- Page 1 VIDEO WALLS VIDEO PROCESSORS VIDEO MATRIX SWITCHES EXTENDERS SPLITTERS WIRELESS CABLES & ACCESSORIES Control Your Video PRODUCT MANUAL Model: HBT2-C6BPOC-SET Transmitter (TX) Receiver(RX HDMI HDBaseT CAT5/6/7 Extender Set with Bi-directional/IR/RS-23/PoC...
- Page 2 Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and disclaims any express or implied warranty, relating to its products of Avenview Inc. is strictly prohibited.
- Page 3 2.2 BEFORE INSTALLATION ........................4 2.3 APPLICATION DIAGRAM ........................5 2.4 PANEL DESCRIPTION ..........................6 2.4.1 INPUT PANEL (Receiver, HBT2-C6BPOC-SET) front .............6 2.4.2 INPUT PANEL (Receiver, HBT2-C6BPOC-SET) Rear ..............6 2.4.3 INPUT PANEL (Receiver, HBT2-C6BPOC-SET) front ............7 2.4.4 INPUT PANEL (Receiver, HBT2-C6BPOC-SET) Rear ..............7 IR EXTENTENDERS ..........................8...
-
Page 4: Getting Started
• Removal, installation, and set-up service charges. SAfETy GUIDELINES The HBT2-C6BPOC-SET, HDMI HDBaseT Extender SET has been tested for conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic equipments, the HBT2-C6BPOC-SET should be used with care. Read the following safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 5: Regulatory N Otices Federal Communication Commission (Fcc)
Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Avenview is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment. -
Page 6: Introduction
(1) RJ45 output port which allows the user to extend video, audio and data signals up to 100m 30ft). The HBT2-C6BPOC-SET supports data pass through via the bi- directional IR and RS-232 ports on both the TX and RX units, allowing the users to transmit any IR or RS-232 information to the desired device to be controlled . -
Page 7: Package Contents
• Unauthorized changes or modifications could void the user's authority to operate the equipment. • Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents. www.avenview.com... -
Page 8: Application Diagram
APPLICATION DIAGRAM www.avenview.com... -
Page 9: Panel Description
(PC or laptop ON: F/W update via D-Sub 9-pin male cable) TX,RX,GND (L to R) OFF: Normal Operating mode HDMI IN: Connect HDMI source via Male to Male HDMI Cable Max 10ft- with Blu-ray player or any HDCP Digital player. www.avenview.com... - Page 10 (PC or laptop via D- ON: F/W upadte Sub 9-pin male cable) TX,RX,GND (L to R) OFF: Normal Operating mode HDMI OUT: Connect HDMI display via Male to Male HDMI Cable Max 10ft- with HDCP compatible display/monitor. www.avenview.com...
- Page 11 IR extenders. please check carefully before plugging in the IR extender to the respective IR sockets. It is clearly marked OUT= IR BlASTER IN=IR RECEIVER WARRANTY WILL NOT COVER THE DAMAGE. www.avenview.com...
- Page 12 INSTALLATION To setup the Avenview HBT2-C6BPOC-SET HDMI 4K Extender please follow these steps for connecting the devices: 1. Turn off all devices including monitors / TV 2. Connect to a HDMI source (such as a Blu-Ray Disc player) to the Transmitter HBT2-C6BPOC-S 3.
-
Page 13: General Troubleshooting
Guidelines to Test & Troubleshoot HDBaseT Systems can be retreived from our website under the category Downloads for this product HBT2-C6BPOC-SET. Readers can view the new 4K rated category cable "Belden 4K Media Cables" press release to learn more about why a specified cable is important for delivering proper HDBaseT signals to its final destination. -
Page 14: Specifications
12V 2A DC (Only one power supply needed) POWER SUPPLY POWER CONSUMPTION 3 Watt (max) 7 Watt (max) ENVIRONMENTAL OPERATING TEMPERATURE 32˚ ~ 104˚F (0˚ to 40˚C) STORAGE TEMPERATURE -4˚ ~ 140˚F (-20˚ ~ 60˚C) RELATIVE HUMIDITY 20~90% RH (no condensation) www.avenview.com... - Page 15 TYPE OF CATEGORY CABLE WIRING SHIELDING CAT5 CAT5E CAT6 UNSHIElDED (UTP) ««« «««« «««« SOLID SHIElDED (STP) ««« «««« ««««« UNSHIElDED (UTP) « «« «« STRANDED SHIElDED (STP) « « «« TERMINATION PLEASE USE EIA/TIA-568-B TERMINATION (T568B) AT ANY TIME www.avenview.com...
-
Page 16: Cable Requirements
CABLE REQUIREMENTS HDMI Cable To achieve best results with our HBT2-C6BPOC-SET we highly recommend a Premium High Speed HDMI Cables and Premium High Speed HDMI Cables with Ethernet. To identify the cable is certified it will carry a special anti- counterfeit label to differentiate them from other HDMI cables. - Page 17 PARTS: During the Warranty Period of of THREE (3) YEARS, Avenview will supply new or rebuilt replacements in exchange for defective parts of the product(s) at no cost if the product(s) is determined to have abide by Avenview’s published guidelines. Cost of Parts applicable to product(s) after Warranty Period. For part(s) costs, please contact support@avenview.com.
- Page 18 www.avenview.com...
-
Page 19: Technical Support
Disclaimer While every precaution has been taken in the preparation of this document, Avenview Inc. assumes no liability with respect to the operation or use of Avenview hardware, software or other products and documentation described herein, for any act or omission of Avenview concerning such products or this documentation, for any interruption of service, loss or interruption of business, loss of anticipatory profits, or for punitive, incidental or consequential damages in connection with the furnishing, performance, or use of the Avenview hardware, software, or other products and documentation provided herein.
