Acrosser Technology AIV-HM76V1FLCi3 User Manual

Aiv-hm76v1fl series. an in-vehicle computer designed for comprehensive mobile applications
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AIV-HM76V1FL Series User Manual
AIV-HM76V1FL
Series
An in-vehicle computer designed for
comprehensive mobile applications
3rd Generation Intel Core i7, i3, or Celeron
Processor with Intel PCH HM76 Chipset
User Manual
Acrosser Technology Co., Ltd.
www.acrosser.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIV-HM76V1FLCi3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Acrosser Technology AIV-HM76V1FLCi3

Summary of Contents for Acrosser Technology AIV-HM76V1FLCi3

  • Page 1 AIV-HM76V1FL Series User Manual AIV-HM76V1FL Series An in-vehicle computer designed for comprehensive mobile applications 3rd Generation Intel Core i7, i3, or Celeron Processor with Intel PCH HM76 Chipset User Manual Acrosser Technology Co., Ltd. www.acrosser.com...
  • Page 2 Acrosser Technology Co., Ltd. In no event will Acrosser Technology Co., Ltd. be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 3: Table Of Contents

    AIV-HM76V1FL Series User Manual Table of Contents 1. System Introduction ..............5 1.1. Specifications ......................5 1.2. Packing List ........................ 8 1.3. Features ........................8 1.4. System Dissection ...................... 9 1.4.1. Dimensions ..................... 9 1.4.2. I/O Panel ....................... 10 1.4.3. Mainboard ......................11 1.4.4.
  • Page 4 Q 9. My system has audio problem? ................64 Q 10. My system can not connect to Internet? ..............65 Q 11. Why my optional module 3.5G connection fail in Fedora 17 x86/x64 system? ..67 Acrosser Technology Co., Ltd.

  • Page 5: System Introduction

    CAN bus, WiFi, 3.5G wireless WAN, Bluetooth, and GPS. 1.1. Specifications System • AIV-HM76V1FLCi7: Intel Core i7-3517UE Processor (4M Cache, 1.7GHz) • AIV-HM76V1FLCi3: Intel Core i3-3217UE Processor (3M Cache, 1.6GHz) • AIV-HM76V1FLCE1: Intel Celeron 1047UE Processor (2M Cache, 1.4GHz) Chipset • Intel HM76 Memory •...
  • Page 6 • Output power from COMBO connector • Status indicator, 1 x 3 LED • Green: PIC Status, Green: HDD, Yellow: Power MiniPCIe Slot • MiniPCIe1 for 3.5G card (Reserve SIM interface) • MiniPCIe2 for WiFi card Acrosser Technology Co., Ltd.
  • Page 7 AIV-HM76V1FL Series User Manual Other Features Audio • Realtek audio codec ALC662 CMOS • RTC (+/- 2 seconds for 24 hours) • Lithium battery (3V) for CMOS data backup Hardware Monitoring • RTC battery voltage • CPU and system temperature •...

  • Page 8: Packing List

    Packing List Check if the following items are included in the package. † 1 x AIV-HM76V1FL System (AIV-HM76V1FLCE1, AIV-HM76V1FLCi3, or AIV-HM76V1FLCi7) † 1 x Quick Guide † 1 x Driver CD † 1 x Screw Pack (2.5” HDD bracket: 4pcs) †...

  • Page 9: System Dissection

    AIV-HM76V1FL Series User Manual 1.4. System Dissection 1.4.1. Dimensions (Unit: mm) www.acrosser.com...

  • Page 10: I/O Panel

    AIV-HM76V1FL Series User Manual 1.4.2. I/O Panel Front IO Power Input COMBO Remote HDMI USB3.0 Rear I/O WiFi Bluetooth Fuse GPIO Acrosser Technology Co., Ltd.

  • Page 11: Mainboard

    AIV-HM76V1FL Series User Manual 1.4.3. Mainboard Top View PWR1 SATA_PWR1 GPIO1 GPS1 PIC1 SATA1 PIC2 CCMOS1 CPIC1 COM2 COM3 COM1 COM4 REMOTE1 LAN1 LAN2 LED1 HDMI1 HDMI2 USB1 USB2 USB3 COMBO1 Bottom View MINIPCIE2 71 73 MINIPCIE1 SIM1 www.acrosser.com...

  • Page 12: Power Board

    AIV-HM76V1FL Series User Manual 1.4.4. Power Board Top View CN_12V1 CN_12V2 Acrosser Technology Co., Ltd.

