10' x 10' Slant Leg Pop-Up Canopy
Assembly Instructions
DeSCrIPtIon
MoDeL #
10'x10' Slant Leg Pop-Up - Red
22966
10'x10' Slant Leg Pop-Up - Checkered
22976
reCoMMenDeD tooLS
Before you start: 2+ individual recommended for assembly, approximate time 15 min.
1-800-524-9970
150 Callender Road
Canada:
Watertown, CT 06795
1-800-559-6175
www.shelterlogic.com
05_22966_22976_0A
5/7/12
Page 1
Advertisement
Table of Contents
Related Manuals for ShelterLogic 22966
Summary of Contents for ShelterLogic 22966
- Page 1 10' x 10' Slant Leg Pop-Up Canopy Assembly Instructions DeSCrIPtIon MoDeL # 10'x10' Slant Leg Pop-Up - Red 22966 10'x10' Slant Leg Pop-Up - Checkered 22976 reCoMMenDeD tooLS Before you start: 2+ individual recommended for assembly, approximate time 15 min.
- Page 2 3. Proper anchoring is the RESPONSIBILITY OF THE OWNER. Any temporary portable shade product that is not anchored securely and properly has the potential to blow away in high winds. ShelterLogic cannot be held responsible for damage caused by any product that blows away.
- Page 3 Step 2: Step 1: Unfold cover. Place Remove assembly cover over frame. from portable, wheeled Align corner pockets storage bag. Grab corner of cover over frame legs in each hand. Lift legs. frame slightly off ground. Stepping backwards, pull frame apart until your arms are fully extended.
- Page 4 to order replacement Parts, Please order by Part number: see 4 see 5 Part Part Number Description 15349 Leg Tube Assembly 15273 Gemel Assembly 15276 Slide Tube Assembly 22603 TOP CREST KIT 22604 SLIDING CONNECTOR KIT 15550 Replacement Cover - Checkered Flag 800813 Replacement Cover - Red not shown...
