HDMIBOX/4
• HDMI Input and 4 Outputs HDCP 1.1 compliant
• Digital signal rebuilding
• In/Out resolutions up to UXGA and 1080p
• Cascade capability
• Up to 15 mt on output @ 1080p
• Built-In EDID simulator
HDMIBOX/4 M 12/02/2007
ELPRO Video Labs s.r.l.
1
St.da della Pronda, 45/B 10142 Torino ITALY
Tel.+39 0117701583 – Fax +39 011703751
1x4 HDMI DISTRIBUTOR / EXTENDER
Advertisement
Table of Contents
Related Manuals for ELPRO HDMIBOX/4
Summary of Contents for ELPRO HDMIBOX/4
- Page 1 • In/Out resolutions up to UXGA and 1080p • Cascade capability • Up to 15 mt on output @ 1080p • Built-In EDID simulator HDMIBOX/4 M 12/02/2007 ELPRO Video Labs s.r.l. St.da della Pronda, 45/B 10142 Torino ITALY Tel.+39 0117701583 – Fax +39 011703751...
- Page 2 A built-in EDID simulator and HDCP keyset allows each output to work independently although the HDMI destination is connected or not. A Sync led detects the signal presence on input. The unit is HDCP 1.1 compliant: so HDMIBOX/4 can be used in all HD systems.
- Page 3 4. Power Input: connect the ADM052 power supply. The LED will illuminate when connected. CONNECTING APPLICATION DIAGRAM ELPRO Video Labs s.r.l. St.da della Pronda, 45/B 10142 Torino ITALY Tel.+39 0117701583 – Fax +39 011703751...
- Page 4 During the warranty period, Elpro will repair the faulty units free of charge. The faulty units must be sent CARRIAGE FREE to the Elpro offices in Turin with a regular accompanying note.
