A1 Security Systems IX-DA Operation Manual page 12

4
Settings and Adjustments
Connect to the same network as the device and manage the settings from PC web browser.
System requirements
The PC should meet the following requirements to be capable of configuring the system.
Network
Web browser
Connecting to a PC
Connect the station with a PC using PoE compatible switch.
• Use CAT5e/6 straight cable to connect the devices through LAN port.
Door Station
Login to this device
Start the PC and open a web
1
browser (Internet Explorer)
Enter the address below into the
2
web browser address bar
https://(IP Address of this device)/webset.cgi?login
When the IP address is IPv6, put brackets
([ ]) around it.
Display the login screen.
Select the language
3
Language for displaying contents on the Web
settings is changed.
Display the login screen of the selected
language.
Set using a PC
Ethernet (10 BASE-T, 100 BASE-TX)
Internet Explorer 7.0, 8.0, or 9.0 (SSI 3.0 or TLS 1.0 or later)
RJ45 RJ45
CAT5e/6 straight cable
Available from A1 Security Cameras
www.a1securitycameras.com email: sales@a1securitycameras.com
RJ45
PoE compatible
switch
CAT5e/6 straight cable
Enter the ID and password, and
4
click
Initial value
Display the setting screen.
Notice
• Be sure to type in "https://" to login.
• Do not login multiple times using multiple browsers
at one time on the same PC.
• If a security warning screen appears, disregard the
warning and continue.
• The initial IP address and Subnet mask values are
below.
IP address: 192.168.1.160
Subnet mask: 255.255.255.0
• Contact the system administrator if the IP address
or subnet mask for the device is not known.
12
RJ45
PC
ID: user
Password: user
