TECHNICAL
TECHNICAL
GUIDE
GUIDE
TECHNICAL GUIDE
PREMIUM SERIES
SPLIT-SYSTEM HEAT PUMPS
18 SEER – R-410A – 1 PHASE
2 THRU 5 NOMINAL TONS
MODELS: HL8B024 THRU 060
® ®
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at
www.upgnet.com and www.fraserjohnston.com
Additional rating information can be found at
www.ahridirectory.org
WARRANTY SUMMARY*
Extended 10-Years limited parts warranty.
Extended Lifetime limited compressor warranty.
Extended parts and compressor warranties require online reg-
istration within 90 days of purchase for replacement or closing for
new home construction.
*Does not apply to R-22 models, 3-Phase models, or internet sales.
See Limited Warranty certificate in User's Information Manual for details.
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
DESCRIPTION
The 18 SEER Series unit is the outdoor part of a versatile climate
system. It is designed with a matching indoor coil component
from Johnson Controls Unitary Products. Available for typical
applications, this climate system is supported with accessories
and documents to serve specific functions.
FEATURES
Superior Coil Protection - A stamped, decorative metal coil
guard protects the tube-in-fin coil from debris and other damaging
material.
Protected Compressor - The compressor is safeguarded
against abnormal pressures and temperatures by an internal
pressure relief valve, an internal temperature sensor, and factory
high and low pressure system controls. A factory installed liquid
line filter-drier further protects the compressor against moisture
and debris.
Environmentally Friendly Refrigerant - The next generation
refrigerant R-410A delivers environmentally friendly performance
with zero ozone depletion.
Durable Finish - An automotive quality finish provides the ulti-
mate protection from harmful UV rays and rust creep, ensuring a
long-lasting, high quality appearance. A powder-paint topcoat is
applied over a baked-on primer using a galvanized, zinc coated
steel base material. The result is a finish that has been proven in
testing to provide 33% greater durability than conventional pow-
der-coat finishes.
Hot Heat Pump - An optional mode that slows the indoor fan for
higher register air temperatures and premium comfort.
Sound Reducing System - Features combination of swept-wing
fan, composite base pan, isolated compressor compartment, and
two-stage compressor to reduce overall sound to a mere whisper.
Low RPM ECM Fan Motor - Helps to reduce airflow noise.
Swept Wing Fan - A fan design boasting technology adapted
from aeronautic and defense engineering provides for whisper-
quiet operation by allowing air to flow smoothly and efficiently
across the fan tips.
Composite Base Pan - The strong and durable composite base
pan provides added strength while resisting rust and corrosion,
as well as reducing sound and vibration.
Isolated Compressor Compartment - A molded composite
bulkhead isolates the refrigeration components and the compres-
sor from the rest of the unit, reducing sound and vibration.
Lower Installed Cost - Designed to provide enhanced installabil-
ity by featuring a slide-down control compartment that allows
easy access to control components, along with angled service
valves to reduce overall installation time and cost.
charged for a 15 foot lineset.
Factory Installed Filter-Drier - A factory installed, solid core liq-
uid line filter-drier removes harmful debris and moisture from the
system.
Easy Service Access - A full end, full service access panel with
handle makes for easy entry to internal components.
Communications Capable - Requiring only a simple 4-wire
installation, the communicating capability enables the use of the
Touch Screen Communicating Control, allowing real time visibility
of system operation and the use of diagnostic features, while still
maintaining the ability to function with a traditional thermostat.
Complete System Control - These heat pumps utilize an
unique microprocessor defrost control system to provide optimal
comfort as well as monitor the overall system for reliable opera-
tion. In the event improper operating conditions occur (high tem-
perature and/or high pressure), the system will automatically shut
the system down to extend the life of the heat pump. The defrost
control features an internal memory to aid the technician in trou-
bleshooting, reducing service time and cost.
Premium System Warranty - Limited lifetime compressor war-
ranty when registered online within 90 days of installation.
Agency Listed - Safety certified by CSA to UL 1995 / CSA 22.2.
Performance certified to ANSI/AHRI Standard 210/240 in accor-
dance with the Unitary Small Equipment certification program.
1109434-FTG-A-0714
Factory