  • Page 13: Components Assembly

    AIV-HM76V1FL Series User Manual Components Assembly 2.1. 2.5” SATA SSD Installation Step 1: Loosen the two disk-tray screws by fingers. Step 2: Pull out the disk-tray and install your 2.5” SATA disk. Step 3: Fasten the disk with 4 screws provided in the package. Step 4: Firmly push the disk-tray back into the disk compartment.

  • Page 14: Cf Card Installation

    Slide your CF card into the card holder. Screw back the card holder. Step 3: If there is no need to install the SIM card, push in the card-tray and fasten the two card-tray screws by your screw driver. Step 4: Complete. Acrosser Technology Co., Ltd.

  • Page 15: Sim Card Installation

    AIV-HM76V1FL Series User Manual 2.3. SIM Card Installation Before completing the CF card installtion, you may want to install the SIM card accroding to your system configuration. Step 1: Leave the CF card-tray on table. Step 2: Use a clip to install your SIM card into the SIM1 slot on the mainboard. Pay attention to its orientation, and do not scratch the contacts.

  • Page 16: Dimm Card Installation

    Install your DIMM card into the CN_DIMM1 or CN_DIMM2 slot on the mainboard. Pay attention to its orientation, and do not scratch the contacts. Step 3: Place back the DIMM card cover plate and have it fastened. Step 4: Complete. Acrosser Technology Co., Ltd.

  • Page 17: G Module Installation

    AIV-HM76V1FL Series User Manual 2.5. 3.5G Module Installation Step 1: Use your screw driver to remove the cover plate located at the chassis bottom. Step 2: Install your 3.5G module into the MINIPCIE1 slot on the mainboard. Pay attention to its orientation, and do not scratch the contacts. Step 3: Attch the RF plug from the system to your module.

  • Page 18: Wifi Module Installation

    Step 3: Attch the RF plugs from the system to your module. Step 4: Place back the cover plate and have it fastened. Step 5: Complete. Acrosser Technology Co., Ltd.

  • Page 19: Antenna Connection

    AIV-HM76V1FL Series User Manual 2.7. Antenna Connection Connect your antenna needed according to your system configuration. 2.8. Power Connection Connect your power cable. Pin # Signal 9V ~ 32V DC input connector 9V ~ 32V DC Power Input Terminal Block: 3 pin Ignition On (Hi Active) Pitch: 5.08mm www.acrosser.com...

  • Page 20: Status/Hdd/Power Led Display

    System cannot be turned on or was turned off because 1 Long, 1 Short battery voltage is below the Battery Low Voltage. System on/off fail. When motherboard cannot turn on or turn 1 Long, 2 Short off after retry. Acrosser Technology Co., Ltd.

  • Page 21: Blade-Type Fuse Holder

    AIV-HM76V1FL Series User Manual 2.10. Blade-type Fuse Holder Power-input fuse suggestion: Output: 12V/100W (Input: 9V~32V/111W, Efficiency: 90%) Car Battery Blade-type fuse suggestion Remarks Voltage Rating: 32V; 12V System CONQUER ATQ-10 Current Rating: 10A Voltage Rating: 32V; 24V System CONQUER ATQ-5 Current Rating: 5A Note: You may have to use a needle-nose pliers to grip on the fuse and pull it out.

  • Page 22: Bios Settings

    F2: Previous Values F3: Optimized Defaults IGFX VBIOS Version 2143 F4: Save & Exit Memory RC Version 1.5.0.0 ESC: Exit Total Memory 4096 MB (DDR3) Memory Frequency 1600 MHz Version 2.15.1226. Copyright (C) 2012 American Megatrends, Inc. Acrosser Technology Co., Ltd.

  • Page 23: System Time

    AIV-HM76V1FL Series User Manual Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Processor Information Set the Time. Use Tab Intel(R) Celeron(R) CPU 1047UE @ 1.40GHz to switch between Time Name IvyBridge elements.

  • Page 24: Advanced Setup

    Port 4 [Enabled] →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.15.1226. Copyright (C) 2012 American Megatrends, Inc. Acrosser Technology Co., Ltd.

  • Page 25: Usb Device

    AIV-HM76V1FL Series User Manual • SATA Controller(s) Options Description Enabled / Disabled Enable or disable SATA device. • SATA Mode Selection Options Description IDE / AHCI Determines how SATA controller(s) operate. 3.2.2. USB Device USB configuration parameters. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Advanced USB Device Enable Legacy USB...

  • Page 26: F81216 Second Super Io Configuration

    Version 2.15.1226. Copyright (C) 2012 American Megatrends, Inc. • COM 1 ~ COM 4 Configuration This option sets the parameters of COM1 ~ COM4. • COM4 422/485 function This option sets the COM4 function to RS-422 or RS-485. Acrosser Technology Co., Ltd.

