XT-800FXO Gateway
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XT-800FXO and is the answer not in the manual?

Questions and answers

Related Manuals for XONTEL XT-800FXO

Summary of Contents for XONTEL XT-800FXO

  • Page 1 XT-800FXO Gateway User Manual...

  • Page 2: Declaration Of Conformity

    Warranty The information in this document is subject to change without notice. XonTel makes no warranty of any kind with regard to this guide, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. XonTel shall not be liable for errors contained herein nor for incidental or consequential damages in connection with the furnishing, performance or use of this guide.

  • Page 3: Table Of Contents

    Contents About This Guide ....................5 Getting Started ....................... 6 Accessing Web GUI ........................6 Web Configuration Panel ...................... 7 Application Description ......................7 FXO Port Settings ....................11 FXO Port Settings ....................... 11 Port Group .......................... 15 VoIP Settings ......................17 VoIP Trunk ..........................
  • Page 4 Security Center ..................... 44 Security Center ........................44 Alert Settings ........................45 AMI Settings ........................47 Certificates .......................... 48 Firewall Rules ........................49 IP Blacklist........................... 51 System Preferences ..................... 53 Password Settings ......................53 Date and Time .......................... 53 Email Settings .......................... 54 Auto Provision Settings .......................

  • Page 5: About This Guide

    VoIP. Audience This manual will help you learn how to operate and manage your XT-800FXO Gateway. In this guide, we describe every detail on the functionality and configuration of XT-800FXO Gateway. We begin by assuming that you are interested in XT- 800FXO Gateway and familiar with networking and other IT disciplines.

  • Page 6: Getting Started

    Getting Started In this chapter, we guide you through the basic steps to start with a new XT-800FXO Gateway: Accessing Web GUI Web Configuration Panel Application Description Accessing Web GUI The default IP address for XT-800FXO Gateway is: 192.168.5.150. In this situation, one IP address within segment 192.168.5.0/255.255.255.0 requires to be added in...

  • Page 7: Web Configuration Panel

    Connect IP PBX and XonTel XT-800FXO Gateway XonTel XT-800FXO gateway is a solution to extend FXO ports for your PBX. Two modes are available for you to connect PBX and XonTel XT-800FXO gateway, we call them VoIP mode and SPS (Service Provider SIP)/SPX (Service Provider IAX) mode.
  • Page 8 SIP server. VoIP Mode Take a SIP account from your SIP server, and register it on XT-800FXO Gateway as a VoIP trunk. In this way, XT-800FXO and your SIP server are connected.
  • Page 9 1) Configure a Port->IP route on XT-800FXO Gateway, choose PSTN trunk in the field “Call Source”, and choose the SPS trunk in the field “Call Destination”. 2) Create one inbound route on your SIP server and select the SIP trunk created just now.
  • Page 10 Figure 2-3 Connect XonTel XT-800FXO Gateway and XonTel S3200 FXS Gateway...

  • Page 11: Fxo Port Settings

    FXO Port Settings This chapter explains how to configure FXO port on XT-800FXO Gateway, go to Gateway→ Port List→ Port List page to configure the FXO ports. FXO Port Settings Port Group FXO Port Settings Click "Edit" button to configure the FXO port.
  • Page 12 6 - 370 Ohm + (820 Ohm || 110nF) 7 - 275 Ohm + (78 Ohm || 150 nF) 8 - 120 Ohm + (820 Ohm || 110 nF) 9 - 350 Ohm + (1000 Ohm || 210nF) 10 - 0 Ohm + (900 Ohm || 30nF) 11 - 600 Ohm + 2.16 uF 12 - 900 Ohm + 1 uF 13 - 900 Ohm + 2.16 uF...
  • Page 13 Configure the time duration when XT-800FXO Alarm threshold(min) Gateway will send the alarm message. The value must be less than “Max Call Duration”. Port Choose the port to dial the alarm call. Number The number to receive the alarm call.
  • Page 14 XT- Type 800FXO Gateway starts to bill. 3) Ring back Tone: If you choose this option, XT-800FXO Gateway will charge the call according to PSTN ring back tone detection. When the "ring duration" or the "ring interval duration"...

  • Page 15: Port Group

    DTMF: DTMF signal Please check with your PSTN service provider to configure Caller ID Settings. If you don’t know how to configure, please contact XonTel support. Other Settings There should be a timeout to determine if there is a hang up Ring Detect before the line is answered.
  • Page 16 Figure 3-4 Port Group...

  • Page 17: Voip Settings

    VoIP Settings To integrate with other IP PBX, we need to configure the VoIP settings in XT-800FXO Gateway to set up VoIP trunk (SIP and IAX). In this chapter, we introduce the following settings: VoIP Trunk Trunk Group SIP Settings...
  • Page 18 2) Trunk It’s a SIP or IAX trunk configured in XT-800FXO Gateway to register to the VOIP provider, please make sure this trunk works properly in advance with provider before configuring XT-800FXO Gateway. Figure 4-3 VoIP Trunk Settings Table 4-2 Description of VoIP Trunk Settings...

