This publication is provided for informational purposes only.

  • Page 3: Warranty

    Warranty 1. Warranty does not cover damages or failures that are raised from misuse of the product, inability to use the product, unauthorized replacement or alteration of components and product specifications. 2. The warranty is void if the product has been subject to physical abuse, improper installation, modification, accidents or unauthorized repair of the product.

  • Page 4: Safety Measures

    Safety Measures To avoid damage to the system: • Use the correct AC input voltage range. To reduce the risk of electric shock: • Unplug the power cord before removing the system chassis cover for installation or servicing. After installation or servicing, cover the system chassis before plugging the power cord.

  • Page 5: Table Of Contents

    Table of Content Copyright ..................................2 Trademarks ..................................2 FCC and DOC Statement On Class A ..........................2 Warranty ..................................3 Static Electricity Precautions ............................3 Safety Measures ................................4 Before Using the System Board ............................. 4 Table of Content ................................5 Chapter 1 General Information 1.1 Main Feature ................................
  • Page 6 Chapter 5 Programming Guide 5.1 Bypass Setting ..............................46 5.2 GPIO ................................50...

  • Page 7: Chapter 1 General Information

    Chapter 1 General Information...

  • Page 8: Main Feature

    1.1 Main Feature Network Security Board BNX-H110 is a Network Security Board, featuring on Intel® H110 chipset, supports Intel® Gen-6 LGA1151 Celeron®, Pentium®, Core®-i3/i5/i7 processors that carry the built-in Intel® HD Graphic engine. Below is a brief list of available processors as a quick reference:...

  • Page 9: Specifications

    1.2 Specifications Core Engine Chipset Intel® H110 PCH Processor Support Intel® Gen-6 Skylake Core i3, i5, i7, Pentium® , Celeron® Processor Single LGA1151 Processor Socket Memory 2x DDR4 2133 ECC/Non-ECC Unbuffered DIMM Slots, up to 32GB Display Intel® HD Graphic 510/530 Ethernet Controller 6x Onboard Intel®...

  • Page 10: Optional Lan Modules

    1.3 Optional LAN Modules BEM-H110-350-C4 Type LAN Module Chipset Intel® i350-AM4 Interface PCIe 2.0 X4 Network Port Four RJ45 1G BEM-H110-350-C4-B Type LAN Module Chipset Intel® i350-AM4 Interface PCIe 2.0 X4 Network Port Four RJ45 1G Bypass 2-Pair BEM-H110-580-C8 Type LAN Module Chipset Dual Intel®...

  • Page 11: Board Layout

    1.4 Board Layout Figure 1.1: Board Layout of BNX-H110...
  • Page 12 Chapter 2 Preparation...

  • Page 13: Before You Begin

    2.1 Before You Begin A stable and clean working environment are essential. Dust and dirt can get into components and cause a malfunction. Use containers to keep small components separated. Adequate lighting and proper tools can prevent you from accidentally damaging the internal components. Most of the procedures that follow require only a few simple tools, including the following: A Philips screwdriver ...

  • Page 14: Setting Jumpers

    A jumper is the simplest kind of electric switch. It consists of two metal pins and a cap. When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is SHORT.

  • Page 15: Edge Connectors

    2.4 Edge Connectors Micro-USB Port Power/Reset Switch RJ45 Console Port Six RJ45 Gigabit LAN Ports Dual Bypass LEDs Dual USB 3.0 Ports Power LED & HDD LED...

  • Page 16: Location Of Jumpers And Connectors

    2.5 Locations Of Jumpers and Connectors...
  • Page 17 List of Onboard Connectors Jumpers SATADOM Power Enable Jumper Watchdog Enable Jumper Clear CMOS Jumper Chassis Intrusion Jumper Bypass Enable Jumper for LAN2-LAN3 Bypass Enable Jumper for LAN4-LAN5 JP11 Auto Power Button Jumper JP13 Power/Reset Switch Selection Jumper JP14 GPIO Power Selection Jumper...
  • Page 18 Connectors SMBus Pin Header Bypass MCU Firmware Update Header Bypass MCU Firmware Update Header JP10 Bypass CPLD Firmware Update Header JP12 Auto Power Button MCU Firmware Update Header SYS_Fan1 SYS_Fan2 HDMI Connector USB 3.0 Connector DDR4 DIMM0 DDR4 DIMM1 2X2 ATX +12V Connector 24pin ATX Connector SATA1 Connector SATA0 Connector with 5V on Pin7 for SATADOM...

  • Page 19: Jumpers

    2.6 Jumpers ► SATADOM Power Enable Jumper (JP2) Definition Power Enabled Power Disabled ► Watchdog Enable Jumper (JP3) Definition Close Enabled Open Disabled ► CMOS Jumper (JP4) Definition Normal Operation (default) Clear CMOS ► Chassis Intrusion Jumper (JP5) Definition Close Enabled Open Disabled...
  • Page 20 ► Bypass Enable Jumper for LAN4-LAN5 (JP7) Definition Enabled Disabled ► Auto Power Button Jumper (JP11) Definition 1-2 Close, 3-4 Close Enabled Open Disabled ► Power/Reset Switch Selection Jumper (JP13) Definition Power Switch Reset Switch ► GPIO Power Selection Jumper (JP14) Definition 3.3V...

