Page 1
Nextiva S4200 Series User Guide Covering the S4200-BZ, S4200-2V-BZ, S4200-AS-2V-BZ, S4200-AS-BZ Firmware Release 5.30 April 2009...
Page 2
Verint Systems Inc. shall not be liable for damages resulting from the use, misuse or unlawful use of the information, links, tools, and materials contained or referenced herein.
Installing the Transmitter ................44 Installing an External Antenna ..............49 Connecting the RS-422/485 Serial Port ............50 Configuring the I/Os .................. 52 Chapter 4 Using the Web Interface ..............55 Installing or Upgrading ActiveX Controls ............56 Verint Video Intelligence Solutions...
Page 4
Performing a Site Survey ................116 Respecting Minimum Distances ..............120 Appendix E Technical Specifications ...............123 Glossary ......................126 Index .......................131 Compliance ......................136 USA ......................137 Canada ....................... 139 Mexico ......................141 Europe ......................143 RoHS Declaration of Compliance ..............145 Verint Video Intelligence Solutions...
A paper copy of the installation guide is included with your order. How to Contact Us The following Web sites and e-mail addresses provide information and support for Verint Video Solutions and the Nextiva Intelligent Edge Device product line. Find general information on Verint Video Solutions, including marketing material and product information at www.verint.com/videosolutions.
Page 6
Find contact information for the Verint Customer Service team, by phone or e-mail, or fill out a Web request for support with a specific issues at www.verint.com/videoservice. For immediate assistance, contact the Customer Service team:...
CCTV cameras to an IP network. Note: The S4200 series edge devices require professional installation. The overview covers the following: About the S4200 Series Installation Kit Hardware Overview Hardware Dimensions and Mounting Angles Verint Video Intelligence Solutions...
IntelliView solution, version 5.1 or higher. Camera tampering detection and analytics run on the first video input of the devices. For details, refer to your Verint representative. The second encoder of each input can be used for analytics or to encode video. The second encoder gives better video encoding performances than the first one.
VSIP communication as well as audio, video, and serial data. Frame Rate and Performance The available video frame rates of each encoder of the transmitter are: NTSC—1 to 7, 10, 15, or 30 frames per second (fps) PAL—1 to 6, 8, 12, or 25 fps Verint Video Intelligence Solutions...
Page 10
Performance document, available on the extranet (Community Links > Technical Briefs > Nextiva Intelligent Edge Devices). Each performance value includes: A video resolution A frame rate expressed in frames per second (fps) using the NTSC/PAL format Verint Video Intelligence Solutions...
PS2440 power supply An indoor-only 24V AC power supply Note: You must use only antennas certified by Verint. Doing so ensures that the combined transmission power of the device and antenna does not exceed the maximum value established by your country’s regulations. For more information, see page 28 and page 136.
An external SMA antenna connector Three LEDs LEDs Auxiliary connector: either video 2 and serial port or alarm and audio External SMA antenna connector Main connector for video 1, serial port, and power Network (RJ-45) connector Verint Video Intelligence Solutions...
1: Overview Hardware Dimensions and Mounting Angles The top view dimensions of the S4200 are: Verint Video Intelligence Solutions...
Page 15
Nextiva S4200 Series User Guide The back view dimensions are: The side view dimensions with the mounting assembly installed are: Verint Video Intelligence Solutions...
Page 16
For more information about the mounting procedure, see “Installing the Wireless System” on page 44. Verint Video Intelligence Solutions...
Page 17
Nextiva S4200 Series User Guide An upward tilt is: Finally, here are rotation examples: Left Rotation Right Rotation Verint Video Intelligence Solutions...
In all cases, follow the recognized RF installation practices. To help you with your planning, you may consult the Verint Video Intelligence Solutions extranet: The Wireless System Margin Calculator is a tool based on an Excel spreadsheet designed to simplify the creation of RF systems.
The 4.9 GHz band is a licensed band for entities providing public safety services focused on the protection of life, health, or property in the United States, Canada, and Mexico. This band provides license holders with an interference-free, secure channel for robust and secure broadband technologies, including wireless video surveillance systems. Verint Video Intelligence Solutions...
5.785 5.805 5.825 In Mexico, the following channels are available, all independent and for indoor or outdoor use: Channel Frequency (GHz) Channel Frequency (GHz) 5.18 5.32 5.745 5.22 5.765 5.24 5.785 5.26 5.805 5.28 5.825 5.30 Verint Video Intelligence Solutions...
Finally, the master allocates bandwidth among all connected slaves. Slave devices need a master to access the wireless medium to transfer data, through a polling mechanism. The S4200 devices are always slaves. Verint Video Intelligence Solutions...
