Robot X5 Glassbot User Manual page 9

Q2: Robot slips and cannot detect the upper frame of window in "Auto Up then Down"
mode
Ans: Press
Q3: Robot cannot finish whole window and stop at middle area.
Ans: Press
Q4: Robot slips and cannot get higher to the window frame.
Ans:
(1) Friction factor is too low that might be caused by glass stickers, window film on the
glass.
(2) Cleaning cloth might be too wet.
(3) If clean window many times, the glass surface will become very slippery.
(4) The glass surface will become slippery if clean several times in low humidity
environment such as in air-conditioned room.
(5) When startup (press
frame.
Q5: Robot does not move smoothly or moves irregularly.
Ans:
(1) Cleaning cloth is too dirty. Please change the cleaning cloth.
(2) Glass surface has different friction factor areas due to stickers, window film, and son
on. Please use it in single area.
(3) The screw of cleaning wheel might be loose, please tighten it.
Q6: After cleaning, remained circle mark on the glass surface.
Ans: Cleaning cloth is too dirty. Please change the cleaning cloth and clean for the
second time.
Q7: What to do if robot stopped at higher area while no electric power supplied, it alarms
and red lamp flashes?
Ans:
(1) User can pull robot back with safety rope. Slightly pull the safety rope at an angle close
to the glass to prevent dropping.
(2) Switch the power-switch to "off" status.
(3) Check whether electric poor-contact, or cable broken.
Q8: What to do if robot abnormally stopped and red lamp keeps flashing, without alarm?
Ans:
key and switch to
or mode to continue cleaning.
, or
or mode to continue cleaning.
or ), keep 10cm away from the window
8
