- Page 1 MRS-1000 RADAR SYSTEM INSTALLATION MANUAL DOCUMENT VERSION 1.0 AUGUST 2015...
- Page 3 DESCRIPTION OF MRS-1000 RADAR STATION PRECAUTIONS AND SAFETY MEASURES INSTALLATION CONNECTING +24 V POWER TECHNICAL SUPPORT...
- Page 4 MRS-1000- RU) and communication cable MRS-1000- СС interconnecting the rotation unit and communication unit. Installed indoors are: communication unit MRS-1000-СU, power cables as well as Ethernet cable providing intercommunication of these units. Power supply CAUTION! The antenna unit and rotation unit are...
- Page 5 PRECAUTIONS AND SAFETY MEASURES The MRS-1000 radar system may only be oper- ated by employees who have read and under- stood this installation manual, as well as the NO PERSONNEL SHALL BE ALLOWED TO Safety Rules for Operation of Powered Electri- REMAIN IN THE NEAR VICINITY OF THE cal Equipment.
- Page 6 INSTALLATION Do the following before the installation: Since no ideal visibility can be achieved for the To avoid any ghost targets and directional whole radar-controlled area, the installation pattern distortion due to rereflection, it is good • Open the package and remove the site should be chosen to maximize coverage to install radar clear off of planar reflectors system components.
- Page 7 Installation site must be a rigid platform with six bores, identical to fastener holes of MRS-1000-RU. The platform should be pole- mounted and should not exceed ±5° from horizontal. The surrounding site should be fall- safe for personnel to mount and dismout the radar.
- Page 8 INSTALLATION Installation of the transceiver unit Lift the antenna unit and the rotation unit to the installation site. WARNING! IT IS STRICTLY FORBIDDEN TO USE THE Use template to mark the rigid platform prepared ANTENNA UNIT FOR SUPPORTING THE for the installation of the rotation unit. RADAR DURING TRANSPORTATION! Install the rotation unit.
- Page 9 INSTALLATION Fasten the rotation unit firmly using six M8 Connect the grounding cable to the grounding Place the antenna unit onto the rotation screws. screw. unit carefully (be sure not to damage the connector) and fasten it with four M8 screws. Grounding screw fig.
- Page 10 INSTALLATION Connecting the communication cable Connect the communication cable to the connector of the rotation unit. WARNING! The minimum cable bending radius must be at least five times the diameter of the cable. The cables must be protected from heat and mechanical damage. WARNING! Connector Try to avoid laying the interface cable close...
- Page 11 INSTALLATION Communication unit installation Communication unit should be installed CAUTION! CAUTION! indoors with temperature range minus 10 to plus 40 °С. Make sure there’s no acid vapours and To avoid mechanical damage to radar other corrosive fumes indoors where units, make sure there’s no construction 220 VAC or +24 V power lines should be radar units are to be installed.
- Page 12 INSTALLATION Connect the grounding cable to the grounding terminal. GND connector Loosen the external nut of the cable gland on the communication unit and pass the commu- Fuse 24VDC nication cable through the gland. 220VAC 24VDC connector Ethernet connector Cable gland nut fig.
- Page 13 INSTALLATION Arrange the cable carefully and fix it with retaining brackets inside the communication unit, then close the protective cover of the communication unit. Tighten the cable gland nut and drive in two M3 screws using a HEX2.5 allen wrench. Front-side view fig.
- Page 14 CONNECTING +24 V POWER The radar system can be powered from a 24V DC power source. WARNING! When the radar is connected to both 220V and 24V sources, power is supplied from the 220V source. If the 220V source loses power, the radar station switches to the 24V power source automatically.
-
Page 15: Technical Support
Should you encounter any problems in the course of radar operation, you can contact our Customer Support. When making a call, be ready to name your organization owning the radar and the radar model. Contact information of Technical Support in Tomsk, Russia: E-mail: radar_service@micran.ru... - Page 16 E-mail: sales@micran.com Phone: +7 (3822) 900-029, +7 (3822) 413-403, +7 (3822) 413-406 Fax: +7 (3822) 423-615 Mailing address: Micran, Kirova Ave., 51d, Tomsk, Russia, 634041 www.micran.com...