Challenge Handshake Authentication protocol) to validate logins and passwords. A certificate is required on the server side. For more information about the TLS (Transport Layer Security) protocol, refer to RFC 2246 at http://www.ietf.org/rfc/rfc2246.txt. The supported encryption methods are: AES-CCMP Verint Video Intelligence Solutions...
The wireless parameters associated to 802.11 differ from those of the SPCF mode. For more information about these parameters, refer to the Verint SConfigurator User Guide. Be aware of the following limitations in using S4200 devices in a 802.11 environment: The S4200 will not be able to connect to an S4300.
As link distances increase, the total available video bandwidth will decrease due to free space loss and other attenuating factors. If this is not taken into account in the design phase, problems will surface which will have a detrimental effect on the total system performance. Verint Video Intelligence Solutions...
Page 26
1 IP camera at 4CIF, 1 Mbps 15/12 fps, 2 Mbps 2 cameras at CIF, 30/25 fps, 1 IP camera at 2CIF, 2 Mpbs 30/25 fps, 2 Mbps 0 camera 1 IP camera at 4CIF, 30/25 fps, 4 Mbps Verint Video Intelligence Solutions...
You should then: Update the devices starting with the farthest (in terms of number of RF hops) from the computer running the procedure. One step at a time, get closer to the computer. Verint Video Intelligence Solutions...
4. S4300 2—You then lose contact will all devices except master S4300 3. 5. S4300 3—You can then reach all devices. For the complete firmware update procedure, refer to the documentation of the Verint software you are using. Video Bit Rate and Data Throughput You can theoretically connect up to 24 S4200 devices to a master access point in a wireless cell.
Note: To minimize the false radar detection problem in colocated systems using adjacent frequency channels, see page 29. You should start the master first, then power the slave when the other device is in normal operation. Verint Video Intelligence Solutions...
To reduce radio interference, separate as much as possible devices sharing the same pole or installed on the same roof, even if they do not use adjacent channels. If using adjacent channels, see page 120 for the recommendations on the minimum distances to respect. Verint Video Intelligence Solutions...
PUK98rewq4123qzx S4200_B3 PUK98rewq4123qzx S4300_C 987123jkl456wert S4200_C1 987123jkl456wert S4200_C2 987123jkl456wert S4200_C3 987123jkl456wert 3. In each cell, install the S4200 devices such that each one has a clear RF line of sight with its associated S4300 access point. Verint Video Intelligence Solutions...
2. Assign a different frequency channel to each S4300 device; the associated S4200 devices will automatically use their master’s channel. For example, in the 5 GHz band: Device Cell Channel Wireless Passkey S4300_A ertynmbvcxzapoiu S4200_A1 ertynmbvcxzapoiu S4200_A2 ertynmbvcxzapoiu S4200_A3 ertynmbvcxzapoiu S4300_B PUK98rewq4123qzx S4200_B1 PUK98rewq4123qzx S4200_B2 PUK98rewq4123qzx Verint Video Intelligence Solutions...
Installing more than six cells in the 5.40–5.725 GHz band requires the use of adjacent channels. This situation demands greater distances between the antennas to reduce potential radio interference and false radar detection. Therefore, you should contact the customer service team for assistance. Verint Video Intelligence Solutions...
Page 35
The default value is Disabled, meaning that the slave does not detect radars; in this case, the slave EIRP is reduced from 30 to 23 dBm and the Tx power is automatically reduced to meet the new maximum EIRP requirement. Verint Video Intelligence Solutions...
Page 36
Two access point applications, in which the transmitters from one system do not see the transmitters from the other cell. Both master devices see each other. S4100 S4100 S4300 S4300 A point-to-multipoint repeater. Both master devices see each other. Slave Master S4300 S4300 S4300 S4200 Repeater Verint Video Intelligence Solutions...
Because the reliability of such an installation is highly unpredictable, Verint does not recommend it. A path free of any obstacle is called an RF line-of-sight path.
Page 38
Note: At 2.4, 4.9, and 5 GHz, radio waves are highly attenuated by dense foliage. A link established in the fall or winter season may be adversely affected in the spring and summertime, if it is established below tree level. Verint Video Intelligence Solutions...
5 GHz band, you can use the Wireless System Margin Calculator located on the Verint Video Intelligence Solutions extranet (under Tools). You must use only antennas certified by Verint. They meet the local regulations regarding the maximum antenna gain allowed. The certified antennas are listed in the “Compliance”...
Configuring and Installing the Device The steps required to prepare your S4200 device for operation are: Basic configuration Physical installation in its final location Alarm and audio configuration, if required Verint Video Intelligence Solutions...
Device configuration requires the use of the proprietary SConfigurator tool. Its latest version is included on the Verint web site (www.verint.com/manuals). You need to copy its executable file (SConfigurator.exe) to the hard disk of your computer. The minimum hardware and software requirements for the host computer needed to...
