n ° : MUV140036
SmartCrystal™ Diamond
Version : A12
USER MANUAL
Date : 11/01/2018
model
VPSP-08000
VPSP-08100
VPSP-08200
www.volfoni.com
This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SmartCrystal Diamond and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Volfoni SmartCrystal Diamond

Summary of Contents for Volfoni SmartCrystal Diamond

  • Page 1 ° : MUV140036 SmartCrystal™ Diamond Version : A12 USER MANUAL Date : 11/01/2018 model VPSP-08000 VPSP-08100 VPSP-08200 www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 2 The SmartCrystal™ Diamond bracket -------------------------------------------------------------------------------------------------------------------------------------------------------------- 13 The technical Specifications -------------------------------------------------------------------------------------------------------------------------------------------------------------------------- 14 List of accessories --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- 15 Mounting of the bracket overview ----------------------------------------------------------------------------------------------------------------------------------------------------------------- 16 Appendix -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- 18 www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 3 TROUBLES SHOOTING ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------- 61 VI. IMPORTANT SAFETY RECOMMENDATIONS ----------------------------------------------------------------------------------------------------------------------------------------------- 63 VII. WARRANTY ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ 63 VIII. FURTHER INFORMATION ------------------------------------------------------------------------------------------------------------------------------------------------------------------------ 63 IX. REGULATORY STANDARDS ---------------------------------------------------------------------------------------------------------------------------------------------------------------------- 64 www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 4 ANNEXE 07 ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- 92 SCD bracket disengagement. --------------------------------------------------------------------------------------------------------------------------------------------------------------------------- 92 ANNEXE 08 ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- 94 SCD bracket disengagement for the models VASP-09XXX. ------------------------------------------------------------------------------------------------------------------------------------- 94 www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 5: Introduction

    Skilled technicians only, who are aware of potential dangers associated with high voltage, ultraviolet exposure and high temperatures generated by lamps and their power circuit, are authorized to install/de-install the SmartCrystal™ Diamond and to service it. www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 6: C. Specification Of The Projector

    The polarizer filters of the glasses need to be compatible with the polarization generated by the SmartCrystal™ Diamond. WARNING THE CINEMA PASSIVE GLASSES MUST NOT BE USED AS SUNGLASSES. POLARIZER FILTERS CANNOT PROTECT FROM ULTRAVIOLETS. www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 7: I. General Presentation

    11- International plugs (EU, US, AUS, China, and UK) 12- Power supply for the SCD Controller   www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 8: A. The Smartcrystal™ Diamond Box

    SCD CONTROLLER (Electronic box) SCD (Optical box) VSSP ≥ 10200 VSSP ≥ 13300 VSSP-10100 VSSP ≤ 13200 VSSP-10000 VSSP ≤ 13200 www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 9 Connector of the SmartCrystal™ Diamond box (SubD-9) Upper half image +/- zoom wheel Lower half image +/- zoom wheel Fig 04 www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 10: B. Smartcrystal™ Diamond Controller

    B: The vision frequency received by the system through the SYNC_3D entry.  C: Other information about the system: bracket state etc. Fig 07 www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 11: Requirements And Important Recommendations To Install The Smartcrystal™ Diamond

    40cm x 40cm if the ‘screen’ side of the system stands at less than 10cm from this window. Fig 09 www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 12: B. Film Theatre Configuration: 'Throw Ratio' Of The Cinema

    (*) : The SmartCrystal™ Diamond Box must be situated as close as possible to the lens, i.e. less than 2cm. TR = (Distance between projector and screen => l) / (screen width => L) www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 13: Smartcrystal™ Diamond Bracket Presentation (Vasp-10Xxx)

    For assembling instructions, please refer to the bracket user guide. contains possible assembly drawings depending on the various configurations. Fig 11 www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 14: B. The Technical Specifications

    BENCH OPTION: 208 mm + 30 mm  HIGH PRECISION ADJUSTMENT +/- 30 mm  HORIZONTAL ADJUSTMENT CURSE: 250 mm + 200 mm Fig 12 www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 15: C. List Of Accessories

