DMX OPERATOR
MIDI
DMX-512
CAPABLE
User Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DMX Operator and is the answer not in the manual?

Questions and answers

Related Manuals for ADJ DMX Operator

Summary of Contents for ADJ DMX Operator

  • Page 1 DMX OPERATOR MIDI DMX-512 CAPABLE User Instructions...
  • Page 2 All non-ADJ Products, LLC brands and product names are trademarks or registered trademarks of their respective companies. ADJ Products, LLC and all affiliated companies hereby disclaim any and all liabilities for property, equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic...
  • Page 3 Programming Scenes Editing Scenes Programming Chases / Editing Chases Playback Scenes & Chases USB Backup / Upload / Firmware MIDI Operation Dimensional Drawing Trouble Shooting Warranty Technical Specifications ADJ Products, LLC - www.adj.com - DMX Operator User Manual Page 2...

  • Page 4: Introduction

    Introduction: The ADJ DMX Operator has 12 individual fixture buttons which allow you to control up to 12 separate intelligent lighting fixtures with up to 16 DMX channels each. With ADJ’s DMX Operator Controller, you can record up to 6 chanses with separate fade times and step speeds. The 8 individual channel faders provide you with easy controllability of any DMX fixture.
  • Page 5 DMX Operator Warranty Registration The DMX Operator carries a 2 year limited warranty. Please fill out the enclosed warranty card to validate your purchase. All returned service items whether under warranty or not, must be freight pre-paid and accompany a return authorization (R.A.) number. The R.A. number must be clearly written on the outside of the return package.

  • Page 6: Safety Precautions

    C. The controller has been exposed to rain or water. D. The controller does not appear to operate normally or exhibits a marked change in performance. E. The controller has fallen and/or subjected to extreme handling. ADJ Products, LLC - www.adj.com - DMX Operator User Manual Page 5...

  • Page 7: Controls And Functions

    DMX Operator Controls and Functions ADJ Products, LLC - www.adj.com - DMX Operator User Manual Page 6...
  • Page 8 For example; if the fade time slider is set to 0 (zero) a scene change will be instant. If the slider is set to ‘30s’ it will take the DMX Operator 30 seconds to complete the change from one scene to the next.

  • Page 9: Rear Connections

    • Contact a USB stick (not included) to upload new controller firmware. NOTE: Please contact ADJ customer support for more details. DC INPUT - Accepts a DC 9~12V, 300 mA minimum, power supply. ADJ Products, LLC - www.adj.com - DMX Operator User Manual Page 8...

  • Page 10: Dmx Addressing

    DMX Operator DMX Addressing ADDRESSING FIXTURES In order to have individual control of each fixture with the DMX Operator, the fixture address- es should be addressed as follows. Fixture Button # 1 starts at 1 Fixture Button # 2 starts at 17...

  • Page 11: Programming Scenes

    11. To exit Program Mode press and hold the PROGRAM BUTTON (6) for three seconds. When exiting Program Mode the Blackout LED is on, to de-activate blackout press the BLACKOUT BUTTON (10). ADJ Products, LLC - www.adj.com - DMX Operator User Manual Page 10...

  • Page 12: Editing Scenes

    2. While holding down the PROGRAM BUTTON (6), press and hold the BANK DOWN BUTTON (4). 3. Disconnect the power from the controller and release the buttons. 4. Reconnect the power to the controller, and all scenes should be erased. ADJ Products, LLC - www.adj.com - DMX Operator User Manual Page 11...
  • Page 13 This function will reset all DMX Channels in a single SCENE back to 0. 1. While pressing and holding AUTO/DEL BUTTON (8), Press and release the SCENE BUTTON (2) 1-8 you want to delete. ADJ Products, LLC - www.adj.com - DMX Operator User Manual Page 12...
  • Page 14 6. Press the Scene Button you want to insert. 6. Press MIDI/REC BUTTON (7) again to insert new step. 7. Press and release the TAP SYNC/DISPLAY BUTTON (11) to return to normal operation. ADJ Products, LLC - www.adj.com - DMX Operator User Manual Page 13...
  • Page 15 2. While holding down the AUTO/DEL (8) & BANK DOWN BUTTONS (4) disconnect the power. 3. Holding down the AUTO/DEL (8) & BANK DOWN BUTTONS (4) reconnect the power hold for 3 seconds LED’s blink all chase memory should be erased. ADJ Products, LLC - www.adj.com - DMX Operator User Manual Page 14...

  • Page 16: Playback Scenes & Chases

    Note: If you want to include all the Chases press the AUTO/DEL BUTTON (8) before selecting Chase. ADJ Products, LLC - www.adj.com - DMX Operator User Manual Page 15...
  • Page 17 1. Insert the USB stick with your backup fixture files into a computer. Open the folder marked “DMX _OPERATOR”. Your fixture files will be display as “FileX”. “X” represents 1 of 12 fixture files. ADJ Products, LLC - www.adj.com - DMX Operator User Manual Page 16...
  • Page 18 7. After releasing bothe FIXTURE BUTTONS (1) and SCENE 3 BUTTON (2), press any other button on the controller to upload the new firmware file to the DMX Operator. ADJ Products, LLC - www.adj.com - DMX Operator User Manual Page 17...

  • Page 19: Midi Operation

    120 TO 125 1 to 6 Chases BLACK OUT 126 BLACKOUT DMX OPERATOR only receives MIDI notes and you may have to transpose your keyboard to find the proper notes. ADJ Products, LLC - www.adj.com - DMX Operator User Manual Page 18...

  • Page 20: Dimensional Drawing

    DMX Operator Dimensional Drawing ADJ Products, LLC - www.adj.com - DMX Operator User Manual Page 19...

  • Page 21: Trouble Shooting

    • If in Auto Mode, is It selected in Display? Did you adjust Speed after selecting Auto? • Is Fade Time to long for Speed Selected? • If total of XLR cable is more than 90 feet make sure it is terminated properly. ADJ Products, LLC - www.adj.com - DMX Operator User Manual Page 20...

  • Page 22: Warranty

    ADJ Products, LLC concludes, after inspection, affects the reliability of the product; if the product has been repaired or serviced by anyone other than the ADJ Products, LLC factory unless prior written authorization was issued to purchaser by ADJ Products, LLC; if the product is damaged because not properly maintained as set forth in the instruction manual.
  • Page 23 ADJ Products, LLC 6122 S. Eastern Ave. Los Angeles, CA 90040 USA Tel: 323-582-2650 / Fax: 323-582-2941 Web: www.adj.com / E-mail: info@americandj.com A.D.J. Supply Europe B.V. Junostraat 2 6468 EW Kerkrade Netherlands service@adjgroup.eu / www.adj.eu...