  • Page 27: W83627Dhg Hw Monitor

    AIV-HM76V1FL Series User Manual 3.2.4. W83627DHG HW Monitor Monitor hardware status. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Advanced F8121PC Health Status SYSTIN temperature : +41°C CPUTIN temperature : +51°C VCORE : +0.840 V : +5.150 V : +11.880 V 3.3V : +3.440 V...

  • Page 28: Power Sub System

    Sets the battery delta level. Once the battery voltage drops below this level, the battery will be detected as battery low. • Remote Switch Options Description Enabled / Disabled Enables or disables the function of remote switch. Acrosser Technology Co., Ltd.

  • Page 29: Chipset Setup

    AIV-HM76V1FL Series User Manual • Power On Delay (Sec.) Options Description 2 ~ 60 The delay between power on and system work. • Soft-Off Delay (Sec.) Options Description 0 ~ 3600 The delay before system shutdown. • Shutdown Delay (Sec.) Options Description 120 ~ 3600...

  • Page 30: Sb Usb Configuration

    Mode Options Description Disabled / Auto / Smart Auto Select the operation mode of xHCI controller. • EHCI1, EHCI2 Options Description Enabled / Disabled Control the USB EHCI functions. One EHCI controller must always be enabled. Acrosser Technology Co., Ltd.

  • Page 31: Graphics Configuration

    AIV-HM76V1FL Series User Manual 3.3.2. Graphics Configuration Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Chipset System Agent Bridege Name IvyBridge Select DVMT 5.0 System Agent RC Version 1.5.0.0 Pre-Allocated (Fixed) VT-d Capability Unsupported Graphics Memory size used by the Internal DVMT Pre-Allocated [64M] Graphics Device.

  • Page 32: Boot Setup

    This item shows the information of the CSM16 Module Version. • Driver Option Priorities This item enables adding, deleting, or selecting the drive options to be shown in the setup sequence. • Boot Option Priorities Set the system boot order. Acrosser Technology Co., Ltd.

  • Page 33: Security Setup

    AIV-HM76V1FL Series User Manual 3.5. Security Setup Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Password Description Set Administrator Password If ONLY the Administrator’s password is set, then this only limits access to Setup and is only asked for when entering Setup.

  • Page 34: Save & Exit Setup

    Restore/Load Default values for all the setup options. • Save as User Defaults Save the changes done so far as User Defaults. • Restore User Defaults Restore the User Defaults to all the setup options. • Boot Override Select the boot device. Acrosser Technology Co., Ltd.

  • Page 35: Driver And Utility Installation

    AIV-HM76V1FL Series User Manual Driver and Utility Installation 4.1. Driver CD Interface Introduction Acrosser provides a Driver CD compiled with all the drivers, utilities, applications and documents this product may need. Put the Driver CD into your CD-ROM drive. The Driver CD will automatically detect the mainboard information to see if they are matched.
  • Page 36 AIV-HM76V1FL Series User Manual Put the correct Driver CD of your mainboard into your CD-ROM drive. The following installation screen should appear. If not, enter the root folder of the Driver CD, run the excution file “Setup.exe“. Acrosser Technology Co., Ltd.

  • Page 37: Driver Installation Page

    AIV-HM76V1FL Series User Manual 4.2. Driver Installation Page Select the “Driver” tab. Click the “Select All” button to select all the driver Step 1: checkboxes, and then click “Install” button to start installing all the selected drivers. Step 2: The driver installation completeed. The configuration will be valid after reboot. www.acrosser.com...

  • Page 38: Utility Installation Page

    To run the Testing Utility completely, you should do it at test-signed kernel-mode under Windows 7 x64 by the command “BCDEdit /set testsigning on”. For more information, please refer to MSDN by the following URL http://msdn. microsoft.com/en-us/library/windows/hardware/ff542202(v=vs.85).aspx Step 1: Select the “Utility” tab. Click the “Test Utility” box. Acrosser Technology Co., Ltd.
  • Page 39 AIV-HM76V1FL Series User Manual Step 2: The “Test Utility” screen appears. Select (1) GPIO Utility: Select (2) WatchDog Utility: www.acrosser.com...
  • Page 40 AIV-HM76V1FL Series User Manual Select (3) Power Subsystem: Select (4) Can Bus: Select (5) I-Button: Acrosser Technology Co., Ltd.