    The packing includes a set of Allen wrenches to mount the bracket (2mm – 2.5mm – 3mm – 4mm – 5mm) www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 16: D. Mounting Of The Bracket Overview

    Beam light should enter in the center entrance windows SCD.  - Adjustment of the SCD angle Fig 14 www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 17 SCD displacement. www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 18: E. Appendix

    (03) Reset (04) Not used (05) 2D / 3D Position (06) BRACKET OK / BRACKET UNREADY (07) +12VDC (08) +5VDC Fig 16 www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 19: Ii. Installation Of The Smartcrystal Diamond

    It will help you to visualize your goal Fig 17 and make the right decisions www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 20: A. The Bracket's Elements And The Different Tools Needed

    SmartCrystal™ Diamond Version : A12 USER MANUAL Date : 11/01/2018 The bracket’s elements and the different tools needed The necessary tools www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 21: B. The Bracket's Installation Type

    Choose your configuration => ANNEXE 02 to 05 Depending on your configuration Bracket Maximum distance Fix D & E parts Minimum height www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 22 Fix F parts using 8 units of M and N pieces Fix A part using 4 units of M and N pieces www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 23 The same operation has to be done on the other side of the bracket. STEP 08 STEP 09 Bracket feet installation : Parts & tools Screw L pieces on J parts www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 24 Fix them together with the Allen key STEP 14 STEP 15 Use the K parts Slide them in the H part www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 25 Use the G part STEP 18 STEP 19 Put H part and G part together Once positioned, fit the screws of K parts www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 26 Add the I pieces at the end of H part STEP 22 STEP 23 Remove fixations for sensor limit cables Remove the 2 bracket position sensors wires from guide www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 27 : Motor command  2 contact : Set 2D / 3D position  1 led : 12V  2 led : 5V www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 28 Bracket will move and will stop face to bracket position sensor. Use first contact The bracket upper plate will be approximately face to projector www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 29 STEP 34 STEP 35 Unscrew 2 screws of the rings on both side of the trolley Loosen stud bolt of the trolley www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 30 In case of bracket upper plate too high or too low Check horizontality is good Readjust its position by modifying F parts position www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 31: Assembly Of The Smartcrystal™ Diamond Box On The Bracket And Positioning In Front Of The Projector

    In case of contact, fit the bracket adjustment to eliminate any risk of contact. www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 32 Screw the 2 screws on the both side of the endless screw In this case the Bracket is at 3D position www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 33 Use first contact. SCD will reach automatically 2D position SCD will follow the sensor until you obtain a maximum of light on the side of the SCD www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 34: The Smartcrystal™ Diamond Box Tilt Adjustment And Locking

    By having a look on “Center alignment” Adjust bracket height Adjust bracket tilt Image input has to be well centered Image output has to be well centered www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 35 If you have respected the procedure, one iteration should be enough. As the position and the orientation are satisfying, the SCD Box is installed. www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 36 Lock bracket height with the right and left rings Lock bracket angle with the counter screw There are more information in looking at ANNEXE 06 Precision and tilt adjustments. www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 37: D/3-D Position Stops Positioning

    Do not hesitate to take a margin of room in order to avoid any subsequent problem. SmartCrystal™ Diamond properly positioned; lock the bracket stop in 2-D position. www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 38 Image size has to be < 10cm x 7cm STEP 54 STEP 55 Adjust, set and lock 2D bracket position sensor Lock 3D bracket position sensor www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 39 Connect all cables except synchronization and RJ45 cables. You Put wires properly must plug the power supply of the SCD controller www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 40: Electrical Installation And Projector Settings

    If the projector is in 2-D mode, the SCD Controller displays: ‘2D’  The SCD Controller also displays the status of the SCD Box bracket: Fig 24 www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 41 2D position and we have 2D / 00.0Hz / BRACKET OK - If 2D-00Hz-Bracket unready : Use the 2 contact to display the right parameters => 2D-00Hz-Bracket OK www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 42 Do not hesitate to contact your technical support. Delay = 0µs 3D Synchronization output activated Triple flash / 6:2 / 48Hz www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 43: The Smartcrystal™ Diamond Box Image Adjustment

