- Page 1 ° : MUV160028 SmartCrystal™ Cinema Neo Version : A07 USER MANUAL Date : 13/09/2017 Model VPSP-11000 www.volfoni.com...
- Page 2 Connect the power cable to SmartCrsytal™ Cinema ................8 Snap hook ............................9 Easy maintenance..........................9 SMARTCRYSTAL CINEMA NEO BRACKET ..................10 VI. INSTALLATION ..........................11 Phase one ............................12 Phase two ............................12 VII. TROUBLESHOOTING ........................13 VIII. SOFTWARE UPDATE ........................14 IX. IMPORTANT SAFETY RECOMMENDATIONS ..................14 WARRANTY ............................14 www.volfoni.com...
- Page 3 ° : MUV160028 SmartCrystal™ Cinema Neo Version : A07 USER MANUAL Date : 13/09/2017 XI. FURTHER INFORMATION ........................15 XII. REGULATORY STANDARDS ......................15 www.volfoni.com...
-
Page 4: I. Product Overview
Date : 13/09/2017 I. PRODUCT OVERVIEW The SmartCrystal™ Cinema Neo is Volfoni’s latest innovation in passive 3D technology. The SmartCrystal™ Cinema polarization window is placed directly in front of a 3D cinema projector lens, thereby generating stereoscopic 3D images on suitable screens when viewed with passive 3D glasses. - Page 5 JVC’s D-ILA™ and Sony’s SXRD™, generate a polarized light beam that may not be compatible with SmartCrystal™ Cinema Neo’s active polarization system. Please consult Volfoni for additional information. Polarization-preserving silver screen In order to enjoy the best quality of 3D images, a polarization-preserving silver screen designed for 3D projection is required.
-
Page 6: Iii. Smartcrystal Cinema Neo Features
• Easy maintenance • 3-year warranty • For use with lightweight circular-polarized passive 3D glasses Passive 3D glasses as well as clip-on 3D glasses are available from Volfoni. Please contact us for more details. contact@volfoni.com B. Technical specifications • Maximum power of projector lamp: 7 kW •... -
Page 7: D. Projector Settings
n ° : MUV160028 SmartCrystal™ Cinema Neo Version : A07 USER MANUAL Date : 13/09/2017 D. Projector settings To use the SmartCrystal™ Cinema Neo, the 3D projector should be set as below: • Dark Time: 350 μs • Delay: 0 IV. -
Page 8: B. Using The User Interface
n ° : MUV160028 SmartCrystal™ Cinema Neo Version : A07 USER MANUAL Date : 13/09/2017 B. Using the user interface ON / OFF switch Put this button in position ON to power the SmartCrystal™ Cinema Neo and begin operating the system. Put it in position OFF when you want to stop using the 3D system. 2D / 3D mode There is one button that moves the polarization window of the SmartCrystal™... -
Page 9: Led Check
n ° : MUV160028 SmartCrystal™ Cinema Neo Version : A07 USER MANUAL Date : 13/09/2017 LED check There are 4 different LED lights that indicate the following information: LED number 1: STATE OF FAN This LED is blue when the fan is running and red when there is a problem with the ventilation system. -
Page 10: Snap Hook
n ° : MUV160028 SmartCrystal™ Cinema Neo Version : A07 USER MANUAL Date : 13/09/2017 Snap hook To increase safety, please use the snap hook when fixing the SmartCrystal™ Cinema Neo. Easy maintenance To facilitate the maintenance, you can operate the frame manually. It allows you to easily clean the LCD from dust for example. -
Page 11: V. Smartcrystal Cinema Neo Bracket
n ° : MUV160028 SmartCrystal™ Cinema Neo Version : A07 USER MANUAL Date : 13/09/2017 V. SMARTCRYSTAL CINEMA NEO BRACKET Before installing the SmartCrystal™ Cinema Neo in front of the projector lens, make sure you have all the needed tools and the instruction manual. This wall fixing part is provided with all the screws and wall anchors you might need. -
Page 12: Vi. Installation
n ° : MUV160028 SmartCrystal™ Cinema Neo Version : A07 USER MANUAL Date : 13/09/2017 VI. INSTALLATION The SmartCrystal™ Cinema Neo should be placed directly in front of the lens of the projector at a distance such that the image from the projector covers as much as possible the entire area of the polarization window in order to minimize thermal heating effects. -
Page 13: A. Phase One
n ° : MUV160028 SmartCrystal™ Cinema Neo Version : A07 USER MANUAL Date : 13/09/2017 A. Phase one B. Phase two... -
Page 14: Vii. Troubleshooting
n ° : MUV160028 SmartCrystal™ Cinema Neo Version : A07 USER MANUAL Date : 13/09/2017 VII. TROUBLESHOOTING PROBLEM SOLUTION The system does not work. Verify that the Power LED is illuminated when working. If it is OFF, this indicates that there is a problem with the power-supply of the system. -
Page 15: Viii. Software Update
Version : A07 USER MANUAL Date : 13/09/2017 VIII. SOFTWARE UPDATE The latest software is available on Volfoni website to update your product. How to use the software update: • Go to Volfoni website (www.volfoni.com) • Choose the menu SERVICES/SUPPORT •... - Page 16 (see section “Installation”). Damage caused by placing the SmartCrystal™ Cinema too close to the projector lens is not covered by the warranty. Volfoni does not guarantee uninterrupted or error-free operation of the product.
