Where should Enuresis Sensors be Located?
The bed mat should be placed between the bottom sheet and the mattress to detect instances of enuresis.
An alarm will be raised immediately moisture is detected thereby alleviating carers from making regular checks which can be
intrusive and unwelcome.
Installation
It is easier to register the Enuresis sensor before installation – see below.
1. Remove the bottom sheet from the bed.
2. Place the bed mat across the width of the bed at a point where
the hips of the person will be when lying down.
The mat must be placed metallic side up – text on the mat shows "THIS SIDE UP".
3. If necessary secure the mat with cord through the 4 corner tie down points.
4. Ensure the wire exits safely without causing a hazard.
5. Place a bath towel over the top of the bed mat for best performance.
Be aware that nylon or polyester sheets can give false alarms.
6. Refit the bottom bed sheet.
7. Plug the lead into the interface unit and make sure it is placed
safely out of the way under the bed.
Testing and Registering the Enuresis Sensor
Remove the battery cover from the interface unit and
connect the battery lead – it only fits one way.
Place a damp cloth on the bed mat to activate.
The RED "ACTIVATED" light will flash for about 8 seconds
when an Enuresis alarm is being transmitted.
The Enuresis sensor must be activated when registering it
onto the warden call, at‐home alarm or Nursecall system.
See the following pages for how to put each of these
products into registration mode.
The range of all radio devices can be affected by the working environment ‐ always take care during installation and
perform several test calls.
Doc No. FM0462 issue D Page 1
169MHz Telecare Devices
Enuresis Sensor & Plastic Bed Mat










Compatible with Reach at‐home alarms, Advent xt warden call,
Altec Response and Touchsafe Pro Nursecall systems
Interface unit complete with plastic bed mat
Foil embossed plastic bed mat with 2.2 metre plug‐in lead
Interface unit with Activated LED indicator
Low battery warning
Bed mat dimensions: 540 x 420 mm
Interface dimensions: 90 x 65 x 28 mm (HxWxD)
Interface weight: 170 grams
Product Code: ZXT431
Replacement bed mat: Part No. W00369
PLACE A DAMP CLOTH ON THE

Tynetec and Aidcall are business units of Legrand Electric Ltd
Unit 10 Cowley Road, Blyth Riverside Business Park, Blyth
Northumberland, NE24 5TF. Tel: 01670 352 371 Fax: 01670 362 807
Email: sales@tynetec.co.uk Web: www.tynetec.co.uk
BED MAT TO ACTIVATE
THE RED "ACTIVATED"
LIGHT WILL FLASH
FOR ABOUT 8 SECONDS