    (at the bottom). They can be spotted with the ‘adjust’ inscription. www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 44 USER MANUAL Date : 11/01/2018 Before starting the image adjustment, display the Volfoni adjustment pattern on the screen. The observed screen image shows line splitting and different gaps between the upper and the lower parts of the image. Fitting the upper half image The purpose of this step is to superimpose all the information of the upper half of the image proceeding as following: First of all you need to make sure that the adjustable wheel is unlocked.
  • Page 45 (see image below). Fig 26 Up/down fitting observing the HORIZONTAL lines www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 46 Using the upper central wheel (n°6 wheel of the figure 5), fit the size of the upper half image superimposing all the information (lines, circles, text). Fig 28 Lock the upper half image www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 47 In this case you have to unlock the adjustable wheel (do the contrary of the previous step) then start over until finding the good balance. Fig 29 www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 48 In general the horizontal moved after this step it is normal. www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 49 It might be necessary to redo this last step 2 or 3 times. The adjustment and locking of the upper half image is completed. www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 50 During this step you must not force. This locking system is working on the principle nut/locknut. The system is now ready to be set. Fig 30 www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 51 (see figure below).  Fig 31 ¶Up/down fitting observing the HORIZONTAL lines www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 52 Using the central wheel (n°7 wheel of the figure 5), fit the size of the lower half image by superimposing all the information (lines, circles, text). Fig 33 • ¶ Final fitting www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 53 THE LOWER HALF IMAGE ADJUSTMENT IS COMPLETED. Fig 34 www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 54 In general, the horizontal alignment moved after this step. www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 55 It might be necessary to redo this last step 2 or 3 times. The bottom image is now locked. THE IMAGE ADJUSTMENT AND LOCKING IS COMPLETED. www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 56 STEP 70 With Volfoni test pattern you will a perfect match between three superposed images. Volfoni test pattern after alignment (line=3 pixels) www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 57 We recommend using the Volfoni test pattern. www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission. www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 58: Iii. Additional Anti-Reflection Filter

    In this case, you might notice undesirable reflections on the screen. Volfoni has developed this filter in order to compensate for this situation to the detriment of a loss of light power. We recommend using this filter as a last resort only and advise instead to change the window angle in order to deflect the reflection or to change it.

  • Page 59: Iv. Software Interface

    The system is run by the SCD Controller. By default, the system is delivered with the newest software version at the moment the product was manufactured. A new software version might be available when you receive/install your system. On receipt of equipment, Volfoni recommends to carry out the following operations to ensure you have the latest software version: ...

  • Page 60: Functioning Modes, Settings, Other Functions

    Remote running (Network Operating Center)  Functioning data recording For further information, refer to the XXXX document (Document in progress, please contact Volfoni support), which contains all the information. For any question, do not hesitate to contact your support. www.volfoni.com...

  • Page 61: V. Troubles Shooting

    • The power of the projector lamp is too low • Change the lamp settings Too dark image • The lamp settings are badly adjusted www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 62 • Let everything plug and press the reset button of the bracket Bracket Error IF YOU DO NOT NOTICE ANY IMPROVEMENT FURTHER TO THE SUGGESTED SOLUTIONS, PLEASE CONTACT YOUR SUPPORT www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 63: Vi. Important Safety Recommendations

    VIII. FURTHER INFORMATION NOTICE: The Volfoni Group reserves the right to make changes in the hardware, packaging or other documentation without prior written notice. SmartCrystal™ Diamond is a trademark of the Volfoni Group. All trademarks are the property of their respective companies.

