  • Page 1 KP-200 Plus KEYBOARD DISPLAY UNIT SERVICE MANUAL...
  • Page 2 Additional RS-232 port for other input devices ex: bar code scanner  List the label forms stored in printer memory  Select forms and print the label  KP-200 Plus is applicable to TSPL printer language  KP-200E Plus is applicable to EPL2 printer language...

  • Page 3: Specifications

    Specifications Keyboard Unit Size 261mm(L)×142.2mm(W)×31mm(H) Weight 440g STN type, 20 characters × 2 lines Max Current 72.3 mA External Power 361.5 mWatt Operating 40°F~104°F (5°C~40°C) Temperature Storage -4°F~140°F (-20°C~60°C) Temperature RS-232 Interface and Communication Parameters (1) The keyboard COM1 port should be connected to the bar code printer. Keyboard power is drawn from printer serial port.
  • Page 4 (3) Keyboard COM1 and COM2 pin assignment KEYBOARD COM1 KEYBOARD COM2 Configuration Configuration Power input 5 volts, Power input 5 volts, 250mA 250mA Not used Not used Ground Ground Not used Not used Not used Not used Not used Not used Not used Connect with Pin1 (Short JP4: Connect with...

  • Page 5: Parts List

    Parts List Spare Item No. Part No. Description Remark Parts 30-0170003-00LF Upper Cover 30-0170004-00LF Lower Cover As shown in Page 2, 36-0170002-10LF Keypad the Outline section 37-1403006-34LF Tap Screw 3*6 2 pcs (MOQ 50 pcs) 37-1403008-34LF Tap Screw 3*8 4 pcs (MOQ 50 pcs) 98-0170200-00LF Main PCB Ass'y 66-2002011-10LF...
  • Page 6 9F., No.95, Minquan Rd., Xindian Dist., No.35, Sec. 2, Ligong 1st Rd., Wujie Township, New Taipei City 23141, Taiwan (R.O.C.) Yilan County 26841, Taiwan (R.O.C.) TEL: +886-2-2218-6789 TEL: +886-3-990-6677 FAX: +886-2-2218-5678 FAX: +886-3-990-5577 Web site: www.tscprinters.com E-mail: printer_sales@tscprinters.com TSC Auto ID Technology Co., Ltd. tech_support@tscprinters.com...
