Set of Equipment supplied – 1 Cryo-Gate – 1 Connecting tube complete with connectors to connect the Cryo-Gate to the CO -tank, 5 m – 1 mains cable 2 m Powercon True plug – 1 Inline-Filter – 1 Operating manual Please check whether all the products you ordered are supplied.
W 21.8 x 1 1/4“ right male (CGA 320 connector). If a tank with this connector cannot be found, you have to use an adaptor. A tube (Ø 200 mm) can be connected to the front of the Cryo-Gate to guide the fog into the requested direction.
2. Safety Instructions A fog machine is not a toy! • Make sure, that all persons who work with the bottle and the gas are professionals. Incorrect use can cause the risk of suffocation! • Carbon dioxide is not toxic but may cause asphyxiation in high concentrations. •...
2. Safety Instructions • Spilled liquid or splashed liquid droplets can cause slip hazard. Mop up the fluid and dispose of it according to regulations. • Fog may activate smoke detectors. Artificially-made fog can be produced in many different ways. The method used here to produce fog, with a device which works according to the vaporizer principle, is the most harmless one.
Page 7
3. Description of the parts Rear view 7: · Power in/out for Powercon 8: · Analogue out 3pin-XLR 9: · DMX out 5pin-XLR 10: · Connector for liquid-CO -tube Connection to the high pressure CO -tank with siphon tube – Avoid dust or dirt particles inside the CO -hose! –...
To use your fog generator in the right way, read the operating manual of the fog machine. After the fog generator has heated up completely, you can start the Cryo-Gate. A ducting hose of 20 cm Ø can be connected to the front of the Cryo-Gate.
Release the remaining CO off the hose as follows: Control via DMX: The Cryo-Gate uses four channels at the DMX-desk: channel 1 = pump, channel 2 = air, channel 3 = cooling/CO , channel 4 = fan Put the fader for the CO to 100% and wait until the CO has been disappeared.
Close the valve properly and connect the other end of the hose to the Cryo-Gate [10]. Tighten both connections properly to make sure that no gas can come out. Open the valve at the tank completely [15].
Page 11
Fig. 2 Settings 1 Fig. 3 Settings 2 After starting the Cryo-Gate the display shows the main screen (Fig. 1). First line from left to right: – Button ANALOG: shows the adjusted mode and the voltage. - See point 4.4.2 –...
4. Operating the Cryo-Gate 4.4.1 Manual operation There are two ways of manual operating: Choosing a preset or adjusting manual values directly at the Touchscreen. a) Selecting one of six Presets: A preset is a specification. Three fixed presets are available, three can be adjusted and saved individually.
4. Operating the Cryo-Gate – Press BACK to return to the main screen. – Press SETTINGS and at the displayed screen (Fig. 2) SAVE MANUAL SETTING, to get to the SAVE MANUAL SETTING screen (Fig. 5). – Select the number of the preset, where you wanted to save the adjusted values and press SAVE.
Settings or the main screen without saving the values. Connect your cable or radio remote to the “analogue in“ at the Cryo-Gate. The ANALOG-Button (Fig. 1, line 1) at the main screen shows the voltage and the selected mode (DIRECT or LATCHED).
4. Operating the Cryo-Gate 4.4.4 Operating via Ethernet Press ETH at the main screen (Fig. 1, line 1) or select SETTINGS –> PROTOCOL. Screen (Fig. 8/10) appears. 4.4.4.1 Artnet Select ARTNET (Fig. 8, line 3). The button will change its colour to cyan, showing that Artnet is activated.
If you press BACK, you will get back to Settings or the main screen without saving the value. Make sure that the Cryo-Gate has a valid network address and a correct subnet mask. You can check and change this by pressing SETTINGS –> IP-CONFIG (see point 4.4.5).
First select whether you want to use a static network address or a dynamic one (DHCP) by pressing STATIC or DHCP (Fig. 12, line 4). If you select DHCP, the Cryo-Gate gets an IP-address and a subnet mask from a DHCP-Server or Router in your network. If you select STATIC, you can type in the IP-address and the subnet mask in the following screen (Fig.
Press BACK to get to the previous screen. FIRMWARE UPDATE starts an update of the software. Therefore an additional programm as well as a Computer and a network connection between PC and Cryo-Gate is needed. More info on request. Fig. 16...
4. Operating the Cryo-Gate 4.4.6.4 Factory Reset Here you can switch back to the default settings. – Press SETTINGS at the main screen, in the following „Settings 1“-screen NEXT and in the „Settings 2“-screen (Fig. 3, line 2) FACTORY RESET.
Page 20
– Wipe up spilled fluid immediately. Moisture - also fluid - can destroy the electric parts of the machine. – If the Cryo-Gate is been used with a tube, there will be some residues in the tube and also the machine after a while.
90 to 240 VAC Power requirement max. 65 Watt Dimensions (L x W X D) 60 x 20 x 17.7 cm Weight 10.5 kg Manufactured for Look Solutions - Fog machines made in Germany · Bünteweg 33 · DE-30989 Gehrden...
7. Warranty conditions For the low fog machine Cryo-Gate Look‘ warranty is: 1. Free of charge, subject to the following conditions (No. 2 - 6) we will repair any defect or fault in the unit if it is caused by a proven factory fault and has been advised immediately after identification and within 12 months of delivery to the end user.