4. If required, connect an external antenna on the S4200; for the procedure, see page 49. 5. Plug an Ethernet cable between the network (RJ-45) connector of the S4200 transmitter and a computer. 6. Plug the supplied video/serial/power cable on the main connector of the S4200 transmitter. Verint Video Intelligence Solutions...
Page 43
Power supplies other than the approved ones require verification of operation with the S4200 before use. If you are using a power supply other than the one supplied by Verint, you need to ensure that it has a minimum capacity of 1.6A (for 12V DC) or 25 VA (for 24V AC).
Page 44
For more information about DHCP, see page 108. 11. Click OK. The device reboots with its new network configuration. 12. In the Units tab, click Discover to update the list of devices. The new S4200 device appears. Verint Video Intelligence Solutions...
Page 45
You must assign the proper country of operation to the device, so that it will comply to the DFS/TPC regulations, if applicable, respect the maximum EIRP, and use the proper set of frequency channels. 4. In the confirmation window that appears, click Yes. Verint Video Intelligence Solutions...
Page 46
8.5 dBi in the 2.4 GHz band and 12 dBi in the 4.9 GHz and 5 GHz bands. Note: Providing a gain lower than the actual gain of the antenna you are using is prohibited. Verint Video Intelligence Solutions...
Page 47
To check communication with the S4300 access point: 1. In the SConfigurator Units tab, the S4200 should be hierarchically positioned under the S4300. 2. In the Link Status pane of the S4300, the S4200 should be in the Clients/Slaves list. Verint Video Intelligence Solutions...
Typically, both devices sit on the same IP subnet as SConfigurator and have the same VSIP port; to access other devices, refer to the device discovery section in the Verint SConfigurator User Guide.
Page 49
For more information, refer to the Nextiva S1900e Series User Guide. 9. Click Connect. 10. In the SConfigurator confirmation window, click OK. Verint Video Intelligence Solutions...
Item Description Scale Drawing Lock washers for the pole clamp (2) and the pole/wall mount pivot (2) Lock washers for the mounting bracket (4) Nuts for the pole clamp (2) and the pole/wall mount pivot (2) Verint Video Intelligence Solutions...
Page 51
Always mount the device with the mating connectors pointing downwards. Note: If you are not installing a high-gain antenna, position the device so that its integrated antenna has a clear RF line of sight with the antenna of its S4300 access point. Verint Video Intelligence Solutions...
Page 52
Nut (item 3) Screw (item 4) 3. To install the device on a wall, use four screws (not supplied) in the four mounting holes located at the ends of the pole/wall pivot mount. Mounting hole Mounting hole Verint Video Intelligence Solutions...
Page 53
(item 6) using a 0.5-inch (13-mm) wrench. Use a large diameter wire (minimum AWG 10; maximum AWG 1), and make it as short as possible. Then ground the cable. Lug screw (item 6) Ground lug Cable Verint Video Intelligence Solutions...
Page 54
Tip: If the S4200 is directly exposed to the sun in an environment likely to reach 122°F (50°C), install a sun shield. Otherwise, reduce the maximum operating temperature by 18°F (10°C) to protect the equipment; that is, without a sun shield, the maximum temperature should be 104°F (40°C). Verint Video Intelligence Solutions...
Note: Power supplies other than the approved ones (PS2440) require verification of operation with the S4200 before use. If you are using a power supply other than the one supplied by Verint, you need to ensure that it has a minimum capacity of 1.6A (for 12V DC) or 25 VA (for 24V AC).
Use the video/serial/power cable to properly connect the device to a serial peripheral. Here is the wiring scheme for the four-wire RS-422 or RS-485 protocol: Cable Peripheral Signal Name Wire Pair Wire Color Signal Name green green/black black yellow yellow/black black Verint Video Intelligence Solutions...
Page 57
Wire Pair Wire Color Signal Name Data+ green Data+ green/black Data- black Data- Signal ground brown Signal ground brown/black Signal ground black Signal ground 2. Set the operating mode to RS-485 2 Wires (see page 60). Verint Video Intelligence Solutions...
(up to 48V at 100 mA) upon alarm activation. For example, with an S1970e-R receiver: S4200 S1970e-R S4300 Alarm Alarm Input 1 Ground Relay Relay Alarm Out+ Alarm Out- Input 1 Ground Event sensor Event sensor Verint Video Intelligence Solutions...
Page 59
You plug the audio input signal of the device to the Line-out connector on a pre-amplifier. Then you plug a microphone on the pre-amplifier. You plug the audio output signal of the device to the Line-in connector on an amplifier. Then you plug a speaker on the amplifier. Verint Video Intelligence Solutions...