  • Page 41: Application Installation Page

    AIV-HM76V1FL Series User Manual 4.4. Application Installation Page Select the “Application” tab. Click the “Acrobat Reader” box. Step 1: Step 2: Please install “Acrobat Reader”. This application is needed for reading the User Manual in PDF format. www.acrosser.com...
  • Page 42 Step 3: Please install “Intel_MEI” and “Acrosser Driver” into the system. Windows OS will create “AcroDev” device. Step 4: If the “Windows Security” warning message appears, select “Install this driver software anyway” to go on next step. Acrosser Technology Co., Ltd.
  • Page 43 AIV-HM76V1FL Series User Manual Step 5: Install “Drivers for Optional Modules”. www.acrosser.com...

  • Page 44: Document Page

    AIV-HM76V1FL Series User Manual 4.5. Document Page The user manual is stored in the “Document” folder. Note: To read the PDF file, you will have to install “Acrobat Reader” first. Please refer to the “Application Installation Page”. Acrosser Technology Co., Ltd.

  • Page 45: Software Installation And Programming Guide

    AIV-HM76V1FL Series User Manual Software Installation and Programming Guide 5.1. Introduction 5.1.1. CAN Bus 5.1.1.1. Overview The CAN bus APIs provide interfaces to CAN bus subsystem. By invoking these APIs, programmers can implement the applications which have the functions listed below: 1.
  • Page 46 Because the ‘data’ field is an 8-byte long array, the range of this field ‘length’ is 0 ~ 8. data[8]: This array of data will be filled with effective data. For example: struct CanMsg msg; msg.data[0] = 0xa1; msg.data[1] = 0xb2; Acrosser Technology Co., Ltd.

  • Page 47: Gpio And Watchdog

    AIV-HM76V1FL Series User Manual msg.data[2] = 0xc3; msg.length = 3; 5.1.2. GPIO and Watchdog 5.1.2.1. Overview This model provides both a GPIO interface and a Watchdog timer. Users can use the GPIO and Watchdog APIs to configure and to access the GPIO interface and the Watchdog timer.

  • Page 48: I-Button Function

    This API returns the version information and store the information in the memory which is pointed at by the pointer ‘ver’. Return Value: If this function gets the version information successfully, it returns 0, any other returned value stands for error. Acrosser Technology Co., Ltd.
  • Page 49 AIV-HM76V1FL Series User Manual Syntax: i32 getCanBaudRate(u8 *baud) Description: This function gets the current setting of the Baud Rate of the CAN Bus. This function gets an ‘unsigned char’ to represent the Baud Rate. Here is the table for the Baud Rate: Unsigned Char Baud Rate...
  • Page 50 CAN bus subsystem and stores the packages in the ‘canAry[]’. unsigned int result = 0; struct CanMsg canAry[30]; result = getCanMessage( canAry, 30 ); if( result != 0) fprintf( stderr, “Fail to receive CAN packets!\n”); Acrosser Technology Co., Ltd.
  • Page 51 AIV-HM76V1FL Series User Manual Syntax: i32 getCanMask(struct CanMask *mask) Description: This function gets the current setting of the acceptance masks. Masks are used to determine which bits in the ID field of the CAN packet are examined with the filters. There are two acceptance masks (mask0 and mask1) and six acceptance filters (filter0 ~ filter5) in the CAN Bus subsystem.
  • Page 52 For example: struct CanFilter varFilter; i32 result; result = getCanFilter(&varFilter); if(result != 0) printf(“Fail to get the filter!\n”); Return Value: If this function gets the filter successfully, it returns 0, any other returned value stands for error. Acrosser Technology Co., Ltd.
  • Page 53 AIV-HM76V1FL Series User Manual Syntax: i32 setCanFilter(struct CanFilter *varFilter) Description: This function sets the bit pattern to the filter. By indicating the ‘filterType’ field in the ‘varFilter’ variable, the bit pattern in the ‘filter’ field will be taken as an ‘Standard ID’ filter or ‘Extended ID’...

  • Page 54: Gpio And Watchdog

    For example: u8 val = 0xf; i32 result; result = setChLevel(val); if(result != 0) printf(“Fail to set GPIO!\n”); Return Value: If the function sets the values successfully, it returns 0, any other returned value stands for error. Acrosser Technology Co., Ltd.

