Masung MS-D347 User Manual

MS-D347&D347-V printers user manual

content

OVERVIEW............................................................................................................................................. 2

SPECIFICATION....................................................................................................................................4

POWER CONNECTION & POWER SUPPLY................................................................................... 7

........................................................................................................................................ 7

OWER CABLE

.......................................................................................................................................8

OWER SUPPLY

INTERFACE............................................................................................................................................ 9

...................................................................................................................................... 10

ERIAL CABLE

USB..................................................................................................................................................... 12

DIMENSION.......................................................................................................................................... 14

INSTALLATION & OPERATION..................................................................................................... 18

......................................................................................................................................... 18

IX PRINTER

OADING PAPER ROLL

...................................................................................................................................... 29

LED

INDICATORS

DIP

......................................................................................................................................... 29

SWITCH

....................................................................................................................................... 31

LACK MARK

................................................................................................................................... 32

ELF TEST PAGE

OW TO OPEN PRINTER HEAD AND CLEAR JAM PAPER

MATTERS NEED TO ATTENTION.................................................................................................. 38

.................................................................................................................................38

AFETY MATTERS

.................................................................................................................................. 38

SAGE MATTERS

.............................................................................................................................. 39

TORAGE MATTERS

..........................................................................................................................25

........................................................................ 34

Table of Contents

Need help?

Do you have a question about the MS-D347 and is the answer not in the manual?

Questions and answers

Summary of Contents for Masung MS-D347

Page 1 MS-D347&D347-V printers user manual content OVERVIEW............................. 2 SPECIFICATION............................4 POWER CONNECTION & POWER SUPPLY................... 7 ............................7 OWER CABLE ............................8 OWER SUPPLY INTERFACE............................9 ............................10 ERIAL CABLE USB..............................12 DIMENSION............................14 INSTALLATION & OPERATION..................... 18 ............................18 IX PRINTER ..........................25 OADING PAPER ROLL ............................
Page 2: Overview
Overview Special attention: 1. MS-D347 and MS-D347-V are 80mm thermal kiosk printer with auto cutter 1. this manual is aim to introduce three model kiosk thermal printers,so terminal user and developer can know them better , and help their development and usage.
Page 3 MS-D347-V Difference: with vertical paper roll bracket for front panel mounting on kiosk cabinet. MS-D347...
Page 4: Specification
Difference: without paper roll bracket , with metal back plate for installation. Specification Model MS-D347-V MS-D347...
Page 5 Printing Dot line thermal printing method Total dots 576 dot/lines line Printing density print Resolution W 8 dots/mm*H 16 dots/mm Printing 200mm/s(max) speed Printing 72mm width Thermal head Thermal sensors temperature Thermal Mechanical switch head switch Detection Out of Reflective infrared light sensor Paper detection Cutter...
Page 6 Transient maximum 6.0A(max) current Paper feed Auto loading Paper cut Full cut/partial cut Paper width 80mm Paper Paper 54~90μm thickness Paper roll diameter(m 160mm Operation -10～60°C（no condensation） temperature humidity environment 10%～85%RH（40°C/85%RH） Storage -20～70°C（no condensation） temperature Activation pulse 100,000000 resistance Service life Abrasion Over 100km resistance...
Page 7: Power Connection & Power Supply
W118.5mm*D96 .13mm*H80.6m W126.4mm*D169.7mm Dimension *H288.4mm (length*depth*he (length*depth*height) ight) 0.95 kg 0.51 kg Mass Communication interface Serial/ USB Serial/USB/parall Power connection & power supply Power cable Outside of power cable is GND，its inner pin diameter is 2.5mm.
Page 8: P Ower Supply
Note: this cable is made by MASUNG. Length : 0.3 m PIN color Definition +24V Black Power supply Attention: Before plug in or plug out any interface and sockets, please make sure the the printer power switch is off. 1. Make sure the printer power switch is off...
Page 9: Interface
2. Supplying power voltage should be 24±10%V 3. Plug in power cable 4. Switch on the power switch，in the meantime , look at green LED on printer head panel, it will light on normally, or please switch off printer power immediately . Interface MS-D347-V MS-D347...
Page 10: S Erial Cable
Serial cable...
Page 12 Notice: the RS-232C cable provided by MASUNG. Which its pin definition is not international standard. User can’t user any other normal serial cable for replacement. Or we won’t take any printer usage problem.
Page 13 Definition VCC(+5V) DATA- DATA+...
Page 14: Dimension
Dimension MS-D347-V...
Page 15 MS-D347...
Page 18: Installation & Operation
Installation & operation Fix printer Step1.Refer to printer dimension, please pay much attention on screw holes as below MS-D347-V...
Page 19 MS-D347...
Page 20 Step2. Fix printer. MS-D347-V MS-D347-V has two types location screw holes, as below.
Page 22 MS-D347...
Page 25: L Oading Paper Roll
Loading paper roll MS-D347-V  Put roll spindle made by MASUNG through paper roll and then load whole roll into bracket, as below...
Page 26  Then power on printer and load paper through plastic yellow shaft. MS-D347  User needs to design their own paper roll bracket and roll spindle and then load paper through plastic yellow shaft.
Page 27 Notice: when user loads thermal paper into printer, please load thermal coating layer of paper upward. As below...
Page 29: Led Indicators
LED indicators  Green power LED on : power on  The two Red LED flash fast:power voltage incorrect  Red Error LED off ,PE LED flash: out of paper. DIP switch 1. location : this DIP switch is located at printer head, user can adjust different switch number to reset different printer configuration.
Page 30 Switch numbe function default Black mark enable disable Communicati Refer to table 1 port Paper near enable disable Off(*) Printing Refer to table 2 density Off(*) Off(*) Baud rate Refer to table 3 Off(*) (*)They are activated when serial port was selected. Table 1 communication port DIP switch number Interface...
Page 31: Black Mark
Table 2 printing density DIP Switch number Printing Density level density 130% 115% 100% Table 3 baud rate Baud rate DIP switch number 115200 9600 19200 38400 Black mark When DIP switch number 1 is ON, the black mark function will be activated.
Page 32 Self test page Self-test page include some configuration information for the printer. you can refer it to set some parameters. how to print self-test page: Method A: As picture shows below,these three model printers have been designed a “TEST” button to get self-test page, when user wants to printer a self-test page, then press this button for 2 seconds after loading paper.
Page 33 Method B: Send hex command: 1D 28 41 02 00 00 02 via printer communication ports. Sample “ self-test page”, as below...
Page 34: H Ow To Open Printer Head And Clear Jam Paper
How to open printer head and clear jam paper  turn off printer power , tear paper at roll end.
Page 35  press the yellow knob to open printer thermal head...
Page 36  Take away jam paper and clear printer head...
Page 38: Matters Need To Attention
Matters need to attention Safety matters 1. Do not apply voltage or current to any pins excess of the absolute maximum ratings.If voltage or current in excess of the absolute maximum is applied,excess current will flow through the device,which may result in heat damage. 2.
Page 39: S Torage Matters
2. The width, inner diameter, outer diameter of paper roll have to meet standard requirements, or it can make paper sensor unable to work and paper jam. 3. Never use hard tools to clean the cutter, or it may result in unrecoverable damage to the cutter.
Page 40 7. To ensure safety, please unplug this product if it unused for a long time. *MASUNG has the right to change the contents of the manual without advanced statement!

This manual is also suitable for:

D347-v