Page 60
3: Configuring and Installing the Device The audio input/output specifications are: Mode Gain Impedance Frequency Range Input -20 to -3 dBV 30 kohm 300–3600 Hz Output -45 to -3 dBV 8 ohms min. Verint Video Intelligence Solutions...
Depending on user account and security settings, you may have to provide a user name and password when logging into the web interface or accessing it in secure mode. For more information, see the Security parameters on page 62. Verint Video Intelligence Solutions...
5. Select Tools > Internet Options > Security to lower the security level in your web browser to enable the ActiveX components to install. Select Trusted sites, then click Sites to add the IP address of the device in the trusted sites list. Verint Video Intelligence Solutions...
Page 63
15. If your environment is Windows XP Service Pack 2 with Internet Explorer 6, click Maintenance in the navigation pane, then the Update button. 16. In the Internet Explorer - Security Warning window, click Install. The ActiveX is installed. 17. Select Tools > Pop-up Blocker > Turn On Pop-up Blocker. Verint Video Intelligence Solutions...
Main pane—The area where to configure the device, view data, and perform maintenance tasks. Firmware version—The current firmware version of the main processor of the device. The latest firmware files are available on the Verint Video Intelligence Solutions extranet. Verint Video Intelligence Solutions...
Page 65
Uptime—The time since the device has been rebooted. This information is also displayed on the bottom banner of the web interface. IP—The IP address of the device. This information is also displayed on the top banner of the web interface. Memory—The available internal memory in the device. Verint Video Intelligence Solutions...
Possible values are RS-422 4 Wires, RS-485 4 Wires, and RS-485 2 Wires. 5. In the Stop Bits list, select the number of stop bits in each transmission. Possible values are 1 or 2 bits. Verint Video Intelligence Solutions...
User Accounts. The user account parameters appear. 2. In the Administrator User Name box, enter the alphanumeric string identifying the administrator user. 3. In the Administrator Password box, enter the alphanumeric string protecting the access to the device for the administrator user. Verint Video Intelligence Solutions...
Page 68
4. In the XML Report Generation list, indicate whether the generation of an XML report presenting the current state of the device is allowed. 5. In the IP Firmware Update list, indicate whether firmware updates on the device through the IP network are allowed. Verint Video Intelligence Solutions...
Page 69
11. To continue the configuration process, select another parameter category in the navigation pane. Otherwise, click Apply to save the changes in the device. Depending on the changes you made, a reboot may be required; follow the on-screen instructions in the Device Configuration Submittal pane. Verint Video Intelligence Solutions...
The following information is available: Firmware Version—The current firmware version of the main processor of the device. The latest firmware files are available on the Verint Video Intelligence Solutions extranet. Loader Version—The version of the firmware used to load the device.
Internal Value 1—Verint technical information. Audio Hardware—The indication of whether audio hardware is present on the device. Unit Tested (MM-YY)—The date the device was tested by Verint production. Board Temperature—The temperature of the main board (in degrees Celcius). Configuring the Network The network parameters allow communication between the device and its IP network.
802.11, see page 17. For each MAC mode, there are two sets of parameters: basic and advanced. Basic Wireless The S4200 contains standard wireless parameters for the SPCF and 802.11 MAC modes. Verint Video Intelligence Solutions...
Page 73
Do not disclose the passkey. The connection security is based on the secrecy and uniqueness of the passkey. It is good practice to change the default passkey during the configuration process. Verint Video Intelligence Solutions...
Page 74
When a slave connects to its master for the first time, it automatically receives the best possible value (the Auto value), with a default RF margin set to 15 dB (to change the margin, see page 75). Verint Video Intelligence Solutions...
Page 75
Nextiva S4200 Series User Guide Once the device is operating properly, Verint strongly recommends to change the configured bit rate from Auto to the actual bit rate of the connection. This way, the wireless communication will be more stable in the presence of changing atmospheric conditions or other RF interferers.
Page 76
AES encryption and resolved the range and security problems of the 802.11 standard, but did not manage the hidden node issue. Note: A change to the MAC mode is automatically applied because it has an immediate impact on other parameters. Verint Video Intelligence Solutions...
Page 77
7. In the WPA Private Key Passphrase box, enter the case-sensitive identifier (from 0 to 63 characters) used to secure the access to an 802.11 certificate. 8. In the WPA Negotiation Timeout box, enter the maximum time (in seconds) given for the device to be authenticated. Verint Video Intelligence Solutions...
Page 78
When a slave connects to its master for the first time, it automatically receives the best possible value (the Auto value), with a default RF margin set to 15 dB (to change the margin, see page 75). Verint Video Intelligence Solutions...
