- Page 1 Please read this owner's manual carefully before operating, and keep it for reference. PORTABLE UNIT OWNER’S MANUAL MODÈLES GPH12AE-A3NNA8A 13-04707 WWW.GREE.CA St-Mathieu-de-Beloeil (Québec) Canada 1-866-680-GREE © Copyright, Sunrise Tradex Corp., 2011 00525-11/10/11...
-
Page 2: Table Of Contents
13. INSTALLATION AND MAINTENANCE OF HEALTHY FILTER ......21 14. WARRANTY ....................22 Thank you for selecting a Gree product By purchasing a room air conditioner, you not only get comfort, but also good health. These operating instructions present the various features your unit has to offer. In addition, they provide important maintenance and service information as well as tips to operate the unit more economically. -
Page 3: Summary
SUMMARY This PORTABLE AIR CONDITIONER is a small, movable air conditioner. It can be run in COOL, DRY and the various ventilation modes, and can be moved when desired. It is great for home and office use, and especially for houses with several rooms. Given its compact configuration, excellent workmanship and elegant appearance make one superior product. -
Page 4: Structure
STRUCTURE Front Air outlet Handle Control panel Rear Upper air inlet grill Heat air exhaust vent Lower air inlet grill Power cord... -
Page 5: Operating Instructions
OPERATING INSTRUCTIONS USAGE NOTICE • The temperature range in the COOL and DRY modes is between 16°C (61°F) and 30°C (86°F). • The Max Cooling temperature for the air conditioner is 35°C (95°F). Unpacking the air conditioner WARNING Excessive Weight Hazard •Use two or more people to move and install the air conditioner. - Page 6 • For safety reasons, please unplug your unit when it is not in use. • Please see the following table for circuit breaker capacity. (Caution: do not use the fuse alone to protect the circuit.) Air-conditioner Circuit breaker capacity GPH12AE-A3NNA8A...
- Page 7 OPERATING INSTRUCTIONS Control panel functions GPH12AE-A3NNA8A: DRY mode COOL mode LED screen HEAT mode FAN mode ON/OFF key MODE key Control panel and the function 1. "ON/ OFF " button Press once to start and press once more to stop the unit.
-
Page 8: Functions Of Displayer And Panel
OPERATING INSTRUCTIONS 1) Select a location near a door or COOL mode window. Install the exhaust duct. 2) Press "MODE" to select the "COOL" mode. 3) Press ‘‘▼’’ or ‘‘▲’’ to set the suitable temp. between 16°C (61°F) ̴ 3 0°C (86°F). - Page 9 PARTS AND FUNCTIONS OF THE REMOTE CONTROL NOTE: Be sure that there are no obstructions between the receiver and the remote control. Do not drop or throw the remote control. Do not let the remote control get wet and keep the remote control out of direct sun light or extreme heat.
-
Page 10: Parts And Functions Of The Remote Control
PARTS AND FUNCTIONS OF THE REMOTE CONTROL NOTE: This is a universal remote control and can be used for different units. The buttons that do not apply to this unit will not be described below. TIMER Timer button AUT O •... - Page 11 PARTS AND FUNCTIONS OF THE REMOTE CONTROL NOTE: This is a universal remote control and can be used for different units. The buttons that do not apply to this unit will not be described below. X-FAN X-FAN button AUT O •...
-
Page 12: How To Use The Remote Control
HOW TO USE THE REMOTE CONTROL Operating Instructions - General Operation ON/OFF MODE 1.Press ON/OFF to turn the unit on after connecting the ON/OFF MODE main unit to the power supply. (Note: Every time the unit is turned on, the large and small louvers will close at first.) 2.Press MODE to select desired running mode. - Page 13 HOW TO USE THE REMOTE CONTROL ★ About AUTO RUN When the AUTO RUN mode is selected, the temperature setting will not be displayed on the LED screen. The unit automatically selects the suitable running mode based on the room temperature. ★...
-
Page 14: Exhaust Hose Accessories And Installation
EXHAUST HOSE ACCESSORIES AND INSTALLATION ● The exhaust pipe should be 50~150cm long. It is recommended to use the shortest length. ● When installing, the exhaust pipe should be as flat as possible. Don't stretch the pipe or connect it to another exhaust pipe, which will affect how the unit runs and damage Correct installation is shown in figure (When installing it on a wall, position about 40 -100cm from floor). - Page 15 EXHAUST HOSE ACCESSORIES AND INSTALLATION If the pipe must be bent, please install it based on the following dimensions. 55 cm 55 cm Incorrect installation is shown in the following figure. (If the pipe is bent too much, it will cause a malfunction.)
- Page 16 EXHAUST HOSE ACCESSORIES AND INSTALLATION PARTS INCLUDED Rear plastic pipe end Front plastic pipe end Window exhaust adapter Flexible exhaust hose...
-
Page 17: Care And Maintenance
CARE AND MAINTENANCE Portable unit There are wheels at the bottom of the unit that enable it to be moved from room to room as needed. Air inlet grill AVERTISSEMENT Before cleaning, please pull out the power plug and turn off the power supply to avoid electric shock. -
Page 18: Electric Schematic Diagram
Do not use gasoline, diesel oil or similar substances to clean the unit. Before cleaning, pull out the power plug. ELECTRIC SCHEMATIC DIAGRAM GPH12AE-A3NNA8A: The circuit diagrams above are only for reference, which are subject to change without notice. -
Page 19: Troubleshooting
TROUBLESHOOTING If a malfunction occurs, please check the following before servicing the unit: Troubles Possible Causes Solutions The power supply is not properly 1. Insert the power plug tightly. The air connected. 2. Replace the power plug or socket. conditioner The power plug is not inserted tightly. -
Page 20: User Notices
USER NOTICES Location • Do not install the unit in a sealed off location. Be sure there is good ventilation to prevent malfunction. • Do not install the unit in direct sunlight, to prevent fading and a reduction of efficiency. •... -
Page 21: After Sales Service
• Do not tilt or turn over. If this occurs, remove the power plug immediately and inform the dealer to verify and service the unit. • Do not use insecticide or other sprays, as they can deform or crack the unit. •... -
Page 22: Installation And Maintenance Of Healthy Filter
INSTALLATION AND MAINTENANCE OF HEALTHY FILTER Installation Instruction 1. Press the handle of air inlet grill and pull outwards to remove. Handle Healthy filter Filter Air inlet grill Fig. a 2. Insert the healthy filter into the air inlet grill as shown in Fig.b. Healthy filter Fig. -
Page 23: Warranty
Note : The internal compressor is covered by a 5-YEAR limited warranty. During the warranty period, if this air conditioner fails under normal use, GREE will, at its option, either repair the unit or replace it, free of charge, within a reasonable period of time after the air conditioner is returned.
