Aux Output #3 (%)
Auxiliary Output #3 is the actual output on the analog Output #3 of the 723plus. The value
will be displayed in 0 - 100% which corresponds with 4 – 20 mA. Which signal is
displayed on the output, can be configured in the configure mode. Following selections
can be made:
- PID Output
- Actual Speed Output
- Actual Load Output (kW)
- Actual Limit Output
- Torsional Level Output
- Jump Rate Limiter Output
- Actual Speed Reference.
Analog Speed#1
Analog Speed #1 displays the actual value in rpm of the first speed sensor. This value is
the unfiltered engine speed.
Analog Speed#2
Analog Speed #2 displays the actual value in rpm of the second speed sensor. This value
is the unfiltered engine speed.
5.3.16 * DISCRETE I/O *
Description
Run/Stop Contact
Fuel Cntrl Mode
Lower Contact
Raise Contact
Reset Contact
Gen /Prop Contact
Limit Contact
Clutch - Gen_br Contact
Unload/ Clutch Relay
Jet Assist Relay
Major Alarm Relay
Run/Stop Contact
Run/Stop Contact displays the status of the Run/Stop contact input.
True --> Contact is made (Run mode).
False --> Contact is not made (Stop mode).
Fuel Cntrl Mode
Fuel Cntrl Mode displays the status of the Fuel Cntrl Mode contact input.
True --> Contact is made (Fuel control mode is ON).
False --> Contact is not made (Fuel control mode is OFF).
Lower Contact
Lower Contact displays the status of the Lower contact input.
True --> Contact is made (Lower is active).
False --> Contact is not made (lower is not active).
Raise Contact
Raise Contact displays the status of the Raise contact input.
True --> Contact is made (Raise is active).
False --> Contact is not made (Raise is not active).