Page 79
Nextiva S4200 Series User Guide Once the device is operating properly, Verint strongly recommends to change the configured bit rate from Auto to the actual bit rate of the connection. This way, the wireless communication will be more stable in the presence of changing atmospheric conditions or other RF interferers.
Page 80
If the MAC mode is SPCF, the parameters are: If the MAC mode is 802.11, the parameters are: 2. In the Passkey Entry Format list, select the format for the wireless and WEP passkeys. The available values are String and Hexadecimal. Verint Video Intelligence Solutions...
Page 81
However, doing so reduces the maximum performances of the wireless network. 9. In the IP Multicast Forward from this Interface list, indicate whether multicast data coming from the wireless network is allowed to be sent to the Ethernet network. Verint Video Intelligence Solutions...
Configuring Video The following aspects of the video functions of the device are available for configuration: General parameters Encoder Depending on the model, you have access to one or two (on the -2V models) video inputs. Verint Video Intelligence Solutions...
The video parameters are the same for the two encoders of each video input in the device. However, they vary depending on the compression mode: There is one set of parameters for the SM4 and MPEG4 Compliant Simple Profile modes, and another one for MJPEG. Verint Video Intelligence Solutions...
Page 84
(fps) that will be encoded and transferred by the transmitter. This parameter can be set to 1 to 7, 10, 15, or 30 fps in NTSC mode and 1 to 6, 8, 12, or 25 fps in PAL mode. Verint Video Intelligence Solutions...
Page 85
15. In the Frame Format list, select the way the video fields are compressed. The available values are: Field over Field—The proprietary mode used by the Nextiva edge devices. Interlaced Frame—The MPEG-4 compliant mode where the two video fields are interlaced. Verint Video Intelligence Solutions...
Page 86
5. In the Input Filter Mode list, select the level of filtering applied to the video signal before it is encoded, helping to remove high frequency noise from lower quality cameras or noisy video feeds. The available values are Low, Medium, High, or None. Verint Video Intelligence Solutions...
Page 87
14. To continue the configuration process, select another parameter category in the navigation pane. Otherwise, click Apply to save the changes in the device. Depending on the changes you made, a reboot may be required; follow the on-screen instructions in the Device Configuration Submittal pane. Verint Video Intelligence Solutions...
Average Quantizer—The average quantizer, multiplied by 100. It is based on a 2-minute moving average. Video Input Locked—The indication of whether the input signal is locked. Video Decoder AGC Value—The automatic gain control value of the video analog-to-digital converter. Verint Video Intelligence Solutions...
6. To continue the configuration process, select another parameter category in the navigation pane. Otherwise, click Apply to save the changes in the device. Depending on the changes you made, a reboot may be required; follow the on-screen instructions in the Device Configuration Submittal pane. Verint Video Intelligence Solutions...
4. To continue the configuration process, select another parameter category in the navigation pane. Otherwise, click Apply to save the changes in the device. Depending on the changes you made, a reboot may be required; follow the on-screen instructions in the Device Configuration Submittal pane. Verint Video Intelligence Solutions...
Page 91
3. To continue the configuration process, select another parameter category in the navigation pane. Otherwise, click Apply to save the changes in the device. Depending on the changes you made, a reboot may be required; follow the on-screen instructions in the Device Configuration Submittal pane. Verint Video Intelligence Solutions...
The main reason to use NTP is to display valid dates in the log files instead of the device uptime. The Local Time parameter indicates the current local time if the device is connected to an NTP server. Verint Video Intelligence Solutions...
Page 93
6. To continue the configuration process, select another parameter category in the navigation pane. Otherwise, click Apply to save the changes in the device. Depending on the changes you made, a reboot may be required; follow the on-screen instructions in the Device Configuration Submittal pane. Verint Video Intelligence Solutions...
UDP that transfers video to a multicast group. It does not guarantee proper reception of video packets. RTP/UDP—A protocol using RTP (Real Time Transport Protocol, RFC 3550) over UDP that transfers video to a unique recipient. It does not guarantee proper reception of video packets. Verint Video Intelligence Solutions...
Note: If you upgraded the firmware of the device or are accessing live video for the first time, you need to install an ActiveX component prior to viewing live video (for more information, see page 56). To configure live video: 1. Ensure that the camera is properly connected to the device. Verint Video Intelligence Solutions...
Page 96
4: Using the Web Interface 2. In the navigation pane, click Live Video. The main web interface pane is split in two, with the live video portion at the bottom. Pane separator Verint Video Intelligence Solutions...
Page 97
YUV video conversion will be used on the computer, to improve video rendering. If this parameter is not activated, RGB rendering will be used. Most graphics video cards support YUV, which is more optimized than RGB. Verint Video Intelligence Solutions...
