Rc
¥2
wl
@
@
&
Mosnt
the bacl{ pZate on_/
7_
Mount
the bad< plate
using the screws
and
anchors
provided,
or if possible,
use the
existin{ t anchors that are already
in the wall
Make sure the _
symbol
on the back
plate is pointing
upward.
Conrtect _JAres
Open
the terminal
latches up to allow the wires
to be inserted
into the holes. Push each wire into
the hole of the terminal
that has the same label
as the label on the wire, and push the latch down
to secure the wire, Do not use excessive
force
on the latches
8_
9_
[r_sert batteries
insert
the
2 AA battedes
into the
battery
compartment
of the Smart
Thermostat,
Set u_o the Sm_Ft
TheFmost_t
After
inserting
the 2 AA batteries
into the
Smart
Thermostat,
the display
will come
on showing
all the displayed
elements
briefly. After
a few
seconds,
a menu wiJJ appear
prompting
you to
select the type of system you have. Use the Up
and Down keys to select one of the following
system types and use the Menu/Select
key to
confirm
your selection:
NHP--HE-C
NHP--HG--C
NH P--HE--NC
NHP--HG-NC
HP--O
HP--B
(Electlic
Heat with air conditioning)
(Gas heat with air conditioning)
(Electric
heat without
air conditioning)
(Gas [seat without
air conditioning)
(Heat Pump
wKh O reverse
valve)
(Heat Pump
with B reverse
valve)
Now you will be prompted
to select your time
zone. Use the Up and Down
keys to select
the
correct
Time Zone for your home and use the
Menu/Select
key to confirm
your selection.
Now you will be prompted
to select your desired
time format
(12 or 24 hour),
set the current
time
and date, and indicate
if you want to use
Daylight
Saving Time