  • Page 21: Internal Connectors

    2.7 Internal Connectors SMBus Pin Header (JP1) Definition Definition SMB CLK SMB Data SMB Alert VCC3 (+3.3V) Bypass MCU Firmware Update Header (JP8) Definition Definition VPP_B VCC (+5V) ICSPDAT_B ICSPCLK_B Bypass MCU Firmware Update Header (JP9) Definition Definition VPP_A VCC (+5V) ICSPDAT_A ICSPCLK_A Bypass CPLD Firmware Update Header...
  • Page 22 Auto Power Button MCU Firmware Update Header (JP12) Definition Definition 5VSB ICSPDAT ICSPCLK SYS_Fan1 (J1) Definition Definition +12V SYSFanIn1 SYSFanOut1 SYS_Fan2 (J2) Definition Definition +12V SYSFanIn2 SYSFanOut2 HDMI Connector (J3) Definition Definition HDMI_BP_TXP0 HDMI_BP_TXN0 HDMI_BP_TXP1 HDMI_BP_TXN1 HDMI_BP_TXP2 HDMI_BP_TXN2 HDMI_BP_CLKP HDMI_BP_CLKN HDMI_SCL HDMI_SDA HDMI_HPD...
  • Page 23 USB 3.0 Connector (J4) Definition Pin Definition VCC_USB1 USB3_P3_RX_DN_R USB3_P3_RX_DP_R USB3_P3_TX_DN_R USB3_P3_TX_DP_R USB_P3_DN_R USB_P3_DP_R USB_P4_DP_R USB_P4_DN_R USB3_P4_TX_DP_R USB3_P4_TX_DN_R USB3_P4_RX_DP_R USB3_P4_RX_DN_R VCC_USB1 Onboard COM2 Connector (J14) Definition Definition F_DSR_N F_SIN F_RTS_N F_SOUT F_CTS_N VCC (+5V) F_RI_N F_DTR_N F_DCD_N TPM Connector (J15) Definition Pin Definition TPM_LPC1CLK_24M...
  • Page 24 Front Panel Connector (J16) Definition Pin Definition VCC (+5V) VCC (+5V) HDD_LED PWRSW SYSRST# DEFAULT- 3Vdual (+3.3V) 3Vdual (+3.3V) PCH_GPD11 PCH_GPD9 Port 80 Connector (J17) Definition Pin Definition LPC_AD0 VCC3 (+3.3V) LPC_AD1 LPC_PLT_RST# LPC_AD2 LPC_FRAME# LPC_AD3 80H_LPC1CLK_24M GPIO Connector (J18) Definition Pin Definition SIO_GP67...
  • Page 25 Factory Default + Power/Reset Switch Up: Power Switch/Reset Switch (SW1) Down: Factory Default...

  • Page 26: Chapter 3 Operation

    Chapter 3 Operation...

  • Page 27: System Memory

    3.1 System Memory BNX-H81 has Intel® H81 chipset built-in, and supports dual channel non-ECC, un-buffered DDR3- 1066/1333/1600MHz memory modules. Two DIMM slots support up to 16GB Memory Capacity. 3.2 Installing Memory To install Memory 1. Open up the two side tabs on the slot. 2.
  • Page 28 4. To remove the Memory modules, please push the tabs outwards, and the memory modules will be automatically disengaged.

  • Page 29: Installing Lga1150 Intel® Core-I Cpu, Heat Sink, And Fan

    3.3 Installing LGA1151 Intel® Core-i CPU, Heatsink, and Fan BNX-H110 supports Intel® LGA1151 Gen-6 Core-i Processor. For a reference list of supported processor, please refer to the specification section. The socket 1151 is formed up with sensitive arrays of pins, improper or careless installation may cause permanent harm to the socket pins.
  • Page 30 Step (B): Install the Processor 1. Hold the processor with your thumb and index finger as shown to align your fingers with the socket cutouts. 2. Make sure that the processor Pin#1 indicator (gold triangle) is aligned with the Pin#1 chamfer on the socket. 3.
  • Page 31 Step (D): Install a Heatsink Note: Heatsinks that come with boxed Intel® processors use pre-applied Thermal Interface Material (TIM) and do not need thermal grease. If a different heatsink is used, please refer to manufacturer’s instructions. 1. Place the heatsink onto the processor socket.

  • Page 32: Adding Power Connectors

    3.4 Adding Power Connectors BNX-H110 motherboard requires correct power plan to properly support Intel® LGA1151 Gen-6 Core-i Processor. Please add the 24-pin ATX Power Connector on the blue connector, and 4-pin 12Vdc Power Connector on the red connector. In case the 12Vdc Power Connector is not added, power supply will be triggered, but the motherboard would...

  • Page 33: Adding Compactflash Cards

    3.5 Add CompactFlash Card  Please do not add CFast card onto this socket.  Make sure to shut down the system board before adding your CompactFlash card.

  • Page 34: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup...