Page 98
8. To view video directly in the Live Video Streaming pane, click Embedded Video Window. The video is embedded in the web interface pane. PTZ controls also appear. 9. To close the Live Video Streaming sub-pane, click Close Window. Verint Video Intelligence Solutions...
To save the current position of the PTZ camera, enter a number in the Preset box , then click Store Preset To use a previously stored preset, enter a number in the Preset box, then click Go to Preset Verint Video Intelligence Solutions...
2. To keep the following network parameters, ensure that Keep Network Settings is checked: DHCP usage Gateway Ping request target Subnet IP address DNS servers Ping request size Host name Otherwise, you will need to reprogram the device for proper operation within the network. Verint Video Intelligence Solutions...
Page 101
3. If the problem persists, connect an Ethernet cable between the device and the network used by the host computer; then start again the update procedure. 4. If the problem persists, look at the status LEDs for abnormal behavior. Verint Video Intelligence Solutions...
Page 102
It can be deactivated in the command line interface (CLI) or the web interface. Ensure that the IP link is stable before starting the procedure; therefore it is not recommended to perform it over the Internet. Verint Video Intelligence Solutions...
You can perform maintenance and troubleshooting tasks on the S4200 system. Specifically: Updating the firmware Losing connection to a camera Finding a lost S4200 Performing a reset Recognizing the status LED conditions Using the command line interface (CLI) Verint Video Intelligence Solutions...
Verint Nextiva; for the detailed procedure, refer to the documentation of the software. The latest firmware files are available on the Verint Video Intelligence Solutions extranet (Quick Links > Firmware and Applications > Nextiva Intelligent Edge Devices).
1. Warmup period if the internal temperature is too low 2. Bootup 3. Normal operation The three LEDs are: LAN—For the Ethernet network (802.3) status: Condition Indication Warmup Red blinks (2.0 sec. intervals) The internal temperature of the device is too low. Bootup Verint Video Intelligence Solutions...
Page 106
The device is in normal operation with at least one RF connection. Flashing green (0.1 sec. off A packet is received or transmitted. for each packet) Red blink (0.1 sec.) There is a communication error. Flashing red (0.1 sec. The device is being identified. intervals) Verint Video Intelligence Solutions...
Steady red or green LED for more than 30 seconds—There is an internal error that prevents the device from starting normally. Power down the device, wait 30 seconds, then power it up. If the condition persists, call Verint Video Intelligence Solutions technical support.
The CLI has a timeout that is triggered after three minutes of inactivity. When the timeout occurs: You lose access to the command line. The “Thank you for using the Verint CLI” message appears at the command line. The Verint Console window becomes disabled. The Disconnect button switches to Connect.
Exit the CLI by entering q at the main menu, then pressing Enter. Depending on the changed settings, the device may perform a soft boot. Close the Verint Console window. Note: Do not use the Disconnect button to exit the CLI, since it does not save your settings.
Page 110
7. Assign the UDP port value to Local UDP Port and Remote UDP Port. 8. Change the value of Connection Type to UDP. Note: The VSIP GUID parameter is not used in UDP. 9. Go back to the main menu. 10. Save the parameters, then exit the CLI. Verint Video Intelligence Solutions...
Factory Default Configuration Verint Video Intelligence Solutions...
Page 112
Target bit rate: 800 kbps Maximum quantizer: 24 Resolution: CIF (352 x 240) Video standard: NTSC Video settings (Europe) Target frame rate: 25 fps Target bit rate: 800 kbps Maximum quantizer: 24 Resolution: CIF (352 x 240) Video standard: PAL Verint Video Intelligence Solutions...
Page 113
Tx bit rate: Auto Antenna gain: 11 dBi Tx power scale: Maximum The frequency band and country vary depending of the purchased product. VSIP VSIP Port: 5510 VSIP Multicast IP Address: 224.16.32.1 VSIP Discovery IP Address: 255.255.255.255 Verint Video Intelligence Solutions...
DHCP (Dynamic Host Configuration Protocol) allows devices and computers connected to a network to automatically get a valid IP configuration from a dedicated server. The APIPA (Automatic Private IP Addressing) scheme, available on the Windows operating systems, enables a device to assign itself a temporary IP address. Verint Video Intelligence Solutions...
Page 115
The first time it boots up After receiving a duplicate IP address After a hardware reset When the DHCP server does not have any available IP addresses After loading the default parameters DHCP configuration is automatically disabled after a factory reset. Verint Video Intelligence Solutions...
Visit the following sites to find interesting information about the statistical occurrences of lightning in your region (worldwide coverage): http://earthobservatory.nasa.gov http://thunder.nsstc.nasa.gov/ Excellent international sources for external surge protection equipment and general surge and lightning protection information are: Polyphaser Corporation—www.polyphaser.com Citel inc.—www.citelprotection.com Transtector—www.transtector.com Verint Video Intelligence Solutions...