  • Page 55: Watchdog

    AIV-HM76V1FL Series User Manual 5.2.2.2. Watchdog Syntax: u8 getWtdTimer(void) Description: This function read the value of the watchdog time counter and returns it to the caller. Parameters: None. Return Value: This function returns the value of the time counter and returns it to the caller as an unsigned character.
  • Page 56 == 0) { if(val == ENABLED) printf(“Remote Switch is enabled.\n”); else if( val == DISABLED ) printf(“Remote Switch is disabled.\n”); Return Value: If this function works successfully, it returns 0, any other value standards for error. Acrosser Technology Co., Ltd.
  • Page 57 AIV-HM76V1FL Series User Manual Syntax: i32 setRemoteSwitch(u8 val) Description: The function sets the status of the Remote Switch. Parameters: This function takes an unsigned char as the parameter. The value of this parameter can be ‘ENABLED’ (0x5A) or ‘DISABLED’(0xA5). Return Value: If this function works successfully, it returns 0, any other value standards for error.
  • Page 58 The parameter is of the type of unsigned long. The value of the parameter ranges from 3~3600. The unit of the value of the parameter is seconds. Return Value: If the function works successfully, it returns 0, any other value stands for error. Acrosser Technology Co., Ltd.
  • Page 59 AIV-HM76V1FL Series User Manual Syntax: i32 getSoftOffDelay(u32 *Time) Description: The Soft Off Delay is the interval between that the system receives a power off signal and that the system generates a power off signal. This function gets the interval. Parameters: The parameter is a pointer which points to an unsigned long variable.

  • Page 60: I-Button

    This function takes an unsigned char variable as the parameter. The command to be written to the I-Button is the value of the parameter ‘data’. Return Value: If this function works successfully, the function returns 0, any other value stands for error. Acrosser Technology Co., Ltd.

  • Page 61: Appendix A

    AIV-HM76V1FL Series User Manual 5.3. Appendix A Users have to modify the boot loader configuration to support COM port. Take the grub configuration file as an example. Add ‘8250.nr_uarts=XX noirqdebug’ at the setting of kernel. Here, XX represents the number of COM ports the system will support.

  • Page 62: Faq

    Make sure all cables are connected correctly and the power has been turned on: • Restore CMOS default setting via CMOS headers, then reboot the system. • If the problem still exist, please keep the necessary components (e.g. CPU, memory, keyboard and HDD) for testing: Acrosser Technology Co., Ltd.

  • Page 63: Q 7. Where Is The Serial Number Located On My System

    AIV-HM76V1FL Series User Manual • If the system could power on well with the above configuration, please plug back the other components one by one to find out which one may cause this problem. • If the system still could not power on, please listen if there is any warning beeps. •...

  • Page 64: Q 9. My System Has Audio Problem

    Make sure the speaker is connected to the correct connector. • Check if the audio function is set to “MUTE”. • Please adjust the audio volume louder. • If the problem still exist, please contact Acrosser FAE or authorized sales channels. Acrosser Technology Co., Ltd.

  • Page 65: Q 10. My System Can Not Connect To Internet

    AIV-HM76V1FL Series User Manual Q 10. My system can not connect to Internet? • Make sure the network adapter can be recognized in Device Manager. • If there is question mark or exclamation mark in the network adapter, please re- install the network driver.
  • Page 66 AIV-HM76V1FL Series User Manual • If the problem still exist, please shut down the firewall and anti-virus software. • If the Network Connections/Local Area Connection show “no connection”, please check your network cable connection. Acrosser Technology Co., Ltd.

  • Page 67: Q 11. Why My Optional Module 3.5G Connection Fail In Fedora 17 X86/X64 System

    AIV-HM76V1FL Series User Manual • If the Network Connections/Local Area Connection show “limited connection”, please disable and enable your connection to fix this problem. Or, you can unplug and plug the LAN cable to fix the problem. • If the problem still exist, please contact your MIS whether there are any DHCP or IP configuration or ISP/WAN setting limitation.
  • Page 68 AIV-HM76V1FL Series User Manual Technical Support Form We deeply appreciate your purchase of Acrosser products. Please find the “tech_form. doc” file in our utility CD. If you have any questions or problems about Acrosser products, please fill in the following information. We will answer your questions in the shortest time possible.
  • Page 69 Acrosser Headquarters Acrosser Shanghai Office 241新北市三重區光復路一段61巷26號10樓 欣扬通电子有限公司 上海分公司 10F., No.26, Ln. 61, Sec. 1, Guangfu Rd., 上海市徐汇区零陵路631号爱乐大厦12E (邮编: Sanchong Dist., New Taipei City 241, Taiwan, 200085) R.O.C. 12E, Aile Building, No.631, Ling-ling Road, TEL: +886-2-29999000 Xu-Hui Dist., Shanghai, China (Postal:200085) FAX: +886-2-29992887 TEL: +86-21-64288853 FAX: +86-21-64288854...