  • Page 19: Trunk Group

    Trunk Type Choose the type of the VOIP protocol, “SIP”. Type A unique label to help you identify this trunk when listed in outbound rules, incoming rules etc. E.g. “xontel”. Provider Name Service provider’s hostname or IP address. Note: 5060 is the standard port number used by SIP Hostname/IP protocol.

  • Page 20: Sip Settings

    Port used for SIP registrations. The default is 5060. TLS Port Port used for SIP registrations. The default is 5061. When using XT-800FXO Gateway as a TLS client, whether or not to TLS Verify Server verify server’s certificate. It is “No” by default.
  • Page 21 Once enabled, when dialing out via SIP/SPS trunks, the Calling Channel Codec codec of calling channel will be selected preferentially. If Priority not, XT-800FXO Gateway will follow the priority order in your SIP/SPS trunks. Video Support Support SIP video or no. The default is yes.
  • Page 22 3) Codecs We can choose the allowed codec in XT-800FXO Gateway, a codec is a compression or decompression algorithm that used in the transmission of voice packets over a network or the Internet.
  • Page 23 XT-800FXO Gateway side. 5) Response Code You can change the response code on XT-800FXO Gateway to the one you want before sending it to the VoIP server. It helps the VoIP server understands better the exact call status, like busy, no response and others.
  • Page 24 Allow Guest that it is disabled for security reason. Pedantic Enable pedantic parameter. Default: no. If enabled, when XT-800FXO Gateway rejects “Register” or “Invite” packets, TA FXO Gateway always respond the packets using “SIP404 NOT Alwaysauthreject FOUND”. It’s recommended that it is enabled for security reason.

  • Page 25: Iax Settings

    IAX Settings IAX is the Internal Asterisk Exchange protocol, you can connect to XT-800FXO Gateway or register IAX trunk to another IAX server. It’s supported by the asterisk- based IP PBX. Figure 4-12 IAX Settings Table 4-7 Description of IAX Settings...

  • Page 26: Routes Settings

    Routes Settings After connecting XT-800FXO Gateway with the VoIP server, you need to configure the routes settings on XT-800FXO Gateway to route the calls through the gateway. In this chapter, we introduce the following sections: IP->Port Port->IP/Port Blacklist Callback Settings IP->Port...
  • Page 27 Hotline Dial the number directly, The dial pattern is ignored. 2) Detail Mode Choose “No” for Simple Mode, you will see the detailed configuration page as the following picture shows. Detailed settings for Match Incoming Calls and Handle Matched Incoming Calls are provided in Detailed Mode. Figure 5-2 Detailed Mode Route Table 5-2 Description of Match Incoming Calls Settings Items...

  • Page 28: Port->Ip/Port

    Port->IP/Port Port->IP/Port routes are used to control incoming calls to PSTN trunks on XT-800FXO Gateway and route the calls to your SIP server or another PSTN trunk on XT-800FXO Gateway. Click “Edit” to check the route details, there are two modes for you.
  • Page 29 Figure 5-3 Simple Mode Route Table 5-3 Description of Simple Mode Route Items Description Define the route name. Route Name Choose the trunk or trunk group for the incoming calls. Call Source Choose the trunk or trunk group to route the incoming calls to. Call Destination Dial the number directly, The dial pattern is ignored.
  • Page 30 Figure 5-4 Detailed Mode Route Table 5-4 Description of Match Incoming Calls Settings Items Description Choose the trunk or trunk group for the incoming calls. Call Source Match the prefix of caller ID for incoming calls. Inbound Caller Pattern Whether to enable callback feature. Enable Callback Table 5-5 Description of Handle Matched lncoming Calls Settings Items...

  • Page 31: Blacklist

    the call is placed. For example, if a trunk requires 10-digit dialing, but users are more comfortable with 7-digit dialing, this field could be used to prepend a 3-digit area code to all 7-digit phone numbers before calls are placed. Blacklist Blacklist is used to block an incoming or outgoing call.
  • Page 32 Figure 5-6 Callback Settings...

  • Page 33: Gateway Settings

    Gateway Settings This chapter explains Gateway settings, which can be applied globally to XT-800FXO Gateway. The gateway settings can be configured under Gateway→ Gateway Settings. General Preferences General Preferences Figure 6-1 General Preferences Table 6-1 General Preferences General Settings The absolute maximum amount of time permitted for a MAX Call Duration call.