Therefore you should add an external surge protector to secure the Ethernet connection of the device. Verint recommends to insert a surge protector next to the S4200; it is up to the user to protect or not the laptop end.
Page 118
C: Surge Protection Verint has evaluated and tested two models of surge protection modules. Each one has its own characteristics and specific advantages, depending on the particular installation case: Manufacturer Model Characteristics Polyphaser NX4-60 Non-waterproof enclosure (connectors) Extended temperature (outdoor)
Page 119
The grounding conductor should be a round cable with a minimum AWG 10 (2.6 mm) and maximum AWG 1 diameter, or the grounding wire that was provided with your protection module. On the S4200, the nearest grounding point is the pole itself. Verint Video Intelligence Solutions...
Reducing Wireless Interference Wireless interference can be caused by: External sources Other Nextiva devices in colocated cells or on adjacent frequency channels Follow specific guidelines to reduce interference as much as possible. Verint Video Intelligence Solutions...
3. Perform a site survey to determine exactly which devices are causing interference. For the procedure, see page 116. 4. Decrease the tx power of the wireless links that have a good RF margin (15 dB or more). This way, the interference generated by the device is reduced. Verint Video Intelligence Solutions...
The following operations relative to RF site surveys are available: Specify the number of consecutive surveys to perform Start and stop a site survey Look at the last survey report Reset the survey database Verint Video Intelligence Solutions...
Page 123
Max is the maximum signal difference (23 dB for a 6 Mbps bit rate in the example). To calculate the emission signal difference between two adjacent wireless cells: 1. Open SConfigurator, then click the Units tab. 2. Select the master device in the wireless cell you are adding, then click Telnet. Verint Video Intelligence Solutions...
Page 124
4. For a thorough scan, specify 60 site survey iterations. 5. Start the site survey operation. Note: During the execution, the RF link will be momentarily broken (duration varies depending on the number of iterations). The link is automatically restored when the survey is finished. Verint Video Intelligence Solutions...
Page 125
The lowest signal in Cell A is -75 (S1) and the highest signal in Cell B is -45 (S2). The result of S2 - S1 (-45 - -75) is 30. Since the signal difference is higher than 23 dB, there will be interference issues. Verint Video Intelligence Solutions...
6.2 feet (1.9m) Back to back 7.8 feet (2.4m) 13.1 feet (4m) 15.7 feet (4.8m) If you are using other antennas with narrower beamwidths, the distances may be reduced. For assistance, contact the customer service team. Verint Video Intelligence Solutions...
Page 127
In the 4.9 GHz band, using only 10 MHz channels, all on the same side of a building: 4.9 GHz 4.9 GHz 4.9 GHz 4.9 GHz 36 feet (11m) 3 feet (1m) each Since only four channels are available, it is unavoidable that two adjacent channels are positioned next to each other. Verint Video Intelligence Solutions...
Page 128
2.4 GHz 5.8 GHz 5.8 GHz 3 feet (1m) each 43 feet (13m) 56 feet (17m) The devices using the adjacent channels 6 and 11 in the 2.4 GHz are separated by the prescribed 56 feet (17m). Verint Video Intelligence Solutions...
Technical Specifications Verint Video Intelligence Solutions...
Page 130
Input: 0 dBm into 600 ohms Output: -8 dBm into 600 ohms Power Input voltage 24V AC +/- 20% 12V DC +/- 10% Maximum 20W (1.6 A at 12V DC), 25 VA at 24V AC consumption Verint Video Intelligence Solutions...
Page 131
CSA C22.2 NO. 60950-1, First Edition Europe CE marked ETSI EN 300 328 v1.7.1 (2006-10) ETSI EN 300 893 v1.3.1 (2005-08) ETSI EN 301 489-1 v1.7.1 (2007-04) ETSI EN 301 489-17 v1.3.2 (2007-06) IEC-60950-1, First Edition UL60950-1, First Edition Verint Video Intelligence Solutions...
Glossary This glossary is common to the Nextiva line of edge device products. Verint Video Intelligence Solutions...
Page 133
IP (Internet Protocol) The network layer for the TCP/IP protocol suite widely used on Ethernet networks. LAN (Local Area Network) A computer network that spans a relatively small area. A LAN can connect workstations, personal computers, and surveillance equipment (like edge devices). See also WAN. Verint Video Intelligence Solutions...
Page 134
RF (Radio Frequency) Any frequency within the electromagnetic spectrum associated with radio wave propagation. When a modulated signal is supplied to an antenna, an electromagnetic field is created that is able to propagate through space. Many wireless technologies are based on RF field propagation. Verint Video Intelligence Solutions...
