FP10-27-11-50-OLOAKS ELECTRIC FIREPLACE HEATER
ASSEMBLY AND OPERATION MANUAL
IMPORTANT SAFETY INSTRUCTIONS
CAUTION / ATTENTION -- DO NOT PLUG THE HEATER INTO ANY
POWER OUTLET OR OPERATE BEFORE READING ALL
INSTRUCTIONS!
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
When using electrical appliances, basic precautions should always be followed to reduce the
risk of fire, electric shock, and injury to persons, including the following:
1. Read all instructions before using this fireplace. Failure to follow these important safety
instructions may cause fire, electric shock or damage. Following proper safety and
operating instructions is the responsibility of the owner.
2. WARNING: This fireplace heater is hot when in use. To avoid burns, do not let bare skin
touch hot surfaces. The grill directly in front of the heater outlet becomes hot during
heater operation.
3. CAUTION – High Temperature. Keep any materials, such as upholstered furniture,
pillows, bedding, papers, plastic, clothes, curtains and other furnishings at least 3 feet
away from the front, sides and rear of the heater element.
4. WARNING: This appliance gets hot and it contains internal parts that could arc or spark.
Do not use it in areas where gasoline, paint, or flammable liquids are used or stored or
where the unit will be exposed to flammable vapors. Do not use near propane tanks.
5. WARNING: This fireplace should not be used as a drying rack for clothing. Do not
hang Christmas stocking or any decoration on the fireplace heater or mantle.
6. Extreme caution is necessary when any heater is used by or near children or those with
disabilities.
7. Do not operate the heater unattended or while sleeping. Stay alert and monitor operation
at all times.
8. Always unplug fireplace when not in use.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FP10-27-11-50-OLOAKS and is the answer not in the manual?

Questions and answers

Related Manuals for Stonegate FP10-27-11-50-OLOAKS

Summary of Contents for Stonegate FP10-27-11-50-OLOAKS

  • Page 1 FP10-27-11-50-OLOAKS ELECTRIC FIREPLACE HEATER ASSEMBLY AND OPERATION MANUAL IMPORTANT SAFETY INSTRUCTIONS CAUTION / ATTENTION -- DO NOT PLUG THE HEATER INTO ANY POWER OUTLET OR OPERATE BEFORE READING ALL INSTRUCTIONS! SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1.
  • Page 2 9. Do not operate any fireplace heater with a damaged cord or plug, or if the heater has malfunctioned, or if the fireplace has been dropped or damaged in any manner. Take fireplace to authorized service facility for examination, electrical or mechanical adjustment or repair.
  • Page 3 30. When transporting or storing the fireplace and cord, keep in a dry place, free from excessive vibration and store so as to avoid damage. NOTE: Procedures and techniques that are considered important enough to emphasize. CAUTION: Procedures and techniques, which, if not carefully followed, will result in damage to the equipment or personal property or may cause personal injury.
  • Page 4 MANTEL ASSEMBLY: Part # DESCRIPTION A -Top Panel B - Upper Back Panel 40PCS C - Middle Panel 40 PCS D - Front Door Panel E - Upper Front Panel 1 PC F - Front Shelf 2pcs G - Base H –...
  • Page 5 **RECOMMEND 2 PEOPLE FOR ASSEMBLY! Step 1: Attach 3 Cam Lock Screws (U1) to the Left Front Panel (J). Attach 3 Cam Lock Screws (U1) to the Left Back Panel (L). Insert 6 Cam Lock Nuts (U2) into Left Side Panel (N). Attach the Left Front Panel (J) and the Left Back Panel (L) to the Left Side Panel (N).
  • Page 6 Step 2: Attach the Upper Front Panel (E) to the Left and Right Inner Panels (P & Q), by inserting the pre-attached Wooden Dowels into the holes in the Inner Panels. Step 3: Attach 4 Cam Lock Screws (U1) into the bottom of Middle Panel (C). Insert 2 Cam Lock Nuts (U2) into the Left Inner Panel (P) and 2 Cam Lock Nuts (U2) into Right Inner Panel (Q).
  • Page 7 Step 4: Attach 2 Cam Lock Screws (U1) to the Left Side Panel (N). Attach 2 Cam Lock Screws (U1) to the Right Side Panel (O). Insert 4 Cam Lock Nuts (U2) under the Middle Panel (C). Attach the Middle Panel (C) to the Side Panels (N & O). Tighten the Cam Lock Nuts (U2).
  • Page 8 Step 6: Attach 8 Cam Lock Screws (U1) to the underside of the Top Panel (A). Insert a total of 8 Cam Lock Nuts (U2) to the Left and Right Front Panels (J & K) and to the Left and Right Back Panels (L & M). Attach the Top Panel (A) to the top of the assembled unit.
  • Page 9 Step 8: Attach 12 Cam Lock Screws (U1) to the Base (G). Attach a total of 12 Cam Lock Nuts to the Left and Right Front Panels (J & K), to the Left and Right Back Panels (L & M) and to the Left and Right Inner Panels (P & Q). Attach the Base (G) to the assembled unit.
  • Page 10 Step 10: Attach 24 Shelf Pegs (U7) to your desired heights in the storage areas. Step 11: Set the Side Shelves (I) on the Shelf Pegs (U7) on the ends of the mantle. Set the Front Shelves (F) on the Shelf Pegs (U7) in the front of the mantle.
  • Page 11 Step 12: Carefully place the Insert Heater through the opening in the center of the Mantle. Secure the Insert to the Mantle using 3 Screws (U8) at the top of the Insert and 2 Brackets (U9) with 2 Screws (U10) at the bottom of the Insert. After assembly is complete, check the fireplace insert controls and make sure they are all in the OFF position.

  • Page 12: Remote Control Battery Replacement

    Heater Operating Instructions: The heater On/Off switch is located on the top right corner of the insert. Remote Control O/I Switch: Press this button ON. The indicator light on the switch will turn on. It means you have power and your remote is ready to operate your unit.

  • Page 13: Maintenance

    Maintenance: WARNING: Completely disconnect power before attempting any maintenance or cleaning, to reduce the risk of fire or electric shock. Maintenance should only be performed by a certified technician. The bulbs in your unit are LED, have a long life and are not replaceable. Cleaning: Before cleaning any parts of the fireplace make sure to first turn off the controls and then unplug the unit from power source.
