MS-FPT301/301K user manual
content
Overview..................................................................................................... 2
Specifications..............................................................................................3
Interface...................................................................................................... 5
"Power & serial" connector cable............................................................ 5
"Power & USB"connector cable..............................................................7
Power supply............................................................................................ 9
Dimension...............................................................................................10
Installation & operation..........................................................................12
How to Fix printer.................................................................................. 12
Loading paper roll.................................................................................. 19
LED indicators........................................................................................25
DIP switch.............................................................................................. 26
Black mark..............................................................................................28
Self test page...........................................................................................28
Common problems & solutions............................................................. 30
Matters need to attention........................................................................32
Safety matters......................................................................................... 32
Usage matters......................................................................................... 32
Storage matters....................................................................................... 33
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS-FPT301 and is the answer not in the manual?

Questions and answers

Related Manuals for Masung MS-FPT301

Summary of Contents for Masung MS-FPT301

  • Page 1: Table Of Contents

    MS-FPT301/301K user manual content Overview..................... 2 Specifications....................3 Interface...................... 5 “Power & serial” connector cable............5 “Power & USB”connector cable..............7 Power supply.................... 9 Dimension....................10 Installation & operation................12 How to Fix printer.................. 12 Loading paper roll.................. 19 LED indicators..................25 DIP switch....................26 Black mark....................28...

  • Page 2: Overview

    ,there is only one difference between two models. MS-FPT301 80mm thermal panel printer with “paper roll bucket opening & closing by button” MS-FPT301K 80mm thermal panel printer with “paper roll bucket opening & closing...

  • Page 3: Specifications

    Specifications Model MS-FPT301/301K Printing method Thermal dot line printing Paper width 80 mm Print speed 170 mm/s( max) Dot density 8 dots/mm Total dots per 576dots Print line Printing width 72mm Paper feed Easy loading method Cutter Cut method Partial cut...
  • Page 4 Paper thickness 60～120um Activation pulse 500,000 resistance Thermal head temperature Thermal resistance detection Detection Out of paper Photo interrupter detection Operation Working voltage 24±10% V voltage Power Mean 1.75A（25% of maximum consumption printing dots） Operation -10~50 ℃（no condensation） temperature Operation 20%~85%RH(40℃/85%RH) humidity environment...

  • Page 5: Interface

    Interface “all-in-one” integrated port In order to meet need of different users, FPT-301 series printers were designed to two types connector cables: power & serial,power & USB. “Power & serial” connector cable...
  • Page 6 Power & serial Definition +24V(DC) 1、2 3、7 RS-232C port Pin definition Serial port Pins definition 4、7 1、6、8、9...

  • Page 7: Power & Usb"Connector Cable

    “Power & USB”connector cable Real figure Power & USB Definition +24V(DC) 1、2 3、11 DATA- DATA+ VCC(USB) USB port USB supports USB2.0 high-speed and full-speed .Standard USB ports are implemented using the standard series B socket defined in the USB specification. printer can not be powered by USB cable.
  • Page 8 USB pins definitions VCC(+5V) DATA- DATA+ Power supply interface Power supply interface definition 24V(DC)

  • Page 9: Power Supply

    Kiosk Terminal power connector standard reference, as below Terminal power connector picture Power supply Attention: Before plug in or plug out any interface and sockets, please make sure the the printer power is off.

  • Page 10: Dimension

    1. Make sure the printer power is off 2. supplying power voltage should be 24±10%V 3. plug in power cable 4. power on printer, in the meantime , look at green LED on printer, it will light on normally, or please switch off printer power immediately . Dimension...

  • Page 12: Installation & Operation

    Installation & operation How to Fix printer Step1. hole size request, as below. punching a specified hole on device panel, Panel thickness can not be less than 1.5mm...
  • Page 13 Step2. Loosen off the four screws on back side of printer to take off the plastic frame. as below...
  • Page 15 Step3. When take off the plastic frame, please notice “tooth edge should be upward. step4. Mounting plastic frame on the device panel hole , please make tooth edge upward and carefully install it. As below Notice: user only can mount this plastic frame from front panel of your device.
  • Page 16 Notice: For MS-FPT301-- by pressing button to open paper roll bucket For MS-FPT301-- by using designed key to open paper roll bucket Please refer to “ how to open paper roll bucket ”on loading paper roll chapter , on page18.
  • Page 17 Step6. Close paper roll bucket Notice: user should check paper roll bucket is closed well. MS-FPT301K key cover part should be reset. As below Step7. Tighten the four screws to fix printer on its frame.
  • Page 18 Suggestion: we suggest you to install panel printers on vertical plane. Application sample as below.

  • Page 19: Loading Paper Roll

    Loading paper roll For MS-FPT301  Press the button to open paper roll bucket.
  • Page 20  Put roll spindle through paper roll and pull the paper pass second metal shaft in printer bottom. Notice: a. paper has to pass second metal shaft b. thermal coating layer should be upward...
  • Page 21  Use both hands to push roll spindle to bucket groove to ensure paper roll is fixed on bucket.  Close bucket panel and let paper out...
  • Page 22 For MS-FPT301-K Push little white plastic cover up. ...
  • Page 23  Plug in designed key into hole Notice:after opening printer bucket,please remember to take away key.  Put roll spindle through paper roll and pull the paper pass second metal shaft in printer bottom. Notice: a. paper has to pass second metal shaft b.
  • Page 24 Use both hands to push roll spindle to bucket groove to ensure  paper roll is fixed on bucket.

  • Page 25: Led Indicators

     Close bucket panel and let paper out LED indicators  Green power LED on : power on  Red error LED on: paper roll bucket unlocked or printer error.

  • Page 26: Dip Switch

     Red paper end LED flash :paper end or paper near end. DIP switch Notice:Any DIP switch is reset, user should reload printer power, then printer will be adjusted to the mode user wanted. Switch function default number Black mark enable disable Communication...
  • Page 27 Table 2 printing density DIP Switch number Printing Density level density 130% 115% 100% Table 3 baud rate Baud rate DIP switch number 115200 9600 19200 38400...

  • Page 28: Black Mark

    Black mark When DIP switch number 1 is ON, the black mark function will be activated. So you need to use black mark thermal paper . BM thermal paper standard as below. Thermal coating layer Paper out direction Black mark detection Start to print Cut paper Self test page...
  • Page 29  send hex command to printer  Send hex command: 1D 28 41 02 00 00 02 As below:...

  • Page 30: Common Problems & Solutions

    Common problems & solutions Problem NO1 . When printer bucket is hard to be opened, most likely its cutter has been stuck Solution: For this case, please turn off printer power and rotate the white gear shows below. This is method is to let cutter reset. Problem NO2.

  • Page 32: Matters Need To Attention

    Matters need to attention Safety matters 1. Do not apply voltage or current to any pins excess of the absolute maximum ratings.If voltage or current in excess of the absolute maximum is applied,excess current will flow through the device,which may result in heat damage. 2.

  • Page 33: Storage Matters

    4. Never pull out the signal cable (USB & serial) or power wire when the printer is power on. 5. Never touch the printer head or motor driver at once directly after the printer has been working a long time, or will get scald. 6.
  • Page 34 *MASUNG has the right to change the contents of the manual without statement!