Page 135
Wireless Transmission A technology in which electronic devices send information to receivers using radio waves rather than wiring. WPA (Wi-Fi Protected Access version 1) An authentication method to secure wireless systems. It is the successor of WEP. WPA implements the majority of the IEEE 802.11i standard. Verint Video Intelligence Solutions...
Page 136
Glossary WPA2 (Wi-Fi Protected Access version 2) An authentication method that implements the full 802.11i standard, but will not work with some older network cards. It is also known as 802.11i. Verint Video Intelligence Solutions...
17 connection to a camera, losing 98 point-to-point 42 power 37 band, frequency. See frequency band. serial 50 bandwidth, channel 14 – – constraints in Europe 24 bidirectional audio 53 contact between two masters 28 Verint Video Intelligence Solutions...
Page 138
36 factory default configuration 94 temporary 108 false radar detection 29 IP camera 19 features of the device 2 finding a lost device 98 LAN LED 99 – LED 99 licensed band. See frequency band. Verint Video Intelligence Solutions...
Page 139
6 requirements order in the configuration and update process 21 antenna 33 – output, alarm or audio 52 computer 35 power supply 37 reset to factory default 94 resolution, video 4 pan-tilt-zoom (PTZ) 50 Verint Video Intelligence Solutions...
Page 140
UDP serial connection 103 serial cable 35 user account 61 serial connection 50 serial port cabling 50 hardware setup 50 Verint web site v parameters for 60 video analytics 2 serial protocols supported 50 video cable 35 – setups in Europe 30 –...
Page 141
– live video 89 maintaining the device with 94 opening 58 preventing access 63 secure access 63 web site, Verint v WEP (Wired Equivalent Privacy) 17 width, channel 14 – wireless cell 16 wireless certification 136 wireless Ethernet LED 100 wireless frequency plan 15 –...
Note: The S4200 series devices require professional installation. They should be installed in a location that would prevent the general population from approaching from 3 feet (1 meter) of the radiating element. You must use only antennas certified by Verint. Verint Video Intelligence Solutions...
Consult the dealer or an experienced radio/TV technician for help Any changes or modifications not expressly approved by Verint Systems Inc. could void the user’s authority to operate the equipment. The compliance information for this country is: 2.4 to 2.472 GHz...
Page 144
27 dBm and 27 dBi Point-to-point Point-to-point for fixed system system: 53 dBm system: 53 dBm 10 MHz width: 30 dBm and 27 dBi for fixed system 20 MHz width: 33 dBm and 27 dBi for fixed system Verint Video Intelligence Solutions...
Patch antenna with 23 dBi gain and 12 dBm tx power The 19 dBi and 23 dBi antennas can use the full tx power (20 dBm) in point-to-point systems. The antennas must be installed by certified professionals only. Verint Video Intelligence Solutions...
Page 146
27 dBm and Point-to-point Point-to-point 27 dBi for fixed system: 53 dBm system: 53 dBm system 10 MHz width: 30 dBm and 27 dBi for fixed system 20 MHz width: 33 dBm and 27 dBi for fixed system Verint Video Intelligence Solutions...
Resolution 229 of Resolution 229 of the the UIT the UIT Regulation: UIT-R Regulation: UIT-R Regulation: UIT-R M.1450-2 and UIT-R M.1450-2 and UIT-R M.1450-2 and UIT-R F.1244 F.1244 F.1244 Radio DCMA-82 HI DCMA-82 HI DCMA-82 HI Verint Video Intelligence Solutions...
Page 148
Patch antenna with 23 dBi gain and 12 dBm tx power Rule summary Band is for Band is for Band is for indoor/outdoor. indoor/outdoor. indoor/outdoor. Max EIRP: 23 dBm Max EIRP: 30 dBm Max EIRP: 36 dBm Verint Video Intelligence Solutions...
CE! France, Monaco: Outdoor restricted to CE! Greece, Italy: channels 1 to 7. Outdoor needs license. CE! Greece, Italy, Spain: Outdoor needs license. CE! Belgium: An outdoor link greater than 300m requires notification to spectrum agency. Verint Video Intelligence Solutions...
ETSI EN 300 893 v1.3.1 (2005-08) ETSI EN 301 489-1 v1.7.1 (2007-04) ETSI EN 301 489-17 v1.3.2 (2007-06) IEC-60950-1, First Edition Verint hereby declares that the equipment specified above conforms to the above Directive(s) and Standard(s). October 17th, 2007 Laval, Canada For the official signed declaration of conformity, visit http://www.verint.com/certifications.
Nextiva S4200 Series User Guide RoHS Declaration of Compliance Verint believes in the importance of conducting our business in a manner that will help protect the environment as well as our employees, customers, and the public. To that end, we are committed to bringing our existing and future product lines into EU RoHS Directive compliance.
