4 Port Ethernet Switch
For advanced settings and more detailed information, download the user
manual from www.shyamnetworks.com.
FS400
Quick Start Guide
Package Contents
4 Port Ethernet Switch
(main unit)
Power Adapter
Console Cable
Ethernet Cable
Quick Start Guide
www.shyamnetworks.com
1
1
1
1
1
Advertisement
Table of Contents
Related Manuals for SHYAM Networks FS400
Summary of Contents for SHYAM Networks FS400
-
Page 1: Quick Start Guide
NETWORKS FS400 4 Port Ethernet Switch Quick Start Guide Package Contents 4 Port Ethernet Switch (main unit) Power Adapter Console Cable Ethernet Cable Quick Start Guide For advanced settings and more detailed information, download the user manual from www.shyamnetworks.com. www.shyamnetworks.com... -
Page 3: Hardware Overview
Ethernet local area network (LAN) ports providing PC connection through Cat6 cables, depending on the model. WAN (Copper/Fiber) Connects FS400 to the Internet or other wide area network (WAN) connection through Cat5e/optical fiber cable. LEDs Indicates the working status of FS400. -
Page 4: Led Behavior
FS400 NETWORKS LED Behavior COLOR STATUS DESCRIPTION Indicates FS400 is receiving power Green and is functioning properly. FS400 is not powered on. LAN port indicates physical connectivity Green is up with the connected device. LAN (1, 2, 3, 4)/ No device is connected to LAN port or link is down. - Page 5 Ethernet cable to the port of the device and other end to the switch’s port. LAN LED should be ‘On’ for each active LAN connection. iNote: Power is supplied through an external DC power adaptor. Check the technical specification for more details about the DC power input voltage. Congratulations! The installation of FS400 is complete.
- Page 6 STEP 2 Set the IP address to 192.168.168.x and subnet mask to 255.255.255.0, where x is a number between 1 and 254, except 2. iNote: If the IP address of FS400 is 192.168.1.2 then the IP address of the system should be other than 192.168.1.2.
-
Page 7: Quick Troubleshooting
FS400 NETWORKS 4. Quick Troubleshooting PROBLEM PROBABLE REASON RESOLUTION The PWR LED is ‘Off’. The switch has no power. • Ensure that power cord is properly connected to the switch. • Ensure that the power adaptor is properly connected to the functioning power outlet. - Page 8 Product ______________________________________________________________________ Model No. _______________________________ Serial No. ___________________________ Dealer’s Stamp & Signature Customer Care, Shyam Networks (A Division of Vihaan Networks Ltd.) 21-B, Sec-18, Udyog Vihar, Gurgaon-122015 Haryana, India Email: customer.care@vnl.in All India Helpline No. - +91 124 309 2000 Ext. 2009, +91 9873573710 Manufactured by Vihaan Networks Ltd.
