Summary of Contents for KANDA Obsidian S
- Page 2 Contents Name of Parts Specification Parameters Package Contents Using the Camera Operate with Obsidian Remote APP Studio...
-
Page 3: Name Of Parts
Name of Parts Battery Cover Lens Power Indicator Battery Status Indicator Power Button Video Record Button Time-lapse Photo Capture Button Working Mode Indicators Micro SD Card Slot Microphone External microphone input / Zoom H2n synchronization Tripod Mount：3/8“UNC Ethernet Port Tripod Mount： 1/4“UNC 12V External Power Tripod Mount：... -
Page 4: Specification Parameters
3800 x 3000 Obsidian R 4k x 4k 1900 x 1500 6k x 6k 3000 x 2160 6k x 6k 3000 x 3000 Obsidian S 4k x 4k 1500 x 1080 4k x 4k 1500 x 1500 Photo Model Photo Resolution... -
Page 5: Package Contents
Package Contents Obsidian Camera Carrying Case Shoulder Strap Manual Lens Cleaning Ethernet Cable for PoE & Camera Cloths Sync control cable PoE Power Supply PoE Power Cord for Zoom H2n Handy for DC54V 60W Recorder(spatial sound) Batteries LP-E6 Lens Cleaning Pen Card Reader USB 3.0 Battery Cover with Hot/Cold-Shoe Mount... -
Page 6: Using The Camera
Using the Camera Power the Camera using one of the following ways PoE (Power over Ethernet) 12V external power supply 2 X Canon LP-E6 or compatible batteries If more than one power source is connected to the camera at the same time, the camera will choose its supply in the order of preference as listed above. - Page 7 Insert Micro SD cards Insert all six Micro SD cards into the slots. U3（USH-I）cards are highly recommended for maximum speed and stability. Power on / off Power on：Long press the [power button] for 3 seconds,if the camera is turned on normally,the power lamp will stay red and the six working mode lamps will blink the then stay blue.
- Page 8 Time lapse shooting Short press the [Time-lapse Photo Capture button] to start the capture.The default time interval is 10 seconds. Short press the [Time-lapse Photo Capture button] again to end the capture. Every time it captures,the blue working mode lamps will twinkle once.Time inverval can be changed in the Obsidian Remote App.
-
Page 9: Operate With Obsidian Remote App
Operate With Obsidian Remote APP Download the Obsidian remote APP to the mobile phone Obsidian Remote Controller Android Download APP Store Google Play Store http://www.kandaovr.com WIFI connection The camera must connect to a wireless router by an Ethernet cable and the mobile phone must connect to the same router. Please note: The camera should be connected to the router’s LAN port, not the WAN port. -
Page 10: Studio
Studio Kandao Studio provides a effortless solution for stitching high quality 3D 360 VR videos and photos. Effortless Immersive 3D Ambisonic GPU acceleration One-Click depth surround to speed up Processing sound support creative workflow 00:00 Download http://www.kandaovr.com/studio.html... - Page 11 Safe Handling Precautions Avoid condensation and freeze -- When moving the camera from one extreme temperature to another, keep your camera in sealed plastic bags to prevent condensation. Allow time for equipment to adjust to temperature change before removing from the plastic bag.
- Page 12 w w w . k a n d a o v r . c o m Kandao is a high tech company committed to virtual reality with a strong mixed of mission and passion to build the best VR camera for the mass. The co-founders and core team members of Kandao graduated from top universities and have either/both technical and/or commercial backgrounds in leading technology organization such as Tencent, Huawei, Philips, Sharp and other well-known enterprises.