  • Page 34: Audio Settings

    Audio Settings This chapter explains prompt settings on XT-800FXO Gateway. Custom Prompts Custom Prompts We can upload the prompts in this page; you can also download it and save it as a backup. Figure 7-1 Custom Prompts The administrator can upload prompts by doing the following: 1) Click “Upload Prompt”.

  • Page 35: Advanced Settings

    Figure 8-1 Tone Zone Settings Users may also configure the tone zone according to the national standard by selecting "User custom for Tone Zone". Please refer to the document below and configure the tone zone settings on XT-800FXO Gateway: http://www.itu.int/ITU-T/inr/forms/files/tones-0203.pdf Figure 8-2 Customize Tones...

  • Page 36: Dtmf Settings

    2nd Dial Tone Used for the second stage dial tone. DTMF Settings DTMF signal sent from XT-800FXO Gateway to the receiver can be set on this page. Digit Length and Dial Pause Between Digit: 100.100 (ms) Default Digit Volume: -10,-10 (dB)

  • Page 37: Network Preferences

    VPN Settings DDNS Settings Static Route LAN Settings After successfully logging in the XT-800FXO Gateway Web GUI for the first time, users could go System→Network Preferences→LAN Settings to configure the network for XT-800FXO Gateway. Figure 9-1 LAN Settings Table 9-1 LAN Settings...

  • Page 38: Wan Settings

    Static IP Address Mode  DHCP  PPPOE IP Address Set the IP Address for XT-800FXO Gateway. Subnet Mask Set the subnet mask for XT-800FXO Gateway. Gateway Set the gateway for XT-800FXO Gateway. Set the primary DNS for XT-800FXO Gateway. Primary DNS Secondary DNS Set the secondary DNS for XT-800FXO Gateway.

  • Page 39: Service

    Figure 9-5 PPPoE Fill in user name and password to access the Internet via PPPoE. Service User can manage all the access methods on XT-800FXO Gateway on "Service" page. Figure 9-6 Service Settings Table 9-3 Description of Service Settings Items...

  • Page 40: Vlan Settings

    A VPN can provide secure information transport by authenticating users, and encrypting data to prevent unauthorized persons from reading the information transmitted. The VPN can be used to send any kind of network traffic securely. XT-800FXO Gateway supports Open VPN.

  • Page 41: Ddns Settings

    1. Uncomment “user” and “group” in the “config” file. You can get the config package from the Open VPN provider. 2. XT-800FXO Gateway works as VPN client mode only. DDNS Settings DDNS (Dynamic DNS) is a method/protocol/network service that provides the...

  • Page 42: Static Route

    You will need to set some Static Route for XT- 800FXO Gateway to force it to go out through different gateway when accessing to different internet. The default gateway priority of XT-800FXO Gateway from high to low is VPN/VLAN LAN port. Figure 9-10 Static Route 1) Route Table The current route rules of XT-800FXO Gateway.
  • Page 43 metric. Routing metrics are assigned to routes by routing protocols to provide measurable statistic which can be used to judge how useful (how low cost) a route is.

  • Page 44: Security Center

    Security Center This chapter describes how to secure your XT-800FXO Gateway. It is strongly recommended that users configure firewall and other security options on XT- 800FXO Gateway to prevent the attack fraud and the system failure or calls loss. Security Center...

  • Page 45: Alert Settings

    WEBLOGIN Web Login Alert Notification: entering the wrong password consecutively for five times when logging in XT-800FXO Gateway Web interface will be deemed as an attack, the system will limit the IP login within 10 minutes and notify the user.
  • Page 46 Figure 10-4 Alert Settings Table 10-1 Description of Alert Settings Phone Notification Settings PHONE Whether to enable phone notification or not. Notification Port Choose the FXO port that you want to use when dial the desired number The numbers could be set for alert notification; users can setup multiple extension and outbound phone numbers.

  • Page 47: Ami Settings

    Important Note: To use alert settings with email notification please configure Email Settings in XT-800FXO Gateway AMI Settings The Asterisk Manager Interface (AMI) is a system monitoring and management interface provided by Asterisk. It allows live monitoring of events that occur in the system, as well enabling you to request that Asterisk perform some action.

  • Page 48: Certificates

    Permitted "IP address/Subnet mask" You can set which IP is allowed to log in XT-800FXO Gateway AMI interface. Certificates XT-800FXO Gateway supports TLS transport, you can configure FXO port with TLS transport. To use TLS, you should upload certificates first.

  • Page 49: Firewall Rules

    Firewall Rules Firewalls are used to prevent unauthorized Internet users from accessing private networks connected to the Internet, especially intranets. All messages entering or leaving the intranet pass through the firewall, which examines each message and blocks those that do not meet the specified security criteria. Figure 10-7 Firewall Settings 1) General Settings Table 10-2 Description of Firewall General Settings...
  • Page 50 Figure 10-8 Common Rules Table 10-3 Description of Common Rules Items Description A name for this rule, e.g. “HTTP”. Name Simple description for this rule. E.g. accept the specific host to Description access the Web interface for configuration. The protocols for this rule. Protocol Initial port should be on the left and end port should be on the right.

