Summary of Contents for Trinity PREAMP
- Page 1 PREAMP MANUAL...
-
Page 2: Thank You
The TRINITY PREAMP sets new standards so that discerning music aficionados can finally enjoy their most beautiful recordings as if it were the true to life original. The PREAMP supports 4 balanced inputs, Polarity switch and a discrete fully balanced volume control with 64 1dB steps. The gain is 6dB. - Page 4 CONTENTS Safety Instructions ....................5 Scope of Supply ............................6 Transportation and Cleaning ........................6 Selecting the Power Voltage ........................7 Connecting and Starting ..........................7 Wiring Up..............................8 Technical descriptions ..........................9 THE FINAL MEASUREMENTS.......................20 Warranty..............................27 Support.................................28...
- Page 5 SAFETY INSTRUCTIONS 1. Please read this operating manual carefully and observe all the instructions affixed to the appliance or written in this manual. 2. Install this product on a stable surface and make sure that nobody can trip over the cables. 3.
-
Page 6: Scope Of Supply
SCOPE OF SUPPLY The scope of supply comprises: • TRINITY PREAMP (440mm x 50mm x 300mm plus 15mm stainless steel feet, weight 8kg) • TRINITY Remote Control (with USB charging cable) • TRINITY XLR cable (optional) • Cotton gloves • Cleaning cloth •... - Page 7 CONNECTING AND STARTING To install the PREAMP, select a stable, level surface directly next to the turn table so that the connecting cable to the tone arm is as short as possible. Avoid placing the appliance in direct sunlight and never place the modules directly next to radiators or fan heaters.
- Page 8 WIRING UP 1. Disconnect the PREAMP from the power source. Never disconnect any wires unless the device is switched off. 2. Connect the PREAMP to the sources like DAC, PHONO and so on. 3. Connect the PREAMP to the POWER AMP.
- Page 9 THE LOW NOISE INPUT STAGE The TRINITY PREAMP is based on the same architecture of the TRINITY PHONO. It uses the same extraordinary gain stage, which is based on 12 ultra-linear fully differential gain stages. The PREAMP is fully balanced from the input to the output.
-
Page 11: The Volume Control
The quality of the volume control, of course, depends on the quality of the resistors and relays. As a result, the TRINITY PREAMP uses special, application-specific, precision thin-film resistors, which have a tolerance of < 0.1%. In addition, they have very low inherent noise and a very low temperature coefficient. - Page 12 Fig. 2 A π-section is a network that generates a known loss when it is located between two matched impedances Z1 and Z2. Z1 represents the source impedance and Z2 the load impedance. The loss is regarded as the ratio of powers and is independent on direction. In the TRINITY PREAMP, Z1=Z2=600 Ohms.
- Page 13 Summarize – Volume Control: The π - ladder attenuator implemented in the TRINITY-PREAMP has a special design which has several basic advantages: 1. The input and output impedances are always constant, independent of the volume setting. 2. Identical, very precise steps are very simple to reproduce.
- Page 14 THE MEASUREMENT RESULTS All TRINITY devices are shipped with a complete measurement protocol and not with some “typical” value published on the web page or in the data sheet. What you see (in the measurement results) is what you get.
- Page 15 Frequency Response...
- Page 16 Intermodulation Distortion...
- Page 17 Total Harmonic Distortion vs. Input Voltage...
- Page 18 Signal to Noise Ratio (no filters)
- Page 19 Volume Control 64 1dB steps (ideal logarithmic response)
- Page 20 WARRANTY The warranty period of the Trinity PREAMP is 2 years. • Within the warranty period, any material and production defects will be rectified according to the following conditions: • The warranty period begins with the purchase of the product and only applies to first buyers.
- Page 21 SUPPORT If you have any questions relating to installation, operation or options, we will be pleased to answer them. TRINITY Electronic Design GmbH Johann Wieser Ring 11 8609 Aschheim, Germany Tel. +49 (0) 89 – 20186577 E-mail. db@trinity-ed.de Internet: http://www.trinity-ed.de...
