Before Using
Part Names
Video Door Station IX-DA
Call indicator
(orange)
Communication
indicator
(green)
Status indicator
(red)
Audio Only Door Station IX-BA
Call indicator
(orange)
Communication
indicator
(green)
Status indicator
(red)
Inthisdocument,theVideoDoorStation(IX-DA)andtheAudioOnlyDoorStation(IX-BA)arereferredtocollectivelyasthe"DoorStation."
WhendescribingtheoperationandexplanationoftheVideoDoorStation(IX-DA),itwillbereferredtoasthe"VideoDoorStation."
Drain holes (4)
T h e s e h o l e s a r e i n t e n d e d f o r
w a t e r t o p a s s t h r o u g h , d o N O T
o b s t r u c t t h e m .
6
Available from A1 Security Cameras
www.a1securitycameras.com email: sales@a1securitycameras.com
Camera
Microphone
Speaker
Call button
LED for night illumination
Pressing the [Call] button at night will
turn the light ON, and when the
communication ends the light will turn
back OFF. The light will also turn ON
when being monitored by the Master
Station.
*There may be times when the light
will not turn ON due to the settings.
Microphone
Speaker
Call button
Drain holes (4)
T h e s e h o l e s a r e i n t e n d e d f o r
w a t e r t o p a s s t h r o u g h , d o N O T
o b s t r u c t t h e m .
