Stonegate Melrose Dark Cherry Assembly And Operation Manual

Electric fireplace heater
Hide thumbs

Advertisement

Quick Links

Download this manual
CAUTION / ATTENTION -- DO NOT PLUG THE HEATER INTO ANY POWER
OUTLET OR OPERATE BEFORE READING ALL INSTRUCTIONS!
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric
shock, and injury to persons, including the following:
1. Read all instructions before using this fireplace. Failure to follow these important safety instructions may
cause fire, electric shock or damage.
responsibility of the owner.
2. WARNING: This fireplace heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces.
The grill directly in front of the heater outlet becomes hot during heater operation.
3. CAUTION – High Temperature. Keep any materials, such as upholstered furniture, pillows, bedding, papers,
plastic, clothes, curtains and other furnishings at least 3 feet away from the front, sides and rear of the heater
element.
ELECTRIC FIREPLACE HEATER
ASSEMBLY AND OPERATION MANUAL

IMPORTANT SAFETY INSTRUCTIONS

Following proper safety and operating instructions is the
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Melrose Dark Cherry and is the answer not in the manual?

Questions and answers

Related Manuals for Stonegate Melrose Dark Cherry

Summary of Contents for Stonegate Melrose Dark Cherry

  • Page 1: Important Safety Instructions

    ELECTRIC FIREPLACE HEATER ASSEMBLY AND OPERATION MANUAL IMPORTANT SAFETY INSTRUCTIONS CAUTION / ATTENTION -- DO NOT PLUG THE HEATER INTO ANY POWER OUTLET OR OPERATE BEFORE READING ALL INSTRUCTIONS! SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1.
  • Page 2 4. WARNING: This appliance gets hot and it contains internal parts that could arc or spark. Do not use it in areas where gasoline, paint, or flammable liquids are used or stored or where the unit will be exposed to flammable vapors.
  • Page 3 24. Do not strike fireplace glass. 25. If the heater unit has been dropped or damaged, do not operate unless fully checked out by a certified repair center. 26. Always use a certified electrician should new circuits or outlets be required. 27.
  • Page 4 MANTEL ASSEMBLY: Parts List: Hardware List: Top Panel Plastic Connector 32 PCS Upper Back Panel Middle Shelf Panel Base Panel KD Screw 96 PCS Upper Left Side Panel Upper Right Side Panel Left Door Shelf Support 8 PCS Right Door Upper Front Panel Left Side Panel Wooden Dowel...
  • Page 5 Top Panel Upper Right Side Panel Upper Left Side Panel Upper Back Panel Middle Panel Upper Front Panel Shelf Panel Shelf Panel Back Back Panel Panel Right Door Left Door Left Side Panel Right Side Panel Base Panel Inner Right Panel Inner Left Panel...
  • Page 6 Step 1: NOTE: Make sure to attach the Plastic Connectors (U1) so the sides with the larger hole openings are facing in the correct direction for the screw heads to go in and be recessed inside the connector. Attach 6pcs Plastic Connectors (U1) to the Upper Back Panel (B) using 12pcs KD Screws (U2). Attach 4pcs Plastic Connectors (U1) to the Upper Left Side Panel (E) using 8pcs KD Screws (U2).
  • Page 7 Step 3: Attach the Left and Right Side Panels (J & K) and the Inner Left and Right Panels (M & N) to the Base Panel (D) using 8pcs KD Screws (U2). See Fig. 3 below. Step 4: Slide in the 2 Back Panels (L) into the grooves on the Left & Right Side Panels (J & K) and the Inner Left and Right Panels (M &...
  • Page 8 Step 5: Attach the Upper Front Panel (I) to the Inner Left and Right Panels (M & N) using 2pcs Wooden Dowels (U4). See Fig. 5 below. Step 6：Attach the Middle Shelf Panel (C) to the assembled unit using 10 pcs KD Screws (U2). See Fig.6 below.
  • Page 9 Step 7：Attach the Upper Left and Right Side Panels (E & F) to the Middle Shelf Panel (C) using 4pcs KD Screws (U2) .See Fig.7 below.
  • Page 10 Step 8： Attach the Upper Back Panel (B) to the Middle Shelf Panel (C) using 3pcs KD Screws (U2). See Fig. 8 below. Step 9：Attach the Top Panel (A) to the assembled unit using 7pcs KD Screws (U2). See Fig. 9 below.
  • Page 11 Step 10: Set the 2 Shelf Panels (O) on top of the Shelf Supports (U3) inside the 2 side cabinets. See Fig. 10 below. Step 11：Attach the 2pcs Door Magnets (U10) to the underside of the Middle Shelf Panel (C) using 4pcs Self-Tapping...
  • Page 12 Screws (U6). See Fig. 11 below. Step 12：Attach the 4pcs Hinges (U5) to the Left and Right Doors (G & H) using 8pcs Self-Tapping Screws (U6). See Fig. 12 below.
  • Page 13 Step 13: Attach the Left and Right Doors (G & H) to the Left & Right Side Panels (J &K) by attaching the Hinges (U5) onto the Left & Right Side Panels (J & K) using 8pcs Self-Tapping Screws (U6). See Fig.13 below. Step 14：Attach the Hole Cover (U7) over the hole on the Upper Back Panel (B).
  • Page 14 Step 15: Carefully place the Electric Fireplace Heater Insert through the back of mantel with the front of the heater facing out the opening in the mantel as shown in Fig. 15 below. Step 16: Once the insert is in place, attach the top of the insert to the back of the Upper Front Panel (I) of the mantel using 3pcs Mounting Screws (U9).
  • Page 15 After assembly is complete, check the fireplace insert controls and make sure they are all in the OFF position. Plug the fireplace into a 15AMP/120Volt outlet. Once the fireplace insert has been properly connected to a grounded, electrical outlet, it is ready to operate. Do not use an extension cord or power strip. OPERATION BY THE CONTROL PANEL The controls are located behind the grill below the front glass and can be accessed by pulling grill from the top, forward and down.

  • Page 16: Maintenance

    750W: For low heat function – Press this switch while the O/I switch is in the ON position. The indicator light will turn on. 1500W: For high heat function – Press this switch are in the on position. The indicator light will turn on (keep the 750W in the ON position).
  • Page 17 Step 1: Unplug the fireplace heater Step 2: Remove 12 screws on the back of fireplace and remove the rear cover. Step 3: You will find 1 X 40W Type B-10 bulb under log-set bed. Step 4: Loosen and remove burnt out bulb and replace with new bulb. Step 5: Close the rear cover and secure with the 12 screws.