  • Page 64: Ix. Regulatory Standards

    The separate collection and recycling of your product at the time of disposal will help conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. This Class B digital apparatus complies with Canadian ICES-003. www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 65: Annexe 01

    BENCH OPTION: 208 mm + 30  HIGH PRECISION ADJUSTMENT +/- 30 mm  HORIZONTAL ADJUSTMENT COURSE: 250 mm + 200 mm www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 66 The packing includes a set of Allen wrenches to mount the bracket (2mm – 2.5mm – 3mm – 4mm – 5mm) www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 67 Beam light should enter in the center of the entrance windows of the SCD. - Adjustment of the SCD angle www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 68 SCD displacement. www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 69 Choose your configuration => ANNEXE 01 to 05 Depending on your configuration Bracket Maximum distance. Fix F & G parts Minimum height www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 70 Fix O part STEP 05 (Part 1/2) STEP 05 (Part 2/2) Fix L parts Fix A part on O & L parts www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 71 After positioning J part, fix screw I part. The same operation has to be done on the other side of the bracket www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 72 Fix screws & bolts on P & Q parts STEP 12 STEP 13 Fix P &Q on both sides of the bracket Fix R part www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 73 Date : 11/01/2018 STEP 14 STEP 15 Put the bolt in the middle hole of R Fix T part and adjust its position www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 74 In this configuration, move right position sensor from its position till a position that will allow to put bracket upper plate face to projector www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 75  Left contact : Motor command  Right contact : Set 2D / 3D position  Left led : 12V  Right led : 5V www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 76 Bracket will move and will stop face to bracket position sensor. The bracket upper plate will be approximately face to projector www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 77 Check distance between bracket upper plate and Set bracket tilt at 0° middle of projector lens. Right distance should be approximately 13cm www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 78 Please go to Step 41 page 31 Unscrew the 4 screws on the both side of the endless screw www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 79: Annexe 02

    ° : MUV140036 SmartCrystal™ Diamond Version : A12 USER MANUAL Date : 11/01/2018 ANNEXE 02 Mounting the bracket in the projector legs www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 80 The 2 L parts are screwed onto part Take parts F and M. Screw part D to part A. A. on the other side. www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 81 Put back projector feet with F and Screw bracket to F and G parts. Loosen bracket screws Adjust G parts attached. height. (DO NOT TAKE OUT) www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 82 Adjust stop sensor to the control installed. screws from step 12 board STEP 16 Fix the sensor to its limit switch desired position www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 83: Annexe 03

    ° : MUV140036 SmartCrystal™ Diamond Version : A12 USER MANUAL Date : 11/01/2018 ANNEXE 03 Mounting the bracket in the projector bench www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 84 Place the bracket after repeated Pin up bracket with part M to parts height Steps 01 to 07 ANNEXE 01 F and G www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 85 Insert K parts (covers) needed, lenght increased STEP 10 STEP 11 STEP 12 Bracket with attachment Insert K parts (covers) Bracket with attachment www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 86 USER MANUAL Date : 11/01/2018 STEP 13 STEP 14 (OPTION 1) Bracket at maximum height (OPTION 2) Bracket at minimum height www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 87: Annexe 04

    ° : MUV140036 SmartCrystal™ Diamond Version : A12 USER MANUAL Date : 11/01/2018 ANNEXE 04 Mounting the desktop bracket www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 88 STEP 04 STEP 05 STEP 06 Place bracket on the table Screw the four fixing points Bracket screwed to the table www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 89: Annexe 05

    ° : MUV140036 SmartCrystal™ Diamond Version : A12 USER MANUAL Date : 11/01/2018 ANNEXE 05 Wall mounting solution www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 90: Annexe 06

    Loosen the stud bolt Adjust height STEP 04 When SCC DIAMOND is at its desired position, fasten again bolts and screws www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 91 Date : 11/01/2018 Tilt adjustment STEP 01 STEP 02 Losen lower bushing Adjust to desired position STEP 03 Tighten lower bushing www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 92: Annexe 07

    STEP 05 STEP 06 Remove the screw with Allen key Once unscrewed, remove the piece Now, we can move the platform manually www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 93 Screw the piece to fix the platform. configuration, position the gold piece The 4 holes must be perfectly aligned The system is again motorized under the platform www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.

  • Page 94: Annexe 08

    2 screws STEP 04 STEP 05 STEP 06 Remove the motor cover: 2 screws Remove the motor cover: 2 screws www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
  • Page 95 To assemble the motor, follow the same steps to remove it but in inverse order. WARNING: Please place the cables before mounting the motor support www.volfoni.com This document is the property of the Co VOLFONI and may not be reproduced or disclosed without permission.