  • Page 51: Ip Blacklist

    Table 10-4 Description of Auto Defense Items Description The port you want to auto defense, for example, 8022. Port Select the protocol. You can select UDP or TCP. Protocol The maximum packets or connections can be handled per unit time. For example, if you configure it as below: Port: 8022 Rate Protocol: TCP...
  • Page 52 Table 10-5 Description of Auto Blacklist Rules Items Description Auto defense port Port Auto defense protocol. TCP or UDP. Protocol Allowed IP packets number in the specific time interval. IP Packets The time interval to receive IP packets. For example, IP packets 90, Time interval time interval 60 means 90 IP packets are allowed in 60 seconds.

  • Page 53: System Preferences

    4. Log in XT-800FXO Gateway using the new password. Figure 11-1 Password Settings Date and Time Please adjust the time of XT-800FXO Gateway (including the time zone) consistent with your local time. Go to System→System Preferences→Date and Time to configure the system date and time.

  • Page 54: Email Settings

    Figure 11-2 Date and Time Time Zone Select your current and correct time zone on XT-800FXO Gateway. Daylight Saving Time The option is disabled by default. Enable it when necessary. Automatically Synchronize with an Internet Time Server XT-800FXO Gateway will adjust its internal clock to a central network server.

  • Page 55: Auto Provision Settings

    Password The password for the email address used above. SMTP Server The hostname of an SMTP server that XT-800FXO Gateway will connect in order to send system alarm or balance alarm via email, i.e. mail.yourcompany.com. Port SMTP Port: the default value is 25.
  • Page 56 Figure 11-5 Set XT-800FXO Gateway as a DHCP Client Another way to do auto provision is to download configuration file from the configured server URL. Fill in the URL, user name, password, and set the time, XT-800FXO will get the configuration file from the server automatically and regularly.

  • Page 57: Firmware Update

    Firmware Update XT-800FXO Gateway can be upgraded to a new firmware version via network or locally. Users could upgrade firmware via HTTP or TFTP. Please go to System→ System Preferences→ Firmware Update to do upgrade. Notes: If “Reset configuration to Factory Defaults” is enabled, the system will be restored to factory default settings.

  • Page 58: Upgrade Through Tftp

    On option “Current Directory”, click “Browse” button, choose the firmware file (BIN file) upgraded patch. Figure 11-8 Configure Tftpd32 Step3. Login to XT-800FXO Gateway Web page and go to System→System Preferences→Firmware Update, choose “TFTP Server”. 1) TFTP Server: fill in IP address of Tftpd32 server (your PC’s IP address).

  • Page 59: Backup And Restore

    XT-800FXO Gateway configurations to a file. Notes: 1. When you have updated the firmware version, it’s not recommended to restore using an old package. 2. Backup from an earlier version cannot be restored on XT-800FXO Gateway of a later version. Create a New Backup Click to create a new backup.
  • Page 60 Figure 11-11 Reset and Reboot...

  • Page 61: Status

    Status Users could check the system status on Status→System Status, where FXO Port and trunk Status, Network Status and System Info can be checked. Port/Trunk Status Network Status System Info Port/Trunk Status Figure 12-1 Port/Trunk Status  FXO Port Status Table 12-1 Description of FXO Port Status Up/Down The FXO module works well.

  • Page 62: Network Status

     VoIP Trunk Status SIP/IAX Type Table 12-2 Description of SIP/IAX Trunk Status Status Description Registered Successful registration, trunk is ready for use. Unregistered Trunk registration failed. Request Sent Registering. Waiting for Wrong password. Authentication 2) SP-SIP/IAX Type Table 12-3 Description of SP-SIP/IAX Trunk Status Status Description Successful registration, trunk is ready for use.

  • Page 63: System Info

    System Info In this page, we can check the hardware/firmware version, or the disk usage of XT- 800FXO Gateway. Figure 12-3 System Info...

  • Page 64: Reports

    Reports Users could check the call logs, system logs on Status→Reports page, and use the packet Tool and Port Monitor Tool to capture debug logs from XT-800FXO Gateway. Call Logs System Logs Packet Tool Port Monitor Tool Call Logs The call log captures all call details, including call time, caller number, callee number, call type, call duration, etc.

  • Page 65: Packet Tool

    Figure 13-2 System Logs Packet Tool This feature is used to capture packets for technician. Integrate packet capture tool “Wireshark” in XT-800FXO Gateway. Users also could specify the destination IP address and port to get the packets. Figure 13-3 Packet Tool ...