  • Page 35: About The Bios

    About the BIOS The BIOS (Basic Input and Output System) Setup program is a menu driven utility that enables you to make changes to the system configuration and tailor your system to suit your individual work needs. It is a ROM-based configuration utility that displays the system’s configuration status and provides you with a tool to set system parameters.

  • Page 36: Entering Setup

    4.1 Entering Setup When the system is powered on, the BIOS will initiate the Power-On-Self-Test (POST) routines. These routines perform various diagnostic checks. If an error is encountered, the error will be reported in one of two different ways: If the error occurs before the display device is initialized, a series of beeps will be transmitted. ...

  • Page 37: The Main Menu

    4.4 The Main Menu Figure 4-1: BIOS Setup Utility Main Menu The menu bar on the top of the first screen has the following submenus: ➢ Main: Basic system configuration. ➢ Advanced: Advanced system settings. ➢ Chipset: Other functions. ➢ Security: Configure Supervisor and User Password ➢...

  • Page 38: The Advanced Menu

    4.5 The Advanced Menu In this section, you may set the configurations for the following items: Super IO Configuration, H/W Monitor, Serial Port Console Redirection, and CSM Configuration. Super IO Configuration Serial Port 1/2 Configuration Serial Port This setting enables/disables the specified serial port. Change Setting Select an optimal setting for Super I/O devices.
  • Page 39 H/W Monitor Display CPU/System Temperature, Fan speed, and voltages. Fan Speed Control Mode Configure Fan Speed Control Mode. Serial Port Console Redirection Console Redirection Enables or disables Console Redirection function. CSM Configuration Boot option filter This controls Legacy/UEFI ROMs priority. Network Control the execution of UEFI and Legacy PXE OpROM.

  • Page 40: The Chipset Menu

    4.6 The Chipset Menu CPU Configuration Display CPU Information...
  • Page 41 System Agent (SA) Configuration PEG Port Configuration PEG Port Options Memory Configuration Display memory size / Frequency SATA Configuration SATA Controller(s) Enable or disable SATA Device.

  • Page 42: The Security Menu

    4.7 The Security Menu Administrator Password Set Administrator Password. User Password Set User Password.

  • Page 43: The Boot Menu

    4.8 The Boot Menu Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting. Bootup NumLock State Select the keyboard NumLock state. Quiet Boot Enables or disables Quiet Boot option. FIXED BOOT ORDER Priorities Set the system boot order...

  • Page 44: The Save & Exit Menu

    4.9 The Save & Exit Menu Save Changes and Reset Reset the system after saving the changes. Discard Changes and Reset Reset system setup without saving any changes. Restore Defaults Restore/Load Default values for all the setup options. Launch EFI Shell from filesystem device Attempts to Launch EFI Shell application (Shell.efi) from one of the available filesystem devices...
  • Page 45 Chapter 5 Programming Guide...
  • Page 46 Get the driver files Please download Bypass driver files from Bestek web-site, unzip the file, and copy the folder to your Linux file system. You will need the root access right to complete the job. Please logon to root now.
  • Page 47 Configuring Bypass pair #1 Bypass pair #1 is defined with network Port #3 and Port #4, as the picture below, where Port #3 is connected internet and Port #4 is connected to a notebook. Also, Bypass pair #1 is now at “PassThrough” mode (the bottom Bypass LED is green) and the network connection is not available.
  • Page 48 Configuring Bypass pair #2 Bypass pair #2 is defined with network Port #5 and Port #6, as the picture below, where Port #5 is connected internet and Port #6 is connected to a notebook. Also, Bypass pair #2 is now at “PassThrough” mode (the top Bypass LED is green) and the network connection is not available.
  • Page 49 Configuring Bypass at “Bypass” mode at boot up To set Bypass pair #1 at “bypass” mode, go to the folder g3bp0, and issue this command: echo 1 > nextboot To set Bypass pair #2 at “bypass” mode, go to the folder g3bp1, and issue this command: echo 1 >...
  • Page 50 Get the driver files Please download GPIO driver files from Bestek web-site, unzip the file, and copy the folder to your Linux file system. You will need the root access right to complete the job. Please logon to root now.
  • Page 51 Example #1 (GPI Test) Script name: GPI_Test.sh Definition of the test: This tests demonstrates how to read the GPIO pin value. The pin #2, #4, #6, #8 are defined as GPO pins with value low. The pin #1, #3, #5, #7 are defined as GPI pins. A few jumpers will be added onto pin #1-#2, #3-#4, #5-#6, #7-#8 so pin #1 will read the value of pin #2, pin #3 will read the value of pin #4, …, etc.
  • Page 52 Now move these two jumpers onto #3-#4 and #7-#8. Pin #3 and pin #7 will now read value [low]. Users are welcome to configure this GPI script for other programming jobs.
  • Page 53 Example #2 (GPO Test) Script name: GPO_Test.sh Definition of the test: This tests demonstrates how to set the GPIO pin value as [high] or [low]. The pin #2, #4, #6, #8 are defined as GPO pins with value low. The pin #1, #3, #5, #7 are defined as GPO pins and the values will be changed throughout the script. Four LEDs are added onto pin #1-#2, #3-#4, #5-#6, #7-#8.
