User Manual
HDB-301R Firmware Update
MODEL:
HDB-301R
HDB-301R Firmware Update / 韌體更新
User Manual
Page 1
Rev. 1.02 – February 6, 2018
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for IEI Technology HDB-301R
Summary of Contents for IEI Technology HDB-301R
-
Page 1: User Manual
HDB-301R Firmware Update MODEL: HDB-301R HDB-301R Firmware Update / 韌體更新 User Manual Page 1 Rev. 1.02 – February 6, 2018... - Page 2 HDB-301R Firmware Update Revision Date Version Changes February 6, 2018 1.02 Updated for the latest software tool that is improved to optimize firmware update process / 韌體新增燒入檢查機制 Added English version / 新增英文版說明 August 24, 2017 1.01 Updated for firmware v2.7.2 / 韌體版本更新為 v2.7.2 June 7, 2017 1.00...
- Page 3 HDB-301R Firmware Update Copyright COPYRIGHT NOTICE / 版權聲明 The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer.
-
Page 4: Manual Conventions
HDB-301R Firmware Update Manual Conventions WARNING / 警告 Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. 此類訊息內警示的資訊可能導致產品損壞甚或造成人身傷害。請嚴正看待 此類訊息內的警示。 CAUTION / 小心 Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product. - Page 5 Download the latest firmware update file: HDB-301R-update_FW-Vx.x.x_FPGA-Vx.x.x (The 'x' represents characters which vary from version to version). Step 1: Connect the HDB-301R to a computer. Confirm the connection in Device Manager. Step 2: Unzip the firmware update file downloaded from IEI website. Open the folder and locate the USB30VB.exe file.
- Page 6 HDB-301R Firmware Update WARNING！ Please follow the procedures described below to perform firmware update. Do not disconnect the USB 3.0 cable during the update process unless told to do so. Disconnecting the USB 3.0 cable can cause power interruption and may lead to firmware update failure or device damage.
- Page 7 HDB-301R Firmware Update Step 6: When the update is finished, the following message window appears. Please unplug the connection between the HDB-301R and the computer, and plug it in again. Then, click OK to close the pop-up window. Page 7...
- Page 8 HDB-301R Firmware Update Step 7: The firmware update program allows users to obtain the current firmware and FPGA version. Click Get Firmware version: the firmware version will be listed above. Click Get FPGA version: the FPGA version will be listed above.
- Page 9 請依照以下步驟更新 HDB-301R 韌體： 注意： 請先至 IEI 官網 （http://www.ieiworld.com/） ， 點選 產品 影像擷取盒 HDB-301R Download，找到並下載最新的韌體安裝包： HDB-301R-update_FW-Vx.x.x_FPGA-Vx.x.x（檔名內的 x 將會隨著軟 體版號不同而有所變更）。 Step 1: 請於電腦接上 HDB-301R 裝置，並透過裝置管理員來確認 HDB-301R 已連接。 Step 2: 解壓縮於網站下載的韌體安裝包，然後開啟解壓縮檔案的資料夾。注意：解壓縮 。 後的資料夾的完整路徑建議均使用英文命名 Step 3: 找到並執行 USB30VB.exe 程式。 Page 9...
- Page 10 HDB-301R Firmware Update 警告！ 請依照更新說明操作。韌體更新過程中，請勿拔除 USB 3.0 連接線！ 若拔除 USB 3.0 連接線導致電源中斷，可能使韌體更新失敗，造成 HDB-301R 無回應或者需要維修。 若有任何問題或需要協助，請聯繫 IEI 客服人員為您處理。 Step 4: 點擊 Update FW/FPGA 開始更新韌體與 FPGA。 Step 5: 使用者可從以下畫面的綠色更新條，瞭解韌體更新狀態。 Page 10...
- Page 11 HDB-301R Firmware Update Step 6: 韌體更新完成後，會出現以下對話方塊。請先拔除再重新插入 USB 3.0 連接線， 並點擊確定。 Page 11...
- Page 12 HDB-301R Firmware Update Step 7: 使用者可透過此韌體更新程式取得目前的韌體/FPGA 版本： 點選 Get Firmware version，韌體版本號會顯示於上方狀態框中； 點選 Get FPGA version，FPGA 版本號會顯示於上方狀態框中。Step 0: Page 12...
